Window Air Conditioner
MAW
USER MANUAL
Warning notices: Before using this product, please read this manual carefully and keep it for future reference.
7KHGHVLJQDQGVSHFL´FDWLRQVDUHVXEMHFWWRFKDQJHZLWKRXWSULRUQRWLFHIRUSURGXFWLPSURYHPHQW
&RQVXOWZLWK\RXUGHDOHURUPDQXIDFWXUHUIRUGHWDLOV
7KHGLDJUDPDERYHLVMXVWIRUUHIHUHQFH3OHDVHWDNHWKHDSSHDUDQFHRIWKHDFWXDOSURGXFWDVWKHVWDQGDUG
MAW05R1JWT-B/MAW06R1JWT-B/
MAW08S1JWT-B/MAW12S1JWT-B
2
CONTENTS
THANK YOU LETTER
Thank you for choosing Midea! Before using your new Midea product, please read this manual
thoroughly to ensure that you know how to operate the features and functions that your new air
conditioner offers in a safe way.
THANK YOU LETTER ...............................................................................................................2
SAFETY INSTRUCTIONS ........................................................................................................3
PRODUCT INSTALLATION ....................................................................................................7
OPERATION INSTRUCTIONS ..............................................................................................14
REMOTE CONTROL AND APP INSTRUCTIONS .........................................................19
CLEANING AND MAINTENANCE......................................................................................33
TROUBLESHOOTING TIPS ..................................................................................................34
WARRANTY ...............................................................................................................................36
3
SAFETY INSTRUCTIONS
Intended Use
The following safety guidelines are intended to prevent unforeseen risks or damage from unsafe or incorrect
operation of the appliance. Please check the packaging and appliance on arrival to make sure everything
is intact to ensure safe operation. If you fi nd any damage, please contact the retailer or dealer. Please note
modifi cations or alterations to the appliance are not allowed for your safety concern. Unintended use may cause
hazards and loss of warranty claims.
Read these operating instructions carefully and attentively before using/commissioning the unit and keep them
in the immediate vicinity of the installation site or unit for later use!
CAUTION
• For support, please call the Service Center at 1-866-646-4332.
• This appliance is not intended for use by people (including children) with reduced physical, sensory, or
mental capabilities or lack of experience and knowledge, unless they have been given supervision or
instruction concerning use of the appliance by a person responsible for their safety.
• Children should be supervised to ensure that they do not play with the appliance.
• The appliance shall be installed in accordance with national wiring regulations.
• Do not operate your air conditioner in a humid room such as a bathroom or laundry room.
Explanation of symbols displayed on the unit
WARNING
This symbol shows that this appliance used a fl ammable refrigerant. If the
refrigerant is leaked and exposed to an external ignition source, there is a
risk of fi re.
CAUTION This symbol shows that the operation manual should be read carefully.
CAUTION
This symbol shows that a service personnel should be handling this
equipment with reference to the installation manual.
CAUTION
This symbol shows that information is available such as the operating
manual or installation manual.
Caution: Risk of fi re/fl ammable materials
(Required for R32 units only)
IMPORTANT NOTE: Read this manual carefully before
installing or operating your new air conditioning unit. Make
sure to save this manual for future reference.
4
WARNING
• Be sure the air conditioner has been securely and correctly installed according to the installation instructions
in this manual. Save this manual for possible future use in removing or installing this unit.
• Plug in power cord plug properly.
Otherwise, it may cause electric shock or fi re due to excess heat generation.
• Do not modify power cord length or share the outlet with other appliances as it may cause electric shock or
fi re due to overheating.
• Always ensure effective grounding.
Incorrect grounding may cause electric shock.
• Unplug the unit if you notice unusual sounds or smells or smoke coming from it.
A damaged product may cause fi re and electric shock.
• Ventilate room before operating the air conditioner if there is a gas leakage from another appliance.
• Do not operate or stop the unit by inserting or pulling out the power cord plug.
• Do not operate with wet hands or in very humid environments.
It may cause electric shock.
• Do not allow water to come into contact with any electric parts.
It may cause failure or electric shock.
• Do not use the socket if it is loose or damaged.
It may cause fi re and electric shock.
• Do not use or keep the power cord close to heating appliances.
It may cause fi re and electric shock.
• Do not use any devices or materials for installation that are not recommended in this manual.
• Do not disassemble or modify unit.
It may cause failure and electric shock.
• Do not damage or use an alternate power cord.
It may cause fi re and electric shock.
If the power cord is damaged, it must be replaced by the manufacturer or an authorized service center or a
similarly qualifi ed person in order to avoid a hazard.
• Do not direct airfl ow straight into persons to avoid possible health hazard.
• Do not open the unit during operation.
It may cause electric shock.
• Do not use the power cord near fl ammable gas or combustibles, such as gasoline, benzene, thinner, etc.
It may cause an explosion or fi re.
• Do not let children hang on the air conditioner or bracket.
A serious injury may occur.
• Avoid fi re hazard or electric shock. Do not use an extension cord or an adaptor plug. Do not remove any
prongs from the power cord.
• Be sure the air conditioner is properly grounded. To minimize shock and fi re hazards, proper grounding is
important. The power cord is equipped with a three-prong grounding plug for protection against shock
hazards.
• Your air conditioner must be used in a properly grounded wall receptacle. If the wall receptacle you intend
to use is not adequately grounded or protected by a time delay fuse or circuit breaker, have a qualifi ed
electrician install the proper receptacle. Ensure the receptacle is accessible after the unit installation.
• Be sure the electrical service is adequate for the model you have chosen. This information can be found on
the serial plate, which is located on the side of the cabinet and behind the grille.
• Do not drink the drain water. It may contain mold and bacteria that can lead to death if ingested.
5
CAUTION
• When the air fi lter is to be removed, do not touch the metal parts of the unit.
It may cause injury.
• When the unit needs cleaning, switch off, and turn off the circuit breaker.
Do not clean unit when power is on as it may cause fi re, electric shock or injury.
• Do not place obstacles around air inlets or inside of air outlet.
It may cause failure or accident.
• Clean with a soft cloth only. Do not use strong detergents that contain wax or thinners as it may damage
the product.
• Use caution when unpacking and installing. Sharp edges could cause injury.
• Do not clean the air conditioner with water.
Water may enter the unit and degrade the insulation which could lead to electric shock.
• Do not put a pet or house plant where it will be exposed to direct air fl ow.
This could injure the pet or harm the plant.
• Hold the plug by the head of the power plug when taking it out.
Otherwise, it may cause electric shock and damage.
• Ensure that the installation is properly secured to prevent the product from potentially falling.
• Do not place heavy objects on the power cord and ensure that the cord is not compressed.
Otherwise, there is danger of fi re or electric shock.
• If water is spilled on the unit, turn off the unit and switch off the circuit breaker. Isolate supply by taking the
power-plug out and contact a qualifi ed service technician.
• Do not use near gas stove or other gas burning appliances, as air fl ow may affect gas combustion.
• Do not use for any purpose other than room comfort.
• Do not use this air conditioner to preserve precision devices, food, pets, plants, and art objects. It may cause
deterioration.
• Turn off the main power switch if the unit is not to be used for an extended time.
• Always insert the fi lters securely. Clean fi lter once every two weeks.
Operation without fi lters may cause failure.
WARNING
• Do not try to accelerate the defrosting process or methods of cleaning that are not recommended by the
manufacturer.
• The appliance shall be stored in a room without a continuously operating ignition source (for example, open
fl ames or an operating gas appliance) or an ignition source (for example, an operating electric heater) close
to the appliance. The appliance shall also be stored in a room without ignition sources.
• Do not pierce or burn.
• Be aware that the refrigerants may not contain an odor.
• Keep ventilation openings clear of obstruction.
• Unit is only to be serviced by a Midea authorized servicer, please call Customer Service at 1-866-646-4332
for support.
• Flammable refrigerant R32 is used within air conditioner. Please follow the instructions carefully to handle,
install, clean, and service the air conditioner to avoid damage or hazard. Do not dispose of air conditioner in
regular trash. Contact qualifi ed agency for proper disposal.
• No open fi re or devices that generate spark/arcing shall be around the air conditioner to avoid causing
ignition of the fl ammable refrigerant used. Please follow the instructions carefully to store or maintain the air
conditioner to prevent mechanical damage from occurring.
6
Operation of Current Device
The power supply cord contains a current measuring device that detects
damage to the power cord. Test your power supply cord as follows:
1. Plug in the air conditioner.
2. The power supply cord will have TWO buttons on the plug head. Press
the TEST button. You will notice a click as the RESET button pops out.
3. Press the RESET Button. You will notice a click as the button engages.
4. The power supply cord is now supplying electricity to the unit. (On
some products this is also indicated by a light on the plug head.)
RESET
TEST
Plug in &
press RESET
The power supply cord with this air conditioner contains a current
detection device designed to reduce the risk of fi re.
In the event that the power supply cord is damaged, it can not be
repaired. It must be replaced with a cord from the manufacturer.
NOTE
• Do not use this device to turn the unit on or off.
• Always make sure the RESET button is pushed in for correct operation.
• The power supply cord must be replaced if it fails to reset when either
the TEST button is pushed, or it can not be reset. Please contact
Customer Service.
NOTE
Do not, under any
circumstances, cut,
remove or bypass
the grounding prong.
Power supply cord with
3-prong grounding plug and
current detection device.
Grounding type wall receptacle
Do not, under any
circumstances, cut,
remove or bypass
the grounding prong.
7
PRODUCT INSTALLATION
Window Requirements
WARNING - Before You Begin
Read these instructions completely and carefully.
• IMPORTANT - Save these instructions.
• IMPORTANT - Observe all governing codes and ordinances.
We recommend that two people install this product.
Proper installation is the responsibility of the installer.
Product failure due to improper installation is not covered under the Limited Warranty.
You MUST use all supplied parts and use proper installation procedures as described in these instructions when
installing this air conditioner.
Do not, under any circumstances, cut or remove the third (ground) prong from the power cord.
Do not change the plug on the power cord of the air conditioner.
Aluminum house wiring may present special problems - consult a qualifi ed electrician.
When handling the air conditioner, be careful to avoid cuts from sharp metal edges and aluminum fi ns on front
and rear coils. Please wear cut-resistant gloves.
Your air conditioner is designed to install in
standard double hung windows with opening
widths of 23 to 36 inches (584mm to 914mm).
Save carton and these Installation Instructions for future reference. The carton is the best way to store unit
during winter, or when not in use.
NOTE
Table 1
Model 5000 BTU/h 6000 ~ 8000 BTU/h
H 13 in (330 mm) 14 in (356 mm) 15-1/2 in (394 mm)
Wooden Windows
INNER
WINDOW
SILL
INTERIOR
WALL
13.75" min
(349 mm)
23" to 36"
(584 mm
to 914mm)
H
12000 BTU/h
8
Tools You Will Need
Mounting Hardware
3/4” (1/2”) Screws 7
Window Sash Seal Foam 1
Lock Frame
(For Wooden Windows)
2
Lock Frame
(For Vinyl-Clad Windows)
2
Sash Lock 1
Top Rail Hardware
3/8” Screws 4
Top Rail 1
Drill and 1/8” drill bit Proper PPE
Phillips Screwdriver Level Flathead Screwdriver
Pencil Ruler or tape measure Scissors or knife
Installation Hardware
NOTE
The MAW12 comes with its own top rail, so there
is no additional top rail.
9
1. Prepare the Window
2. Prepare the Air Conditioner
• For safety reasons, all four (4) screws MUST be securely fastened.
• Before installing unit, the top rail must be assembled on the unit.
NOTE
Lower sash must open suffi ciently to allow a clear vertical opening (see dimension H in Table 1). Side louvers
and the rear of the AC must have clear air space to allow enough air ow through the condenser for heat
removal. The rear of the unit must be outdoors, not inside a building or garage.
Before installing the unit, the top rail must be
assembled on the unit for some models with
a capacity of less than 10,000Btu/h.
A. Remove the air conditioner from the
carton and place on a at surface.
B. Remove top rail from the packaging
material as shown in Fig. A.
C. Align the hole in the top rail with those in the top of the unit as shown in Fig. B.
D. Secure the top rail to the unit with the 3/8” Screws as shown in Fig. C.
Top Rail
Top Rail
Packaging
Fig. A
MAW05/06 Model MAW08 Model
Fig. C
Fig. B
Fig. B
Fig. C
10
3. Install Accordion Panels on Air Conditioner
The Top rail and Sliding Panels on each side are offset to provide the proper pitch to the rear of the unit (5/16”).
This is necessary for proper condensate management and drainage. If you are not using the Side Panels for any
reason, this pitch to the rear must be maintained.
NOTE
A. Place unit on the fl oor, a bench or a table. Hold the Accordion Panel
in one hand and gently pull back the center to free the open end.
See Fig. 1.
Fig. 2
“
I
“ section
If storm window blocks AC, see Fig. 12.
NOTE
Fig. 4
Bottom Rail
Top RightTop Rail
Top Left
B. Slide the free end “
I
“ section of the panel directly into the cabinet as
shown in Fig. 2. Slide the panel down. Be sure to leave enough space
to slip the top and bottom of the frame into the rails on the cabinet.
C. Once the panel has been installed on the side of the cabinet, make
sure it sits securely inside the frame channel by making slight
adjustments.
Slide the top and bottom ends of the frame into the top and
bottom rails of the cabinet. Fig. 3.
D. Slide the panel all the way in and repeat on
the other side.
Fig. 1
Fig. 3
Top Rail
Bottom Rail
Top Rail
Bottom Rail
11
Fig. 6
Fig. 5
Check that air conditioner is tilted back per
dimension H (Fig. 5) (tilted about 3° to 4°
downward to the outside). After proper
installation, condensate should not drain
from the overfl ow drain hole during normal
use. Adjust the slope if otherwise.
NOTE
4. Install Air Conditioner
A. Keep a fi rm grip on the air conditioner,
carefully place the unit into the window
opening so the bottom of the air
conditioner frame is against the window
sill (Fig. 5). Carefully close the window
behind the top rail of the unit.
B. Extend the side panels out against the
window frame (Fig. 6).
Wooden Windows
INSIDE
OUTSIDE
H:About 3/4” to 1”
(for 5K to 8K)
Measure from the cabinet edge
3
H:About 1” to 1
/
8”
H
Vinyl-Clad Windows
INSIDE
OUTSIDE
H:About 3/4” to 1”
(for 5K to 8K)
Measure from the cabinet edge
3
H:About 1” to 1
/
8”
H
5. Secure Air Conditioner
Fig. 7A Fig. 7B
To prevent window sill from splitting, drill 1/8”
(3 mm) pilot holes before driving screws.
NOTE
A. Place the frame lock between the frame
extensions and the window sill as shown
(Fig. 7A for Wooden windows), (Fig. 7B
for Vinyl-Clad windows). Drive 3/4” (19
mm) or 1/2” (12.7 mm) locking screws
through the frame lock and into the sill.
Window
frame
Window
frame
(for 12k)
(for 12k)
12
Fig. 8A
B1: For wooden windows:
Drive 1/2” (12.7 mm) locking screws through the
top rail and into the window sash (Fig. 8A).
To prevent window sill from splitting, drill 1/8” (3mm)
pilot holes before driving screws. Drive 1/2” (12.7mm)
locking screws through frame holes into window sash
(Fig. 8B/8C).
NOTE
Before driving the screws, drill 5 holes into the
window through the holes of the top rail and side
panel frames as shown (Fig. 8B/8C).
NOTE
B2: For Vinyl-Clad windows:
Drive 1/2” (12.7 mm) locking screws through the
top rail and into the window sash (Fig. 8B/8C).
MAW08/12 Models
Fi
g
.8
Fig. 8D
MAW05/06 Models
Fig. 8C
13
REMOVING AC FROM WINDOW
Fig. 9
Fig. 10
FOAM SEA
L
FOAM SEAL
C. Secure lower sash in place by
attaching the sash lock with the
3/4” (19 mm) or 1/2” (12.7 mm)
screw as shown (Fig. 9).
D. Cut Window sash seal foam and
insert it in the space between
the upper and lower sashes
(Fig. 10).
• Turn AC off, and disconnect power cord.
• Remove sash seal from between windows, and unscrew sash lock.
• Remove screws installed through top rail and side panel frames.
• Slide the accordion panels into the rails to close.
• Keeping a fi rm grip on the air conditioner, raise the sash and carefully remove.
• Be careful not to spill any condensate while lifting unit from window. Store parts WITH air conditioner.
IF AC IS BLOCKED BY STORM WINDOW
Add wood as shown in Fig. 11, or remove storm
window before air conditioner is installed.
If storm window frame must remain, be sure
the drain holes or slots are not caulked or
painted shut. Accumulated rain water or
condensation must be allowed to drain out.
SASH
OUTSIDE INSIDE
1-1/2" min
(38 mm)
B
o
r
e
pi
e
n
w
Storm window
frame or other
obstruction.
Storm window
frame or other
obstruction.
Board thickness
as required, for
proper pitch to
rear, along entire
sill. Fasten with
nails or screws.
1-1/2” min
(38 mm)
INSIDE
SASH
OUTSIDE
Fig. 11
14
OPERATION INSTRUCTIONS
Normal Sounds
Sound of Rushing Air
In front of the unit, you may
hear the sound of rushing
air being moved by the fan.
High Pitched Chatter
High effi ciency compressors may have a
high pitched sound during cooling cycle.
Trickling Sound
Droplets of water
hitting condenser
during normal
operation may cause
a trickling sound.
Gurgle/Hiss
Gurgling or hissing noises may be heard
due to refrigerant fl owing through
evaporator during normal operation.
Vibration
Unit may vibrate and make
noise because of poor wall
or window construction or
incorrect installation.
All the illustrations in this manual are for explanation purpose only. The actual installation may vary.
NOTE
Gurgle/Hiss
Gurgling or hissing noises may be heard
due to refrigerant fl owing through
evaporator during normal operation.
Sound of Rushing Air
In front of the unit, you may
hear the sound of rushing
air being moved by the fan.
High Pitched Chatter
High effi ciency compressors may have a
high pitched sound during cooling cycle.
Vibration
Unit may vibrate and
make noise because of
poor wall or window
construction or
incorrect installation.
Trickling Sound
Droplets of water
hitting condenser
during normal
operation may cause
a trickling sound.
MAW05/06 Models
MAW10/12 Models
15
This air conditioner is designed to be operated under the following conditions:
Air Conditioner Features (general)
WARNING
To reduce the risk of fi re, electrical shock, or injury to people or property, read the SAFETY PRECAUTIONS
before operating this appliance.
Cooling Operation
Outdoor temperature: 64°F ~ 109°F / 18°C ~ 43°C
Indoor temperature: 62°F ~ 90°F / 17°C ~ 32°C
• The relative humidity of the room should be less than 80%. If the unit is used in a condition with a relative
humidity over 80%, there will be condensed water on the surface of the unit.
• Performance may be reduced outside of these operating temperatures.
NOTE
Air Conditioner Features
Air Directional Louvers
Always wait 3 minutes when turning the unit off and then on again, or when changing from cool to fan and back
to cool. This prevents damage from occurring to the compressor.
NOTE
To begin operating the air conditioner, follow these steps:
1. Plug in the air conditioner (be sure to follow the power cord instructions).
2. Turn the power on to the air conditioner, using the ON/OFF button.
3. Set the thermostat to the coldest temperature setting.
4. Select the Cool mode setting.
5. Adjust the louver for comfortable air fl ow (see Air Directional Louvers).
6. Once the room has cooled, adjust the thermostat to the setting you fi nd most comfortable.
7. Make sure the air fl ow inside and outside is not obstructed by anything.
The louvers will allow you to direct the air fl ow
Left or Right, or Up and Down (optional on some
models) throughout the room as needed.
Move the Levers from side to side until the
desired Left/Right direction is obtained.
You can also move the LEFT lever to adjust air
fl ow up/down as needed.
Levers
Air Direction
16
9
1
2 2
4
38
5
7
Air Conditioner Features (MAW05/06 Models)
17
2. TO CHANGE TEMPERATURE SETTING:
Press UP/DOWN button to change temperature
setting.
1. TO TURN UNIT ON OR OFF:
Press Power button to turn unit on or off.
Press or hold either UP ( ) or DOWN ( )
button until the desired temperature is seen on
the display.
NOTE
Description
1 • Press to turn unit on or off.ON / OFF
2
UP / DOWN
• Press to change temperature setting.Button
3 Fan Speed
• Press to select the Fan Speed in four steps - Auto, Low, Med
or High.
4 • Press to initiate the sleep mode.Sleep Function
5 • Press to turn off the cleaning filter reminder.Check Filter Feature
6
CONNECT
• Press to initiate smart connection mode. (Smart models only)Connect Function
7 Energy Saver Feature
• Press to initiate this feature, which will maintain comfort and
save energy.
8 Mode Fuctions
• Press to choose operating mode in a sequence that goes
from Auto, Cool, Dry and Fan.
9 • Press to turn unit Auto Start/Stop.Timer Feature
This temperature will be automatically
maintained anywhere between 62°F (17°C) and
86°F (30°C). If you want to display the actual
room temperature, see To Operate on Fan Only
section.
3. TO ADJUST FAN SPEEDS:
Press to select the Fan Speed in four steps - Auto, Low,
Med or High. Each time the button is pressed, the fan
speed mode is changed. On Dry mode, the fan operates
on Low speed automatically and cannot be changed.
On Auto mode, the fan operates on Auto fan speed
automatically and cannot be changed.
4. SLEEP FEATURE:
Press Sleep button to initiate the sleep mode. In this
mode the selected temperature will increase by 2°F
(1°C) 30 minutes after the mode is selected. The
temperature will then increase by another 2°F (1°C)
after an additional 30 minutes.
6 9 4 8 3 7 5 12 2
LED Display
with the remote.
then follow the symbol for the functions you desire. The unit can be controlled by the unit control alone or
Before you begin, thoroughly familiarize yourself with the control panel as shown below and all its functions,
ELECTRONIC CONTROL OPERATING INSTRUCTIONS
Air Conditioner Features (MAW08/12 Models)
This new temperature will be maintained for 7 hours
before it returns to the originally programmed mode
and the unit will continue to operate as originally
programmed mode.
The Sleep mode program can be canceled at any time
during operation by pressing the Sleep button again.
18
Displays
LED Display:
Shows the set temperature in “°C” or “°F” and the
Auto-timer settings. While on Fan Only mode, it
shows the room temperature. If the room temperature
is too high or low, it will display “HI” or “LO”.
Error codes:
AS - Room temperature sensor error - Unplug the
unit and plug it back in.
If error repeats, call for service.
ES - Evaporator temperature sensor error - Unplug
the unit and plug it back in.
If error repeats, call for service.
• To change the AC between Celsius and Fahrenheit
scales, press the temperature control arrows at
the same time for 5 seconds.
outage, it will restart with the previous function
setting automatically when the power resumes.
NOTE
The unit will automatically initiate the Energy Saver
function under Cool, Dry, Auto modes.
NOTE
To cancel timer operation, press and hold the timer
button for 2 seconds until the beep/buzzer is heard.
NOTE
5. CHECK FILTER FEATURE:
The Clean Filter indicator light is a reminder to clean
the air fi lter for more effi cient operation. The light
will illuminate after 250 hours of operation. After
cleaning the air fi lter, reset by pressing the Clean
Filter button. After resetting, the light will go off.
6. CONNECT FEATURE:
Press CONNECT button for 3 seconds to turn off the
unit and initiate smart connection mode.
For detailed instruction on how to connect your
7. ENERGY SAVER FEATURE (ECO):
Press Energy Saver button to initiate this function.
This function is available on COOL, DRY, AUTO (only
AUTO-COOLING and AUTO-FAN) modes. The fan will
continue to run for 3 minutes after the compressor
shuts off. The fan then cycles on for 2 minutes at 10
minute intervals until the room temperature is above
the set temperature, at which time the compressor
turns back on and Cooling resumes.
8. TO SELECT THE OPERATING MODE:
To choose operating mode, press Mode button.
Each time you press the button, a mode is selected
in a sequence that goes from Auto, Cool, Dry and
Fan. The indicator light adjacent will be illuminated
and remain on once the mode is selected.
When the unit is turned off and back on via the power
button, the unit will automatically switch on the Energy
Saver function for the following modes: Cool, Dry, Auto.
To operate on AUTO feature:
• When you set the air conditioner to AUTO mode,
it will automatically select cooling or fan only
operation depending on what temperature you
have selected and the current room temperature.
• The air conditioner will control room temperature
automatically according to temperature you’ve set.
• In this mode, the fan speed cannot be adjusted
as it’s automatically controlled according to
temperature setting and room temperature.
To operate on Fan Only:
• Use this function only when cooling is not desired,
such as for room air circulation or to exhaust stale
air (on some models). (Remember to open the
vent during this function, but keep it closed during
cooling for maximum cooling effi ciency.) You can
choose any fan speed you prefer.
• During this function, the display will show the
actual room temperature, not the set temperature
as in the cooling mode.
• In Fan Only mode, the temperature is not adjusted.
To operate on DRY mode:
• In this mode, the air conditioner will generally
function as a dehumidifi er. Since the conditioned
space is a closed or sealed area, some degree of
cooling will occur.
9. TIMER: AUTO START/STOP FEATURE:
• When the unit is on, press the Timer button. The
“Timer off ” LED indicator light will illuminate
indicating the Auto stop feature has been activated.
- When the unit is off, press the Timer button.
The “Timer on” LED indicator light will illuminate
indicating the Auto start feature has been activated.
• When the time of TIMER ON is displayed, press
the Timer button again. The TIMER OFF indicator
light illuminates. It indicates the Auto Stop
program has initiated.
• Press or hold the UP or DOWN button to change the
Auto time by 0.5 hour increments, up to 10 hours,
then at 1 hour increments up to 24 hours. The control
will count down the time remaining until start.
• The selected time will register in 5 seconds, and
the system will automatically revert back to
display the previous temperature setting or room
temperature when the unit is on. (when the unit is
off, there is no display.)
• The selected time indicates the amount of time
after the current time which you want the unit to
turn on or off. If you select Timer On and adjust
the time to 2.0h, the unit will turn on 2 hours after
the current time.
• Turning the unit ON or OFF at any time or
adjusting the timer setting to 0.0 will cancel the
Auto Start/Stop timed program.
Display
device, see page 29
• If the unit shuts off unexpectedly due to the power
19
Location of the remote control
Use the remote controller within a distance of 26.2 ft (8 meters) from
the air conditioner, pointing it towards the receiver. Reception is
confirmed by a beep.
Handling the Remote Control
•
The air conditioner will not operate if curtains, doors or other
materials block the signals from the remote control to the unit.
•
Prevent any liquid from spilling onto the remote control. Do not
expose the remote control to direct sunlight or heat.
•
If the infrared signal receiver on the indoor unit is exposed to
direct sunlight, the air conditioner may not function properly.
Use curtains to prevent the sunlight from falling on the receiver.
•
If other electrical appliances react to the remote control, either
move these appliances or consult your local dealer.
CAUTION
26.2 ft (8 meters)
NOTICE
Remote Controller Specifications
•
Button design is based on typical model and may vary slightly from the actual one you purchased.
•
All the functions described are accomplished by the unit. If the unit is without a feature, the unit will not
respond if the corresponding button on the remote is pressed.
•
illustration and the actual functions described in the USER’S MANUAL, the descriptions in the USER’S
MANUAL shall prevail.
the remote control
Rated Voltage: 3.0V (Dry batteries R03/LR03x2)
Environment: 23°F ~140°F (-5°~60°)
REMOTE CONTROL AND APP INSTRUCTIONS
FAN
ON/OFF
MODE
TEMP
TIMER
ON
SHORT
CUT
SLEEP
TIMER
OFF
ECO LED
20
Function Buttons
Before you begin using your new air conditioner, make sure to familiarize yourself with its remote
control. The following is a brief introduction to the remote control itself. For instructions on how to
operate your air conditioner, refer to pages 22-25.
ECO button
Press this button to activate the
Energy saving mode.
Press it again to stop the function
SHORT CUT
Sets and activates your favorite pre-settings.
TEMP
Increases temperature in 1° increments.
Max. temperature is 86°F (30°C).
TIMER ON
Sets timer to turn unit on (see page 24
for instructions)
TIMER OFF
LED
SLEEP
Saves energy during
sleeping hours.
TEMP
Decreases temperature in 1° increments.
Min. temperature is 62°F (17°C).
NOTE: Pressing and holding and
buttons together for 3 seconds will
alternate the temperature display
between the °F & °C scale.
Selects fan speeds in the
following order:
AUTO LOW MED HIGH
MODE
Scrolls through operation
modes as follows:
AUTO COOL DRY
HEAT FAN
NOTE:
Please do not select HEAT
mode if the machine you
purchased is cool-only type.
Heat mode is not supported
by cool-only models.
ON/OFF
FAN SPEED
for instructions)
FAN
ON/OFF
MODE
TEMP
TIMER
ON
SHORT
CUT
SLEEP
TIMER
OFF
ECO LED
Sets timer to turn unit off (see page 24
21
Information is displayed when the remote controller is powered up.
All indicators shown in the figure are for the purpose of clear presentation.
But during the actual operation, only the relative function signs are shown
on the display window.
Remote Screen Indicators
Note:
AUTO
COOL
DRY
HEAT
FAN
Transmission Indicator
Lights up when remote sends signal to unit
MODE display
Displays the current
mode, including:
TIMER ON display
Displays when
TIMER ON is set
TIMER OFF display
Displays when
TIMER OFF is set
Battery display
Low battery detection
SLEEP display
Displays when SLEEP
function is activated
FAN SPEED display
Displays selected FAN SPEED:
HIGH
MED
LOW
This display is blank when
set to AUTO speed.
Temperature/Timer display
Displays the set temperature by default, or timer setting
when using TIMER ON/OFF functions:
- Temperature range: 62°F-86°F (17°C-30°C)
- Timer setting range: 0-24 hours
This display is blank when operating in FAN mode.
ON/OFF display
Appears when the remote is enabled and can send a signal to the un
it.
If you would like to turn the remote off without affecting the unit, point
the remote away from the unit and press the ON/OFF button.
To turn the remote on, point the remote away from the unit and press
the ON/OFF button.
The unit will not receive commands from the remote if this indicator is
not illuminated.
FAN
ON/OFF
MODE
TEMP
TIMER
ON
SHORT
CUT
SLEEP
TIMER
OFF
ECO LED
SETTING THE DESIRED TEMPERATURE
The operating temperature range for this unit is 62°F-86°F (17-30°C).
You can increase or decrease the set temperature in 1°F or 1°C increments.
Changing the Mode
1. To change the operating mode, press the MODE button until the
desired mode appears on the remote’s display.
2. Set the desired temperature.
NOTICE
If the unit does not change when the button is pressed, check that
the ON/OFF indicator is illuminated. If it is not, point the remote at
the unit and press the ON/OFF button.
NOTICE
If the unit does not change when the button is pressed, check that
the ON/OFF indicator is illuminated. If it is not, point the remote at
the unit and press the ON/OFF button.
Changing the Fan Speed
To change the fan speed, press the FAN button until the desired fan
speed appears on the remote’s display.
1
3
2
1
2
3
22
How to Use the Buttons
FAN
ON/OFF
MODE
TEMP
TIMER
ON
SHORT
CUT
SLEEP
TIMER
OFF
ECO LED
FAN
ON/OFF
MODE
TEMP
TIMER
ON
SHORT
CUT
SLEEP
TIMER
OFF
ECO LED
23
How to Use the Advanced Functions
SHORTCUT Function
ECO button
SLEEP Function
The SLEEP function is used to decrease
energy use while you sleep (and don’t need
the same temperature settings to stay
comfortable).
Press this button to activate the
Energy saving mode.
Press it again to stop the function
Used to restore the current settings or resume
previous settings.
Push this button when remote controller is on,
the system will automatically revert back to the
previous settings including operating mode,
set temperature, fan speed level and sleep
feature (if activated).
By pressing for more than 2 seconds, the
system will automatically store the current
operation settings including operating mode,
set temperature, fan speed level and sleep
feature (if activated).
Note:
The SLEEP function is not
available in FAN or DRY mode.
24
Timer Functions
NOTICE
This number indicates the amount of time after the current time
after which you want the unit to turn on.
For example, if you set TIMER ON for 2 hours, “2.0h“ will appear on
the screen, and the unit will turn on after 2 hours.
Your air conditioning unit has two timer-related functions:
TIMER ON - sets the amount of time after which the unit will
automatically turn on.
TIMER OFF - sets the amount of tim
e after which the unit will
automatically turn off.
TIMER ON function
The TIMER ON function allows you to set a period of time after
which the unit will automatically turn on, such as when you come
home from work.
1. Press the TIMER ON button. By default, the last time period that
you set and an “h” (indicating hours) will appear on the display.
2sec
ON
/
O
F
F
M
O
DE
F
A
N
S
HO
RT
CU
T
TI
M
E
R
O
N
TI
M
E
R
O
F
F
TE
MP
S
L
E
E
P
1sec
x5
1
3
2
4
TIMER ON TIMER ON
Example: Setting unit to turn
on after 2.5 hours.
2. Press the TIMER ON button repeatedly to set the time that you
want the unit to turn on.
3. Wait 2 seconds, then the TIMER ON function will be activated.
The digital display on your remote control will then return to the
temperature display.
2
sec
x10
O
N
/
O
F
F
M
O
DE
F
A
N
S
HO
RT
CUT
T
I
M
E
R
O
N
TI
M
E
R
O
F
F
TE
MP
S
L
E
E
P
1
sec
1
3
2
4
Example: Setting unit to turn
off after 5 hours.
TIMER OFF function
The TIMER OFF function allows you to set a period of time after
which the unit will automatically turn off, such as when you wake up.
1. Press the TIMER OFF button. By default, the last time period that
you set and an “h” (indicating hours) will appear on the display.
2. Press the TIMER OFF button repeatedly to set the time that you
This number indicates the amount of time after the current time
after which you want the unit to turn off.
want the unit to turn off.
For example, if you set TIMER OFF for 2 hours, “2.0h“ will
appear on the screen, and the unit will turn off after 2 hours.
NOTICE
TIMER OFF TIMER OFF
FAN
ON/OFF
MODE
TEMP
TIMER
ON
SHORT
CUT
SLEEP
TIMER
OFF
ECO LED
25
Timer Functions (cont.)
3. Wait 2 seconds, then the TIMER OFF function will be activated.
The digital display on your remote control will then return to
the temperature display.
NOTICE
When setting the TIMER ON or TIMER OFF functions, up to 10
hours, the time will increase in 30 minute increments with each
press. After 10 hours and up to 24, it will increase in 1 hour
increments. The timer will revert to zero after 24 hours.
You can turn off either function by setting the timer to “0.0h“.
ON
/
O
F
F
M
O
DE
S
HO
RT
CUT
TI
M
E
R
O
N
TE
M
P
sec
4
ON
/
O
F
F
M
O
DE
S
HO
RT
CUT
TI
M
E
R
O
N
TE
M
P
sec
8
1
TIMER ON
X12
2
TIMER ON
5
TIMER OFF
X16
6
TIMER OFF
3
7
Setting both TIMER ON and
TIMER OFF at the same time
Keep in mind that the time periods
you set for both functions refer to
hours after the current time. For
example, say that the current time
is 1:00 PM, and you want the unit to
turn on automatically at 7:00 PM and
want it to operate for 2 hours, then
automatically turn off at 9:00 PM.
Do the following (side figure):
Example: Setting the unit to turn on after 6hours, operate for 2 hours, then turn off (see the figure below).
Timer is set
To turn ON
6 hours from
current time
Timer is set
To turn OFF
8 hours from
current time
Unit turns Unit turns
Timer
Starts
Your remote display
Continue
to press
TIMER ON
or
TIMER OFF
until desired
time is
reached.
26
NOTES
• Button design is based on a typical model and may slightly vary from the actual
one you purchased.
• This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference,
and (2) this device must accept any interference received, including interference
that may cause undesired operation.
• This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by
interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
- Changes or modifications not approved by the party responsible for compliance
could void users authority to operate the equipment.
Battery Warning:
Do not mix old and new batteries and Do not mix alkaline, standard (carbon-zinc)
or rechargeable (ni-cad, ni-mh, etc.) batteries
Unique Identifier: Midea brand，RG57J4(B)/BGCEU1
Responsible Party U.S. Contact Information
Midea America Corporation
300 Kimball Dr
Parsippany NJ
07054
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.
Telephone number or internet contact information: Midea.com/us
FCC Compliance Statement ( products subject to Part 15)
Supplier's Declaration of Conformity
47 CFR § 2.1077 Compliance Information
27
Declaration of Conformity
We hereby declare that this AC is in compliance with the essential requirements and other relevant provisions of
Directive 1999/5/EC.
Specification of Wireless Module
Model: US-SK105 Dimensions: 41 x 24 x 5 (mm)
Operation Temperature: 0°C ~ 45°C / 32°F ~ 113°F
Antenna Type: Printed PCB Antenna
Operation Humidity: 10% ~ 85%
Frequency: WLAN 2400-2483.5 MHz
Power Input: DC 5V/500 mA
Maximum Transmitted Power: <20 dBm Max
1. Supports operating systems: Please refer to page 28
2.
In the event of a OS update, there may be a delay between the update of the OS
and a related software update during which your OS may or may not be supported
until a new version is released. Your specific mobile phone or problems in your
network may prevent the system from working and Midea will not be responsible
for any problems that could be caused by incompatibility or network issues.
3.
This Smart AC only supports WPA-PSK/WPA2-PSK (recommended) encryption.
4.
To ensure proper scanning of the QR code, your smart phone must have at least a
5-megapixel camera.
5.
Due to unstable network connectivity, requests may time out. If this happens, rerun
the network configuration.
6. Due to unstable network connectivity, commands may time out. If this happens,
the smartphone app and the actual product may display conflicting information.
The information displayed on the actual product is always the most accurate
available. Refresh the app to re-sync.
PRECAUTIONS
28
Midea will not be responsible for any problems that could be caused by
incompatibility or network issues, your wireless router and mobile phone.
NOTICE
NOTE:
The functions shown in the Alexa, Google Home or Apple Home apps may change with updates to
their products or apps.
Setup processes and features may vary between ecosystems.
Periodically, we will update the device’s software to improve the experience.
Device software updates can be accomplished through the SmartHome app.
App & Smart Speakers can support Matter only when using these
versions or above.
9094439556
Google Play services min version: 22.36.15
Google Home app (GHA) min version: 2.58.24.1-dogfood
Google Hub firmware min version: 1.56.324896
(appears on hub as Chromecast firmware version)
2.2.536317
16.5
Device Version
iOS 16.5iPhone
Apple Home
Pod
Alexa Echo
Device
Android
Google
Home Hub
Alexa App
29
1
How to use SmartHome App (smart models only)
Ensure that your mobile phone is connected to the wireless network. Bluetooth must be turned on.
The device must also be powered up.
Scan the QR code below to download the SmartHome app from app store or search for it directly
on the Google Play Store or Apple's App Store.
Step 1: Download the SmartHome app
Open the SmartHome app. Log in directly if you have an existing SmartHome account or create a
new account. Alternatively, you can also use a 3rd party login platform.
Step 2: Log in
Download the app
& activate product
30
1) When you log in, you may see the message "Smart devices discovered nearby".
Tap to add your device.
2) If no such message appears, proceed as follows: Tap on "+" and select your device in the list of
nearby available devices.
If your device is not listed, please add your device manually, first selecting the device category e.g.
Window AC.
Step 3: Connecting the device
31
After pairing successfully, a card will be created for the device in the SmartHome app.
Shortcuts for basic functions will appear on the card such as changing the temperature or switching
Tapping on the card, will reveal additional features and settings. The actual UI design may look
Step 4: Controlling the device
SmartHome
3) Follow the steps in the app to connect your device to the wireless network. If your device fails to
connect, follow the additional instructions in the app.
Add device
For Window AC For Portable
AC
Add device
32
Declaration of conformity
FCC ID: 2ADQOMDNA21
IC: 12575A-MDNA21
This device complies with Part 15 of the FCC Rules and Industry Canada’s licence exempt
RSSs.
Operation is subject to the following two conditions:
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following
measures:
--Reorient or relocate the receiving antenna.
--Increase the separation between the equipment and receiver.
--Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
--Consult the dealer or an experienced radio/TV technician for help.
Hereby, we declare that this AC is in compliance with the essential requirements and
other relevant provisions of RE Directive 2014/53/EU. A copy of the full DoC is attached
(European Union products only).
Only operate the device in accordance with the instructions supplied. Changes or
could void the user's authority to operate the equipment.This device complies with FCC
radiation exposure limits set forth for an uncontrolled environment. In order to avoid the
possibility of exceeding the FCC radio frequency exposure limits, human proximity to the
antenna shall not be less than 20cm (8 inches) during normal operation.
(1) This device may not cause interference;and
(2) This device must accept any interference,including interference that may cause
undesired operation of the device.
NOTE:
33
CLEANING AND MAINTENANCE
Air Filter Cleaning
Cabinet Cleaning
Winter Storage
The air fi lter should be checked at least once every two
weeks to see if cleaning is necessary. Trapped particles in
the fi lter can build up and cause an accumulation of frost
on the cooling coils and reduce performance.
• Grasp the fi lter by the center and pull up and out.
• Wash the fi lter using warm water. Rinse fi lter thoroughly.
• Gently shake excess water from the fi lter. Be sure the
fi lter is thoroughly dry before replacing.
• Instead of washing, you may also vacuum the fi lter clean
rather than washing.
• Be sure to unplug the air conditioner to prevent shock or fi re hazard. The cabinet and front may be
dusted with an oil-free cloth or washed with a cloth dampened in a solution of warm water and mild liquid
dishwashing detergent. Rinse thoroughly and wipe dry.
• Never use harsh cleansers, wax, or polish on the cabinet front.
• Be sure to wring excess water from the cloth before wiping around the controls. Excess water in or around
the controls will cause damage to the air conditioner.
If you plan to store the air conditioner during the winter, remove it carefully from the window according to the
installation instructions. Cover the unit with plastic or return it to the original carton.
CAUTION
Clean your air conditioner occasionally to keep it looking new. Be sure to unplug the unit before cleaning to
prevent shock or fi re hazards.
Never use hot water over 104°F (40°C) to clean the air fi lter.
Never attempt to operate the unit without the air fi lter.
NOTE
MAW05/06 Models
MAW10/12 Models
34
TROUBLESHOOTING TIPS
Problem Solution
Air conditioner does not start.
Wall plug disconnected. Push plug fi rmly into wall outlet.
Circuit breaker tripped. Reset circuit breaker.
Check if the light on the plug is on. If it is off, press the RESET button.
Power is OFF. Turn power ON.
Unit turned off and then on quickly. Turn unit off and wait 3 minutes
before restarting.
Air from unit does not feel cold
enough.
Room temperature below 62°F (17°C). Cooling may not occur until room
temperature rises above 62°F (17°C).
Temperature sensor behind the air fi lter is touching the cold coil. Try to
move it so it does not contact the cold coil.
Reset to a lower temperature.
Compressor shut-off by changing modes. Wait approximately 3 minutes
and listen for compressor to restart when set in the COOL mode.
Check for potential obstructions blocking the outdoor intake/exhaust.
Clear any obstructions.
Air conditioner cooling, but room
is too warm - ice forming on
cooling coil behind air fi lter.
Outdoor temperature below 64°F (18°C). To defrost the coil, set to FAN
ONLY mode.
Air fi lter may be dirty. Clean fi lter. Refer to Cleaning and Maintenance
section. To defrost, set to FAN ONLY mode.
Thermostat set too cold for night-time cooling. To defrost the coil, set to
FAN ONLY mode. Then, set temperature to a higher setting.
Air conditioner cooling, but room
is too warm - NO ice forming on
cooling coil behind air fi lter.
Dirty or restricted air fi lter. Clean fi lter. Refer to Cleaning and Maintenance
section. To defrost, set to FAN ONLY mode.
Temperature is set too high, set temperature to a lower setting.
Air directional louvers positioned improperly. Position louvers for better
air distribution.
Front of unit is blocked by drapes, blinds, furniture, etc. - restricts air
distribution. Clear obstruction in front of unit.
Any open doors, windows, or registers may allow cold air to escape. Close
any doors, windows, or registers.
The room may be too warm. Allow additional time to remove “stored
heat” from walls, ceiling, oor and furniture.
Before calling for service, review this list. It may save you time and expense. This list includes common
occurrences that are not the result of defective workmanship or materials in this appliance.
35
Problem Solution
Air conditioner turns on and off
rapidly.
Dirty air fi lter - air restricted. Clean air fi lter.
Outside temperature extremely hot. Set FAN speed to a higher setting to
bring air past cooling coils more frequently.
Check for potential obstructions blocking the outdoor intake/exhaust.
Clear any obstructions.
Noise when unit is cooling.
Air movement sound. This is normal. If too loud, set to a slower FAN
setting.
Window vibration - poor installation. Refer to installation instructions or
check with installer.
Water dripping INSIDE when unit
is cooling.
Improper installation. Tilt air conditioner slightly to the outside to allow water
drainage. Refer to installation instructions - check with installer.
Water dripping OUTSIDE when
unit is cooling.
Unit removing large quantity of moisture from humid room. This is normal
during excessively humid days.
Remote sensing deactivating
prematurely (some models).
Remote control not located within range. Place remote control within
16.4 feet & 180°, radius of the front of the unit, and pointed in the general
direction of the air conditioner unit.
Remote control signal obstructed. Remove obstruction.
Room too cold. Temperature setting too low. Increase temperature setting.
Noise when unit starts.
A “da-da” sound may occur for thirty seconds when the unit is turned on
due to the compressor starting. It is normal.
Unit will not connect to
or App does not work (some
models).
For additional support and troubleshooting tips, visit the “Help” tab
within the SmartHome app.
Wireless
36
WARRANTY
Air Conditioner Limited Warranty
Your product is protected by this Limited Warranty:
Warranty service must be obtained from Midea Consumer Services or an authorized Midea servicer.
Warranty
• Two Year Full Warranty from original purchase date.
Midea, through its authorized services will:
• Pay all costs for repairing or replacing parts of this appliance which prove to be defective in materials or
workmanship.
Consumer will be responsible for:
• Diagnostics, removal, transportation and reinstallation cost required because of service.
• Costs of service calls that are a result of items listed under NORMAL RESPONSIBILITIES OF THE CONSUMER**
Midea replacement parts shall be used and will be warranted only for the original warranty.
NORMAL OF THE CONSUMER**
This warranty applies only to products in ordinary household use, and the consumer is responsible for the items
listed below:
2. Routine maintenance and cleaning necessary to keep the good working condition.
3. Proper installation by an authorized service professional in accordance with instructions provided with the appliance and
in accordance with all local plumbing, electrical and/or gas codes.
4. Proper connection to a grounded power supply of sufficient voltage, replacement of blown fuses, repair of loosen
connections or defects in house wiring.
5. Expenses for making the appliance accessible for servicing.
6. Damages to finish after intallation.
EXCLUSIONS
This warranty does not cover the following:
1) Failure caused by damage to the unit while in your possession (other than damage caused by defect or
malfunction), by its improper installation, or by unreasonable use of the unit, including without limitation, failure to
provide reasonable and necessary maintenance or to follow the written Installation and Operating Instructions.
2) Damages caused by serviced performed by persons other than those authorized by Midea customer service; or
external causes such as abuse, misuse, inadequate power supply or acts of God.
3) If the unit is put to commercial, business, rental, or other use or application other than for consumer use, we make
no warranties, express or implied, including but not limited to, any implied warranty of merchantability or fitness
for use or purpose.
4) Products without original serial numbers or products that have serial numbers which have been altered or cannot
be readily determined.
NOTICE: Some states do not allow the exclusions or limitation of incidental or consequential damages. So this
limitation or exclusion may not apply to you.
IF YOU NEED SERVICE
Keep your bill of sale, delivery slip, or some other appropriate payment Record.
The date on the bill establishes the warranty period, should service be required.
If service is performed, its your best interest to obtain and keep all receipts.
This written warranty gives you specific legal rights. You may also have other rights that vary from state to state.
Service under this warranty must be obtained by following these steps, in order:
1) Contact Midea Consumer Services or an authorized Midea services at 1 866 646 4332.
2) If there is a question as to where to obtain service, contact our consumer relations Departament.
RESPONSIBILITIES
1. Proper use of the appliance in accordance with instructions provided with the product.
CWS002IU-TYN8(GF)
20231109
