Dreame L10S PRO ULTRA HEAT Robot Vacuums User Manual

The illustrations in this manual are for reference only. Please refer to the actual product.

Robot Vacuum and Mop

with Auto-Empty and Mop Self-Cleaning

User Manual

For more support, contact us via https://global.dreametech.com

Manufactured by: Dreame Trading (Tianjin) Co., Ltd.

Made in China

The word "dreame" is the abbreviation of Dreame Technology Co., Ltd. and its subsidiaries in China. It is the transliteration of the company's Chinese name " ",

which means striving for excellence in every endeavor and reflects the company's vision of continuous pursuit, exploration and search in technology.

RLL82CE-EU-S00

Contents

001User Manual

028Benutzerhandbuch

056Manuel d'utilisation

083Manuale utente

110Manual de usuario

137Руководство пользователя

165Instrukcja obsługi

193Gebruikershandleiding

220Brukerhåndbok

247Användarmanual

Safety Information

· This product should not be used by children younger than 8 years old nor

persons with physical, sensory, intellectual deficiencies, or limited experience

or knowledge without the supervision of a parent or guardian to ensure safe

operation and to avoid any risks. Cleaning and maintenance shall not be

performed by children without supervision.

· The appliance is only to be used with the power supply unit provided with the

appliance.

· This appliance contains batteries that are only replaceable by skilled persons.

· Clear the area to be cleaned. Children shall not play with the appliance.

Ensure children and pets are kept at a safe distance from the robot while it is

operating.

· Do not install, charge or use the appliance in the bathrooms or around the

pools.

· This product is for floor cleaning in a home environment only. Do not use it

outdoors, on non-floor surfaces, or in a commercial or industrial setting.

· Ensure that the appliance operates correctly in a proper environment.

Otherwise, do not use the appliance.

· If the power cord is damaged, it must be replaced by a special cord or

assembly available from the manufacturer or its service agent.

· Do not use the robot in an area suspended above ground level without a

protective barrier.

To avoid electric shock, fire or injury caused by improper use of the appliance, please read the user

manual carefully before using the appliance and keep it for future reference.

Usage Restrictions

Contents

001User Manual

028Benutzerhandbuch

056Manuel d'utilisation

083Manuale utente

110Manual de usuario

137Руководство пользователя

165Instrukcja obsługi

193Gebruikershandleiding

220Brukerhåndbok

247Användarmanual

Safety Information

· This product should not be used by children younger than 8 years old nor

persons with physical, sensory, intellectual deficiencies, or limited experience

or knowledge without the supervision of a parent or guardian to ensure safe

operation and to avoid any risks. Cleaning and maintenance shall not be

performed by children without supervision.

· The appliance is only to be used with the power supply unit provided with the

appliance.

· This appliance contains batteries that are only replaceable by skilled persons.

· Clear the area to be cleaned. Children shall not play with the appliance.

Ensure children and pets are kept at a safe distance from the robot while it is

operating.

· Do not install, charge or use the appliance in the bathrooms or around the

pools.

· This product is for floor cleaning in a home environment only. Do not use it

outdoors, on non-floor surfaces, or in a commercial or industrial setting.

· Ensure that the appliance operates correctly in a proper environment.

Otherwise, do not use the appliance.

· If the power cord is damaged, it must be replaced by a special cord or

assembly available from the manufacturer or its service agent.

· Do not use the robot in an area suspended above ground level without a

protective barrier.

To avoid electric shock, fire or injury caused by improper use of the appliance, please read the user

manual carefully before using the appliance and keep it for future reference.

Usage Restrictions

2 3

ENEN

Safety InformationSafety Information

· Do not vacuum hard or sharp objects. Do not use the appliance to pick up

objects such as stones, large pieces of paper or any item that may clog the

appliance.

· Plug must be removed from the socket-outlet before cleaning or maintaining

the appliance.

· Do not wipe the robot or the base station with a wet cloth or rinse them

with any liquid. After cleaning washable parts, fully dry the parts before

reinstalling and using them.

· Please use this product in accordance with the instructions in the User Manual.

Users are responsible for any loss or damage that arise from improper use of

this product.

· Do not use any third-party battery or base station. The robot can only be used

with the model RCLE0301 base station.

· Do not attempt to disassemble, repair, or modify the battery or the base

station on your own.

· Do not place the base station near a heat source.

· Do not use a wet cloth or wet hands to wipe or clean the base station's

charging contacts.

· Do not improperly dispose of old batteries. Unneeded batteries should be

discarded at an appropriate recycling facility.

· If the power cord becomes damaged or broken, stop using it immediately and

contact after-sales service.

· Do not place the robot upside down. Do not use the LDS cover, robot cover, or

bumper as a handle for the robot.

· Do not use the robot at an ambient temperature above 40°C or below 0°C or

on a floor with liquids or sticky substances.

· To prevent damage or harm from dragging, clear any loose objects from

the floor, and remove cables or power cords on the cleaning path before

operating the appliance.

· Remove fragile or small items from the floor to prevent the robot from

bumping into and damaging them.

· Keep hair, fingers, and other body parts away from the suction opening of the

robots.

· Keep the cleaning tool out of reach of children.

· Do not operate the appliance in a room where an infant or child is sleeping.

· Do not place children, pets, or any item on top of the robot regardless of

whether it is stationary or moving.

· Keep the cleaning solution out of reach of children.

· Use only the officially-approved detergent. Do not add any liquid such as

alcohol or disinfectant.

· Do not use the robot to clean any burning objects. Do not use the robot to pick

up flammable or combustible liquids, corrosive gases, or undiluted acids or

solvents.

Usage Restrictions

Batteries and

Charging

Usage Restrictions

2 3

ENEN

Safety InformationSafety Information

· Do not vacuum hard or sharp objects. Do not use the appliance to pick up

objects such as stones, large pieces of paper or any item that may clog the

appliance.

· Plug must be removed from the socket-outlet before cleaning or maintaining

the appliance.

· Do not wipe the robot or the base station with a wet cloth or rinse them

with any liquid. After cleaning washable parts, fully dry the parts before

reinstalling and using them.

· Please use this product in accordance with the instructions in the User Manual.

Users are responsible for any loss or damage that arise from improper use of

this product.

· Do not use any third-party battery or base station. The robot can only be used

with the model RCLE0301 base station.

· Do not attempt to disassemble, repair, or modify the battery or the base

station on your own.

· Do not place the base station near a heat source.

· Do not use a wet cloth or wet hands to wipe or clean the base station's

charging contacts.

· Do not improperly dispose of old batteries. Unneeded batteries should be

discarded at an appropriate recycling facility.

· If the power cord becomes damaged or broken, stop using it immediately and

contact after-sales service.

· Do not place the robot upside down. Do not use the LDS cover, robot cover, or

bumper as a handle for the robot.

· Do not use the robot at an ambient temperature above 40°C or below 0°C or

on a floor with liquids or sticky substances.

· To prevent damage or harm from dragging, clear any loose objects from

the floor, and remove cables or power cords on the cleaning path before

operating the appliance.

· Remove fragile or small items from the floor to prevent the robot from

bumping into and damaging them.

· Keep hair, fingers, and other body parts away from the suction opening of the

robots.

· Keep the cleaning tool out of reach of children.

· Do not operate the appliance in a room where an infant or child is sleeping.

· Do not place children, pets, or any item on top of the robot regardless of

whether it is stationary or moving.

· Keep the cleaning solution out of reach of children.

· Use only the officially-approved detergent. Do not add any liquid such as

alcohol or disinfectant.

· Do not use the robot to clean any burning objects. Do not use the robot to pick

up flammable or combustible liquids, corrosive gases, or undiluted acids or

solvents.

Usage Restrictions

Batteries and

Charging

Usage Restrictions

4 5

ENEN

Safety Information Product Overview

Package Contents

· Make sure the robot is turned off when being transported and kept in its

original packaging if possible.

· If the robot will not be used for an extended period of time, fully charge it,

then turn it off and store it in a cool, dry place. Recharge the robot at least

once every 3 months to avoid over-discharging the battery.

Hereby, Dreame Trading(Tianjin)Co., Ltd. declares that the radio equipment type RLL82CE is in compliance with Directive 2014/53/EU. The full text of the EU

declaration of conformity is available at the following internet address: https://global.dreametech.com

For detailed e-manual, please go to https://global.dreametech.com/pages/user-manuals-and-faqs

· The laser sensor in this product meets the IEC 60825-1:2014/EN 60825-

1:2014/A11:2021 Standard for Class 1 laser products. Please avoid direct eye

contact with it during use.

CLASS 1 LASER PRODUCT

CONSUMER LASER PRODUCT

EN 50689:2021

Batteries and

Charging

Laser Safety

Information

Other Accessories

Side Brush

Mop Pad

(pre-installed)

Robot

Mop Pad Holder

Power Cord

Cleaning ToolCleaning

Solution

Dust Bag

(1 pre-installed)

Base Station Ramp

Extension Plate

User Manual

Base Station

×2 ×2×2

4 5

ENEN

Safety Information Product Overview

Package Contents

· Make sure the robot is turned off when being transported and kept in its

original packaging if possible.

· If the robot will not be used for an extended period of time, fully charge it,

then turn it off and store it in a cool, dry place. Recharge the robot at least

once every 3 months to avoid over-discharging the battery.

Hereby, Dreame Trading(Tianjin)Co., Ltd. declares that the radio equipment type RLL82CE is in compliance with Directive 2014/53/EU. The full text of the EU

declaration of conformity is available at the following internet address: https://global.dreametech.com

For detailed e-manual, please go to https://global.dreametech.com/pages/user-manuals-and-faqs

· The laser sensor in this product meets the IEC 60825-1:2014/EN 60825-

1:2014/A11:2021 Standard for Class 1 laser products. Please avoid direct eye

contact with it during use.

CLASS 1 LASER PRODUCT

CONSUMER LASER PRODUCT

EN 50689:2021

Batteries and

Charging

Laser Safety

Information

Other Accessories

Side Brush

Mop Pad

(pre-installed)

Robot

Mop Pad Holder

Power Cord

Cleaning ToolCleaning

Solution

Dust Bag

(1 pre-installed)

Base Station Ramp

Extension Plate

User Manual

Base Station

×2 ×2×2

6 7

ENEN

Robot Robot and Sensors

Product Overview Product Overview

Spot Cleaning Button

· Press to start spot cleaning

Power / Clean Button

· Press and hold for 3 seconds to turn on or o

· Press to start cleaning after the robot is turned on

Dock Button

· Press to send the robot back to the base station

· Press and hold for 3 seconds to disable Child Lock

Status Indicator

· Solid White: Cleaning or cleanup completed

· Blinking Orange: Error

· Solid Orange: Standby at low battery or paused at low battery

Note:

·Press any button on the robot to pause while the robot is cleaning

or returning to charge.

·Child Lock can be turned on and o through the Dreamehome App.

Cli Sensors

Main Wheel

Main Brush

Omnidirectional

Wheel

Brush Guard

Main Wheel

Brush Guard Clips

Mop Pad Holder

Mounting Holes

Side Brush

Carpet Sensor

LDS Cover

Microphone

Laser Distance Sensor (LDS)

Bumper

AI Visual Sensor

Camera Indicator

(The camera indicator will light up

when the camera is activated)

Press and hold for 3

seconds to restore to

factory settings

Line Laser Sensors

Dust Box

Filter

Filter Handle

Dust Outlet

Dust Box Cover Clip

Dust Box Clip

Dust Box Cover

Air Inlet

Mop Assembly

Mop Pad

Attachment Area

Mop Pad Holder Mop Pad

Cover

Charging

Contacts

Connectors

Automatic Water

Refilling Inlet

Reset Button

Wi-Fi Indicator

Edge Sensor

Auto-empty

Vent

MopExtend

Assembly

6 7

ENEN

Robot Robot and Sensors

Product Overview Product Overview

Spot Cleaning Button

· Press to start spot cleaning

Power / Clean Button

· Press and hold for 3 seconds to turn on or o

· Press to start cleaning after the robot is turned on

Dock Button

· Press to send the robot back to the base station

· Press and hold for 3 seconds to disable Child Lock

Status Indicator

· Solid White: Cleaning or cleanup completed

· Blinking Orange: Error

· Solid Orange: Standby at low battery or paused at low battery

Note:

·Press any button on the robot to pause while the robot is cleaning

or returning to charge.

·Child Lock can be turned on and o through the Dreamehome App.

Cli Sensors

Main Wheel

Main Brush

Omnidirectional

Wheel

Brush Guard

Main Wheel

Brush Guard Clips

Mop Pad Holder

Mounting Holes

Side Brush

Carpet Sensor

LDS Cover

Microphone

Laser Distance Sensor (LDS)

Bumper

AI Visual Sensor

Camera Indicator

(The camera indicator will light up

when the camera is activated)

Press and hold for 3

seconds to restore to

factory settings

Line Laser Sensors

Dust Box

Filter

Filter Handle

Dust Outlet

Dust Box Cover Clip

Dust Box Clip

Dust Box Cover

Air Inlet

Mop Assembly

Mop Pad

Attachment Area

Mop Pad Holder Mop Pad

Cover

Charging

Contacts

Connectors

Automatic Water

Refilling Inlet

Reset Button

Wi-Fi Indicator

Edge Sensor

Auto-empty

Vent

MopExtend

Assembly

8 9

ENEN

Product Overview Preparing Your Home

Base Station

Filter

Auto-Detergent

Compartment

Slot

Washboard

Upper Cover

Clean Water Tank

Used Water Tank

Auto-empty Vent

Water Tank Clip

Water Tank

Clip

Float Ball

Water Pipe

Filter

Used Water Tank Clean Water Tank

Floater

Reserved Slot for Connecting

the Water Hookup Kit for

Auto Refilling and Draining

Power Cord Holder

Power Port

Dust Tank

Cover

Status Indicator

Solid white: The base station is

connected to power

Solid Orange: The base station

has an error

Signaling Area

Charging Contacts

Automatic Water Adding

Outlet

Note: The water hookup kit for auto refilling and draining needs to be purchased separately. (Only available in specific regions)

Before cleaning, please move away unstable, fragile, valuable or dangerous items,

and clean up cables, cloths, toys, hard objects and sharp objects on the ground to

avoid being entangled, scratched or knocked over by the robot and causing losses.

Open the door of the room to be cleaned, and put the furniture in its proper

place to leave more space.

With the AI visual sensor, the robot can better recognize and avoid obstacles

such as power cords, shoes, and socks, to get the most out of the AI visual

sensor, make sure that all areas to be cleaned are well-lit.

Before cleaning, place a physical barrier at the edge of the stairs and sofa to

ensure the secure and smooth operations of the robot.

Note:

·When operating the robot for the first time, follow it around while cleaning to remove any potential obstacles in time.

·To prevent the robot from not recognizing areas that need to be cleaned, do not stand in front of the robot, threshold, hallway, or narrow places.

·Do not vacuum hard objects like stones, steel balls and toy parts, or sharp objects like construction waste, broken glass and nails, otherwise the ground may be

scratched.

Ramp Extension

Plate

8 9

ENEN

Product Overview Preparing Your Home

Base Station

Filter

Auto-Detergent

Compartment

Slot

Washboard

Upper Cover

Clean Water Tank

Used Water Tank

Auto-empty Vent

Water Tank Clip

Water Tank

Clip

Float Ball

Water Pipe

Filter

Used Water Tank Clean Water Tank

Floater

Reserved Slot for Connecting

the Water Hookup Kit for

Auto Refilling and Draining

Power Cord Holder

Power Port

Dust Tank

Cover

Status Indicator

Solid white: The base station is

connected to power

Solid Orange: The base station

has an error

Signaling Area

Charging Contacts

Automatic Water Adding

Outlet

Note: The water hookup kit for auto refilling and draining needs to be purchased separately. (Only available in specific regions)

Before cleaning, please move away unstable, fragile, valuable or dangerous items,

and clean up cables, cloths, toys, hard objects and sharp objects on the ground to

avoid being entangled, scratched or knocked over by the robot and causing losses.

Open the door of the room to be cleaned, and put the furniture in its proper

place to leave more space.

With the AI visual sensor, the robot can better recognize and avoid obstacles

such as power cords, shoes, and socks, to get the most out of the AI visual

sensor, make sure that all areas to be cleaned are well-lit.

Before cleaning, place a physical barrier at the edge of the stairs and sofa to

ensure the secure and smooth operations of the robot.

Note:

·When operating the robot for the first time, follow it around while cleaning to remove any potential obstacles in time.

·To prevent the robot from not recognizing areas that need to be cleaned, do not stand in front of the robot, threshold, hallway, or narrow places.

·Do not vacuum hard objects like stones, steel balls and toy parts, or sharp objects like construction waste, broken glass and nails, otherwise the ground may be

scratched.

Ramp Extension

Plate

10 11

ENEN

3. Connect to an Electrical Outlet 5. Place the Robot

6. Add the Cleaning Solution

7. Add Water to the Clean Water Tank

Before Use Before Use

Place the base station in a location that is as open as possible with a good Wi-

Fi signal. Then insert the power cord into the base station and plug it into the

socket.

Place the Base Station and remove any objects that are closer than 1.5 m

from the front and 5cm from either side of the base station. Then install the

ramp extension plate down to the base station.

Side Brush

Clip

Firmly insert the power

cord upwards until the

indicator turns on.

I:ON

O:OFF

1. Remove the Protections

4. Place the Base Station and Install the Base Station Ramp

Extension Plate

2. Install the Side Brush and the Mop Assembly

Note: Install the side brush until it clicks into place.

Note: To prevent water stains from wetting wood floors or carpets, placing

the base station on tile floors or marble floors is recommended.

Note: It is recommended to fully charge the robot before its first use. When

the robot cannot be turned on after the battery is depleted, manually

connect the robot with the station to charge it.

Note: Do not add hot water into the water tank, as this may cause the tank

to become deformed.

Press and hold the button on the robot for 3 seconds to turn it on. Place

the robot onto the base station with the mop assembly facing toward

the washboard. Then you will hear a voice notification when the robot

successfully connects to the base station. After the robot is fully charged,

the status indicators on the robot and the base station will remain lit for 10

minutes and will then dim.

(1) Remove the dust tank cover and pull out the auto-detergent

compartment.

(2) Open the upper lid of the compartment and add the cleaning solution.

(3) Close the lid of the compartment, put it back it into the base station, and

then reinstall the dust tank cover. The cleaning solution will be added into

the clean water tank automatically while working.

Take out the clean water tank from the base station and add clean water into

the tank. Then install it back into the base station.

Note:

·Do not add any liquid other than the ocially-approved cleaning solution

to help prevent malfunction.

·Install the auto-detergent compartment until it clicks into place.

10 11

ENEN

3. Connect to an Electrical Outlet 5. Place the Robot

6. Add the Cleaning Solution

7. Add Water to the Clean Water Tank

Before Use Before Use

Place the base station in a location that is as open as possible with a good Wi-

Fi signal. Then insert the power cord into the base station and plug it into the

socket.

Place the Base Station and remove any objects that are closer than 1.5 m

from the front and 5cm from either side of the base station. Then install the

ramp extension plate down to the base station.

Side Brush

Clip

Firmly insert the power

cord upwards until the

indicator turns on.

I:ON

O:OFF

1. Remove the Protections

4. Place the Base Station and Install the Base Station Ramp

Extension Plate

2. Install the Side Brush and the Mop Assembly

Note: Install the side brush until it clicks into place.

Note: To prevent water stains from wetting wood floors or carpets, placing

the base station on tile floors or marble floors is recommended.

Note: It is recommended to fully charge the robot before its first use. When

the robot cannot be turned on after the battery is depleted, manually

connect the robot with the station to charge it.

Note: Do not add hot water into the water tank, as this may cause the tank

to become deformed.

Press and hold the button on the robot for 3 seconds to turn it on. Place

the robot onto the base station with the mop assembly facing toward

the washboard. Then you will hear a voice notification when the robot

successfully connects to the base station. After the robot is fully charged,

the status indicators on the robot and the base station will remain lit for 10

minutes and will then dim.

(1) Remove the dust tank cover and pull out the auto-detergent

compartment.

(2) Open the upper lid of the compartment and add the cleaning solution.

(3) Close the lid of the compartment, put it back it into the base station, and

then reinstall the dust tank cover. The cleaning solution will be added into

the clean water tank automatically while working.

Take out the clean water tank from the base station and add clean water into

the tank. Then install it back into the base station.

Note:

·Do not add any liquid other than the ocially-approved cleaning solution

to help prevent malfunction.

·Install the auto-detergent compartment until it clicks into place.

12 13

ENEN

Connecting with the Dreamehome App How to Use

Wi-Fi Indicator

· Blinking slowly: To be connected

· Blinking quickly: Connecting

· On: Connected

QR Code

1. Download the Dreamehome App 2. Add Device

Scan the QR code on the robot, or search "Dreamehome" in the app store to

download and install the app.

Open the Dreamehome app, tap " " in the upper right corner, and scan the

same QR code on the robot again to add the device. Please follow the prompts

to finish the Wi-Fi connection.

Note:

·Only 2.4 GHz Wi-Fi is supported.

·Due to upgrades in the app software, the actual operations may dier from

the directions in this manual. Please follow the instructions based on the

current app version.

Note:

·The robot will turn o automatically if it is left in the sleep mode for more

than 12 hours.

·If the robot is paused and placed onto the base station, the current cleaning

process will end.

Note:

·The scheduled cleaning tasks will be performed on time during the DND

period.

·The robot will resume cleanup where it left o after the DND period expires.

Note: If you want to reset Wi-Fi, repeat step 2 and then follow the prompts to

finish the Wi-Fi connection.

Fast Mapping

Do Not Disturb (DND) Mode

Spot Cleaning

Robot Restarting

Turn On/O

Pause/Sleep

After configuring the network for the first time, follow the instructions on

the app to quickly create a map, and the robot will start mapping without

cleaning. The mapping process will be completed when the robot returns to

the station, and the map will be saved automatically.

When the robot is set to the Do Not Disturb (DND) mode, the robot will be

prevented from resuming cleaning and the power indicator goes out. The

DND mode is disabled by default at the factory. You can use the app to

enable the DND mode or modify the DND period. The DND period is 22:00-

8:00 by default.

When the robot is on standby, press briefly the button to enable the spot

cleaning mode. In this mode, the robot cleans a square-shaped area of 1.5 ×

1.5 meters around it and returns to its starting point once the spot cleaning is

completed.

If the robot stops responding or cannot be turned o, press and hold the

button for 10 seconds to forcefully turn it o. Then, press and hold the

button for 3 seconds to turn the robot on.

Press and hold the button for 3 seconds to turn on the robot. The power

indicator should be illuminated. Place the robot onto the base, the robot

should turn on automatically and begin charging. To turn o the robot,

move the robot away from the base and press and hold the button for 3

seconds.

When the robot is running, press any button to pause it.

If the robot is paused for more than 10 minutes, it automatically enters sleep

mode. The power indicator and charging indicator will turn o. Press any

button on the robot, or use the app to wake up the robot.

Note: To use this function, please open it in the app.

Auto Resume Cleaning

If the battery is too low, the robot will automatically return to the base

station to charge. After charging to the appropriate battery level, it will

resume unfinished cleaning tasks.

12 13

ENEN

Connecting with the Dreamehome App How to Use

Wi-Fi Indicator

· Blinking slowly: To be connected

· Blinking quickly: Connecting

· On: Connected

QR Code

1. Download the Dreamehome App 2. Add Device

Scan the QR code on the robot, or search "Dreamehome" in the app store to

download and install the app.

Open the Dreamehome app, tap " " in the upper right corner, and scan the

same QR code on the robot again to add the device. Please follow the prompts

to finish the Wi-Fi connection.

Note:

·Only 2.4 GHz Wi-Fi is supported.

·Due to upgrades in the app software, the actual operations may dier from

the directions in this manual. Please follow the instructions based on the

current app version.

Note:

·The robot will turn o automatically if it is left in the sleep mode for more

than 12 hours.

·If the robot is paused and placed onto the base station, the current cleaning

process will end.

Note:

·The scheduled cleaning tasks will be performed on time during the DND

period.

·The robot will resume cleanup where it left o after the DND period expires.

Note: If you want to reset Wi-Fi, repeat step 2 and then follow the prompts to

finish the Wi-Fi connection.

Fast Mapping

Do Not Disturb (DND) Mode

Spot Cleaning

Robot Restarting

Turn On/O

Pause/Sleep

After configuring the network for the first time, follow the instructions on

the app to quickly create a map, and the robot will start mapping without

cleaning. The mapping process will be completed when the robot returns to

the station, and the map will be saved automatically.

When the robot is set to the Do Not Disturb (DND) mode, the robot will be

prevented from resuming cleaning and the power indicator goes out. The

DND mode is disabled by default at the factory. You can use the app to

enable the DND mode or modify the DND period. The DND period is 22:00-

8:00 by default.

When the robot is on standby, press briefly the button to enable the spot

cleaning mode. In this mode, the robot cleans a square-shaped area of 1.5 ×

1.5 meters around it and returns to its starting point once the spot cleaning is

completed.

If the robot stops responding or cannot be turned o, press and hold the

button for 10 seconds to forcefully turn it o. Then, press and hold the

button for 3 seconds to turn the robot on.

Press and hold the button for 3 seconds to turn on the robot. The power

indicator should be illuminated. Place the robot onto the base, the robot

should turn on automatically and begin charging. To turn o the robot,

move the robot away from the base and press and hold the button for 3

seconds.

When the robot is running, press any button to pause it.

If the robot is paused for more than 10 minutes, it automatically enters sleep

mode. The power indicator and charging indicator will turn o. Press any

button on the robot, or use the app to wake up the robot.

Note: To use this function, please open it in the app.

Auto Resume Cleaning

If the battery is too low, the robot will automatically return to the base

station to charge. After charging to the appropriate battery level, it will

resume unfinished cleaning tasks.

14 15

ENEN

How to Use How to Use

Vacuum and Mop

2. Auto mop washing

Vacuum Only

Mop Only

3. Automatically empty the dust box and wash and dry the mop pads after

finishing the "Vacuum and Mop" task

1. Start cleaning

Note: When using the mop assembly for the first time, the robot performs the

"Vacuum and Mop" task by default.

When cleaning, the robot will automatically return to the base station to wash

mop pads based on the mop pad cleaning frequency specified in the app. The

base station will automatically refill the robot's water tank and the robot will

resume cleanup.

Vacuum then Mop

Select "Vacuum then Mop" in the app, and the robot will automatically lift the

mop assembly to vacuum the floor. After vacuuming is completed, the robot

will return to empty the dust box, and then start mopping after automatically

lowering the mop assembly.

Select “Vacuum Only” in the app and the robot will automatically lift the mop

assembly and start vacuuming.

Select "Mop Only" in the app, and the robot will check if the mop assembly is

installed. If not, manually install the mop assembly, and then the robot will

automatically start mopping.

4. Clean the used water tank

After the robot has completed the task, please clean the used water tank to

avoid any odor.

After the robot finishes a cleaning task and returns to the base station to charge,

the base station will automatically start emptying the dust box, and then clean

and dry the mop pads.

Press the button

on the robot, or use the app to make the robot start from the

base station. Then the robot will plan the optimal cleaning route and perform

the cleaning task based on the created map.

Note:

·The mop pads will be cleaned before the robot starts mopping, please wait

patiently.

·Do not move the base station, the clean water tank, the used water tank, or

the washboard during its working.

·Hot water cleaning can be enabled in the app for mop pad and base station

cleaning tasks, which applies to all modes. To prevent scalding, do not

touch the water outlet of the washboard when the function is on.

Note:

·If the auto-empty function is turned o in the app, the base station will not

automatically empty the dust box.

·The base station will empty the dust box according to the frequency set in

the app.

Note: If the robot returns to the base station to wash its mop pads during

cleaning, the base station will not automatically empty the dust box.

14 15

ENEN

How to Use How to Use

Vacuum and Mop

2. Auto mop washing

Vacuum Only

Mop Only

3. Automatically empty the dust box and wash and dry the mop pads after

finishing the "Vacuum and Mop" task

1. Start cleaning

Note: When using the mop assembly for the first time, the robot performs the

"Vacuum and Mop" task by default.

When cleaning, the robot will automatically return to the base station to wash

mop pads based on the mop pad cleaning frequency specified in the app. The

base station will automatically refill the robot's water tank and the robot will

resume cleanup.

Vacuum then Mop

Select "Vacuum then Mop" in the app, and the robot will automatically lift the

mop assembly to vacuum the floor. After vacuuming is completed, the robot

will return to empty the dust box, and then start mopping after automatically

lowering the mop assembly.

Select “Vacuum Only” in the app and the robot will automatically lift the mop

assembly and start vacuuming.

Select "Mop Only" in the app, and the robot will check if the mop assembly is

installed. If not, manually install the mop assembly, and then the robot will

automatically start mopping.

4. Clean the used water tank

After the robot has completed the task, please clean the used water tank to

avoid any odor.

After the robot finishes a cleaning task and returns to the base station to charge,

the base station will automatically start emptying the dust box, and then clean

and dry the mop pads.

Press the button

on the robot, or use the app to make the robot start from the

base station. Then the robot will plan the optimal cleaning route and perform

the cleaning task based on the created map.

Note:

·The mop pads will be cleaned before the robot starts mopping, please wait

patiently.

·Do not move the base station, the clean water tank, the used water tank, or

the washboard during its working.

·Hot water cleaning can be enabled in the app for mop pad and base station

cleaning tasks, which applies to all modes. To prevent scalding, do not

touch the water outlet of the washboard when the function is on.

Note:

·If the auto-empty function is turned o in the app, the base station will not

automatically empty the dust box.

·The base station will empty the dust box according to the frequency set in

the app.

Note: If the robot returns to the base station to wash its mop pads during

cleaning, the base station will not automatically empty the dust box.

16 17

ENEN

Routine Maintenance Routine Maintenance

Part Maintenance Frequency

Replacement

Period

Used Water Tank After each use

Clean Water Tank

Once every 2 weeks

Main brush

Every 6 to 12

months

Dust box's filter

Every 3 to 6

months

Side brush

Washboard

Once every month /

Base station's

signaling area

Base station's

charging contacts

Base station's auto-

empty vent

Omnidirectional

wheel

Edge sensor

Laser Distance

Sensor (LDS)

Line laser sensor

Part Maintenance Frequency

Replacement

Period

AI Visual Sensor

Once every month

Carpet Sensor

Cli Sensors

Robot's charging

contacts

Bumper

Robot's auto-empty

vent

Robot's automatic

water refilling inlet

Bottom of the robot

Dust box Clean it as needed

Dust bag

6-8 weeks

Mop pad

Every 1 to 3

months

Parts

To keep the robot in good condition, it is recommended to refer to the accessory usage in the app or the following table for routine maintenance.

Base Station Cleaning

1. Select "Base Station Cleaning" in the app, and the robot will exit the base

station automatically. Take out the washboard and wait for water to fill the

bottom of the base station.

3. After a moment, the base station will automatically pump out the used

water. Then dry it with a soft and dry cloth, and put the washboard back into

place.

2. Rinse the washboard with clean water, and use the cleaning tool to clean

the bottom of the base station.

4. Use the app or briefly press the button on the robot to make it return to

the base station.

Note: During cleaning, do not make the robot return to the base station.

Note: The replacement frequency will depend on your usage of the robot.

If an exception occurs due to special circumstances, the parts should be

replaced.

16 17

ENEN

Routine Maintenance Routine Maintenance

Part Maintenance Frequency

Replacement

Period

Used Water Tank After each use

Clean Water Tank

Once every 2 weeks

Main brush

Every 6 to 12

months

Dust box's filter

Every 3 to 6

months

Side brush

Washboard

Once every month /

Base station's

signaling area

Base station's

charging contacts

Base station's auto-

empty vent

Omnidirectional

wheel

Edge sensor

Laser Distance

Sensor (LDS)

Line laser sensor

Part Maintenance Frequency

Replacement

Period

AI Visual Sensor

Once every month

Carpet Sensor

Cli Sensors

Robot's charging

contacts

Bumper

Robot's auto-empty

vent

Robot's automatic

water refilling inlet

Bottom of the robot

Dust box Clean it as needed

Dust bag

6-8 weeks

Mop pad

Every 1 to 3

months

Parts

To keep the robot in good condition, it is recommended to refer to the accessory usage in the app or the following table for routine maintenance.

Base Station Cleaning

1. Select "Base Station Cleaning" in the app, and the robot will exit the base

station automatically. Take out the washboard and wait for water to fill the

bottom of the base station.

3. After a moment, the base station will automatically pump out the used

water. Then dry it with a soft and dry cloth, and put the washboard back into

place.

2. Rinse the washboard with clean water, and use the cleaning tool to clean

the bottom of the base station.

4. Use the app or briefly press the button on the robot to make it return to

the base station.

Note: During cleaning, do not make the robot return to the base station.

Note: The replacement frequency will depend on your usage of the robot.

If an exception occurs due to special circumstances, the parts should be

replaced.

18 19

ENEN

Routine Maintenance

Dust Bag Used Water Tank Main Brush

1. Discard the dust bag. 1. Remove the used water tank, open its cover and pour out the used water. 1. Press the brush guard clips inwards to remove the brush guard and lift the

brush out of the robot.

2. Pull out the brush covers at both ends of the brush as shown in the figure.

Use the provided cleaning tool to remove the hair tangled in the brush.

2. Rinse the used water tank with clean water, and use the provided cleaning

tool to clean the inner wall of the used water tank.

3. Install a new dust bag.

4. Close the cover of the dust tank.2. Remove the dust and debris from the filter with a dry cloth.

Note: Pulling upwards on the handle will seal the bag to prevent the dust

and debris from accidentally falling out.

Note: The float ball in the used water tank is a movable part. Do not apply

too much force when cleaning it to avoid damaging it.

18 19

ENEN

Routine Maintenance

Dust Bag Used Water Tank Main Brush

1. Discard the dust bag. 1. Remove the used water tank, open its cover and pour out the used water. 1. Press the brush guard clips inwards to remove the brush guard and lift the

brush out of the robot.

2. Pull out the brush covers at both ends of the brush as shown in the figure.

Use the provided cleaning tool to remove the hair tangled in the brush.

2. Rinse the used water tank with clean water, and use the provided cleaning

tool to clean the inner wall of the used water tank.

3. Install a new dust bag.

4. Close the cover of the dust tank.2. Remove the dust and debris from the filter with a dry cloth.

Note: Pulling upwards on the handle will seal the bag to prevent the dust

and debris from accidentally falling out.

Note: The float ball in the used water tank is a movable part. Do not apply

too much force when cleaning it to avoid damaging it.

20 21

ENEN

Routine Maintenance

Side Brush Dust Box and Filter

Omnidirectional Wheel

Remove and clean the side brush. 1. Open the robot cover and press the dust box clip to remove the dust box.

Then remove the filter and tap its basket gently.

2. Rinse the dust box and filter with water and dry them completely before

reinstalling.

Note:

·Use a tool such as a small screwdriver to separate the axle and tire of the

omnidirectional wheel. Do not use excessive force.

·Rinse the omnidirectional wheel under the running water and put it back

after drying it completely.

Note:

·Rinse the dust box and filter with clean water only. Do not use any

detergent.

·Use the dust box and filter only when they are completely dry.

Note: Do not attempt to clean the filter with a brush, a finger or sharp

objects to prevent damage.

Carpet Sensor

Cli Sensors

Edge Sensor

AI Visual Sensor

Line Laser Sensors

Bumper

Charging Contacts

Laser Distance

Sensor (LDS)

Robot Sensors and Charging Contacts

Wipe sensors and charging contacts of the robot by using a soft and dry

cloth, as shown in the below figure:

Note: A wet cloth can damage sensitive elements within the robot and the

base station. Please use a dry cloth for cleaning.

Charging Contacts

Auto-empty Vents

Clean the charging contacts and the signaling area of the base station with

a soft and dry cloth.

Clean the auto-empty vents of the robot and the base station with a soft and

dry cloth.

20 21

ENEN

Routine Maintenance

Side Brush Dust Box and Filter

Omnidirectional Wheel

Remove and clean the side brush. 1. Open the robot cover and press the dust box clip to remove the dust box.

Then remove the filter and tap its basket gently.

2. Rinse the dust box and filter with water and dry them completely before

reinstalling.

Note:

·Use a tool such as a small screwdriver to separate the axle and tire of the

omnidirectional wheel. Do not use excessive force.

·Rinse the omnidirectional wheel under the running water and put it back

after drying it completely.

Note:

·Rinse the dust box and filter with clean water only. Do not use any

detergent.

·Use the dust box and filter only when they are completely dry.

Note: Do not attempt to clean the filter with a brush, a finger or sharp

objects to prevent damage.

Carpet Sensor

Cli Sensors

Edge Sensor

AI Visual Sensor

Line Laser Sensors

Bumper

Charging Contacts

Laser Distance

Sensor (LDS)

Robot Sensors and Charging Contacts

Wipe sensors and charging contacts of the robot by using a soft and dry

cloth, as shown in the below figure:

Note: A wet cloth can damage sensitive elements within the robot and the

base station. Please use a dry cloth for cleaning.

Charging Contacts

Auto-empty Vents

Clean the charging contacts and the signaling area of the base station with

a soft and dry cloth.

Clean the auto-empty vents of the robot and the base station with a soft and

dry cloth.

22 23

ENEN

Routine Maintenance

Mop Pad

Battery

Remove the mop pad from the mop pad holder to replace it.

The robot contains a high-performance lithium-ion battery pack. Make sure

that the battery remains well-charged for daily use to maintain optimal

battery performance.

Problem Solution

The robot will not turn on.

The battery is low. Recharge the robot on the base and try again.

The temperature of the battery is too low or too high. It is recommended to operate the appliance at a temperature

between 32°F (0°C) and 104°F (40°C).

The robot will not charge.

The base station is not connected to power, please make sure both ends of its power cord are correctly plugged in.

The contact between the charging contacts on the base station and the robot is poor, please clean the charging contacts.

Check whether there is any foreign object at the connector of the robot and remove the foreign object if any.

The robot fails to connect

to Wi-Fi.

The Wi-Fi network password is incorrect. Make sure the password used to connect to your Wi-Fi network is correct.

The robot does not support a 5 GHz Wi-Fi connection. Make sure the robot is connected to a 2.4 GHz Wi-Fi connection.

The Wi-Fi signal is weak. Make sure the robot is in an area with good Wi-Fi coverage.

The robot may not be ready to be configured. Please exit and re-enter the app, and then try again as instructed.

The robot cannot find and

return to the base station.

The base station is disconnected from power or moved when the robot is not on it.

There are too many obstructions around the base station. Place the base station in a more open area.

Moving the robot may cause it to re-position itself, and it will recreate a map if re-positioning fails. If the robot is too far

from the base station, it might not be able to automatically return on its own, in which case you will need to manually

place the robot onto the base station.

Wipe the signaling area on the base station to remove dust or debris.

The robot gets stuck in

front of the base station

and cannot return to it.

Clear any obstruction within 5 cm on the left and right sides or within 1.5 m in front of the base station to prevent the robot

from being blocked.

The route for returning to charge is blocked, e.g. the door is closed.

The robot may slip if the floor in front of the base station is overly wet. If so, clean the excess water before trying again.

It is recommended to move the base station to a dierent place and try again.

Make sure the ramp extension plate is installed properly.

Troubleshooting

22 23

ENEN

Routine Maintenance

Mop Pad

Battery

Remove the mop pad from the mop pad holder to replace it.

The robot contains a high-performance lithium-ion battery pack. Make sure

that the battery remains well-charged for daily use to maintain optimal

battery performance.

Problem Solution

The robot will not turn on.

The battery is low. Recharge the robot on the base and try again.

The temperature of the battery is too low or too high. It is recommended to operate the appliance at a temperature

between 32°F (0°C) and 104°F (40°C).

The robot will not charge.

The base station is not connected to power, please make sure both ends of its power cord are correctly plugged in.

The contact between the charging contacts on the base station and the robot is poor, please clean the charging contacts.

Check whether there is any foreign object at the connector of the robot and remove the foreign object if any.

The robot fails to connect

to Wi-Fi.

The Wi-Fi network password is incorrect. Make sure the password used to connect to your Wi-Fi network is correct.

The robot does not support a 5 GHz Wi-Fi connection. Make sure the robot is connected to a 2.4 GHz Wi-Fi connection.

The Wi-Fi signal is weak. Make sure the robot is in an area with good Wi-Fi coverage.

The robot may not be ready to be configured. Please exit and re-enter the app, and then try again as instructed.

The robot cannot find and

return to the base station.

The base station is disconnected from power or moved when the robot is not on it.

There are too many obstructions around the base station. Place the base station in a more open area.

Moving the robot may cause it to re-position itself, and it will recreate a map if re-positioning fails. If the robot is too far

from the base station, it might not be able to automatically return on its own, in which case you will need to manually

place the robot onto the base station.

Wipe the signaling area on the base station to remove dust or debris.

The robot gets stuck in

front of the base station

and cannot return to it.

Clear any obstruction within 5 cm on the left and right sides or within 1.5 m in front of the base station to prevent the robot

from being blocked.

The route for returning to charge is blocked, e.g. the door is closed.

The robot may slip if the floor in front of the base station is overly wet. If so, clean the excess water before trying again.

It is recommended to move the base station to a dierent place and try again.

Make sure the ramp extension plate is installed properly.

Troubleshooting

24 25

ENEN

Troubleshooting Troubleshooting

Problem Solution

The robot will not turn o.

The robot cannot be turned o when it is charging. It is recommended to move the robot from the base station, and then

press and hold the button for 3 seconds to turn it o.

If the robot cannot be turned o by performing step 1, press and hold the button for 10 seconds to forcibly turn o the

robot. If the problem persists, please contact after-sales service.

The charging speed is

slow.

It takes about 3.5 hours to fully charge the robot when its battery is low.

If you operate the robot at temperatures outside of the specified range, the charging speed will automatically slow down

to extend the battery life.

The charging contacts on both the robot and the base may be dirty, please wipe them with a dry cloth.

The noise increases while

the robot is operating.

Check whether the dust box filter is clogged. If so, clean it or replace it.

A hard object may be caught in the main brush or the dust box. Check and remove any hard object.

The main brush or the side brush may become tangled. Check and remove any foreign objects.

Switch the suction mode to Standard or Quiet.

The robot moves without

following the set route.

Objects such as power cords and slippers should be organized before using the robot.

Working on wet slippery surfaces causes the main wheel to slip. It is recommended to dry the wet places before using the

robot.

Wipe the line laser sensors and the AI visual sensor on the robot with a clean, soft cloth to keep them clean and

unobstructed.

The robot misses the

rooms to be cleaned.

Make sure that the doors of the rooms to be cleaned are open.

Check whether there is a threshold higher than 2 cm at the door of the room. The robot cannot climb over high thresholds

or steps.

The place in front of the room to be cleaned may be wet and slippery, causing the robot to slip and work abnormally.

Please try drying the floor before using the robot.

Problem Solution

The robot will not resume

cleaning after charging.

Make sure that the robot is not set to the Do Not Disturb (DND) mode, which will prevent it from resuming cleaning.

The robot will not resume cleaning after you manually return the robot to the base station to charge, which includes

manually placing the robot on the base station or sending the robot to charge via the app or the robot itself.

The station cannot

automatically empty the

dust box.

Check whether the dust bag in the dust tank is full.

If the dust bag is not full, check whether there is any obstruction at the auto-empty vents of the robot, the base station, or

the dust box. If any, clean the blocked part in time.

The water level in the

washboard is abnormal.

Remove the washboard and check whether the sewage drain is blocked and clean it.

Gently press down on the used water tank to make sure it is installed correctly.

Check whether the seal on the used water tank is loose or not correctly installed, and manually reset it if so. If the problem

persists, please contact the after-sales service team.

Check the cleaning solution. Do not add any liquid other than the ocially-approved cleaning solution.

For more support, contact us via https://global.dreametech.com

24 25

ENEN

Troubleshooting Troubleshooting

Problem Solution

The robot will not turn o.

The robot cannot be turned o when it is charging. It is recommended to move the robot from the base station, and then

press and hold the button for 3 seconds to turn it o.

If the robot cannot be turned o by performing step 1, press and hold the button for 10 seconds to forcibly turn o the

robot. If the problem persists, please contact after-sales service.

The charging speed is

slow.

It takes about 3.5 hours to fully charge the robot when its battery is low.

If you operate the robot at temperatures outside of the specified range, the charging speed will automatically slow down

to extend the battery life.

The charging contacts on both the robot and the base may be dirty, please wipe them with a dry cloth.

The noise increases while

the robot is operating.

Check whether the dust box filter is clogged. If so, clean it or replace it.

A hard object may be caught in the main brush or the dust box. Check and remove any hard object.

The main brush or the side brush may become tangled. Check and remove any foreign objects.

Switch the suction mode to Standard or Quiet.

The robot moves without

following the set route.

Objects such as power cords and slippers should be organized before using the robot.

Working on wet slippery surfaces causes the main wheel to slip. It is recommended to dry the wet places before using the

robot.

Wipe the line laser sensors and the AI visual sensor on the robot with a clean, soft cloth to keep them clean and

unobstructed.

The robot misses the

rooms to be cleaned.

Make sure that the doors of the rooms to be cleaned are open.

Check whether there is a threshold higher than 2 cm at the door of the room. The robot cannot climb over high thresholds

or steps.

The place in front of the room to be cleaned may be wet and slippery, causing the robot to slip and work abnormally.

Please try drying the floor before using the robot.

Problem Solution

The robot will not resume

cleaning after charging.

Make sure that the robot is not set to the Do Not Disturb (DND) mode, which will prevent it from resuming cleaning.

The robot will not resume cleaning after you manually return the robot to the base station to charge, which includes

manually placing the robot on the base station or sending the robot to charge via the app or the robot itself.

The station cannot

automatically empty the

dust box.

Check whether the dust bag in the dust tank is full.

If the dust bag is not full, check whether there is any obstruction at the auto-empty vents of the robot, the base station, or

the dust box. If any, clean the blocked part in time.

The water level in the

washboard is abnormal.

Remove the washboard and check whether the sewage drain is blocked and clean it.

Gently press down on the used water tank to make sure it is installed correctly.

Check whether the seal on the used water tank is loose or not correctly installed, and manually reset it if so. If the problem

persists, please contact the after-sales service team.

Check the cleaning solution. Do not add any liquid other than the ocially-approved cleaning solution.

For more support, contact us via https://global.dreametech.com

26 27

ENEN

Specifications Battery Disposal and Removal

Model RLL82CE

Charging Time Approx. 3.5 hours

Rated Voltage 14.4 V

Rated Power 75 W

Operation Frequency 2400-2483.5 MHz

Maximum Output Power <20 dBm

Model RCLE0301

Rated Input 220-240 V 50-60 Hz

Rated Output 20 V 2 A

Rated Power

(during dust emptying)

1000 W

Rated Power

(during hot water cleaning)

1150 W

Rated Power (during

charging and drying)

89 W

Robot Base Station

Under normal use of condition, this equipment should be kept a separation

distance of at least 20cm between the antenna and the body of the user.

CAUTION:

Removal Guide:

Before removing the battery, disconnect the power and run out the battery as much as possible.

Unneeded batteries should be discarded at an appropriate recycling facility.

Do not expose to high temperature environment to avoid risks of explosion.

Under abusive conditions, liquid may be ejected from the battery. If contact occurs, flush with water and seek medical help.

1. Turn over the robot, use a proper tool to remove the screws on the back of the robot, and then remove the cover.

2. Unplug the terminals between the battery and PCB board to remove the battery.

The built-in lithium-ion battery contains substances that are hazardous to the environment. Before disposing of the battery, make sure the battery is removed

by qualified technicians and discarded at an appropriate recycling facility.

– the battery must be removed from the appliance before it is scrapped;

– the appliance must be disconnected from the supply mains when removing the battery;

– the battery is to be disposed of safely.

All products bearing this symbol are waste electrical and electronic equipment (WEEE as in directive 2012/19/EU) which should not be mixed

with unsorted household waste. Instead, you should protect human health and the environment by handing over your waste equipment to a

designated collection point for the recycling of waste electrical and electronic equipment, appointed by the government or local authorities.

Correct disposal and recycling will help prevent potential negative consequences to the environment and human health. Please contact the

installer or local authorities for more information about the location as well as terms and conditions of such collection points.

WEEE Information

Note:

·Rated Power (during hot water cleaning) is determined by the power value

during the representative period (water temperature 25 ).

·Rated Power (during charging and drying) is determined by the power

value during full load period.
