YF-CS-607LWU photo

User Manual

This is the main product document for model YF-CS-607LWU. Additionally, the document applies to other Elechelf models: YF-CS-607LBU

The file format is pdf, 6 pages, you can download this manual here .

background
8-IN-1 60W CHARGING STATION
7-port 60W Charger Station
USER MANUAL
YF-CS-607LWU 60W-7USBA-LED-WHITE-
YF-CS-607LBU 60W-7USBA-LED-BLACK-
THIS INSTRUCTION CONTAINS IMPORTANT SAFETY INFORMATION.
PLEASE READ AND KEEP FOR FUTURE REFERENCE.
Follow ELECHELF
Visit us:www.elechelf.com
background
About this Product
Specification
Thank you for choosing WELNOTTI products!
Please read this user manual carefully before using.
This charging station can charge mobile phones and tablets
simultaneously, suitable for home, oce, school, restaurant
and other occasions. It will bring you a new charging
experience.
Power Indicator
Baes
Baes light ajustment button
Wireless Charging Area
Apple Watch
Charger Stand
Charging
Interface
Power line
Interface
Power Switch
Name:8-IN-1 60W CHARGING STATION
7-Port 60W Charger Station
Model: YF-CS-607LWU 60W-7USBA-LED-WHITE-
YF-CS-607LBU 60W-7USBA-LED-BLACK-
Dimension: 205(L) X 150(W) X 32.5/76.2(H) mm
Input: AC 100-240V~, 50/60Hz 1.5A Max
Output: 5VDC/9.48A(USB1-7)
Each USB-A 5V/0-2.4A
Wireless Charger Output: 5V/9V DC(5W/7.5W/10W)
1
background
Feature
Warning
To comply with the published safety standards,the following
must be observed when using this charging station.
Safety
Baes light ajustment button
Eight protections: over current protection, oversurge
protection, overvoltage protection, short-circuit protection,
overcharge protection, overpower protection and
high-quality flame-retardant material.
High eciency
It adopts synchronous rectification technology to improve
conversion eciency and reduce heat generation and adjust
voltage for minimal charging time.
Compatibility
The USB interface is equipped with a smart detection IC
that intelligently identifies all digital devices on the market
and automatically identifies and delivery optimal current
for the device.
Function
It can charge 8 devices at the same time with 7 charging
port and 1 wireless charging pad.The maximum output for 7
ports is 60W and 10W for wireless charging pad.You could
adjust the baes brightness or turn it off with the light
1.The socket shall be installed near the charging station and
can be easily
accessible.
2. Maximum ambient temperature around the charging
station can not
exceed 122 °F.
3. The charging station is not intended to be repaired by
yourself in case
2
background
6. Do not open,disassemble and modify the product
without Permission.
Thank you so much for purchasing WELNOTTI product.
Please refer to this user manual when using this product or
having any issues. Additionally, please kindly contact
WELNOTTI customer support team if you have any concerns.
FCC
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received,
including interference that may cause undesired
operation.
Declaration
To comply with the published safety standards,the following
must be observed when using this charging station.
3
background
Made in China
+49(0)211-97538868
+44(0)7825478124
β
elechelfclub
Manufacturer: Yingfu(Jiangxi) Intelligence Electric Co Ltd
Address: Blocks #4#5#6, Area E.F. Anyuan County Industrial
New Zone, Ganzhou City,GANZHOU CITY, Jiangxi
R
background
www.elechelf.com
