USER MANUAL
Cordless Vacuum Cleaner
Model: VC30
Email: tech-support@ibuture.com
LANGUAGE
English
Deutsch
Italiano
Français
Español
日本語
01-14
15-28
29-42
43-56
57-70
71-84
CONTENT
1. WARNING
01
02
03
05
07
08
2. PACKAGE LIST
3. KNOW THE PRODUCT
3.1 Product Details
3.2 Accessories Function
4.1 Install Vacuum Cleaner
4.2 Install Wall Mount
4. PRODUCT ASSEMBLY
5.1 Charging
5.2 Operating
5. HOW TO USE
6.1 Main Body Cleaning
6.2 Empty Dust Cup
6.3 Wash the air inlet HEPA and filter cone
6.4 Clean Air outlet HEPA
6.5 Brush Roller Cleaning
6. MAINTENANCE
12
7. SPECIFICATION
13
8. TROUBLESHOOTING
14
9. WARRANTY
1.WARNING
① This BuTure appliance is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless they have been given
supervision or instruction by a responsible person concerning use of the appliance to ensure that they
can use it safety.
② Suitable for dry locations only. Do not use or store outdoors with wet surfaces. Do not handle any
part of the plug or appliance with wet hands. Store properly in a dry place indoors.
③ Do not use a damaged cable or plug. If the device or charger does not work properly, dropped,
damaged, missed or dropped into water, please contact tech-support@ibuture.com, BuTure
after-sales team for support.
④ Do not vacuum flammable or combustible liquids, such as petrol, or use in areas where liquids may
be present.
⑤ Turn off the power switch before plug or unplug the adapter.
⑥ Do not vacuum anything that is burning or smoking, such as cigarettes, matches or hot ashes
⑦ Do not use without filters or dust cup to avoid damaging the motor and contaminating the air. Wash
hands after using the vacuum cleaner.
⑧ FIRE WARNING: Do not place this product on or near a cooker or any other hot surface and do not
incinerate this appliance even if it is severely damaged. The battery might catch fire or explode.
⑨ Unplug the charger from the power outlet before performing routine cleaning or maintenance.
⑩ Battery leaks may occur under extreme conditions. If any liquid gets on your skin wash quickly with
soap and water. f liquid gets into your eyes, rinse with water for at least 15 minutes immediately. Seek
medical attention immediately.
⑪ Charge the unit with the charger we provided.
⑫ Avoid using this product to vacuum hard, sharp objects, as this may cause damage.
Note: The vacuum cleaner adopted thermal protection technology to prevent overheating, will stop
working when the item is over-heated.
Thank you for purchasing the BuTure VC30 cordless vacuum cleaner. Before using this machine,
please read the following safety warning first and take safety protection measures to avoid
malfunctions caused by improper operation.
EN 01 02 03 04 05 06 07 08 09 10 11 12 13 14
15 16 17 18 19 20 21 22 23 24 25 26 27 28
29 30 31 32 33 34 35 36 37 38 39 40 41 42
43 44 45 46 47 48 49 50 51 52 53 54 55 56
57 58 59 60 61 62 63 64 65 66 67 68 69 70
71 72 73 74 75 76 77 78 79 80 81 82 83 84
After-sales Service Email: tech-support@ibuture.com
Part Name
Main Body 1
1
1
1
1
1
1
1
1
1
1
3
1
Battery Pack
Adjustable Extension Tube
Motorized Brush Head
Soft Rolling Brush (Installed)
Carbon Fiber Rolling Brush
Long Crevice Nozzle
2 in 1 Upholstery Brush
Wall Mount Stand
Extra Air Inlet HEPA
Charger
Screw
User Manual
Quantity
2.PACKAGE CONTENT
Please check and confirm the accessories and parts according to the following sheet before using.
EN01 02 03 04 05 06 07 08 09 10 11 12 13 14
15 16 17 18 19 20 21 22 23 24 25 26 27 28
29 30 31 32 33 34 35 36 37 38 39 40 41 42
43 44 45 46 47 48 49 50 51 52 53 54 55 56
57 58 59 60 61 62 63 64 65 66 67 68 69 70
71 72 73 74 75 76 77 78 79 80 81 82 83 84
After-sales Service Email: tech-support@ibuture.com
3.KNOW THE PRODUCT
3.1PRODUCT DETAILS
Dust cup release button
Telescopic Tube Release Button
Wall Mount Stand
Battery Release Button
Switch Button
Dust Cup
Suction
Adjustment
Button
Battery Pack
Charging Port
Dust Empty Button
LED light
Motorized Floor Brush
Adjustable Extension Tube
Length Adjustment Button
Motorized Floor Brush Release Button
+
/
-
EN01 02 03 04 05 06 07 08 09 10 11 12 13 14
15 16 17 18 19 20 21 22 23 24 25 26 27 28
29 30 31 32 33 34 35 36 37 38 39 40 41 42
43 44 45 46 47 48 49 50 51 52 53 54 55 56
57 58 59 60 61 62 63 64 65 66 67 68 69 70
71 72 73 74 75 76 77 78 79 80 81 82 83 84
After-sales Service Email: tech-support@ibuture.com
① 2 in 1 Upholstery Brush
Easy to snap-on design,can help you remove
dust and hair on the carpet.
② Long crevice Nozzle
Remove dust on the hard-to-reach areas like
windows, bed feet, gaps between sofa, etc.
③ Wall Mount Stand
Hold the vacuum and accessories on the
wall-mounted plate for easy storage and
battery charging.
④ Soft rolling Brush
Remove dust, debris, and hair from hard floors.
⑤ Carbon Fiber Rolling Brush
Remove debris, dust, and hair in carpets, velvet.
3.2 ACCESSORIES FUNCTION
EN01 02 03 04 05 06 07 08 09 10 11 12 13 14
15 16 17 18 19 20 21 22 23 24 25 26 27 28
29 30 31 32 33 34 35 36 37 38 39 40 41 42
43 44 45 46 47 48 49 50 51 52 53 54 55 56
57 58 59 60 61 62 63 64 65 66 67 68 69 70
71 72 73 74 75 76 77 78 79 80 81 82 83 84
After-sales Service Email: tech-support@ibuture.com
① Directly Install Cleaning Accessories
4.PRODUCT ASSEMBLY
4.1 Install Vacuum Cleaner
Ka da
Press and hold the extension tube length adjustment button, push forward or pull backward to select
the appropriate length of the extension tube.
② Install the extension tube and cleaning accessories
Ka da
Ka da
Ka da
Ka da
EN01 02 03 04 05 06 07 08 09 10 11 12 13 14
15 16 17 18 19 20 21 22 23 24 25 26 27 28
29 30 31 32 33 34 35 36 37 38 39 40 41 42
43 44 45 46 47 48 49 50 51 52 53 54 55 56
57 58 59 60 61 62 63 64 65 66 67 68 69 70
71 72 73 74 75 76 77 78 79 80 81 82 83 84
After-sales Service Email: tech-support@ibuture.com
4.2 Wall-Mounted Plate Assembling Diagram
1
3
2
• Please make sure there is no gas, water, or electrical cables and wires behind
the mounting area.
• To avoid the dock dropping down, please make sure it must be installed firmly.
• Store appropriately indoors in a dry place. Do not expose the machine to sunlight
or freezing temperature. Recommended temperature range:
39.2°F (4°C)-104°F(40°C).
WARNING
EN01 02 03 04 05 06 07 08 09 10 11 12 13 14
15 16 17 18 19 20 21 22 23 24 25 26 27 28
29 30 31 32 33 34 35 36 37 38 39 40 41 42
43 44 45 46 47 48 49 50 51 52 53 54 55 56
57 58 59 60 61 62 63 64 65 66 67 68 69 70
71 72 73 74 75 76 77 78 79 80 81 82 83 84
After-sales Service Email: tech-support@ibuture.com
5.HOW TO USE
5.1 Charging
• Charging Methods
• Battery power indicator
• When using a new battery or using it for the first time after long-term
storage, please fully charge the battery first.
• When storing and not using the vacuum cleaner for a long time, please
ensure that it is charged and discharged at least once every three months.
① Connect the main body to charge
③ Charge the battery directly
② Hang on the wall mount to charge
+
/
-
+
-
/
EN01 02 03 04 05 06 07 08 09 10 11 12 13 14
15 16 17 18 19 20 21 22 23 24 25 26 27 28
29 30 31 32 33 34 35 36 37 38 39 40 41 42
43 44 45 46 47 48 49 50 51 52 53 54 55 56
57 58 59 60 61 62 63 64 65 66 67 68 69 70
71 72 73 74 75 76 77 78 79 80 81 82 83 84
After-sales Service Email: tech-support@ibuture.com
5.2 Operating
• Start to Work
Press the switch button to turn it on and it will start Min mode suction . Press again to turn it off.
• Select Suction Level Min-Max
Press the button +/- to adjust the suction
6.1 Main Body Cleaning
Before each use, make sure that
• The battery is fully charged, and fixed in place.
• The dust cup and filters are cleaned, and fixed in place.
+
-
/
+
-
/
6.HOW TO USE
Tip: Please clean the vacuum cleaner regularly to extend its lifespan.
• Turn off the power before cleaning the body.
• Please use a neutral detergent, wipe the body with half-wet cloth.
• Please avoid sun exposure and store in a cool and dry place.
EN01 02 03 04 05 06 07 08 09 10 11 12 13 14
15 16 17 18 19 20 21 22 23 24 25 26 27 28
29 30 31 32 33 34 35 36 37 38 39 40 41 42
43 44 45 46 47 48 49 50 51 52 53 54 55 56
57 58 59 60 61 62 63 64 65 66 67 68 69 70
71 72 73 74 75 76 77 78 79 80 81 82 83 84
After-sales Service Email: tech-support@ibuture.com
6.2 Empty Dust Cup
6.3 Wash the air inlet HEPA and filter cone
• When using, if the garbage in the dust cup exceeds MAX Line, please empty it in time.
• Press the dust empty button to empty the dust.
• Remove dust cup from main body.
Press the dust cup release button. Rotate the dust cup clockwise to separate the dust cup from the
main body.
MAX
MAX
×
√
MAX
MAX
EN01 02 03 04 05 06 07 08 09 10 11 12 13 14
15 16 17 18 19 20 21 22 23 24 25 26 27 28
29 30 31 32 33 34 35 36 37 38 39 40 41 42
43 44 45 46 47 48 49 50 51 52 53 54 55 56
57 58 59 60 61 62 63 64 65 66 67 68 69 70
71 72 73 74 75 76 77 78 79 80 81 82 83 84
After-sales Service Email: tech-support@ibuture.com
• Take out the air inlet HEPA from the dust cup.
• Take out the filter cone.
• Clean the air inlet HEPA and filter cone with water.
• Install the HEPA and filter cone
Make sure that the dust cup and filters have dried before use.
First screw the filter cone counterclockwise into the bottom of the dust bucket, and the bottom cover
button resets and self-locks.
Then put the air inlet HEPA back into the dust bucket body. Rotate the dust bucket body counter-
clockwise and hear a "click", indicating that it has been fully installed in place.
1min
24h
EN01 02 03 04 05 06 07 08 09 10 11 12 13 14
15 16 17 18 19 20 21 22 23 24 25 26 27 28
29 30 31 32 33 34 35 36 37 38 39 40 41 42
43 44 45 46 47 48 49 50 51 52 53 54 55 56
57 58 59 60 61 62 63 64 65 66 67 68 69 70
71 72 73 74 75 76 77 78 79 80 81 82 83 84
After-sales Service Email: tech-support@ibuture.com
6.4 Clean Air outlet HEPA
6.5 Brush Roller Cleaning
• Push the button to the “unclock"sign, remove the brush roller.
Rotate the end cap of the air outlet HEPA counterclockwise, take out the HEPA and clean it.
To install the air outlet HEPA. Put the HEPA into the air outlet bucket, and then rotate the back end
cover clockwise.
Tip: After long periods of use, the bristle may be jammed by hair or similar build-up. It's recommend-
ed to clean the brush roller periodically to ensure efficient operation and maintain suction.
EN01 02 03 04 05 06 07 08 09 10 11 12 13 14
15 16 17 18 19 20 21 22 23 24 25 26 27 28
29 30 31 32 33 34 35 36 37 38 39 40 41 42
43 44 45 46 47 48 49 50 51 52 53 54 55 56
57 58 59 60 61 62 63 64 65 66 67 68 69 70
71 72 73 74 75 76 77 78 79 80 81 82 83 84
After-sales Service Email: tech-support@ibuture.com
Model
VC30
Rated voltage
22.2V
Suction level
Min-Max
Charge time 4-5H
7.SPECIFICATION
• Remove the debris wrapped around the roller with your own brush, then flush the roller with water.
• Gently push the brush roller into the motored brush,until securely in place. Make sure the brush
roller is completely dry before using.
24h
EN01 02 03 04 05 06 07 08 09 10 11 12 13 14
15 16 17 18 19 20 21 22 23 24 25 26 27 28
29 30 31 32 33 34 35 36 37 38 39 40 41 42
43 44 45 46 47 48 49 50 51 52 53 54 55 56
57 58 59 60 61 62 63 64 65 66 67 68 69 70
71 72 73 74 75 76 77 78 79 80 81 82 83 84
After-sales Service Email: tech-support@ibuture.com
ISSUE SOLUTION
Vacuum cleaner
not work
Weak suction
CAUSE
①Out of power
②Battery pack not installed in place
or has failed
③Motor has failed
①Full charge the vacuum cleaner
②Battery pack installed in place
③Contact BuTure Team via email for
replacing the battery or motor
①Dust cup is full of garbage
②Motorized floor brush, tube or
filters is clogged with garbage
③Low battery power
①Empty the dust cup
②Clear out any garbage that is
blocking the motorized floor brush,
tube or filters
③Full charge the vacuum cleaner
Charging is not
normal
①Charger is not correctly connected
②Battery pack or charger has failed
③Charger is not original
①Make sure the charger are fully
plugged in socket
②Contact BuTure Team via email for
replacing the battery or charger
③Use the original charger provided by
BuTure
Insufficient running
time after charging
①Insufficient charging time
②Motorized floor brush, dust cup,
tube or filters is clogged with garbage
③Battery aging
①Full charge the vacuum cleaner
②Clear out any garbage that is
blocking the motorized floor brush,
dust cup, tube or filters
③Contact BuTure Team via email for
replacing the battery
Motorized brush
head not rotate
①Brush roller are blocked with hair,
pebbles or other debris
②Dust cup is full of dust
③The brush may be defective
①Clean the brush roller
②Empty the dust cup
③Connect the brush head with the
main body to see if it would spin or not,
then contact us
8.TROUBLESHOOTING
EN01 02 03 04 05 06 07 08 09 10 11 12 13 14
15 16 17 18 19 20 21 22 23 24 25 26 27 28
29 30 31 32 33 34 35 36 37 38 39 40 41 42
43 44 45 46 47 48 49 50 51 52 53 54 55 56
57 58 59 60 61 62 63 64 65 66 67 68 69 70
71 72 73 74 75 76 77 78 79 80 81 82 83 84
After-sales Service Email: tech-support@ibuture.com
9.WARRANTY
9.1 The 2-Year Limited Warranty
• Our BuTure machine has a 2-year warranty against original defects in material and workmanship,
when used for private household purposes in accordance with the BuTure Instruction Manual.
• This warranty provides, at no extra cost to you, all labor and parts necessary to ensure your
machine is in proper operating condition during the warranty period.
9.2 What is covered?
Only applies to purchases made from authorized retailers of BuTure.
This warranty will only be valid if the machine is used in the country in which it was sold.
9.3 How to claim?
Please keep your proof of purchase. To make a claim under our warranty, you need to provide your
original purchase receipt with the purchase date and order number on it.
If your machine is not functioning properly, or you still have any questions after reading this
manual carefully, please feel free to contact us, we will reply to you in 24 hours and try our
best to provide you with a satisfactory solution.
Email our Customer Service: [email protected]
EN01 02 03 04 05 06 07 08 09 10 11 12 13 14
15 16 17 18 19 20 21 22 23 24 25 26 27 28
29 30 31 32 33 34 35 36 37 38 39 40 41 42
43 44 45 46 47 48 49 50 51 52 53 54 55 56
57 58 59 60 61 62 63 64 65 66 67 68 69 70
71 72 73 74 75 76 77 78 79 80 81 82 83 84
After-sales Service Email: tech-support@ibuture.com
Declaration of Conformity
We (Manufacturer is responsible for this declaration)
Ekoo Electronic Co.,Ltd.
(Company name)
B09,block B,f2,bldg.b,runfeng Pioneer Park,no.973, minzhi Avenue, Minzhi St.,
Longhua, Shenzhen, CN
(Company address)
declare under our sole responsibility that the product
Trade name: BUTURE
Equipment: VC30 Cordless Vacuum Cleaner
Model No. : VC30
to which this declaration relates is in conformity with the essential requirement set
out in the Council Directive on the Approximation of the laws of the Member
States relating to LVD Directive(2014/35/EU) & EMC Directive(2014/30/EU) &
RoHS(2011/65/EU) product is responsible to affix CE marking, the following
standards were applied:
EN 60335-2-2:2010+A11:2012+A1:2013
EN 60335-1:2012+A11:2014+A13:2017+A1:2019+A14:2019+A2:2019
EN 62233:2008
EN 55014-1:2021
EN 55014-2:2021
EN IEC 61000-3-2:2019+A1:2021
EN 61000-3-3:2013+A2019
IEC62321-3-1:2013
IEC62321-4:2013
IEC62321-5:2013
IEC62321-6:2015
IEC62321-7-1:2015
IEC62321-7-2:2017
IEC62321-8:2017
Full Name: George.wang Position: Approbation Manager
Signature: George.wang Place/Date: Shenzhen,China/Doc.03-2021
Correct Disposal of this product
This marking indicates that this product should not be
disposed with other household wastes throughout the EU.
To prevent possible harm to the environment or human
health from uncontrolled waste disposal, recycle it
responsibly to promote the sustainable reuse of material
resources. To return your used device, please use the
return and collection systems or contact the retailer where
the product was purchased. They can take this product for
environmental safe recycling.
We (Manufacturer is responsible for this declaration)
Ekoo Electronic Co.,Ltd.
(Company name)
B09,block B,f2,bldg.b,runfeng Pioneer Park,no.973, minzhi Avenue, Minzhi St.,
Longhua, Shenzhen, CN
(Company address)
declare under our sole responsibility that the product
Trade name: BUTURE
Equipment: VC30 Cordless Vacuum Cleaner
Model No. : VC30
to which this declaration relates is in conformity with the essential requirement set
out in the Council Directive on the Approximation of the laws of the Member
States relating to LVD Directive(2014/35/EU) & EMC Directive(2014/30/EU) &
RoHS(2011/65/EU) product is responsible to affix CE marking, the following
standards were applied:
EN 60335-2-2:2010+A11:2012+A1:2013
EN 60335-1:2012+A11:2014+A13:2017+A1:2019+A14:2019+A2:2019
EN 62233:2008
EN 55014-1:2021
EN 55014-2:2021
EN IEC 61000-3-2:2019+A1:2021
EN 61000-3-3:2013+A2019
IEC62321-3-1:2013
IEC62321-4:2013
IEC62321-5:2013
IEC62321-6:2015
IEC62321-7-1:2015
IEC62321-7-2:2017
IEC62321-8:2017
Full Name: George.wang Position: Approbation Manager
Signature: George.wang Place/Date: Shenzhen,China/Doc.03-2021
We (Manufacturer is responsible for this declaration)
Ekoo Electronic Co.,Ltd.
(Company name)
B09,block B,f2,bldg.b,runfeng Pioneer Park,no.973, minzhi Avenue, Minzhi St.,
Longhua, Shenzhen, CN
(Company address)
declare under our sole responsibility that the product
Trade name: BUTURE
Equipment: VC30 Cordless Vacuum Cleaner
Model No. : VC30
to which this declaration relates is in conformity with the essential requirement set
out in the Council Directive on the Approximation of the laws of the Member
States relating to LVD Directive(2014/35/EU) & EMC Directive(2014/30/EU) &
RoHS(2011/65/EU) product is responsible to affix CE marking, the following
standards were applied:
EN 60335-2-2:2010+A11:2012+A1:2013
EN 60335-1:2012+A11:2014+A13:2017+A1:2019+A14:2019+A2:2019
EN 62233:2008
EN 55014-1:2021
EN 55014-2:2021
EN IEC 61000-3-2:2019+A1:2021
EN 61000-3-3:2013+A2019
IEC62321-3-1:2013
IEC62321-4:2013
IEC62321-5:2013
IEC62321-6:2015
IEC62321-7-1:2015
IEC62321-7-2:2017
IEC62321-8:2017
Full Name: George.wang Position: Approbation Manager
Signature: George.wang Place/Date: Shenzhen,China/Doc.03-2021
