DIGITAL TYRE INFLATOR WITH CLIP-ON
CONNECTOR
MODEL NO: SA400
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY
9 Disconnect the gauge from the air supply before servicing or performing any maintenance.
9 Maintain the gauge in good condition (use an authorised service agent), and keep the gauge clean for best and safest performance.
9 Replace or repair damaged parts. Use recommended parts only. Unauthorised parts may be dangerous and will invalidate the warranty.
9 Locate gauge in a suitable work area, keep area clean and tidy and free from unrelated materials and ensure there is adequate lighting.
9 Keep children and unauthorised persons away from the work area.
8 DO NOT direct gauge outlet at yourself or at other persons or animals.
8 DO NOT carry by the hose, or yank the hose from the air supply.
8 DO NOT use the gauge for a task which it is not designed to perform.
8 DO NOT operate the gauge when you are tired or under the influence of alcohol, drugs or intoxicating medication.
8 DO NOT operate gauge if parts are missing or the gauge is damaged, as this may cause failure and/or personal injury.
2. INTRODUCTION
Die-cast body and digital type gauge with rubber protector. Displayed in psi, bar, kpa and kg/cm². Fitted with 500mm rubber hose and
single clip-on connector. Supplied with 2 x AAA batteries.
3. SPECIFICATION
Model no ..................................................................... SA400
Max. air supply ............................................................ 150psi
Pressure units .................................. psi, bar, kpa and kg/cm²
Range ....................................................... 0-10bar(0-150psi)
Inlet size ....................................................................1/4”BSP
Battery ......................................................2 x AAA (supplied)
4. OPERATION
4.1. Theairsupplymustbecleananddry,useasuitablelter/watertrap.
4.2. Thesupplypressuremustbetospecication(seeabove).
4.3. Max. available pressure can not exceed the supply pressure.
4.4. TURN ON
4.4.1. PressOn/Obutton.
4.4.2. Press again to scroll through units.
4.4.3. PresslightOn/Obuttontoturnlighto(ifnotrequired).
4.5. ATTACH ADAPTOR TO VALVE
4.5.1. Push down clip and place the connector onto the tyre valve.
4.5.2. The connector will now be locked in place.
4.6. TO INFLATE
4.6.1. Momentarily depress the operation lever fully, then release to
display tyre pressure.
4.7. Fullydepressleverforanappropriateperiod.Avoidoverination,releaseleverfrequentlytocheckthepressure.
TO DEFLATE
4.7.1. Depressdeatebutton(untilaircanbeheardescaping)foranappropriateperiod.Fullydepresslevermomentarilythenreleaseto
display new pressure.
IMPORTANT - ALWAYS FULLY DEPRESS LEVER MOMENTARILY BEFORE READING TYRE PRESSURE.
Refer to
instruction
manual
Wear eye
protection
Original Language Version
© Jack Sealey Limited
SA400 Issue:2 (3) 28/07/23
Original Language Version
© Jack Sealey Limited
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 sales@sealey.co.uk www.sealey.co.uk
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be sorted, taken to
a recycling centre and disposed of in a manner which is compatible with the environment. When the product becomes completely
unserviceable and requires disposal, drain any fluids (if applicable) into approved containers and dispose of the product and fluids
according to local regulations.
Note: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior
notice.
Important: No Liability is accepted for incorrect use of this product.
Warranty: Guarantee is 12 months from purchase date, proof of which is required for any claim.
5. MAINTENANCE
5.1. PERIODIC CHECKS AND MAINTENANCE
For long service and accuracy, the following actions should be carried out at the recommended intervals:
WEEKLY - CHECK OPERATION
The gauge should be checked weekly for correct operation. Look for smooth lever operation and fast, smooth gauge movements.
Checkforleaksfromtyreconnectorseals,andforchangorwearoftheexiblehoses.Anyproblemsshouldbeimmediatelyrectied.
QUARTERLY - CHECK CALIBRATION
We recommend the accuracy of the gauge be checked against a calibrated ‘master’ gauge every 3 months, or at shorter intervals
depending on operator’s own quality procedures.
5.2. BATTERY CHANGE
5.2.1. When display will not illuminate renew battery. Undo clip door, remove batteries and replace, observing polarity.
BATTERY REMOVAL
Under the Waste Batteries and Accumulators Regulations 2009, Jack Sealey Ltd are required to inform potential purchasers of products
containing batteries (as defined within these regulations), that they are registered with Valpak’s registered compliance scheme. Jack
Sealey Ltd Batteries Producer Registration Number (BPRN) is BPRN00705.
WEEE REGULATIONS
Dispose of this product at the end of its working life in compliance with the EU Directive on Waste Electrical and Electronic
Equipment (WEEE). When the product is no longer required, it must be disposed of in an environmentally protective way.
Contact your local solid waste authority for recycling information.
SA400 Issue:2 (3) 28/07/23
