Dryer
User manual
DV45DG6000**
Untitled-2 1 2024-06-27() 6:30:09
English2
Contents
Safety information 4
What you need to know about the safety instructions 4
Important safety symbols 4
CALIFORNIA PROPOSITION 65 WARNING 7
IMPORTANT SAFETY INSTRUCTIONS 8
Warnings 9
Cautions 9
Regulatory notice 11
FCC Notice 11
IC Notice 12
Open Source Announcement 13
Installation requirements 14
Key installation requirements 14
Location considerations 14
Ducting requirements (Not applicable to ventless (heat pump) models) 19
Exhausting requirements (Not applicable to ventless (heat pump) models) 20
Gas requirements (Not applicable to ventless (heat pump) models) 21
Electrical requirements 22
Installation 24
What’s included 24
Step-by-step installation 26
Connect the drain hose 30
Installation checklist 33
Before using the dryer 33
Exhaust ducting guide (Not applicable to ventless (heat pump) models) 34
Door reversal 34
Before you start 39
Sort and load 39
Functional prerequisite 39
Untitled-2 2 2024-06-27() 6:30:09
English 3
Operations 40
Control panel 40
Simple steps to start 42
Cycle overview 43
Cycle chart 44
Cycle guide 46
Special features 47
SmartThings 48
Maintenance 49
Emptying the water tank 49
Installing the micro soft filter (Optional Filter) 50
Cleaning 51
Troubleshooting 57
Checkpoints 57
Information codes 59
Specifications 60
Fabric care chart 60
Protecting the environment 61
Specification sheet 61
Untitled-2 3 2024-06-27() 6:30:09
SAVE THESE INSTRUCTIONS
English4
Safety information
Congratulations on your new Samsung dryer. This manual contains important information on the
installation, use and care of your appliance. Please take some time to read this manual to take full
advantage of your dryer’s many benefits and features.
What you need to know about the safety instructions
Please read this manual thoroughly to ensure that you know how to safely and efficiently operate the
extensive features and functions of your new appliance. Please store the manual in a safe location close
to the appliance for future reference. Use this appliance only for its intended purpose as described in this
instruction manual.
Warnings and Important Safety Instructions in this manual do not cover all possible conditions and
situations that may occur. It is your responsibility to use common sense, caution and care when installing,
maintaining and operating your dryer.
Because the following operating instructions cover various models, the characteristics of your dryer may
differ slightly from those described in this manual and not all warning signs may be applicable. If you have
any questions or concerns, contact your nearest service center or find help and information online at www.
samsung.com.
Important safety symbols
What the icons and signs in this user manual mean:
WARNING
Hazards or unsafe practices that may result in severe personal injury, death and/or property damage.
CAUTION
Hazards or unsafe practices that may result in personal injury and/or property damage.
NOTE
Indicates that a risk of personal injury or material damage exists.
These warning signs are here to prevent injury to yourself and others.
Please follow them explicitly.
After reading this manual, store it in a safe place for future reference.
Read all instructions before using the appliance.
As with any equipment that uses electricity and moving parts, potential hazards exist. To safely operate
this appliance, familiarize yourself with its operation and exercise care when using it.
Untitled-2 4 2024-06-27() 6:30:09
SAVE THESE INSTRUCTIONS
English 5
WARNING - Risk of Fire
• Clothes dryer installation must be performed by a qualified
installer.
• Install the clothes dryer according to the manufacturer’s
instructions and local codes.
• Do not install a clothes dryer with flexible plastic venting materials.
If flexible metal (foil type) duct is installed, it must be of a specific
type identified by the appliance manufacturer as suitable for
use with clothes dryers. Flexible venting materials are known to
collapse, be easily crushed, and trap lint. These conditions will
obstruct clothes dryer airflow and increase the risk of fire.
• Do not install a booster fan in the exhaust duct.
• To reduce the risk of severe injury or death, follow all installation
instructions.
• Save these instructions.
Untitled-2 5 2024-06-27() 6:30:09
SAVE THESE INSTRUCTIONS
Safety information
English6
WARNING - To reduce the risk of fire or
explosion:
• Do not dry items that have been previously cleaned, washed,
soaked, or spotted with gasoline, dry cleaning solvents, or other
flammable or explosive substances. They emit vapors that could
ignite or explode. Any material that has been in contact with a
cleaning solvent or flammable liquids or solids should not be placed
in the dryer until all traces of these flammable liquids or solids and
their fumes have been removed. There are many highly flammable
items used in homes, such as acetone, denatured alcohol, gasoline,
kerosene, some liquid household cleaners, some spot removers,
turpentine, waxes, and wax removers.
• Items containing foam rubber (which may be labeled latex foam)
or similarly textured rubberlike materials must not be dried on
a heat setting. Heated foam rubber materials can, under certain
circumstances, ignite spontaneously.
Untitled-2 6 2024-06-27() 6:30:09
SAVE THESE INSTRUCTIONS
English 7
WARNING - Fire or explosion hazard
• Failure to follow safety warnings exactly could result in serious
injury, death or property damage.
• Do not store or use gasoline or other flammable vapors and liquids
near this or any other appliance.
• Installation and service must be performed by a qualified installer,
service agency, or the gas supplier.
• Do not install a booster fan in the exhaust duct.
WARNING - What to do if you smell gas:
• Do not try to light any appliance.
• Do not turn on the appliance.
• Do not touch any electrical switch.
• Do not use any phone in your building.
• Clear the room, building or area of all occupants.
• Immediately call your gas supplier from a neighbor’s phone. Follow
the gas supplier’s instructions.
• If you cannot reach your gas supplier, call the fire department.
CALIFORNIA PROPOSITION 65 WARNING
WARNING
Cancer and Reproductive Harm - www.P65Warnings.ca.gov.
Untitled-2 7 2024-06-27() 6:30:09
SAVE THESE INSTRUCTIONS
Safety information
English8
IMPORTANT SAFETY INSTRUCTIONS
WARNING
To reduce the risk of fire, electric shock, or injury to persons when using your appliance, follow basic
precautions, including the following:
1. Read all instructions before using this appliance.
2. Do not dry articles that have been previously cleaned in, washed in, soaked in, or spotted with gasoline,
dry-cleaning solvents, or other flammable or explosive substances, as they give off vapours that could
ignite or explode.
3. Risk of Suffocation and Injury from Entrapment: Do not allow children to play on or in the appliance.
Close supervision of children is necessary when the appliance is used near children.
4. Before the appliance is removed from service or discarded, remove the door to the drying compartment.
5. Do not reach into the appliance if the drum is moving.
6. Do not install or store this appliance where it will be exposed to the weather.
7. Do not tamper with controls.
8. Do not repair or replace any part of the appliance or attempt any servicing unless specifically
recommended in the user-maintenance instructions or in published user-repair instructions that you
understand and have the skills to carry out.
9. Do not use fabric softeners or products to eliminate static unless recommended by the manufacturer of
the fabric softener or product.
10. Do not use heat to dry articles containing foam rubber or similarly textured rubber-like materials.
11. Clean lint screen before or after each load.
12. Keep area around the exhaust opening and adjacent surrounding areas free from the accumulation of
lint, dust, and dirt.
13. The interior of the appliance and exhaust duct should be cleaned periodically by qualified service
personnel.
14. Do not place items exposed to cooking oils in your dryer. Items contaminated with cooking oils may
contribute to a chemical reaction that could cause a load to catch fire. To reduce the risk of fire due to
contaminated loads, the final part of a tumble dryer cycle occurs without heat (cool down period). Avoid
stopping a tumble dryer before the end of the drying cycle unless all items are quickly removed and
spread out so that the heat is dissipated.
15. Do not use replacement parts that have not been recommended by the manufacturer (e.g. parts made
at home using a 3D printer).
16. (For Heat pump Clothes dryer) Sharp Edges – to reduce the risk of injury, use care when cleaning the
condenser or evaporator coil fins.
Untitled-2 8 2024-06-27() 6:30:09
SAVE THESE INSTRUCTIONS
English 9
Warnings
WARNING
• Ensure pockets are free of small, irregularly shaped hard objects and foreign material, i.e. coins, knives,
pins, etc. These objects could damage your dryer.
• Gas leaks may occur in your system, resulting in a dangerous situation.
Cautions
CAUTION
• Do not allow children or pets to play on, in, or in front of the appliance. Close supervision is necessary
when the appliance is used near children and pets.
• Before discarding or removing your dryer from service, remove the door to the drying compartment to
prevent children or animals from becoming trapped inside.
• Do not reach into the appliance when the drum is moving.
• Do not install or store this appliance where it will be exposed to the weather.
• Do not tamper with the controls.
• Do not repair, replace, or attempt to service any part of the appliance unless specifically instructed to in
the user-repair instructions and you have the understanding and skills to carry out the procedure.
• Do not use fabric softeners or products to eliminate static unless the softener or product is
recommended for dryer use by the manufacturer of the fabric softener or product.
• Clean the lint screen before or after each load.
• Keep the area around the exhaust opening and surrounding areas free from lint, dust, and dirt.
• The interior of the dryer and exhaust duct should be cleaned periodically by qualified service personnel.
• This appliance must be properly grounded. Never plug the power cord into a receptacle that is
not grounded adequately or not in accordance with local and national codes. See the installation
instructions for information about grounding this appliance.
• Do not sit on top of the dryer.
• Do not dry clothing with large buckles, buttons, or other heavy metal or solid objects.
• Gas leaks may not be detected by smell alone.
• Gas suppliers recommend you purchase and install a UL-approved gas detector.
• Install and use in accordance with the manufacturer’s instructions.
• Do not place items in your dryer that have been spotted or soaked with vegetable oil or cooking oil. Even
after being washed, these items may contain significant amounts of these oils.
Untitled-2 9 2024-06-27() 6:30:09
SAVE THESE INSTRUCTIONS
Safety information
English10
• Residual oil on clothing can ignite spontaneoulsy. The potential for spontaneous combustion increases
when items containing vegetable oil or cooking oil are exposed to heat. Heat sources such as your dryer
can warm these items, allowing an oxidation reaction in the oil to occur. Oxidation creates heat. If this
heat cannot escape, the items can become hot enough to catch fire. Piling, stacking, or storing these
kinds of items may prevent heat from escaping and can create a fire hazard.
• All washed and unwashed fabrics that contain vegetable oil or cooking oil can be dangerous.
Washing these items in hot water with extra detergent will reduce, but not eliminate, the hazard.
Always use the Cool Down cycle for these items to reduce their temperature. Never remove these items
from the dryer hot or interrupt the drying cycle until the items have run through the Cool Down cycle.
Never pile or stack these items when they are hot.
Untitled-2 10 2024-06-27() 6:30:09
SAVE THESE INSTRUCTIONS
English 11
Regulatory notice
FCC Notice
CAUTION
Any changes or modifications not expressly approved by the party responsible for compliance could void
the user’s authority to operate the equipment.
This device complies with Part 15 of FCC Rules. Operation is Subject to following two conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received including interference that cause undesired
operation.
For products sold in the US and Canadian markets, only channels 1–11 are available. You cannot select any
other channels.
FCC STATEMENT:
This equipment has been tested and found to comply within the limits for a Class B digital device, pursuant
to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation.
This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications. However, there
is no guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the interference by one or more of the following
measures:
• Reorienting or relocating the receiving antenna
• Increasing the separation between the equipment and receiver
• Connecting the equipment to an outlet that is on a different circuit than the radio or TV.
• Consulting the dealer or an experienced radio/TV technician for help.
FCC RADIATION EXPOSURE STATEMENT:
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment.
This equipment should be installed and operated so there is at least 8 inches (20 cm) between the radiator
and your body. This device and its antenna(s) must not be colocated or operated in conjunction with any
other antenna or transmitter.
Untitled-2 11 2024-06-27() 6:30:10
SAVE THESE INSTRUCTIONS
Regulatory notice
English12
IC Notice
The term “IC” before the radio certification number only signifies that Industry Canada technical
specifications were met. Operation is subject to the following two conditions:
1. This device may not cause interference, and
2. This device must accept any interference, including interference that may cause undesired operation of
the device.
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe B est conforme á la norme NMB-003 du Canada.
For products sold in the US and Canadian markets, only channels 1–11 are available. You cannot select any
other channels.
IC RADIATION EXPOSURE STATEMENT:
This equipment complies with IC RSS-102 radiation exposure limits set forth for an uncontrolled
environment. This equipment should be installed and operated so there is at least 8 inches (20 cm)
between the radiator and your body. This device and its antenna(s) must not be colocated or operated in
conjunction with any other antenna or transmitter.
Untitled-2 12 2024-06-27() 6:30:10
SAVE THESE INSTRUCTIONS
English 13
Open Source Announcement
The software included in this product contains open source software. You may obtain the complete
corresponding source code for a period of three years after the last shipment of this product by sending an
email to mailto:oss.r[email protected].
It is also possible to obtain the complete corresponding source code in a physical medium such as a CD-
ROM; a minimal charge will be required.
The following URL http://opensource.samsung.com/opensource/SMART_AT_051/seq/0 leads to the
download page of the source code made available and open source license information as related to this
product. This offer is valid to anyone in receipt of this information.
NOTE
Hereby, Samsung Electronics, declares that the radio equipment type appliance is in compliance with
Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the following internet
address: The official Declaration of conformity may be found at http://www.samsung.com, go to Support >
Search Product Support and enter the model name.
Wi-Fi max transmitter power : 20 dBm at 2.412 GHz – 2.472 GHz
Untitled-2 13 2024-06-27() 6:30:10
English14
Installation requirements
Read through the following instructions before installing the dryer and keep this manual for future
reference.
WARNING
Certain internal parts are intentionally not grounded and may present a risk of electric shock only during
servicing.
Service Personnel - Do not contact the following parts while the appliance is energized: Control board and
inlet valve.
Key installation requirements
• A grounded electrical outlet.
• A power cord for electric dryers (except in Canada).
• Gas lines (for gas models) that meet national and local regulations.
• An exhaust system made of rigid metal or flexible stiff-walled metal exhaust duct. (Not applicable to
ventless (heat pump) models)
WARNING
Remove the door from all discarded appliances to prevent a child from suffocating.
Location considerations
The dryer should be located where there is enough space at the front for loading the dryer and behind
space behind for the exhaust system. This dryer is factory-ready for the rear exhaust option. To exhaust out
the bottom, right or the left, use the accessory exhaust kit. Instructions are included with the kit. Make sure
the room in which the dryer is located has enough fresh air. The dryer must be located where there are no
air-flow obstructions. For gas dryers, adequate clearance must be maintained as noted on the data plate to
ensure adequate air for combustion and the proper dryer operation.
The dryer must not be installed or stored in an area where it will be exposed to water and/or weather. The
dryer area must be kept clear of combustible materials, gasoline, and other flammable vapors and liquids.
A dryer produces combustible lint. The area around the dryer should be kept lint-free.
Untitled-2 14 2024-06-27() 6:30:10
English 15
Dimensions
Type Front loading dryer
Models DV45DG6000**
Dimensions
(in. (mm))
A. Overall height 38.7 (984)
B. Width 27 (686)
C. Depth with the door open 54.2 (1378)
D. Depth 33.2 (844)
Untitled-2 15 2024-06-27() 6:30:10
Installation requirements
English16
Clearance requirement
This clearance requirement is applicable for dryers only.
NOTE
• For the washer's clearance requirement, see the washer's user manual.
• If the washer and dryer have different clearance requirements, use the one with the larger value.
Alcove or closet installations
WARNING
• The dryer must be exhausted to the outside to reduce the risk of fire when installed in an alcove or
closet.
• No other fuel-burning appliance should be installed in the same closet as the dryer.
• Place the dryer at least 18 in. (460 mm) above the floor for a garage installation.
Minimum clearance for stable operation:
Sides Top Rear Front
1 in. (25 mm) 1 in. (25 mm) 2 in. (50 mm) 1 in. (25 mm)
If both the washer and a dryer are installed in the same location, the front of the alcove or closet must have
two unobstructed air openings for a combined minimum total area of 72 in.
2
(465 cm
2
).
Untitled-2 16 2024-06-27() 6:30:10
English 17
Undercounter installation
B
C
A
A 39.7 in. (1009 mm)
B 1 in. (25 mm)
C 1 in. (25 mm)
Pedestal installation
A 2 in. (50 mm)
B 6 in. (152 mm)
C 52.8 in. (1341 mm)
Untitled-2 17 2024-06-27() 6:30:10
Installation requirements
English18
This clearance requirement is applicable for washer and dryer pair installation.
Side-by-side installation Stacked installation
B*
A 1 in. (25 mm)
B* 2 in. (50 mm)
C 5.1 in. (129 mm)
D 6 in. (152 mm)
E 77.5 in. (1968 mm)
(B*): This clearance requirement only applies to the dryer. For the washer's clearance requirement, see the
washer's user manual.
NOTE
Stacking (SKK-8HK)
Many of Samsung's washers and dryers can be stacked to maximize usable space. You can purchase an
optional stacking kit from your Samsung retailer. For details about stacking and compatible models, refer
to the user manual included in the stacking kit you purchase.
Untitled-2 18 2024-06-27() 6:30:10
English 19
Ducting requirements (Not applicable to ventless (heat pump) models)
Weather hood type
Recommended
Use only for short-run
installation
4” (10.2 cm) 2.5” (6.4 cm)
No. of 90° elbows Rigid Rigid
0 80 ft. (24.4 m) 74 ft. (22.6 m)
1 68 ft. (20.7 m) 62 ft. (18.9 m)
2 57 ft. (17.4 m) 51 ft. (15.5 m)
3 47 ft. (14.3 m) 41 ft. (12.5 m)
NOTE
* Use a 4-inch (10.2 cm) diameter rigid aluminum or galvanized steel duct.
If you integrate the dryer’s vent system with an existing exhaust system:
• Make sure the exhaust system meets all applicable local, state, and national regulations.
• Verify you are not using a flexible plastic duct.
• Make sure to check for and remove all lint buildup from inside the existing ducts.
• Confirm the duct is not kinked or crushed.
• Make sure the exhaust hood damper opens and closes freely.
Manometer measurements
The static pressure in any exhaust system must not exceed 0.83 inches of water column or be less than 0.
Note that these values are measured with the dryer running with a manometer presented to the exhaust
duct that connects to the dryer. The dryer’s drum must be empty and the lint filter must be clean.
Untitled-2 19 2024-06-27() 6:30:11
Installation requirements
English20
Exhausting requirements (Not applicable to ventless (heat pump) models)
The dryer must not be exhausted into a chimney, a wall, a ceiling, an attic, a crawl space, or a concealed
space of a building. Exhausting the dryer to the outside will prevent large amounts of lint and moisture
from being blown into the room.
In the United States and Canada
• All dryers must be exhausted to the outside.
• The required exhaust duct is 4 inches (10.2 cm) in diameter.
• See the “Ducting requirements (Not applicable to ventless (heat pump) models)” section for the
maximum duct length and number of elbows that can be used.
• The total length of the flexible metal duct must not exceed 7’ 10
1
/2” (2.4 m).
• Do not assemble the duct with screws or other fasteners that extend into the duct and catch lint.
• For the United States only: Use only those foil-type flexible ducts, if any, specifically identified for use
with the appliance by the manufacturer and that comply with the Outline for Clothes Dryer Transition
Duct. Use Subject 2158A.
Outside the United States and Canada
• Refer to the local codes.
WARNING
• You must exhaust the dryer to the outside to reduce the risk of fire when you install the dryer in an
alcove or closet.
• Do not use a plastic or non-metal flexible duct.
• If your existing ductwork is plastic, non-metal, or combustible, replace it with metal.
• Use only a metal exhaust duct that is non-flammable to ensure containment of exhaust air, heat, and
lint.
Untitled-2 20 2024-06-27() 6:30:11
English 21
Gas requirements (Not applicable to ventless (heat pump) models)
WARNING
• Use only natural or LP (liquid propane) gases.
• The installation must be conformed with local codes, or in the absence of local codes, with the national
fuel gas code, ANSI Z223.1/NFPA 54, latest revision (for the UNITED STATES), or with the natural gas and
propane installation code, CSA B149.1 (for Canada).
• Gas dryers are equipped with a burner vent for use with natural gas. If you plan to use your dryer with
LP (liquid propane) gas, it must be converted for safe and proper performance by a qualified service
technician. (LNG models only)
You must check the burner of your model and use the proper LP Kit accordingly. To check the detail
information of the burner, open the door and check the rating label location on the door frame.
- 20,000 BTU: LPKIT-4/XAA (DC98-04114A)
- 22,000 BTU: LPKIT-3/XAA (DC99-00792A)
• A
1
/2” (1.27 cm) gas supply line is recommended and must be reduced to connect to the
3
/8” (1 cm) gas
line on your dryer. The National Fuel Gas Code requires that an accessible, approved manual gas shut-
off valve be installed within 6” of your dryer.
• Gas dryers installed in residential garages must be raised 18 inches (46 cm) above the floor.
• Additionally, a
1
/8” (0.3 cm) N.P.T. (National Pipe Thread) plugged tapping, accessible for test gauge
connection, must be installed immediately upstream of your dryer’s gas supply connection.
• Your dryer must be disconnected from the gas supply pipe system during any pressure testing of the
system.
• Do not reuse old flexible metal gas lines. Flexible gas lines must be designed and certified by the
standard for connectors for Gas Appliances, ANSI Z21.24 • CSA 6.10.
NOTE
• Your dryer uses an automatic ignition system to ignite the burner. There is no constant burning pilot.
• Any pipe joint compound used must be resistant to the action of any liquefied petroleum gas.
• As a courtesy, most local gas utilities will inspect a gas appliance installation.
Commonwealth of Massachusetts installation instructions
Your dryer must be installed by a licensed plumber or gas fitter. A “T” handle manual gas valve must be
installed in the gas supply line to your dryer. If a flexible gas connector is used to install your dryer, the
connector can be no longer than 3’ (36”).
WARNING
• Gas leaks may occur in your system, creating a dangerous situation.
• Gas leaks may not be detected by smell alone.
• Gas suppliers recommend you purchase and install a UL-approved gas detector.
• Install and use in accordance with the manufacturer’s instructions.
Untitled-2 21 2024-06-27() 6:30:11
Installation requirements
English22
Electrical requirements
The wiring diagram is located on the plate under the control panel or rear frame.
WARNING
When local codes allow, you can connect the dryer’s electrical supply with a new power supply cord kit,
marked for use with a dryer, that is U.L. listed and rated at a minimum of 120 / 240 volts, 30-amperes with
three No. 10 copper wire conductors terminated with closed loop terminals, open-end spade lugs with
turned up ends, or with tinned leads.
• Improperly connecting the equipment grounding conductor can result in a risk of electric shock.
Check with a qualified electrician or serviceman if you are in doubt as to whether your dryer is properly
grounded. Do not modify the plug provided with your dryer – if it doesn’t fit the outlet, have a proper
outlet installed by a qualified electrician.
• To prevent unnecessary risk of fire, electrical shock, or personal injury, all wiring and grounding must be
done in accordance with local codes, or in the absence of local codes, in accordance with the National
Electrical Code, ANSI/NFPA No. 70-Latest Revision (for the U.S.) or the Canadian Electrical Code CSA
C22.1 – Latest Revisions and local codes and ordinances. It is your responsibility to provide adequate
electrical service for your dryer.
• All gas installations must be done in accordance with the National Fuel Code ANSI/Z2231 – Latest
Revision (for the U.S.) or CAN/CGA – B149 Installation Codes – Latest Revision (for Canada) and local
codes and ordinances.
Grounding
This dryer must be grounded. In the event of a malfunction or breakdown, the ground will reduce the risk of
electrical shock by providing a path of least resistance for the electrical current.
Gas models
WARNING
• Your dryer has a cord with an equipment-grounding conductor and a grounding plug. The plug must be
plugged into an appropriate outlet that is properly installed and grounded in accordance with all local
codes and ordinances.
• Do not modify the plug provided with your dryer – if it doesn’t fit the outlet, have a proper outlet
installed by a qualified electrician.
• Do not connect the ground wire to plastic plumbing lines, gas lines, or hot water pipes.
Electric models
WARNING
• Your dryer has an optional cord with an equipment-grounding conductor and a grounding plug. This
cord is sold separately.
• The plug must be plugged into an appropriate outlet that is properly installed and grounded in
accordance with all local codes and ordinances.
• Do not modify the plug provided with your dryer – if it doesn’t fit the outlet, have a proper outlet
installed by a qualified electrician.
Untitled-2 22 2024-06-27() 6:30:11
English 23
• If a power cord is not used and the electric dryer is to be permanently wired, the dryer must be
connected to a permanently grounded metal wiring system, or an equipment grounding conductor
must be run with the circuit conductors and connected to the equipment grounding terminal or lead on
the dryer.
Electrical connections
Before operating or testing, follow all grounding instructions in the “Grounding” section. An individual
branch (or separate) circuit serving only your dryer is recommended.
Do not use an extension cord.
Gas models – U.S. and Canada
A 120 volt, 60 Hz AC approved electrical service with a 15-ampere fuse or circuit breaker is required.
Electric models – U.S. only
Most U.S. dryers require a 120 / 240 volt, 60 Hz AC approved electrical service. Some require 120 / 208 volt,
60 Hz approved electrical service. The electric service requirements can be found on the data label located
behind the door. A 30-ampere fuse or circuit breaker on both sides of the line is required.
• If a power cord is used, the cord should be plugged into a 30-ampere receptacle.
• The power cord is not provided with U.S. electric model dryers. This cord is sold separately.
Risk of Electric Shock
WARNING
When local codes allow, you can connect the dryer’s electrical supply with a new power supply cord kit,
marked for use with a dryer, that is U.L. listed and rated at a minimum of 120 / 240 volts, 30-amperes with
three No. 10 copper wire conductors terminated with closed loop terminals, open-end spade lugs with
turned up ends, or with tinned leads.
• Do not reuse a power supply cord from an old dryer. The power cord electric supply wiring must be
supported at the dryer cabinet by a suitable UL-listed strain relief.
• Grounding through the neutral conductor is prohibited for (1) new branch-circuit installations, (2)
mobile homes, (3) recreational vehicles, and (4) areas where local codes prohibit grounding through the
neutral conductor. (Use a 4-prong plug for a 4–wire receptacle, NEMA type 14-30R.)
Electric models – Canada Only
A 120 / 240 volt, 60 Hz AC approved electrical service fused through a 30-ampere fuse or circuit breaker on
both sides of the line is required.
NOTE
All Canadian models are shipped with the power cord attached. The power cord should be plugged into a
30-ampere receptacle. In Canada, you may convert a dryer to 120 / 208 volts.
Untitled-2 23 2024-06-27() 6:30:11
English24
Installation
This dryer must be installed by a qualified technician. The installer is responsible for connecting the dryer
to the main power while observing the relevant safety regulations of your area.
What’s included
Make sure all the parts are included in the product package. If you have a problem with the dryer or the
parts, contact a local Samsung customer center or the retailer.
01
02
04
05
06
03
01 Water tank 02 Door 03 Leveling legs
04 Worktop 05 Control panel 06 Lint filter
Untitled-2 24 2024-06-27() 6:30:11
English 25
Accessories (supplied)
User manual Long drain hose (78.7 in. (2 m)) Cable tie
Cleaning brush Micro soft filter (Optional Filter)
NOTE
• The stacking kit allows the dryer to be stacked on top of a washer. Please note that the stacking kit can
only be used with Samsung washers and dryers. To purchase a stacking kit above, contact a Samsung
service center or local appliance retailer. The stacking kit differs with the washer model.
• For stacking instructions with the dryer, see the installation manual included in the stacking kit.
• For information on which stacking kit model you can use to stack your dryer on the washer, see the user
manual included in your Samsung washer.
WARNING
Packing materials can be dangerous to children. Keep all packing materials (plastic bags, polystyrene, etc.)
out of children’s reach.
Untitled-2 25 2024-06-27() 6:30:11
Installation
English26
Step-by-step installation
Make sure you have a qualified technician install the dryer. Step-by-step installation instructions start
below.
• Do not remove the protective film on the door before completing the product installation. If you remove
the protective film before the installation is complete, the door may get scratched or damaged during
installation.
• Make sure the installation location allows enough space for the dryer door to be fully open.
STEP 1 Install the exhaust system
1. Select a location and move the dryer to the site. For easy access, we recommend you install the dryer in
the same location as your washer.
2. To change the door direction, see “Door reversal” on page 34.
3. Install the exhaust system as instructed in the “Exhaust ducting guide (Not applicable to ventless (heat
pump) models)” section. (Not applicable to ventless (heat pump) models)
CAUTION
Before installing your dryer, remove the packing in the duct.
NOTE
• To move the dryer easily, lay two of the carton cushions from the packaging on the floor. Tip the dryer
on its side so it lies across both cushion-tops. Push the dryer so that it is near its final location, and then
set the dryer upright.
• Secure room around the dryer to facilitate ducting and wiring.
STEP 2 Connect the gas line (for gas models)
Before connecting the gas line, make sure you have read the “Gas requirements (Not applicable to ventless
(heat pump) models)” section on page 21.
1. Remove the protective cap from the gas pipe.
2. Apply an LPG (Liquefied Petroleum Gas)-safe compound or 1.5 wraps of Teflon tape to all threaded
connections.
3. Connect the gas supply to the dryer. An additional fitting is required to connect the
3
/4” (1.9 cm) female
thread end of a flexible connector to the
3
/8” (1 cm) male threaded end on the dryer. Tighten up the
fitting over all threads.
4. Turn on the gas supply, and check for any leaks using a soap solution. If a leak is found, tighten the
connections and try again. Do not use an open flame to check for gas leaks.
Untitled-2 26 2024-06-27() 6:30:12
English 27
STEP 3 Connect the electrical wiring (for electric models)
Before connecting the electrical wiring, make sure you have read the “Electrical requirements” section on
page 22.
3-wire system
A B C L2 L1
D
E
A. External ground connector
B. Neutral grounding wire (white)
C. Center silver-colored terminal block
screw
D. Neutral wire (white or center wire)
E.
3
/4” (1.9 cm) UL-listed strain relief
1. Loosen or remove the screws from the center
terminal block.
2. Connect the neutral wire (white or center wire) of the
power cable to the center, silver-colored terminal
screw of the terminal block. Tighten the screws.
3. Connect the other wires to the outer terminal block
screws. Tighten the screws.
4. Tighten the strain relief screws.
5. Insert the terminal block cover into the rear panel of
the dryer. Then, secure the cover with a hold-down
screw.
CAUTION
• To convert from the 4-wire system to a 3-wire
system, connect the ground strap to the terminal
block support to ground the dryer frame to the
neutral conductor.
• Ring-type terminals are recommended. If using strap
terminals, make sure they are tightened.
• Connect the power cord and check the L1/L2/D (N)
voltage. If the voltage is low, it may not heat properly.
Review the “Electrical requirements” section on page
22 if needed.
Untitled-2 27 2024-06-27() 6:30:12
Installation
English28
4-wire system
F
A B C L2 L1
D
E
A. External ground connector
B. Neutral grounding wire (white)
C. Center silver-colored terminal block
screw
D. Neutral wire (white or center wire)
E.
3
/4” (1.9 cm) UL-listed strain relief
F. Neutral wire (white or center wire)
1. Remove the external ground connector’s screw and
connect the ground wire (green or unwrapped) of the
power cable to the screw.
CAUTION
- To connect the ground wire to the neutral position
without through contact A (cabinet ground),
contact a technician. This is not user serviceable.
- Ring-type terminals are recommended. If using
strap terminals, make sure they are tightened.
2. Loosen or remove the screws from the center
terminal block.
3. Connect the neutral wire (white or center wire)
and ground wire (white) to the center screw of the
terminal block. Tighten the screw.
4. Connect the other wires to the outer terminal block
screws. Tighten the screws.
5. Tighten the strain relief screws.
6. Insert the tab of the terminal block cover into the
rear slot of the dryer. Secure the cover with a hold-
down screw.
CAUTION
Connect the power cord and check the L1/L2/D (N) voltage. If the voltage is low, it may not heat properly.
Review the “Electrical requirements” section on page 22 if needed.
WARNING
• All U.S. models are designed for a 3-wire system connection. The dryer frame is grounded to the
neutral conductor at the terminal block. A 4-wire system connection is required for new or remodeled
construction, mobile homes, or if local codes do not permit grounding through neutral. If you use the
4-wire system, you cannot ground the dryer frame to the neutral conductor at the terminal block.
• Remove the terminal block cover plate. Insert the power cord with a UL-listed strain relief through the
hole provided in the cabinet near the terminal block.
• A strain relief must be used. Do not loosen the nuts already installed on the terminal block. Be sure
they are tight. Use a
3
/8” (1 cm) deep well socket.
• Since January 1, 1996, the National Electric Code requires that new wiring (not existing) utilize a 4-wire
connection to this dryer.
Untitled-2 28 2024-06-27() 6:30:12
English 29
STEP 4 Level the dryer
To ensure optimal performance, the dryer must be level.
A
B
Using a level (A), check if the dryer is level side to side
and then front to back. If the dryer is not level, turn
the leveling feet (B) clockwise to lower the dryer or
counterclockwise to raise the dryer.
A B
NOTE
• To set the dryer to the same height as your washer,
fully retract (A) the leveling feet by turning them
counterclockwise, then loosen (B) the feet by turning
them clockwise. Once the dryer is the same height as
the washer, follow the directions above to level the
dryer.
• Adjust the leveling feet only as much as necessary to
level the dryer. Extending the leveling feet more than
necessary can cause the dryer to vibrate.
Untitled-2 29 2024-06-27() 6:30:12
Installation
English30
STEP 5 Power on (for gas models)
Make sure all gas connections, the exhaust line, and all wiring are connected correctly. Then, plug the
power cord into a power source and check the dryer’s installation and operation using the final checklist in
Step 6 below.
STEP 6 Final Check
When the installation is complete, confirm that:
• The dryer is plugged into an electrical outlet and grounded properly.
• The exhaust ductwork is connected, and the joints are taped.
• You have used rigid or stiff-walled flexible metal duct material, not plastic flexible duct.
• The dryer is level and is sitting firmly on the floor.
• The dryer starts, runs, heats, and shuts off properly.
• The gas is supplied properly with no leaks (For gas models only).
CAUTION
The burner may not ignite initially due to air in the gas line. Allowing your dryer to operate on a heat setting
will purge the line. If the gas does not ignite within 5 minutes, turn your dryer off and wait 5 minutes. Be
sure the gas supply to your dryer has been turned on. To confirm gas ignition, check the exhaust for heat.
Connect the drain hose
Draining directly into a drainage system
• We strongly recommend draining condensed water
directly into your drainage system instead of draining
to the built-in water tank.
• Use the provided accessory hose (long drain hose) to
drain condensed water directly to your drain system
instead of draining to the built-in water tank (which
is a default method).
• Use the built-in water tank only if you cannot drain
the condensed water directly to a drainage system.
NOTE
As a factory default, this dryer is set to use the built-in
water tank to drain condensed water.
Untitled-2 30 2024-06-27() 6:30:12
English 31
1. Remove the water tank drain hose from the drain
water outlet (A), and then insert it to the holder (B).
89
01 2.8 in. (70 mm)
2. Insert one end of the accessory hose (long drain
hose) into the drain water outlet (A).
3. Place the other end (outlet) of the accessory hose at
least 2.8 in. (70 mm) away from a drain hole.
4. If necessary, insert the one end of the accessory
hose (long drain hose) into the connector (C) of
disassembled hose to combine two hoses.
Untitled-2 31 2024-06-27() 6:30:13
Installation
English32
CAUTION
• Place the other end (outlet) of the accessory hose about 70 mm away from a drain hole. Do not insert
the end (outlet) of the accessory hose into a sewer.
- A sewer smell may flow into the dryer.
• Wring out excess water from items before putting them in the dryer.
- Wet items may cause an unpleasant smell inside the dryer.
• Open the dryer door and the heat exchanger cover after completing a drying cycle to maintain the dryer
interior more hygienically.
• Run the Self Dry cycle if there is an unpleasant smell inside the dryer.
Draining to the water tank
1. Remove the long drain hose from the drain water
outlet (A).
* 2.8 in. (70 mm)
NOTE
Completely dry the removed long drain hose and keep it
in a safe place for later use.
2. Remove the water tank drain hose from the holder
(B), and then connect it to the drain water outlet (A).
- Firmly connect the water tank drain hose so that
it does not move around.
Untitled-2 32 2024-06-27() 6:30:13
English 33
Installation checklist
• The dryer is plugged into a properly grounded outlet.
• All packaging material is completely removed and properly disposed.
• The dryer is level and standing firmly on the floor.
• The long drain hose is installed if you want water captured by the drying process drained automatically.
• Start the dryer to make sure that it runs, heats, and shuts off.
• Run a TIME DRY cycle for 20 minutes to see if the HC information code is displayed. If this is the case,
contact a local service center.
• After installation, we recommend that you wait at least 1 hour before using the dryer.
Before using the dryer
• Make sure no accessory remains inside the drum.
• Plug in the power cord just before operating the dryer.
• Do not block the air inlet hole of the cooling grill at the front of the dryer.
• Do not place flammable objects near the dryer and keep the surrounding area clean.
• Keep the dryer level with the ground.
• Do not remove the adjustable leveling feet of the dryer. They are necessary to keep the dryer level.
Untitled-2 33 2024-06-27() 6:30:13
Installation
English34
Exhaust ducting guide (Not applicable to ventless (heat pump) models)
Ducting
1. Make sure the dryer is installed properly so the air exhausts freely.
2. Use 4-inch rigid metal ducts. Tape all joints including the dryer connection. Never use lint-trapping
screws.
3. To facilitate the exhaust, keep the ducts as straight as possible.
Cleaning
Clean all old ducts before installing the dryer, and make sure the vent flap opens and closes freely. We
recommend that you clean the exhaust system annually or on a regular basis.
WARNING
• To prevent fire, do not use plastic, thin-foil, or non-metal flexible ducts of any kind.
• Do not use a poor exhaust system because it slows down the dryer’s performance.
• Do not use excessively long ducts that have multiple elbows.
• Do not use crushed or clogged venting or ducts.
Door reversal
CAUTION
• Unplug the power cord before you reverse the door.
• Put a soft rug on the floor to place the door when you remove it. This will prevent the door from being
scratched.
1. Remove the door glass gasket.
Untitled-2 34 2024-06-27() 6:30:13
English 35
2. Remove the six screws fastening the door glass at
the inner side of the door.
- Remove the bottom three screws first.
3. Disassemble the door glass.
CAUTION
Be careful not to drop it during disassembling.
• You may damage the parts, and broken glass parts
may lead to injury.
4. Remove the two screws fastening the door to
disassemble the door.
- Use an Allen Wrench to prevent the screws from
wearing out.
NOTE
There is a screw on the back side of the hinge that will
support the door as you unscrew the hinge screws.
Untitled-2 35 2024-06-27() 6:30:13
Installation
English36
5. Remove the two screws that are above and below the
cut-out in the front frame.
6. Remove the two screws above and below the lever
holder on the opposite side of the door opening.
7. Remove the two screws that hold the lever holder in
place, and then remove the lever holder.
8. Re-insert the two screws that held the lever holder
into the same screw holes, and then tighten.
Untitled-2 36 2024-06-27() 6:30:14
English 37
9. Remove the single screw from the back of the door
hinge.
NOTE
This is the screw that supports the door against the
frame so you can unscrew or screw in the hinge without
needing to support the door yourself.
10. Insert the screw you just removed into the other
screw hole on the back of the door hinge, and then
tighten.
11. Place the door on the other side, and then reattach it
to the dryer.
NOTE
Insert the head of the screw on the back of the hinge
into the hole above the cut-out in the frame, and then
slide the door hinge down until it stops. Make sure the
protrusion on the back of the hinge is pressed into the
cut-out before you tighten the hinge screws.
12. Push the lever holder into the cut-out on the other
side of the door opening. Insert screws, and then
tighten as shown.
Untitled-2 37 2024-06-27() 6:30:14
Installation
English38
13. Re-attach the remaining screws to the remaining
holes above and below the lever holder, and then
tighten.
14. Attach the door on the opposite side and put the door
glass back in its place.
15. Fasten the door glass with the six screws.
NOTE
Firmly hold the door glass to prevent from dropping it
while you fasten it with the screws.
16. Assemble the door glass gasket back onto its place.
Untitled-2 38 2024-06-27() 6:30:15
English 39
Before you start
Here are a few things you should know before starting your dryer.
Sort and load
• Put one wash load in the dryer at a time.
• Do not mix heavy and lightweight items.
• To improve drying efficiency for one or two items, add a dry towel to the load.
• For best results, untangle items before inserting them into the dryer. Tangled items may degrade the
drying efficiency or cause the door to open.
• Overloading reduces the tumbling action, resulting in uneven drying and wrinkling.
• Unless recommended on the care label, do not dry woolens or fiberglass items.
• Avoid drying unwashed items.
• Do not dry items soiled with oil, alcohol, gasoline, etc.
Functional prerequisite
Lint filter
A
To prevent a risk of fire, make sure to clean the lint filter
before or after every load.
1. Turn off the dryer.
2. Open the door and pull out the lint filter (A) from
inside the drum.
3. Open the lint filter by separating it at the top.
Remove the lint, and then clean the lint filter.
4. Close the lint filter, reinsert the lint filter into the
dryer, and then close the dryer door.
CAUTION
• Do not operate the dryer without the lint filter in
place.
• Do not use a damaged or broken lint filter. This may
reduce performance and/or cause a fire.
Untitled-2 39 2024-06-27() 6:30:15
English40
Operations
WARNING
To reduce the risk of fire, electric shock, or injury, read the “Safety information” before operating this
appliance.
Control panel
11
12
03 04 05 06
07 08
09 10
01
02
01 Cycle Selector
Turn the Cycle Selector to select a desired cycle. When a cycle is selected,
the cycle indicator lights up.
• Manual Dry: The drying time is fixed.
02 Digital Graphic
Display
Displays all cycle information, including the cycle time, information code,
and operating status.
03 Dryness
Press to select a dry level. You can select from 4 different options (1 to
4). Please refer to following recommendations to select the appropriate
dryness.
• For larger or bulkier loads, select 4 for complete dryness.
• For items that needs to lay flat or hang to dry, use 1 to partially dry items.
NOTE
This option is not available with ACTIVEWEAR, SANITIZE, TIME DRY and AIR
FLUFF.
04 Time
Press to adjust the drying time for the Manual Dry cycles. This is not
available with the Standard cycles because the dryer determines the drying
time by sensing the current moisture level of the load.
05 Damp Alert
This option alerts you when shirts and other items that require ironing are
dry enough to be suitable for ironing.
NOTE
This option is available with NORMAL, DELICATES and PERM PRESS.
06 Wrinkle Prevent
Wrinkle Prevent provides approximately 180 minutes of intermittent
tumbling in unheated air at the end of the cycle to reduce wrinkling. Press
Wrinkle Prevent to activate this feature. The load is dry, and can be removed
at any time during the Wrinkle Prevent cycle.
Untitled-2 40 2024-06-27() 6:30:16
English 41
07 Self Dry
Use this cycle to keep inside the dryer dry. This cycle effectively dries every
corner of the dryer, even if they cannot be seen.
• Remove all laundry first, and then run the Self Dry cycle for better
hygiene inside your dryer.
• The lamp on the Self Dry button will flash after the drying process to
remind you to run the Self Dry cycle. It will flash every 10 times up to the
initial 30 times, and then every 25 times afterwards.
CAUTION
The drum must be empty when you run the Self Dry cycle.
08 Drum Light
Press to turn the interior lamp on or off. The lamp stays lit for 2 minutes after
it has turned on, regardless of whether the power is on or off or the door is
open or closed, and then turns off automatically.
09 Sound Off You can turn on or off the sound from the dryer.
10 Smart Control
After connecting the Tumble Dryer to your home network using the
Samsung Smart Washer/Dryer app, you can control the dryer remotely.
When started, the Smart Control indicator blinks. The dryer enters waiting
mode and waits for remote commands.
11 Power Press to turn on/turn off the dryer.
12 Start/Pause Press and hold to start or stop operation.
NOTE
Do not take extremely tangled items from your washer and put them into the dryer. They can degrade the
drying efficiency of the dryer or cause the door to open. We recommend that you untangle the items before
putting them into the dryer. Also, do not put objects on the dryer, especially on the control panel.
CAUTION
Do not spray water directly onto the control panel. This may cause a system failure.
Untitled-2 41 2024-06-27() 6:30:16
Operations
English42
Icon description
Sensor Dry
This icon appears when the dryer operates the cycle which senses the
internal humidity to determine the drying time.
AI Energy Mode
You can save energy for your dryer through the AI Energy Mode
provided by SmartThings Energy Service. When AI Energy Mode is
applied, this icon is displayed and shows the saved energy compared
to when AI Energy Mode was not used after the drying is completed.
• The predicted amount of energy saved may differ from the actual
usage depending on the usage environment.
Filter Check
This icon displays after every load as a reminder to clean the lint
filter. Clean the lint filter before every cycle and make sure the filter is
properly inserted before starting a cycle.
If this icon remains on the display during the cycle and does not turn
off, clean the Micro soft filter (Optional Filter) (Refer to the "Micro soft
filter (Optional Filter)" section on page 56.)
Water Tank Check
This icon indicates that the water tank is full. Emptying the water tank
refer to the "Emptying the water tank" section on page 49.
Heat Exchanger
Clean
This icon indicates that clean the heater exchanger.
Clean the dust on the heater exchanger and optional filter refer to the
"Heat exchanger" section on page 54.
Child Lock
This icon indicates that Child Lock is on. For more information on Child
Lock, see page 47.
Wi-Fi This icon indicates that the dryer is connected to Wi-Fi.
Simple steps to start
1. Press Power to turn the dryer on.
2. Turn the Cycle Selector to select a cycle.
3. Change the cycle settings (Dryness, and Time) as necessary.
4. Select desired options as necessary.
5. Press and hold Start/Pause.
To change the cycle during operation
1. Press Start/Pause to stop operation.
2. Select a different cycle, and repeat steps 2-4 above if necessary.
3. Press and hold Start/Pause again to start the new cycle.
Untitled-2 42 2024-06-27() 6:30:17
English 43
Cycle overview
Standard cycles
Cycle Description
NORMAL For most fabrics including cottons and linens.
HEAVY DUTY
For drying items made out of heavy fabrics, such as jeans, corduroys, or work
clothes, with high temperature heat.
SANITIZE
Use to sanitize items by applying high-temperature heat deeply to the
fabric.
BEDDING For bulky items such as blankets, sheets, and comforters.
PERM PRESS
For drying wrinkle-free cottons, synthetic fabrics, and permanent press
fabrics automatically.
DELICATES For heat-sensitive items at a low drying temperature.
DOWNLOADED
• Select to choose from more cycles available on the Samsung Smart
Washer/Dryer app on your smartphone.
• Available cycles: ECO NORMAL, SHIRTS, DENIM, WOOL, AIR BEDDING
CARE, DOWN JACKET CARE, OUTDOOR CARE
• Factory setting: ECO NORMAL
TOWELS Use to dry loads such as bath towels.
ACTIVEWEAR
For exercise wear and outdoor wear such as sports jerseys, training pants,
and other performance clothing.
QUICK DRY
For mixed loads consisting of cotton and synthetic fabrics that need quick
drying.
Untitled-2 43 2024-06-27() 6:30:18
Operations
English44
Manual Dry
You can change the drying settings manually to your preference.
Cycle Description
TIME DRY
Use to set a desired dry time.
Turn the Cycle Selector to select TIME DRY and tap Time to set the drying
time between 20 minutes and 240 minutes. Tap Time repeatedly to select
the available time options in this order: 20 / 40 / 60 / 90 / 120 / 150 / 180 /
240.
NOTE
If you use this cycle for additional drying after finishing one of the Standard
cycles, set the minimum drying time (20 minutes). Excessive drying may
cause damage or deform to an item.
AIR FLUFF Tumbles the load in room temperature air.
Cycle chart
NOTE
For best results, follow the load size recommendations for each dry cycle.
• Large load: Fill the drum to about 3/4 full. Do not add items over this level as they need to tumble
freely.
• Medium load : Fill the drum to about 1/2 full.
• Small load : Fill the drum with 3-5 items, not more than 1/4 full.
Cycle Recommended items Load size Dry level
Standard
NORMAL Cottons, work clothes, linens, mixed loads 3 (Adjustable)
HEAVY DUTY
Heavy Fabrics such as jeans, corduroys, heavy work
clothes
3 (Adjustable)
SANITIZE Bedding, curtains, children’s clothing 4 (Not adjustable)
BEDDING
Bulky items such as blankets, sheets, comforters,
pillows
3 (Adjustable)
PERM PRESS
Shirts, synthetic fabrics, knits, wrinkle-free cottons,
permanent press
2 (Adjustable)
DELICATES Underwear, blouses, lingerie 2 (Adjustable)
TOWELS Bath towels and similar items 3 (Adjustable)
ACTIVEWEAR Exercise wear, sports jerseys 2 (Not adjustable)
QUICK DRY Cotton, mixed loads of cotton and synthetic fabrics. 3 (Adjustable)
Manual Dry
TIME DRY Any load -
AIR FLUFF Foam, rubber, plastic -
Untitled-2 44 2024-06-27() 6:30:18
English 45
NOTE
: factory setting, : can be selected
Cycle
Options
Time setting Wrinkle Prevent Damp Alert
Standard
NORMAL
HEAVY DUTY
SANITIZE
BEDDING
PERM PRESS
DELICATES
TOWELS
ACTIVEWEAR
QUICK DRY
Manual Dry
TIME DRY
AIR FLUFF
Untitled-2 45 2024-06-27() 6:30:18
Operations
English46
Cycle guide
The best way to dry items is to follow the instructions on the care label. If no drying instructions are
provided, see the following table for reference.
Cycle Description
Bedspreads & Comforters
Follow the care label instructions or dry using BEDDING.
• Make sure the item is thoroughly dry before using or storing.
• May require repositioning in the drum to ensure even drying.
Blankets
Use BEDDING and dry only one blanket at a time for best tumbling action.
• Make sure blankets are thoroughly dry before using or storing.
Curtains & Draperies
Do not dry on a heat setting. Doing so may cause a fire hazard. Only use the
AIR FLUFF cycle.
• Dry curtains and draperies in small loads for best results and remove as
soon as possible.
Cloth Diapers Use NORMAL and the Medium temperature setting for soft, fluffy diapers.
Down–filled Items
(jackets, sleeping bags,
comforters, etc.)
Do not dry on a heat setting. Doing so may cause a fire hazard. Only use the
AIR FLUFF cycle.
Foam Rubber (rug backs,
stuffed toys, shoulder
pads, etc.)
Do not dry on a heat setting.
WARNING
Drying a rubber item with heat may damage it or cause a fire.
Pillows
Use NORMAL.
• Add a couple of dry towels and a pair of clean sneakers to help the
tumbling action and to fluff the items.
• Do not dry kapok or foam pillows using a heated drying cycle. Use only
the AIR FLUFF cycle.
Plastics (shower curtains,
outdoor furniture covers,
etc.)
Use TIME DRY and the Low or Extra Low temperature settings depending on
the care label instructions.
WARNING
Do not dry:
• Fiberglass items (curtains, draperies, etc.)
• Woolens, unless recommended on the label
• Items spotted or soaked with vegetable or cooking oils
Untitled-2 46 2024-06-27() 6:30:19
English 47
Special features
Child Lock
Child Lock prevents children from playing with the dryer. When Child Lock is activated, all buttons except
for the Power button are disabled.
To activate/deactivate Child Lock, simultaneously press and hold Dryness and Time for 3 seconds.
NOTE
Once Child Lock is activated, it will remain active even after you restart the dryer. If other buttons, except
for the Power button, do not respond, check the Child Lock indicator. If the indicator is on, follow the
instructions above to turn Child Lock off.
Sound Off
You can turn on or off the sound from the dryer. Please note that this setting does not affect the sound that
notifies information codes and Damp Alert.
• To mute the sound, Press Sound Off.
• To unmute the sound, Press again Sound Off.
Smart Control
To enable this function, you must first download the Samsung Smart Washer/Dryer app at the Play Store or
the App Store and install it on a mobile device featuring a camera function. The Smart Control function has
been optimized for Galaxy & iPhone series (applicable models only).
1. When the dryer detects an issue to check, an information code appears on the display. To enter Smart
Control mode, press Smart Control.
2. The dryer starts the self-diagnosis procedure and displays an information code if a problem is detected.
3. Run the Samsung Smart Washer/Dryer app on your mobile device, and then tap Smart Control.
4. Put the mobile device close to the dryer’s display so that the smartphone camera and the dryer face
each other. The app automatically recognizes the information code.
5. When the information code is recognized correctly, the app provides detailed information about the
problem with applicable solutions.
NOTE
• The function name, Smart Control, may differ depending on the language.
• If light is reflected off the dryer’s display, the app may fail to recognize the information code.
• If the app fails to recognize the information code, you can enter the code manually in the app.
DOWNLOADED cycle
You can choose from more cycles available on the SmartThings app on your smartphone.
1. On your smartphone, select the DOWNLOADED cycle.
You can choose from ECO NORMAL, SHIRTS, DENIM, WOOL, AIR BEDDING CARE, DOWN JACKET CARE,
OUTDOOR CARE.
2. Press Power on your dryer.
Untitled-2 47 2024-06-27() 6:30:19
Operations
English48
3. Turn the Cycle Selector to DOWNLOADED.
4. Press and hold Start/Pause.
SmartThings
Wi-Fi connection
On your smartphone, go to Settings, turn on the wireless connection, and then select your AP (Access
Point).
• This appliance supports the Wi-Fi 2.4 GHz protocols.
Download
On an app market (Google Play Store, Apple App Store, Samsung Galaxy Apps), find the SmartThings app
using the search term “SmartThings”. Download and install the app on your device.
NOTE
The app is subject to change without notice for improved performance.
Log in
You must first log into SmartThings with your Samsung account. To create a new Samsung account, follow
the instructions in the app. You don’t need a separate app to create your account.
NOTE
If you have a Samsung account, use the account to log in. A registered Samsung smartphone user
automatically logs in.
To register your appliance to SmartThings
1. Make sure your smartphone is connected to a wireless network. If not, go to Settings and turn on the
wireless connection, and then select your AP (Access Point).
2. Open SmartThings on your smartphone.
3. If the “A new device is found.” message appears, select Add.
4. If no message appears, select + and then select your appliance from the list of devices available. If
your appliance is not listed, select Device Type > Specific Device Model, and then add your appliance
manually.
5. Register your appliance to the SmartThings app.
a. Add your appliance to SmartThings. Make sure your appliance is connected to SmartThings.
b. When registration is complete, then name of your appliance appears on your smartphone.
Untitled-2 48 2024-06-27() 6:30:19
English 49
Maintenance
Emptying the water tank
Empty the water tank after each use to prevent leaks.
1. Remove the water tank (A) from the dryer.
- Pull the water tank handle with one hand until the
tank is halfway out.
- Once the water tank is halfway out, support the
bottom of the tank with the other hand and pull it
slowly with both hands.
CAUTION
• The water tank is heavy. Slowly remove the water
tank using both hands while keeping the tank at a
level.
• Be careful when removing the full water tank. It is
very heavy and can cause injury if you drop it.
2. Empty the water through the drain hole (B), and then
clean inside the water tank.
- Mix some neutral detergent in lukewarm water.
Fill the water tank with the mixture through the
drain hole (B) and leave it for 30 minutes. Then,
rinse the tank with clean water and completely
dry it.
3. Place the water tank back into place.
NOTE
If the dryer displays the icon and stops while drying is in progress, empty the water tank and tap and
hold . The icon will disappear, and the dryer will resume drying.
Untitled-2 49 2024-06-27() 6:30:19
Maintenance
English50
Installing the micro soft filter (Optional Filter)
You can install the provided micro soft filter (Optional Filter) to prevent dust accumulation on the heat
exchanger.
1. Gently press the top part of the outer cover (A) to
open.
2. Unlock the inner cover fixers (B), and then pull the
inner cover to remove.
3. Insert the provided micro soft filter (Optional Filter)
(C) on the back of the inner cover as shown in the
figure.
- Make sure to install the filter in the correct
position. (The tap on the top of the filter should
face outward.)
Untitled-2 50 2024-06-27() 6:30:20
English 51
4. Reinsert the inner cover to its original position, and
then lock the fixers.
5. Close the heat exchanger’s outer cover.
Cleaning
WARNING
• Do not clean the dryer by directly spraying water onto the dryer.
• Do not clean the dryer with benzene, thinner, alcohol, or acetone. This may cause discoloration,
deformation, damage, electric shock, or fire.
• Before cleaning the dryer, be sure to unplug the power cord.
Exterior
Clean with a soft, damp cloth. Do not use abrasive cleaners. Avoid using or placing sharp or heavy objects
near/on the dryer. Keep detergent and laundry supplies on the pedestal (sold separately) or in a separate
storage container.
Control panel
Clean with a soft, damp cloth. Do not use abrasive cleaners. Do not spray cleaners directly on the panel.
Immediately wipe up any spills or liquids from the control panel.
Drum
Clean with a damp cloth with a mild, non-abrasive cleaner suitable for stainless steel.
Wipe the remaining residue with a clean, dry cloth.
Door
Foreign substances can contaminate or build up on the inside of the door. Clean the inside of the door using
a soft piece of cloth or brush.
CAUTION
Do not detach the door’s rubber sealing.
Untitled-2 51 2024-06-27() 6:30:20
Maintenance
English52
Lint filter
Clean the lint filter after each use.
1. Open the dryer door, grab the top of the lint filter,
and pull to remove the filter.
- Do not detach the rubber sealing after removing
the filter.
A
2. Open the outer filter and remove the inner filter (A).
3. Spread open the outer filter and the inner filter.
4. Remove the lint from both filters, and then clean the
filters with the cleaning brush.
Untitled-2 52 2024-06-27() 6:30:20
English 53
NOTE
To clean the filters thoroughly, clean the filters in
running water, and then dry them completely.
5. Put the inner filter into the outer filter, and then
reinsert the lint filter into the original position.
CAUTION
• Clean the lint filter after each load. Otherwise, the drying performance may decrease.
• If the filter surface is wet, allow it to completely dry before use.
- Inserting the filter while it is wet can cause mold and/or odor to form and/or result in less drying.
• When cleaning or removing the lint filter, do not shake or tap on the filter. Doing so can damage the
filter.
• Opening the outer and inner filters carelessly and with excessive force can damage the filters.
Untitled-2 53 2024-06-27() 6:30:21
Maintenance
English54
Heat exchanger
When it is time to clean the heat exchanger, the Heat Exchanger Clean icon ( ) appears on the display.
A dirty heat exchanger will hinder the product’s performance and should be cleaned regularly.
NOTE
• Water droplets can form around the heat exchanger due to condensation caused by a temperature
difference. This is normal and is not a sign of a leak.
• If you are not planning on using the dryer for a long period, open the heat exchanger cover and ventilate.
1. Gently press the top part of the outer cover (A) to
open.
2. Unlock the inner cover fixers (B), and then pull the
inner cover to remove.
3. Clean the dust on the heat exchanger using the
provided brush.
- After cleaning with the brush, wipe off the
remaining dust using a smooth, damp cloth.
CAUTION
• To avoid physical injury and burns, do not touch or
clean the heat exchanger with bare hands.
• When cleaning the heat exchanger, be careful not to
damage the fins.
NOTE
If the heat exchanger is completely dry and therefore
hard to clean, spray some water on the heat exchanger
and clean using a brush.
Untitled-2 54 2024-06-27() 6:30:21
English 55
4. Clean the inner cover with a smooth, damp cloth.
- There may be moisture and/or foreign substances
around the inner cover.
5. Reinsert the inner cover to its original position, and
then lock the fixers.
6. Close the heat exchanger’s outer cover.
Untitled-2 55 2024-06-27() 6:30:21
Maintenance
English56
Micro soft filter (Optional Filter)
When it is time to clean the Micro soft filter (Optional Filter), the icon remains on the display and does
not turn off. A dirty Micro soft filter (Optional Filter) will hinder the product’s performance and should be
cleaned regularly.
1. Open the heat exchanger's outer cover, and
then remove the inner cover. (Refer to the “Heat
exchanger” section on page 54.)
2. Remove the Micro soft filter (Optional Filter) from the
inner cover.
3. Clean the dust on the Micro soft filter (Optional
Filter) with the provided brush, and then wash the
filter in running water.
- Completely dry the filter after a wash.
- Clean the filter regularly. A dirty filter can degrade
a drying performance.
4. Insert the filter into the inner cover, and then insert
the inner cover back to its place.
- Make sure into install the filter in the correct
position. (The tap on the top of the filter should
face outward.)
NOTE
• Clean the Micro soft filter (Optional Filter) every 25 uses of the dryer.
- Heavily soiled Micro soft filter (Optional Filter) may degrade the drying performance.
• When cleaning the Micro soft filter (Optional Filter), check the heat exchanger and clean it if it is dusted.
Untitled-2 56 2024-06-27() 6:30:22
English 57
Troubleshooting
Checkpoints
If you encounter a problem with the dryer, first check the table below and try the suggestions.
Problem Action
Dryer does not start.
• Make sure the dryer is plugged in.
• Make sure the door is properly closed.
• Check the fuse or reset the circuit breaker.
• If you opened the door during a cycle, tap and hold again.
• Clean the filter.
• Make sure Child Lock is not activated.
The dryer does not warm
up.
• Check the fuse or reset the circuit breaker.
• Check the lint filter and the heat exchanger. Clean them if necessary.
• The dryer may be in the cooling down process of the cycle.
Items are not dried.
Check all of the above. Additionally:
• Do not overload the dryer. If the dryer is overloaded, it could take longer
for items to dry.
• Dry heavy fabrics separately from light fabrics.
• The item(s) are too small and may not get enough spinning inside the
drum.
• Clean the filter.
• Clean the heat exchanger.
• If the Heat Exchanger Clean icon ( ) appears on the display, clean the
heat exchanger (Refer to the "Heat exchanger" section on page 54.)
• If the Filter Check icon ( ) on the display and does not turn off, clean
the heat exchanger (Refer to the "Micro soft filter (Optional Filter)"
section on page 56.)
• If a drain hose is connected, make sure water is draining properly.
The dryer is too loud.
• Look for coins, loose buttons, nails, and other objects and remove them
immediately.
• Check the lint filter. Remove any items stuck inside the lint filter.
• Make sure the dryer is level and standing firmly on the floor.
• The dryer may hum due to air moving through the drum and fan. This is
normal.
Items are not dried evenly.
• Seams, pockets, and other parts of clothing are harder to dry than
others. This is normal.
• Sort heavy and light items separately.
Untitled-2 57 2024-06-27() 6:30:22
Troubleshooting
English58
Problem Action
There is a smell coming
from the dryer.
• The smell of paint, varnish, cleaning agents, and other household items
could have circulated in the air and entered the dryer. If you notice such
a smell, ventilate completely before using the dryer.
• If drying in an enclosed area, the dryer could cause the ambient
temperature to rise. Accordingly, make sure to open a window and
ventilate the area.
• Do not attempt to dry wet items after leaving them in the washing
machine or dryer for a long time.
The dryer turns off before
the items are dry.
• The load is too small. Throw in few additional items like towels and try
drying again.
The clothes have lint on
them.
• Always make sure the lint filter is clean before putting items into the
dryer. When drying items that generate a large amount of lint, you may
need to clean the lint filter in the middle of a cycle.
• Some fabrics (such as white towels) causes more lint and should be
dried separately from fabrics that lint attaches easily (such as black
linen pants).
• Check the inside of the pockets to make sure they are empty before
drying.
Items still wrinkled after
Wrinkle Prevent (Wrinkle
Away, Wrinkle Release).
• Small loads of 1 to 4 items work best.
• Load fewer items. Load similar-type items.
• Take out the items immediately after drying is complete.
Extended time.
• Sensor Dry automatically senses the moisture in the load and shuts the
dryer off when the selected dryness level is reached.
The drying time can change according to the type and amount of
laundry. See the cycle chart for reference.
The ambient temperature
around the dryer rises or
there is a damp, soggy
smell.
• Heat pump dryers circulate ambient air inside and outside the dryer
during the drying process to cool the system. Using the dryer in a poorly
ventilated area may, depending on the operating environment, raise the
ambient humidity level and/or cause a damp, soggy smell to develop.
Ensure proper ventilation when using the dryer.
Water is not draining.
• Check the draining hose for twists and kinks.
Straighten out the hose if it is twisted or kinked and securely connect it
to the drain on the floor.
• Check to see if the draining hose is frozen.
If the hose is frozen, submerge it in warm water to allow the water inside
the hose to melt and drain out. Reconnect the hose and check for proper
draining.
If a problem persists, contact a local Samsung service center.
Untitled-2 58 2024-06-27() 6:30:22
English 59
Information codes
If the dryer fails to operate, you may see an information code on the display panel. To determine what you
should do, check the list of codes in the table below, and then try the suggested actions.
Code Action
dC
Operating the dryer with the door open.
• Make sure the door is properly closed.
• Make sure laundry is not caught in the door.
AC
Electronic control problem (Invalid Communication).
• Contact a Samsung service center.
HC
High temperature heating check.
• Clean the lint filter.
• If this information code remains, contact a Samsung service center.
9C1
The electronic control needs to be checked.
• Check if power is supplied properly.
• If the information code remains, contact a Samsung service center.
9C9
Check for overheating around the power module (IPM).
• Turn off the dryer and operate the dryer again.
• If error code keeps appearing, contact service center.
TC
The Thermistor1 resistance is very low or high.
• Resistance of thermistors sensor is over limit.
• Turn off the dryer and, contact a Samsung service center.
3C
The PBA needs to be checked.
• Unplug the power plug and contact a Samsung service center.
5C
The water tank is full or the drain pump not working.
• Check the water tank is full or not. Empty it if it is full.
• Check the Drain pump
NC
The Dryer filter or heat exchanger protection conver is not inserted
• Check the Dryer filter or heat exchanger protection conver is not inserted or
not.
NC2
The heat exchanger protection conver is not inserted
• Check heat exchanger protection conver is not inserted or not.
BC2/BC4
Continuous button press detection inspection
• Check to see if the button is stuck.
• In case of unresolved, contact a Samsung service center.
If any information code keeps appearing on the display, contact a Samsung service center.
Untitled-2 59 2024-06-27() 6:30:22
English60
Specifications
Fabric care chart
The following symbols provide garment care direction. The clothing care labels include symbols for drying.
The use of symbols ensures consistency among garment manufacturers of domestic and imported items.
Follow care label directions to optimize garment life and reduce laundering problems.
Tumble Dry Cycles
Dry
Normal
Permanent Press
Delicate/Gentle
Do Not Dry (Used with Do Not Wash)
Do Not Tumble Dry
In the Shade (Added to Line Dry, Drip Dry or Dry Flat)
Line Dry/ Hang to Dry
Drip Dry
Dry Flat
Tumble Dry Heat Setting
Any Heat
High
Medium
Low
No Heat/ Air
Untitled-2 60 2024-06-27() 6:30:24
English 61
Protecting the environment
This appliance is manufactured from recyclable materials. If you decide to dispose of this appliance, please
observe local waste disposal regulations. Cut off the power cord so that the appliance cannot be connected
to a power source. Remove the door so that animals and small children cannot get trapped inside the
appliance.
Specification sheet
Type Front loading dryer
Capacity (Cu.ft) 7. 5
Water pressure (psi (kPa)) 20-116 (137-800)
Weight (lb (kg)) 154 (70)
Power consumption (W) 2750
Allowable temperature 5-35 °C
Untitled-2 61 2024-06-27() 6:30:25
English62
LIMITED WARRANTY (U.S.A.)
SAMSUNG DRYER
LIMITED WARRANTY TO ORIGINAL CONSUMER PURCHASER WITH PROOF OF PURCHASE AND/
OR PROOF OF DELIVERY
This SAMSUNG brand product, as supplied and distributed by SAMSUNG ELECTRONICS AMERICA, INC.
(SAMSUNG) and delivered new, in the original carton to the original consumer purchaser, is warranted by
SAMSUNG against manufacturing defects in materials or workmanship for the following limited warranty
periods, starting on the date of delivery to the original consumer purchaser:
One (1) Year All Parts and Labor
This limited warranty is valid only on products purchased and used in the United States that have been
installed, operated, and maintained according to the instructions attached to or furnished with the product.
To receive warranty service, the purchaser must contact SAMSUNG at the address or phone number
provided below for problem determination and service procedures. Warranty service can only be performed
by a SAMSUNG authorized service center. The original dated bill of sale and/or proof of delivery must be
presented upon request to SAMSUNG or SAMSUNG’s authorized service center to receive warranty service.
SAMSUNG will provide in-home service within the contiguous United States during the warranty period
at no charge, subject to availability of SAMSUNG authorized servicers within the customer’s geographic
area. If in-home service is not available, SAMSUNG may elect, at its option, to provide transportation of
the product to and from an authorized service center. If the product is located in an area where service by a
SAMSUNG authorized servicer is not available, you may be responsible for a trip charge or required to bring
the product to a SAMSUNG authorized service center for service.
To receive in-home service, product must be unobstructed and accessible to the service agent.
During the applicable warranty period, a product will be repaired, replaced, or the purchase price refunded,
at the sole option of SAMSUNG. SAMSUNG may use new or reconditioned parts in repairing a product, or
replace the product with a new or reconditioned product. Replacement parts and products are warranted
for the remaining portion of the original product’s warranty or ninety (90) days, whichever is longer. All
replaced parts and products are the property of SAMSUNG and you must return them to SAMSUNG.
Untitled-2 62 2024-06-27() 6:30:25
English 63
This limited warranty covers manufacturing defects in materials or workmanship encountered in normal
household, noncommercial use of this product and shall not cover the following: damage that occurs in
shipment, delivery, installation, and uses for which this product was not intended; damage caused by
unauthorized modification or alteration of the product; product where the original factory serial numbers
have been removed, defaced, changed in any way, or cannot be readily determined; cosmetic damage
including scratches, dents, chips, and other damage to the product’s finishes; damage caused by abuse,
misuse, pest infestations, accident, fire, floods, or other acts of nature or God; damage caused by use of
equipment, utilities, services, parts, supplies, accessories, applications, installations, repairs, external
wiring or connectors not supplied or authorized by SAMSUNG; damage caused by incorrect electrical
line current, voltage, fluctuations and surges; damage caused by failure to operate and maintain the
product according to instructions; in-home instruction on how to use your product; and service to correct
installation not in accordance with electrical or plumbing codes or correction of household electrical or
plumbing (i.e., house wiring, fuses, or water inlet hoses). The cost of repair or replacement under these
excluded circumstances shall be the customer’s responsibility.
Visits by an authorized servicer to explain product functions, maintenance or installation are not covered
by this limited warranty. Please contact SAMSUNG at the number below for assistance with any of these
issues.
EXCLUSION OF IMPLIED WARRANTIES
IMPLIED WARRANTIES, INCLUDING THE IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR
A PARTICULAR PURPOSE, ARE LIMITED TO ONE YEAR OR THE SHORTEST PERIOD ALLOWED BY LAW.
Some states do not allow limitations on how long an implied warranty lasts, so the above limitations or
exclusions may not apply to you. This warranty gives you specific rights, and you may also have other rights,
which vary from state to state.
Untitled-2 63 2024-06-27() 6:30:25
LIMITED WARRANTY (U.S.A.)
English64
LIMITATION OF REMEDIES
YOUR SOLE AND EXCLUSIVE REMEDY IS PRODUCT REPAIR, PRODUCT REPLACEMENT, OR REFUND OF
THE PURCHASE PRICE AT SAMSUNG’S OPTION, AS PROVIDED IN THIS LIMITED WARRANTY. SAMSUNG
SHALL NOT BE LIABLE FOR SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES, INCLUDING BUT NOT
LIMITED TO TIME AWAY FROM WORK, HOTELS AND/OR RESTAURANT MEALS, REMODELING EXPENSES,
LOSS OF REVENUE OR PROFITS, FAILURE TO REALIZE SAVINGS OR OTHER BENEFITS REGARDLESS OF
THE LEGAL THEORY ON WHICH THE CLAIM IS BASED, AND EVEN IF SAMSUNG HAS BEEN ADVISED OF
THE POSSIBILITY OF SUCH DAMAGES. Some states do not allow exclusion or limitation of incidental or
consequential damages, so the above limitations or exclusions may not apply to you. This warranty gives
you specific rights, and you may also have other rights, which vary from state to state.
SAMSUNG does not warrant uninterrupted or error-free operation of the product. No warranty or
guarantee given by any other person, firm, or corporation with respect to this product shall be binding on
SAMSUNG.
To obtain warranty service, please contact SAMSUNG at:
Samsung Electronics America, Inc.
85 Challenger Road
Ridgefield Park, NJ 07660
1-800-SAMSUNG (726-7864)
www.samsung.com/us/support
Untitled-2 64 2024-06-27() 6:30:25
English 65
Warranty (CANADA)
SAMSUNG DRYER
LIMITED WARRANTY TO ORIGINAL PURCHASER
This SAMSUNG brand product, as supplied and distributed by SAMSUNG ELECTRONICS CANADA, INC.
(SAMSUNG) and delivered new, in the original carton to the original consumer purchaser, is warranted by
SAMSUNG against manufacturing defects in materials and workmanship for a limited warranty period of:
• One (1) year part and labor
This limited warranty begins on the original date of purchase, and is valid only on products purchased and
used in the Canada.
To receive warranty service, the purchaser must contact SAMSUNG for problem determination and service
procedures.
Warranty service can only be performed by a SAMSUNG authorized service center.
The original dated bill of sale must be presented upon request as proof of purchase to SAMSUNG or
SAMSUNG’s authorized service center.
SAMSUNG will provide in-home service during the warranty period at no charge, subject to availability
within the Canada.
In-home service is not available in all areas.
To receive in-home service, product must be unobstructed and accessible to the service agent.
If service is not available, SAMSUNG may elect to provide transportation of the product to and from an
authorized service center.
SAMSUNG will repair, replace, or refund this product at our option and at no charge as stipulated herein,
with new or reconditioned parts or products if found to be defective during the limited warranty period
specified above.
All replaced parts and products become the property of SAMSUNG and must be returned to SAMSUNG.
Replacement parts and products assume the remaining original warranty, or ninety (90) days, whichever is
longer.
This limited warranty covers manufacturing defects in materials and workmanship encountered in normal,
noncommercial use of this product and shall not apply to the following: damage that occurs in shipment;
delivery and installation; applications and uses for which this product was not intended; altered product
or serial numbers; cosmetic damage or exterior finish; accidents, abuse, neglect, fire, water, lightning,
or other acts of nature or God; use of products, equipment, systems, utilities, services, parts, supplies,
accessories, applications, installations, repairs, external wiring or connectors not supplied or authorized
by SAMSUNG that damage this product or result in service problems; incorrect electrical line voltage,
fluctuations and surges; customer adjustments and failure to follow operating instructions, maintenance
and environmental instructions that are covered and prescribed in the instruction book; product removal
and reinstallation; problems caused by pest infestations.
This limited warranty does not cover problems resulting from incorrect electric current, voltage or supply,
light bulbs, house fuses, house wiring, cost of a service call for instructions, or fixing installation errors.
SAMSUNG does not warrant uninterrupted or error-free operation of the product.
Untitled-2 65 2024-06-27() 6:30:25
Warranty (CANADA)
English66
EXCEPT AS SET FORTH HEREIN, THERE ARE NO WARRANTIES ON THIS PRODUCT EITHER EXPRESS OR
IMPLIED, AND SAMSUNG DISCLAIMS ALL WARRANTIES INCLUDING, BUT NOT LIMITED TO, ANY IMPLIED
WARRANTIES OF MERCHANTABILITY, INFRINGEMENT OR FITNESS FOR A PARTICULAR PURPOSE.
NO WARRANTY OR GUARANTEE GIVEN BY ANY PERSON, FIRM, OR CORPORATION WITH RESPECT TO THIS
PRODUCT SHALL BE BINDING ON SAMSUNG.
SAMSUNG SHALL NOT BE LIABLE FOR LOSS OF REVENUE OR PROFITS, FAILURE TO REALIZE SAVINGS OR
OTHER BENEFITS, OR ANY OTHER SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES CAUSED BY THE
USE, MISUSE, OR INABILITY TO USE THIS PRODUCT, REGARDLESS OF THE LEGAL THEORY ON WHICH THE
CLAIM IS BASED, AND EVEN IF SAMSUNG HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.
NOR SHALL RECOVERY OF ANY KIND AGAINST SAMSUNG BE GREATER IN AMOUNT THAN THE PURCHASE
PRICE OF THE PRODUCT SOLD BY SAMSUNG AND CAUSING THE ALLEGED DAMAGE.
WITHOUT LIMITING THE FOREGOING, PURCHASER ASSUMES ALL RISK AND LIABILITY FOR LOSS, DAMAGE,
OR INJURY TO PURCHASER AND PURCHASER’S PROPERTY AND TO OTHERS AND THEIR PROPERTY
ARISING OUT OF THE USE, MISUSE, OR INABILITY TO USE THIS PRODUCT.
THIS LIMITED WARRANTY SHALL NOT EXTEND TO ANYONE OTHER THAN THE ORIGINAL PURCHASER OF
THIS PRODUCT, IS NONTRANSFERABLE AND STATES YOUR EXCLUSIVE REMEDY.
Some provinces do not allow limitations on how long an implied warranty lasts, or the exclusion or
limitation of incidental or consequential damages, so the above limitations or exclusions may not apply to
you.
This warranty gives you specific rights, and you may also have other rights, which vary from province to
province.
To obtain warranty service, please contact SAMSUNG at:
Samsung Electronics Canada Inc.
2050 Derry Road West,
Mississauga, Ontario L5N 0B9 Canada
1-800-SAMSUNG (726-7864)
www.samsung.com/ca/support (English)
www.samsung.com/ca_fr/support (French)
Visits by a Service Engineer to explain functions, maintenance, or installation is not covered by warranty.
Please contact the Samsung call center at the number above for help with any of these issues.
Untitled-2 66 2024-06-27() 6:30:25
Memo
Untitled-2 67 2024-06-27() 6:30:25
Scan this with your smartphone
This product qualifies for ENERGY STAR in the factory default
"NORMAL" setting.
If you change the factory default setting or enable other features,
power consumption could increase and exceed the limits qualified
for ENERGY STAR.
QUESTIONS OR COMMENTS?
COUNTRY CALL OR VISIT US ONLINE AT
U.S.A 1-800-SAMSUNG (726-7864) www.samsung.com/us/support
CANADA 1-800-Samsung (726-7864)
www.samsung.com/ca/support (English)
www.samsung.com/ca_fr/support (French)
Untitled-2 68 2024-06-27() 6:30:25
