Congratulaons on your purchase of the Boss Audio Phantom Series
Subwoofer. Boss Audio takes great pride in producing products that
look great, sound great, and stand up to the daily rigors applied by
audio enthusiasts around the world.
D12F 12” (30cm) Flat Subwoofer
Single 4 Ω Voice Coil
1000 W Peak Power Handling
High Temperature Voice Coil
Butyl Rubber Surround
2
5
Enclosure
The D12F is opmized for operaon in a sealed enclosure.
Since the woofer has pole-vent, it needs a minimum clearance from the
rear wall of the enclosure of 0.75” (19 mm).
Below you will nd the dimensions to make the enclosure to suit the
subwoofers needs, it has been designed for maximum output while
retaining great sound quality. The dimensions have already accounted
for the volume displacement of the subwoofer, using 3/4” (19mm) MDF.
All dimensions are external.
Sealed Dimensions:
Length (L) : 21” (533 mm)
Width (W) : 9” (229 mm)
Height (H) : 14” (356 mm)
Cutout Diameter: 11-1/8” (283 mm)
Int. Volume: 1.0 ³
Enclosure Dimensions
4
4 Ω
Wiring your Subwoofer
Mulple Subwoofers
Series
8 Ω
Parallel
2 Ω
Mulple Subwoofers
3
Product Specicaons
Impedance 4 Ω
Resonant Frequency 35 Hz
Qts 0.691
Qms 5.398
Qes 0.793
Vas 2.055 cu . (58.19 liters)
Xmax 5mm
Sensivity (1 W/ 1 m) 87 dB
Peak Power Handling 1000 W
Mounng Depth 3-7/8” (98 mm)
Cutout Diameter 11-1/8” (283 mm)
4
4 Ω
Wiring your Subwoofer
Mulple Subwoofers
Series
8 Ω
Parallel
2 Ω
Mulple Subwoofers
3
Product Specicaons
Impedance 4 Ω
Resonant Frequency 35 Hz
Qts 0.691
Qms 5.398
Qes 0.793
Vas 2.055 cu . (58.19 liters)
Xmax 5mm
Sensivity (1 W/ 1 m) 87 dB
Peak Power Handling 1000 W
Mounng Depth 3-7/8” (98 mm)
Cutout Diameter 11-1/8” (283 mm)
D12F 12” (30cm) Flat Subwoofer
Single 4 Ω Voice Coil
1000 W Peak Power Handling
High Temperature Voice Coil
Butyl Rubber Surround
2
5
Enclosure
The D12F is opmized for operaon in a sealed enclosure.
Since the woofer has pole-vent, it needs a minimum clearance from the
rear wall of the enclosure of 0.75” (19 mm).
Below you will nd the dimensions to make the enclosure to suit the
subwoofers needs, it has been designed for maximum output while
retaining great sound quality. The dimensions have already accounted
for the volume displacement of the subwoofer, using 3/4” (19mm) MDF.
All dimensions are external.
Sealed Dimensions:
Length (L) : 21” (533 mm)
Width (W) : 9” (229 mm)
Height (H) : 14” (356 mm)
Cutout Diameter: 11-1/8” (283 mm)
Int. Volume: 1.0 ³
Enclosure Dimensions
