Technical Support
If you need technical support with your Boss Audio product or have
quesons about its use, please contact us:
805.751.4853
www.BossAudio.com
6
*Due to ongoing product development, specicaons are subject to change without noce.
D10F_1114_v2
1
Congratulaons on your purchase of the Boss Audio Phantom Series
Subwoofer. Boss Audio takes great pride in producing products that
look great, sound great, and stand up to the daily rigors applied by
audio enthusiasts around the world.
D10F 10” (25cm) Flat Subwoofer
Single 4 Ω Voice Coil
800 W Peak Power Handling
High Temperature Voice Coil
Butyl Rubber Surround
2
5
Enclosures
The D10F will work in a compact sealed enclosure. Since the woofer
has pole-vent, it needs a minimum clearance from the rear wall of
the enclosure of 0.75” (19 mm).
Below you will nd the dimensions to make the enclosure to suit the
subwoofers needs, it has been designed for maximum output while
retaining great sound quality.
The dimensions have already accounted for the volume displacement
of the subwoofer, and using 3/4” (19mm) MDF. All dimensions are
external.
Sealed Dimensions:
Length (L) : 16” (406 mm)
Width (W) : 9” (229 mm)
Height (H) : 12” (305 mm)
Cutout Diameter: 9-1/8” (232 mm)
Int. Volume: 0.6 ³
Enclosure Dimensions
4
4 Ω
Wiring your Subwoofer
Mulple Subwoofers
Series
8 Ω
Parallel
2 Ω
Mulple Subwoofers
3
Product Specicaons
Impedance 4 Ω
Resonant Frequency 50 Hz
Qts 0.814
Qms 5.416
Qes 0.957
Vas 0.692 cu . (19.6 liters)
Xmax 5mm
Sensivity (1 W/ 1 m) 87 dB
Peak Power Handling 800 W
Mounng Depth 3-7/8” (98 mm)
Cutout Diameter 9-3/16” (233 mm)
4
4 Ω
Wiring your Subwoofer
Mulple Subwoofers
Series
8 Ω
Parallel
2 Ω
Mulple Subwoofers
3
Product Specicaons
Impedance 4 Ω
Resonant Frequency 50 Hz
Qts 0.814
Qms 5.416
Qes 0.957
Vas 0.692 cu . (19.6 liters)
Xmax 5mm
Sensivity (1 W/ 1 m) 87 dB
Peak Power Handling 800 W
Mounng Depth 3-7/8” (98 mm)
Cutout Diameter 9-3/16” (233 mm)
D10F 10” (25cm) Flat Subwoofer
Single 4 Ω Voice Coil
800 W Peak Power Handling
High Temperature Voice Coil
Butyl Rubber Surround
2
5
Enclosures
The D10F will work in a compact sealed enclosure. Since the woofer
has pole-vent, it needs a minimum clearance from the rear wall of
the enclosure of 0.75” (19 mm).
Below you will nd the dimensions to make the enclosure to suit the
subwoofers needs, it has been designed for maximum output while
retaining great sound quality.
The dimensions have already accounted for the volume displacement
of the subwoofer, and using 3/4” (19mm) MDF. All dimensions are
external.
Sealed Dimensions:
Length (L) : 16” (406 mm)
Width (W) : 9” (229 mm)
Height (H) : 12” (305 mm)
Cutout Diameter: 9-1/8” (232 mm)
Int. Volume: 0.6 ³
Enclosure Dimensions
Technical Support
If you need technical support with your Boss Audio product or have
quesons about its use, please contact us:
805.751.4853
www.BossAudio.com
6
*Due to ongoing product development, specicaons are subject to change without noce.
D10F_1114_v2
1
Congratulaons on your purchase of the Boss Audio Phantom Series
Subwoofer. Boss Audio takes great pride in producing products that
look great, sound great, and stand up to the daily rigors applied by
audio enthusiasts around the world.
