022023-BR
Outdoor Screens Drape Skirt
120” – 145” Models | User’s Guide
__________________
Model Number
Length x Height
Compatible Outdoor Screen Products
ZOMS2PL-DK
176.7”x60”
Portable Fast-Folding Screen : 120” – 145” models
*** Drape skirt for this model may be longer than the height of the screen
Parts List \
Please make sure all parts listed below are included before installation.
Drape Skirt *1pcs
Plastic Clips *16-20pcs
ZOMS2PL-DK* 20pcs
Setup Instructions
1. Place all plastic clips on the bottom side of the frame, over
the screen material. (do not pleat the material)
2. Place 4 clips to face the opposite direction as
shown here. (2 on each end)
3. Attach the skirt on to the Velcro starting in the middle of
the frame and then to the outer edges.
4. Attach any excess material to the clips that are
facing the opposite direction. (back of the frame)
5. Reverse steps to dismantle the skirt for storing.
Note: Direct sunlight and high temperatures may cause for
the adhesive of the Velcro to dissolve. Store the skirt and clips
in a cool, dry area.
For more information or technical support,
please visit www.akiascreens.com
