Technical Support
If you need technical support with your Boss Audio product or have
quesons about its use, please contact us:
805.751.4853
www.BossAudio.com
6
Due to ongoing product development, specicaons are subject to change without noce.
P106DVC_1114_v2
1
Congratulaons on your purchase of the Boss Audio Phantom Series
Subwoofer. Boss Audio takes great pride in producing products that
look great, sound great, and stand up to the daily rigors applied by
audio enthusiasts around the world.
P106DVC 10” (25cm) Subwoofer
Dual 4 Ω Voice Coils
2100 W Peak Power Handling
High Temperature Voice Coils
Butyl Rubber Surround
2
5
Enclosures
The P106DVC will work in a sealed or ported enclosure ranging from
0.65 ³-1.0 ³. Since the woofer has pole-vent, it needs a minimum
clearance from the rear wall of the enclosure of 0.75” (19 mm).
Below you will nd the dimensions to make the enclosure to suit the
subwoofers needs, it has been designed for maximum output while
retaining great sound quality.
The dimensions have already accounted for the volume displacement
of the subwoofer, and using 3/4” (19mm) MDF. All dimensions are
external.
Sealed Dimensions:
Length (L) : 16” (406 mm)
Width (W) : 9” (203 mm)
Height (H) : 12” (305 mm)
Cutout Diameter: 9-1/8” (232mm)
Int Volume: 0.65 ³
Enclosure Dimensions
Ported Dimensions:
Length (L) : 18” (457mm)
Width (W) : 12” (305 mm)
Height (H) : 12” (305 mm)
Cutout Diameter: 9-1/8” (232 mm)
Port Dimensions: 3” (76 mm)
Port Length: 8” (203 mm)
Tuning Freq: 38 Hz
Int. Volume: 1.0 ³
4
Mulple Subwoofers
8 Ω 2 Ω
Wiring your Subwoofer
Parallel Series
4 Ω
1 Ω
3
Product Specicaons
Impedance Dual 4 Ω
Resonant Frequency 34 Hz
Qts 0.489
Qms 4.592
Qes 0.548
Vas 1.424 ³ (40.32 liters)
Xmax 6 mm
Sensivity (1 W/ 1 m) 88 dB
Peak Power Handling 2100 W
Mounng Depth 6-3/8” (162mm)
Cutout Diameter 9-1/8” (232mm)
4
Mulple Subwoofers
8 Ω 2 Ω
Wiring your Subwoofer
Parallel Series
4 Ω
1 Ω
3
Product Specicaons
Impedance Dual 4 Ω
Resonant Frequency 34 Hz
Qts 0.489
Qms 4.592
Qes 0.548
Vas 1.424 ³ (40.32 liters)
Xmax 6 mm
Sensivity (1 W/ 1 m) 88 dB
Peak Power Handling 2100 W
Mounng Depth 6-3/8” (162mm)
Cutout Diameter 9-1/8” (232mm)
P106DVC 10” (25cm) Subwoofer
Dual 4 Ω Voice Coils
2100 W Peak Power Handling
High Temperature Voice Coils
Butyl Rubber Surround
2
5
Enclosures
The P106DVC will work in a sealed or ported enclosure ranging from
0.65 ³-1.0 ³. Since the woofer has pole-vent, it needs a minimum
clearance from the rear wall of the enclosure of 0.75” (19 mm).
Below you will nd the dimensions to make the enclosure to suit the
subwoofers needs, it has been designed for maximum output while
retaining great sound quality.
The dimensions have already accounted for the volume displacement
of the subwoofer, and using 3/4” (19mm) MDF. All dimensions are
external.
Sealed Dimensions:
Length (L) : 16” (406 mm)
Width (W) : 9” (203 mm)
Height (H) : 12” (305 mm)
Cutout Diameter: 9-1/8” (232mm)
Int Volume: 0.65 ³
Enclosure Dimensions
Ported Dimensions:
Length (L) : 18” (457mm)
Width (W) : 12” (305 mm)
Height (H) : 12” (305 mm)
Cutout Diameter: 9-1/8” (232 mm)
Port Dimensions: 3” (76 mm)
Port Length: 8” (203 mm)
Tuning Freq: 38 Hz
Int. Volume: 1.0 ³
Technical Support
If you need technical support with your Boss Audio product or have
quesons about its use, please contact us:
805.751.4853
www.BossAudio.com
6
Due to ongoing product development, specicaons are subject to change without noce.
P106DVC_1114_v2
1
Congratulaons on your purchase of the Boss Audio Phantom Series
Subwoofer. Boss Audio takes great pride in producing products that
look great, sound great, and stand up to the daily rigors applied by
audio enthusiasts around the world.
