1
18” Floor Fan Chrome
Model No. COL1572
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
2
18” Floor Fan Chrome
Model No. COL1572
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
READING AND STORING THE USER MANUAL
Before using this product, please read through this manual
carefully paying particular attention to the safety instructions.
Failure to do so may result in personal injury or damage to the
product.
Carefully save this instruction manual for future reference. Ensure the
user manual is included when passing the product on to any third
parties.
Only use the product as described in this user manual. Any other
use is considered improper and may result in damage to
property or persons.
The manufacturer or vendor cannot be held liable for damages
or injury incurred through improper or incorrect use.
• Read and familiarise yourself with all operating
instructions before using this 18” Floor Fan.
• Before plugging your unit into the mains, visually check
that the unit is intact and has not suffered any transit
damage.
• DO NOT use this product with a programmer, timer,
separate remote-control system or any other device.
• Check that the voltage indicated on the data plate
corresponds with that of the local network before
connecting the appliance to the mains power supply.
• This appliance can be used by children aged from 8 years
and above and persons with reduced physical sensory or
mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction
concerning use of the appliance in a safe way and
understand the hazards involved. Children shall not play
with the appliance. Cleaning and user maintenance shall
not be made by children without supervision.
• Close supervision is required when using this appliance
near children.
• Never leave this appliance within reach of children
• Children of less than 3 years should be kept away unless
continuously supervised.
3
18” Floor Fan Chrome
Model No. COL1572
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
• DO NOT immerse the appliance or its cord in water or any
other liquids.
• DO NOT leave the appliance unattended during use.
• DO NOT leave the appliance unattended whilst connected
to the mains supply
• Always use this appliance on solid, level, surface.
• DO NOT use this appliance outdoors.
• It is imperative to unplug the power cord after the
appliance has been used, before it is cleaned and whilst
being repaired.
• Repairs to electrical appliances should be performed by
qualified personnel. Improper repairs may place user at
serious risk.
• DO NOT operate this appliance with a damaged plug or
cord, after a malfunction or after being dropped or
damaged in any way.
• Regular, periodic checks should be carried out on the
mains cable to ensure no damage is evident. Should there
be any signs of damage the appliance should not be used.
• If the power cable is damaged, it should only be replaced
by suitably qualified personnel in order to avoid a hazard.
• DO NOT allow the mains cable to hang over sharp edges
or come in contact with hot surfaces.
• DO NOT run the mains cable under carpets, rugs, etc.
• This appliance is intended for household use only and
should not be used for industrial purposes.
• DO NOT use any accessories or attachments with this
appliances other than those supplied or recommended by
the supplier.
• DO NOT use this appliance for anything other than
intended use.
• DO NOT push objects (including fingers) into the fan grill
or any openings as this could risk injury or damage to the
appliance.
• Unplug after each use. Grasp the plug not the cord.
4
18” Floor Fan Chrome
Model No. COL1572
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Explanation of Symbols
The following warning symbols or words are used in this instruction manual:
Products labelled with UK Conformity Assessment identifies
products conforming to UK statutory requirements.
Products labelled with this symbol conform to applicable
provisions of the European Economic Area.
You should now recycle your waste electrical goods and in
doing so help the environment. This symbol means waste
electrical products at the end of their useful life should not be
disposed of with normal household waste and not sent to
landfill. Please ensure it is taken to a suitable facility for
disposal. Check with your Local Authority or retailer for
recycling advice or visit www.recycle-more.co.uk enter your
postcode to find out your nearest recycling site.
This symbol provides useful additional information on the use
of this product.
This symbol indicates that the supply uses an alternating
current mains supply.
5
18” Floor Fan Chrome
Model No. COL1572
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Description of Parts
Before first use of your Fan
Remove all packing materials and discard responsibly.
Ensure all parts are present – see Description of parts above.
Check that there is no transit damage to the mains cable or product.
Operating your Fan
1. Place the fan on a stable level surface.
2. Ensure that the On/Off/Speed Switches (10) has the ‘0’
switch be pressed to ensure the fan is in the ‘off’ mode.
3. To alter the vertical tilt position, move the Fan Guard (1)
up & down accordingly.
Never adjust the fan whilst connected to the mains and/or switched on.
Ensure the fan is in the ‘off’ mode before inserting the Power Cord (6) into
the nearest socket.
• Press button 1 for the low speed.
• Press button 2 for the medium speed.
• Press button 3 for the high speed.
• Press button 0 to switch the fan off.
To carry the fan, lift by the built in Carrying Handle (9).
1. Fan Guard
2. Fan Blade
3. Pivot
4. Stand with Feet
5. Guard Screw and Nut
6. Power Cord and Plug
7. Guard Retaining Clips x 5
8. Blade Retaining Screw and Nut
9. Carrying Handle
10. On/Off/Speed Switches
11. Motor Housing
12. Clips x 5
1
2
3
4
6
7
9
10
5
8
6
18” Floor Fan Chrome
Model No. COL1572
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Care and Maintenace of Your Fan
Ensure that the fan is switched off and it is not connected to the
mains supply before cleaning.
Do not immerse the fan or its cord in water or any other liquid.
Wipe the fan body clean with a clean, soft damp cloth.
Please refer to below to disassembly instructions for cleaning:
1. Release the Guard Retaining Clips (7) from around the outer edge of the Fan
Guard (1).
2. Remove the Guard Screw and Nut (5) from the bottom edge of the Fan Guard
(1) using a suitable pozidrive screwdriver (not supplied).
3. Carefully lift off the Fan Guard (1) front section.
4. Unscrew the Blade Retaining Screw (8) holding the Fan Blade (2) to the motor
spindle and take care not to lose the nut.
5. Remove the Fan Blade (2) from motor spindle.
6. Clean the Fan Guard (1) and Fan Blade (2) using a soft damp cloth, clean the
Motor Housing using a soft brush.
7. Once the fan has been cleaned, reassemble the fan using the above procedure
in reverse.
5
8
2
7
1
7
18” Floor Fan Chrome
Model No. COL1572
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Non-Rewireable Mains Plug
If your appliance is supplied with a non-rewireable plug fitted to the mains lead
and should the fuse needed replacing, you must use an ASTA approved one
(conforming to BS 1362 of the same rating). Never use a plug with the fuse cover
missing. If in doubt, consult a qualified electrician.
If you need to remove the plug - DISCONNECT FROM THE MAINS - and then cut it
off the mains lead an immediately dispose of it safely. Never attempt to reuse the
plug or insert it into a socket outlet as there is a danger of electric shock.
Technical Specification
Model No.
COL1572
Voltage
220-240V~ 50/60Hz
Rated Power
90W
Protection Class
I (This Appliance Must be Earthed)
Recycling Information
Disposal of the Packaging
Dispose of paper and cardboard in appropriate paper re-cycling facilities.
Dispose of recyclable plastics in appropriate plastic re-cycling facilities.
Dispose of non-recyclable plastics in the appropriate plastics collection service.
Disposal of the Product
You should now recycle your waste electrical goods and in doing so
help the environment. This symbol means waste electrical products
at the end of their useful life should not be disposed of with normal
household waste and not sent to landfill. Please ensure it is taken to
a suitable facility for disposal. Check with your Local Authority or
retailer for recycling advice or visit www.recycle-more.co.uk, enter
your postcode to find out your nearest recycling site.
8
18” Floor Fan Chrome
Model No. COL1572
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
9
18” Floor Fan Chrome
Model No. COL1572
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
WARRANTY
Thank you for purchasing your Daewoo product.
As part of our commitment to quality, we are offering you an extra 2 years warranty in
addition to your 1 year guarantee
Your Daewoo product is guaranteed for 1 year from the date of original purchase, with proof
of purchase or receipt. If any defect should occur due to faulty workmanship or material, your
faulty product should be returned to the place of purchase, replacement or refund is at the
discretion of the retailer.
The guarantee is subject to the following provisions:
•
The product must be correctly installed and operated in accordance with the
requirements contained in the instruction manual.
•
The product must be used solely for domestic purposes.
•
It does not cover general wear and tear, damage, misuse or any consumable parts.
•
The guarantee will be rendered invalid if the product is re-sold or has been damaged through
inexpert repair.
•
The guarantee is only valid within the UK and Eire.
Your standard 1 year guarantee will only be extended to the maximum available for your
individual product upon registration. (Note: products must be registered individually and
covers the main body and housing). If you do not register your product within 28 days of the
original purchase date, your product will only be guaranteed for 1 year.
To validate your extended 2 year warranty*please register your purchase online within 28
days of the original purchase date by registering at:
https://help.daewooelectricals.com
or
Contact Us (daewooelectricals.com)
*Your extended warranty is only valid with proof of purchase receipt and subject to the
conditions outlined above.
Daewoo is a registered trademark.
Produced and imported under licence by
Eurosonic Group Limited
Brightgate House
1 Brightgate Way
Manchester M32 0TB UK
EU Rep: EuroSonic Magppie (ESM) Ltd. Ireland D05 X006
www.esgltd.com
