User Manual
VC60
Cordless Vacuum Cleaner
EN
2.
tech-support@ibuture.com
1. WARNING
Thank you for purchasing the BUTURE VC60 cordless vacuum cleaner. Before using this machine, please read the following safety warning first and take
safety protection measures to avoid malfunctions caused by improper operation.
Note: The vacuum cleaner adopted thermal protection technology to prevent overheating, will stop working when the item is over-heated.
The product provides a free 2-year warranty by default. To extend the warranty to 3 year, please contact tech-[email protected]om in time to activate.
①
This BuTure appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience
and knowledge, unless they have been given supervision or instruction by a responsible person concerning use of the appliance to ensure that they can
use it safety.
②
Suitable for dry locations only. Do not use or store outdoors with wet surfaces. Do not handle any part of the plug or appliance with wet hands. Store
properly in a dry place indoors.
③
Do not use a damaged cable or plug. If the device or charger does not work properly, dropped, damaged, missed or dropped into water, please contact
techsupport@ibuture.com , BuTure after-sales team for support.
④
Do not vacuum flammable or combustible liquids, such as petrol, or use in areas where liquids may be present.
⑤
Turn off the power switch before plug or unplug the adapter.
⑥
Do not vacuum anything that is burning or smoking, such as cigarettes, matches or hot ashes.
⑦
Do not use without filters or dust cup to avoid damaging the motor and contaminating the air. Wash hands after using the vacuum cleaner.
⑧
FIRE WARNING: Do not place this product on or near a cooker or any other hot surface and do not incinerate this appliance even if it is severely
damaged. The battery might catch fire or explode.
⑨
Unplug the charger from the power outlet before performing routine cleaning or maintenance.
⑩
Battery leaks may occur under extreme conditions. If any liquid gets on your skin wash quickly with soap and water. f liquid gets into your eyes, rinse with
water for at least 15 minutes immediately. Seek medical attention immediately.
⑪
Charge the unit with the charger we provided.
⑫
Avoid using this product to vacuum hard, sharp objects, as this may cause damage.
EN
3.
tech-support@ibuture.com
2. PACKAGE LIST
Main Body*1 Telescopic Tube*1 Motorized Brush*1 (Roller installed)
Long Crevice Tool *1 2 in 1 Brush*1 Extra Hepa & Sponge Filter Adapter*1
Wall Mount (with screw*3,expansion
tube*3) Aromatic Tablet*1 Cleaning Brush*1 Quick User Guide*1
Please check and confirm the accessories and parts according to the following sheet before using.
Stick Vacuum Cleaner
VC60
EN
4.
tech-support@ibuture.com
3. KNOW YOUR PRODUCT
Display Screen
Speed Adjustment
Button
Dust Cup
Release Button
Dust Cup
Dust Empty Button
Tube Release Button
Telescopic Tube
Length Adjustment
Button
3.1 Product Details 3.2 Digital Display Screen
Switch Button
Charging Port
Battery Release Button
Air Outlet of the
Fragrance
Detachable Battery
Motor
Motorized
Floor Brush
Motorized Brush
Release Button
CHECK THE BRUSH AIRWAY BLOCKAGE
100
%
ECO
50%
%
0
C
1
E
0
O
100
%
ECO
Suction Level
Indicator
Not Original
Charger Indicator
Battery
Percentage
Check
the Brush
Low Battery
Indicator
Airway
Blockage
EN
5.
tech-support@ibuture.com
3.3 Accessories Function
Remove dust on the hard-to-reach areas like windows, bed
feet, gaps between sofa, etc.
Fix the cordless vacuum cleaner and accessories on the wall
mount for easy storage.
Easy to snap-on, and can help you remove dust and hairs in
keyboard or on the carpet.
Remove hair, rubbish, and micro dust on the accessories or
filters.
•
Long Crevice Nozzle
•
Wall Mount
•
2 in 1 Upholstery Brush
•
Mini Cleaning Brush
EN
6.
tech-support@ibuture.com
4. PRODUCT ASSEMBLY
4.1 Install the Battery Pack
Insert the battery pack into the main body in the direction guided as
the photo below.
4.2 Install Full Vacuum Cleaner
①
Install Extention Tube & Cleaning Accessories
③
Install Wall Mount
②
Directly Install Cleaning Accessories
EN
7.
tech-support@ibuture.com
⑤
According to different needs, place or take out the aromatic tablet.
④
According to different needs, the length of the tube can be adjusted.
WARNING
•
Please make sure there is no gas, water, or electrical cables and wires behind the mounting area.
•
To avoid the dock dropping down, please make sure it must be installed firmly.
•
Store appropriately indoors in a dry place. Do not expose the machine to sunlight or freezing temperature.
Recommended temperature range: 39.2°F (4°C)-104°F(40°C).
EN
8.
tech-support@ibuture.com
5. HOW TO USE
5.1 Charging
When the battery indicator on the display screen is under 30% or
the following animation appears, the vacuum cleaner needs to be
charged as soon as possible.
Three Charging Methods
①
Connect the main body to charge.
②
Hang on the wall mount to charge.
③
Charge the battery directly.
The battery indicator light on it will keep flashing in red when the
battery is being charged, and will turn blue when it is fully charged.
Battery indicator light
ECO
C
E
O
ECO
30%
EN
9.
tech-support@ibuture.com
5.2 Operating
Warning:
1. Do not exceed the "MAX" dust collection capacity of the dust cup.
2. Please keep the suction nozzle unobstructed and avoid blockage. Otherwise, the motor will overheat and cause danger.
Press the suction adjustment button to adjust the power as you need.
The suction on the screen shows
green, the vacuum cleaner is in ECO
mode.
Press the button once, the suction on the
screen shows mint green, the vacuum
cleaner is in MID mode.
Press the button once, the suction on the
screen shows blue, the vacuum cleaner is at
the MAX suction mode.
100
%
ECO
100
%
MID
100
%
MAX
•
Press the switch button to start work
•
Adjust suction power
Switch button
Speed control button
EN
10.
tech-support@ibuture.com
6. MAINTENANCE
Warm Tips:
•
Please clean the vacuum cleaner regularly to extend its lifespan.
•
After cleaning the parts of the vacuum cleaner, please wait until they are completely dry before reinstalling
them on the vacuum cleaner.
•
Turn off the power and remove the battery pack before cleaning the main body.
•
Please use a neutral detergent, and wipe the main body with half-wet cloth.
•
Please avoid sun exposure and store in a cool and dry place.
6.1 Main Body Cleaning
EN
11.
tech-support@ibuture.com
•
When the garbage in the dust cup exceeds MAX Line, please
empty it in time.
•
Remove the dust cup
•
Press the dust empty button to empty the dust.
•
Take out the stainless steel filter and the HEPA filter.
6.2 Dust Cup and Filters Cleaning
①
Empty the Dust Cup
②
Remove the Dust Cup and Filters
MAXMAX
EN
12.
tech-support@ibuture.com
③
Clean the Dust Cup and Filters with Water
④
Install the Dust Cup and Filters
(Warning: make sure the dust cup and filters are completely dry before installation.)
•
Put the filters into dust cup, the sponge is placed under the
HEPA.
•
Press the dust cup release button and reinstall it on the vacuum
cleaner.
EN
13.
tech-support@ibuture.com
6.3 Brush Roller Cleaning
Ensure the appliance is disconnected from the charger before removing the roller brush. Be careful not to pull the ON button.
③
Clean the roller brush with/without water
. ④
Push in gently to install the roller brush. Before replacing,
make sure the brush is completely dry.
①
Push the button to the “unclock" sign, remove the brush
roller
②
Remove the debris wrapped around the roller with the
mini cleaning brush
EN
14.
tech-support@ibuture.com
7. SPECIFICATIONS
Product Cordless Vacuum Cleaner
Model VC60
Rated Voltage DC 25.9V
Battery Type Li-ion
Cleaning Mode MANUAL
EN
15.
tech-support@ibuture.com
8. TROUBLESHOOTING
If there is any problem during use, please check the following troubleshooting table. If the problem can't be solved, please contact the after-sales email:
tech-support@ibuture.com
* When the vacuum cleaner does not work properly, there will be a corresponding fault remind animation on the screen, please check it in time.
Low battery warning, please charge in time.
Airway blockage reminder, please check
and clean the extension tube and dust cup as
shown in the animation on the screen.
Floor brush clogging reminder, please check
whether the floor brush is entangled by
obstructions and clean it promptly.
CHECK THE BRUSH
AIRWAY BLOCKAGE
Wrong charger used. A wrong charger can
destroy your vacuum, please make sure you are
using the original charger, and confirm that the
specification is: 31.0V 0.5A
8.1 Abnormal Indicator
EN
16.
tech-support@ibuture.com
Common Trouble Possible Causes Solutions
Vacuum can not work
1. Low battery power
2. Automatic protection triggered by excessive
temperature due to blockage
3. Battery damaged
1. Charge before use
2. Clean the floor brushes, dust suction ports or air inlet
filters, and restart after cooling down
3. Replace a battery
Suction reduced
1. The dust cup is full of dust
2. The filters are full of dust
3. The telescopic tube or brush inlet blocked
4. Low battery power
1. Empty the dust cup
2. Clean or replace the filter
3. Remove blockage in tube and brush inlet
4. Charge before use
Insufficient use time after
charging
1. Insufficient charging time
2.Battery aging
3.The dust cup is full of dust
4. The filters are full of dust
5. The telescopic tube or brush inlet blocked
6. Always use the highest speed to clean the whole
house
1. Recharge the battery
2. Change a battery
3. Empty the dust cup
4. Clean or replace the filter
5. Remove blockage in tube and brush inlet
6. For simple cleaning, it is recommended to use the lowest
speed or the medium speed. Only larger garbage needs
the highest speed, which can effectively prolong the
battery life. If you have a larger space to clean, contact
tech-support@ibuture.com to get additional spare
battery.
8.2 Other Common Trouble
EN
17.
tech-support@ibuture.com
Common Trouble Possible Causes Solutions
Battery indicator does not
light up when charging
1. Battery damaged
2. Wrong charger used
3. Adaptor incorrectly connected or damaged
1. Replace a battery
2. Check whether the adapter is plugged in.
3. Make sure to use the original charger, the specification is:
31.0V 0.5A
Not charging
1. Battery temperature is too high or too low
2. The battery indicator does not light up when
charging
1. Please wait for the battery temperature to return to
normal before charging
2. Check whether the adapter is plugged in. Replace a
battery or adaptor
EN
18.
tech-support@ibuture.com
9. WARRANTY
BuTure cordless vacuum cleaner has a two-year warranty. To extend the warranty to 3 year, please contact tech-support@ibuture.com in time to activate.
The warranty includes: free maintenance of the cordless stick vacuum, free replacement of defective parts, including battery, filters, floor brush, dust
container, charger and motor.
If your machine is not functioning properly, or you still have any questions after reading this manual carefully, please feel free to contact us via
tech-support@ibuture.com, we will reply to you in 24 hours and try our best to provide you with a satisfactory solution.
•
Warranty Service
•
Technical Support
tech-support@ibuture.com
