Please take a moment to register your new Katadyn product by completing the
short product registration form online at www.katadyn.com. The information you
provide will enable us to better serve you with products developed to meet your
needs and interests.
Please register your Katadyn product online at www.katadyn.com (under
Service section) and you will be automatically entered into a drawing to win a
free Katadyn Group product. We will keep you informed of new products from
Katadyn, Optimus and our dehydrated food brands (see our website for more
details).
E) How to get service
To receive coverage under this warranty, please return your Katadyn Hiker
/ Hiker Pro to the retailer where you purchased the product for repair,
replacement or refund. If you are not completely satisfied with the service
you receive from your retailer, or if you have any questions regarding this
warranty, please contact Katadyn Customer Service by telephone, email or
in writing at:
Katadyn North America, Inc.
Customer Service
4830 Azelia Ave North
Minneapolis, MN 55429 | USA
Tel 800-755-6701
F) How state law applies
This warranty gives you specific legal rights. You may also have other rights
which vary from state to state.
2 YEAR LIMITED WARRANTY on Katadyn Hiker / Hiker Pro
A) What is covered
Your Katadyn Hiker / Hiker Pro is warrantied to be free from defects in
materials and workmanship.
B) How long warranty coverage lasts
This warranty lasts two years from the date of purchase of your Katadyn
Hiker / Hiker Pro.
C) What Katadyn will do
In the event of a defect in material or workmanship within the two-year
warranty period, Katadyn will either repair, replace or refund the purchase
price of your Katadyn Hiker / Hiker Pro, at Katadyn’s sole discretion.
D) What is not covered
This warranty does not cover any damage caused by product misuse, abuse
or failure to follow instructions provided herein for proper use, maintenance,
cleaning or storage. This warranty also does not cover, and expressly
excludes coverage for, any incidental or consequential damages arising out
of the purchase, use or performance of the product. Some state laws do not
allow exclusion or limitation of incidental or consequential damages, so the
above exclusion or limitation may not apply to you.
Disinfect your microfilter before storage to prevent microbiological growth within
the pump.
1) Fill a liter container with tap water and add 2 tablets of Micropur (if not
available use 2 tablespoons of ordinary household bleach).
2) Place prefilter into solution.
3) Pump entire amount of solution through unit (into sink or container).
4) Remove prefilter from the solution and continue pumping another 5 to 10
strokes to remove remaining water from the pump body and hoses.
5) Remove cartridge and allow to dry.
6) Wrap hoses around body and store in carry bag.
Note: When removing unit from long term storage, flush the system with one liter
of water to remove any stale tasting water.
MANUAL SUPPLEMENT HIKER PRO
Congratulations on your purchase of the Katadyn Hiker / Hiker Pro. When
used properly in accordance with the instructions provided in this manual,
this product is designed to reduce the levels of bacteria and protozoan cysts
commonly found in fresh water sources to make it safer for drinking. It meets the
U.S. Environmental Protection Agency’s microbiological water purifier standards
for reduction of bacteria (99.9999% Klebsiella terrigena) and protozoan cysts
(99.9% Giardia and Cryptosporidium). It is ideal for hiking, camping, or
traveling in areas where treated water is unavailable.
Water definitions as used in this manual
Fresh water = Untreated water (Lakes, Rivers, Streams, etc.)
Filtered fresh water = Potable drinking water
Treated water = Treated tap water or chemically disinfected water, or boiled
disinfected water
INTENDED USE OF THE Katadyn Hiker / Hiker Pro
Katadyn Hiker / Hiker Pro Water Microfilter
Katadyn Hiker / Hiker Pro Replacement Cartridge
Log on to our website to learn more about our full line of products including
Katadyn, Optimus Stoves and AlpineAire Foods.
www.katadyn.com
www.optimusstoves.com
www.alpineaire.com
www.spectrawatermakers.com
Katadyn North America, Inc.
4830 Azelia Ave North #300 I Minneapolis, MN 55429 I USA
Tel 800-755-6701
Print No. 8018606/0
PRODUCT REGISTRATION & SPECIFICATIONSLIMITED WARRANTY
(continued)
LIMITED WARRANTY
PRODUCT SPECIFICATIONS
Flow Rate: Up to 1L of water per minute
Filter Capacity: Hiker: Up to 750 l, depending on water quality
Hiker Pro: Up to 1150 l, depending on water quality
Weight: 310 g / 11 oz
Dimensions: 7.6 x 16.5 x 6.1 cm / 2.9 x 6.4 x 2.4 in
Cleaning Filter Protector
If your Hiker Pro becomes difficult to pump, clean the Filter Protector. To clean,
carefully remove the netting and Filter Protector from cartridge. Place Filter
Protector on flat surface and clean with damp sponge or fabric. Rinse with water
and reinstall. It is also recommended to clean the filter cartridge by holding it by
the top and „swishing“ it in water. This will remove most particles that may have
collected on the filter surface.
The Hiker Pro includes quick-connect fittings for both input and output hoses.
The fittings make hose handling quick and easy. The output hose quick-connects
may also be used to connect directly to the drink hose (1/4“ diameter only) of a
hydration pack or bladder allowing quick filling without opening your pack.
Input Hose Set up Instructions (required)
Connect the black hydration quick-connect insert to the end of input hose
(opposite end of prefilter). Connect input hose insert to quick release body at
base of pump housing.
Output Hose Quick-Connect Set Up Instructions (optional):
Option #1:
This configuration is ideal for easy removal and storage of output hose to avoid
cross contamination. Output hose may easily be stored inside the re-sealable
bag provided.
1) Install output hose and cut hose approximately 2-4 inches from filter cartridge.
2) Attach first white quick-connect insert (B) to the „short“ section of hose.
Attach the white quick-connect body (A) to the „long“ section of the cut hose.
Connect them together. See Figure 3-1
3) If a direct connect to hydration bladder is desired, install the second white
quick-connect insert (C) to the end of the output hose. This will match with
many popular hydration systems. See Figure 3-2
Option #2:
This configuration is ideal for pumping filtered water directly into hydration
packs (such as Camelbak). It allows quick filling without removing pack or
bladder. Note: Ensure quick-connect fittings are correct size for your hydration
pack drink hose (1/4“ inside diameter) before proceeding to Step 1.
1) Cut hydration pack drink hose at desired length (approximately 4 inches from
end of drinkhose). See Figure 4-1
2) Connect the white quick-connect body (A) to long section of drink hose that
attaches to hydration bladder
3) Connect first white quick-connect insert (B) to short section of drink hose that
attaches to bite valve.
4) Connect second white quick-connect insert (C) to end of water filter output
hose.
5) To fill bladder, connect white insert (C) on output hose to white body (A) on
drink hose. Reconnect bite valve. See Figure 4-1 and Figure 4-2
Figure 3-1 Figure 3-2
Figure 4-1 Figure 4-2
LONG TERM STORAGE
(after your trip is over)
MANUAL SUPPLEMENT HIKER PRO
(continued)
13
MANUAL SUPPLEMENT HIKER PRO
The Hiker Pro includes additional features for improved performance. Use this
instruction supplement for updated information on product set up and usage
options.
Removable Filter Protector
The Filter Protector is a cleanable screen that covers the Hiker Pro cartridge. The
Hiker Pro does not require frequent cleaning, however using the Filter Protector
will extend the life of your cartridge. It may be used continually or when source
water contains suspended particulate or dirt.
Cartridge
Protector Screen
Netting
Step 1
Step 2
Installing Filter Protector
Wrap protector screen around (cartridge there will be approximately a 2“
overlap) and hold in place. Slip the flexible netting over the cartridge. Adjust
Filter Protector screen and netting so they are positioned evenly. The use of the
Filter Protector will extend cartridge life to up to 1150 l depending on water
quality.
(B)
(A)
(C)
(B)
(A)
(C)
(C)
(A)
(B)
