Folding Shiatsu Massage Chair
User Manual
CF-9202
2
Safety Instruc�ons
Please read the following instruc�ons carefully before pu�ng your massage
device into use. Please retain these opera�ng instruc�ons for further use!
• The massage device conforms to recognized technical principles and the latest safety
regula�ons.
• Do not wet,do not use pins, never remove chair cover.
• This items is NOT A TOY. Close supervision is necessary when this appliance is used by ,
or near children or disabled persons.
• This appliance should never be le� una�ended when plugged in.
• Never use any power sources other than the home adapter provided as original
equipment with this machine.
• Any possible repairs may only be carried out by authorized expert staff. Improper use
and unauthorized repairs are not permi�ed for safety reasons and lead to loss of
warranty.
• Never touch the power plug with wet hands.
• Please avoid contact of the device with water, high temperatures and direct sunlight.
• Do not use any damaged cables, plugs or loose sockets.
• If plugs or cords are damaged, they must be replaced by the manufacturer, a service
representa�ve or by qualified personnel.
• In case of malfunc�on, disconnect immediately from the mains.
• Do not use if you have skin disorders, open wounds,or swollen or inflamed areas.
• Misuse or incorrect use excludes any liability for damage.
• Do not use while sleeping.
• In order to avoid excessively s�mula�ng the muscles and nerves, the recommended
massage �me should not be exceeded 15 minutes at a �me.
• Do not use this product for medical treatment.
• Each massage – even a hand massage – must be refrained from during pregnancy or if
one or more of the following complaints are present in the massage area: recent
injuries, thrombo�c diseases, all kinds of in flamma�ons and swellings, and cancer.
It is recommended to consult a doctor before having a massage for the treatment of
ailments and illnesses.
• If you are dependent on electrical aids e.g. pacemakers, please be sure to consult your
doctor for medical advice before taking a massage.
• The packaging material supplied should not be used as a toy.
Failure to observe the above instruc�ons may cons�tute misuse of the product
and can cause serious injury or burns.
Note!
3
Instruc�on
CONTENTS
TECHNICAL DATA
Measurements:
Weight:
Voltage:
Nominal Power:
Default Automa�c run�me:
18.5 x 29.5 inches (Back) 18.5 x17.3 inches (Seat)
16 lbs (Net)
Input: AC 100-240V ~50/60Hz
Output:12VDC 5.0A
max. 60Wa�
15 minutes
Thank you for purchasing Comfier Folding Shiatsu Massage Chair.
With normal care and proper treatment, it will provide years of reliable service.
Please read all instruc�ons carefully before using this product.
Please retain this manual for future reference.
FEATURES
- Electrically height-adjustable Shiatsu neck massage
- Kneading Shiatsu back massage
- Customized Area back Massage
- Op�onal heat func�on on neck & back massage
- Seat vibra�on massage (3 intensity levels for op�ons)
- Premium PU leather and breathable mesh cloth
- Adjustable backrest height
- Innova�ve no-assembly design sets up easily and
conveniently folds away for storage
Detachable intensity
control flap
Removeable &
Washable cover
NECK
BACK
M
A
S
S
A
G
E
Z
O
M
E
FULL TARGET
SEAT
UP
LOWER
Heat
M HL
1.CF-9202 Folding shiatsu massage chair
2. 12V home adapter
4
Setup and Opera�on
1.Place the massage chair on the flat floor.
2.Open the folding chair (Figure 1).
① Horizontally open the
chair by moving apart from
the backrest and Seat
Cushion.
① Turn the handles
to unlock posi�on
( Point Down ).
② Manually fold the
chair from the middle
by moving the Backrest
and Cushion together.
② Adjust the
backrest to the desired
posi�on, then lock the
chair by rota�ng the
securing handles on both
sides to lock point
( Point up).
Fig.1
3. Turn the handles on both sides of chair to unlock point (Figure 2)
4. Adjust the backrest to the desired posi�on.
5. Rotate the handles back to lock posi�on and make sure the backrest is stable to lean on.
6.Connect the adapter cable to the corresponding cable on the massage chair
7.Plug the home adapter into an electric outlet between 100-240V.
8.Turn on the device using the controller ( instruc�ons on page 6 ).
9.Folded away for storage when not in use for a long �me (Figure 3).
Fig.2
Fig.3
UP
DOWN
UP
DOWN
5
Setup and Opera�on
• The device will automa�cally switch off a�er 15 minutes �mer run out
• Remove the adapter from the outlet when not in use.
• Do not setup or use the massager in a bathroom or similary wet / damp areas.
Blanket
/Towel
① Install the flap onto the chair to get a so�er massage.
① ② ③
② Place a blanket or towel between you and the massager to achieve a far so�er massage
intensity if you s�ll feel shiatsu too strong a�er installing the flap onto the chair
③ If you want to massage your neck, shoulder,lower back, but the shiatsu nodes can not
reach the area in need. You may adjust the backrest height, or place a seat cushion or
a pillow on the si�ng part.
If the Shiatsu is too strong
If the shiatsu can’t reach your neck,shoulder,lower back area
Removable
cover/flap
Seat cushion
! A�en�on
You should allow your body some rest periods. To avoid straining your
muscles too much, we recommend to not exceed a con�nuous massage of 15
Minutes per �me and not exceed 3 �mes use one day.
1. Detachable flap for back lets you choose a so�er or more intense back massage.
2. Detachable cover for neck lets you choose a so�er or more intense neck massage.
Note !
6
Controller Instruc�ons
NECK
BACK
FULL TARGET
SEAT
M
A
S
S
A
G
E
Z
O
M
E
UP
LOWER
Heat
M HL
Neck Massage Adjustment:
Adjust the shiatsu nodes
position up or down
Neck Massage
Manual programme:
Press to turn on neck
shiatsu,press again to
shift rotation direction,
press once again to
turn off
Back Shiatsu Area:
Select Full, Up or
Lower back to
designate the area
covered by the shiatsu
massage.
Seat Vibration:
Press to activate the
seat Vibration, you
may cycle through
High, Medium, Low
or off settings
Power ON/OFF:
Press the device
ON or OFF
Target Button:
Press to keep shiatsu
nodes in target area.
Target Area
Adjustment:
Press to adjust the
shiatsu nodes position
up or down
Heat Therapy:
Press to activate heat
function on neck and
back Simultaneously.
The heat can be turned
on independently.
Neck Massage
Auto Programme:
Press to turn on neck
shiatsu and automatically
shift rotation direction per
1 minute,Press again to
turn off neck shiatsu
Note!
1.Press the power bu�on, then only press the "HEAT" bu�on once to ac�vate the heat func�on
on both the neck and back area, you may adjust the heat nodes around the neck up or down by
pressing the arrow bu�ons on the neck area; Pressing the arrow bu�ons on the Back area would
adjust the posi�on of the heat nodes on the Back (Up & Down) and simultaneously ac�vate the
Shiatsu Func�on on the back.
2.A�er the whole massage experience is completed, press the Power bu�on again to turn
off the massager. The back massager rollers would be automa�cally reset and return to the
lowest posi�on. i.e Storage posi�on
7
Care and Cleaning Instruc�ons
TROUBLESHOOTING GUIDE
1. Do not wash the machine or immerse the product or the adapter in water.
2. Always switch off before cleaning and remove the adapter from the socket with clean, dry hands.
3. The massager should be wiped with a slightly moist cloth and dried thoroughly. Do not wipe the
product with alcohol or harsh chemicals such as thinner or bleach.
4. Keep away from heat, fire or exposure to direct sunlight.
5. Do not apply excessive pressure or impact onto massager/massage heads. Applica�on of a direct
force in excess of 110 lbs. may damage your massager and invalidate your warranty. Refrain from
over usage of the device.
6. Avoid contact with sharp edges or pointed objects which might cut or puncture the cover of
massager.
7. Folded away for storage when not in use for long �me.
8. Store the massager in a cool, dry place.
Massage heads rota�ng at
reduced speed.
Massage heads only rotate in
the upper or lower region.
Device switches off suddenly
Jerky mo�on of massage heads /
Vibra�ons from device
Excessive pressure may have been applied onto the
device. Reduce the load and try again.
only ac�vate the heat func�on, press other bu�ons to
ac�vate the shiatsu func�on.
Infra-red lights are on but no
mo�on from massage heads
Fault Solutions
The load on the massage heads is excessive. Reduce
load and try again.
The massage has been ac�vated for the upper or
lower back region. Press the 'Full Back' bu�on for the
massage to cover both regions.
Device may have been in use for 15mins. Auto-shut-
off func�on ac�vated. Con�nue using by pressing the
‘power’ bu�on a�er res�ng the unit for 15mins.
Over-heat protec�on func�on ac�vated. Device is
switched off for your safety. Please rest device for 15-
30mins before restar�ng.
Check if adapter is plugged into socket.
Check if adapter output is connected to device
power inlet wire.
Check if device has been used for more than 15mins.
If so, let device rest for 15mins before con�nuing.
Device may require longer �me to cool in warmer
environments.
Device fail to start
8
Warranty
30 days uncondi�onally Return
Comfier product can be returned to receive a full refund for any reason within 30 days.
Please contact our customers service (supportus@comfier.com), our staff will contact
you within 24 hours.
90 days refund/replace
Comfier product can be returned / replaced within 90 days if the product break down
in the period of proper use.
12 months Warranty
If the product break down within 12 months in the period of proper use, customers can
enjoy the relevant warranty to get them replaced.
A�en�on!
No warranty will be given to any force majeure and man-made causes to a defec�ve
product, such as improper care, personal tear down and willful damage,etc.
If you have any issue about the product, please feel free to contact us by sending
email to supportus@comfier.com We will strive to provide the best service
possible within 24 hours.
Tel: (248) 819-2623
Monday-Friday 9:00AM-4:30PM
Email: supportus@comfier.com
Extend Warranty for Free
1) Enter the following URL or scan the QR code below to find COMFIER facebook
page and like it, enter“Warranty” to messenger to extend your warranty from
1 year to 3 years.
h�ps://www.facebook.com/comfiermassager
OR 2) Send message“Warranty” and email us supportus@comfier.com to extend your
warranty from 1 year to 3 years.
Have queson ?
NOTE: This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed
to provide reasonable protec�on against harmful interference in a residen�al
installa�on. This equipment generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instruc�ons, may cause harmful
interference to radio communica�ons.However, there is no guarantee that
interference will not occur in a par�cular installa�on. If this equipment does cause
harmful interference to radio or television recep�on, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separa�on between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
• Consult the dealer or an experienced radio / TV technician for help.
This device complies with Part 15 of the FCC Rules. Opera�on is subject to the following
two condi�ons: (1) this device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may cause undesired
opera�on.
WARNING: Changes or modifica�ons to this unit is not expressly approved by the party
responsible for compliance could void the user's authority to operate the equipment.
FCC STATEMENT
COMFIER TECHNOLOGY CO.,LTD.
Address:573 BELLEVUE RD
NEWARK, DE 19713 USA
www.facebook.com/comfiermassager
www.comfier.com
