WWW.WATCHMARK.COM
USER MANUAL
Time, date
Pedometer
Brightness control
Calorie counter
Distance
Blood pressure
Saturation
Heart rate
Body temperature
ECG
Sports modes
Laser therapy
Stopwatch
Sleep monitor
Change of dial theme
Settings
11
12
13
14
TABLE OF CONTENTS
Introduction
About the watch
4
Device configuration
Packaging content
Hardware requirements
Charging the watch
Additional information
How to wear
a smartwatch?
7
Belt change
8
5
6
Applications and functions
Installing the app
9
Smartwatch functions
10
20
21
22
Measurement history
Blood pressure monitor
calibration
Sports modes
Care function
Movement reminder
Automatic monitoring of
health functions
Notifications
Do not disturb" mode
Alarm clock
Fever alarm
High heart rate alarm
ECG
Find phone
G-Sensor
Adjust screen brightness
Reset to factory settings
16
17
18
23
19
TABLE OF CONTENTS
General Information Applications and functions
Specifications
Product complaint
Product return
Product exchange
App functions
16
This is an advanced smartwatch for measuring health functions
and laser therapy. The smartwatch is equipped with many
functions to help take care of your health. The watch has the
latest generation of chips from Texas Instruments and OSRAM
measuring saturation, ECG and PPG. Thanks to the laser
therapy function, the smartwatch supports blood purification,
lowering hypertension and combating diabetes. The watch's
menu is in English.
Device configuration
Contents of the package
4
About Watchmark WF800
Introduction
Smartwatch (colour and
material may vary depending on
the colour chosen)
Strap (colour and material
may vary depending on the
colour chosen)
Charger (colour and material
may vary depending on the
model selected)
iOS 8.2 and above
Android 4.4 and later
Bluetooth supported: 5.0
Hardware requirements
Charging instructions
This smartwatch uses magnetic charging.
Attach the charging pad to the back charging contacts and
connect the charging cable to the USB input. Once connected,
charging will start automatically and the charging icon will appear
on the screen.
It takes approximately 2 hours to fully charge the battery. Do not
use the watch while it is charging.
Caution: do not connect the magnetic charging cable to any
2 contacts at the same time with conductive material, as this
may cause a short circuit.
Android 4.4+ IOS 8.2+
5
6
Please read the entire user manual carefully before using the
equipment. It is recommended to use only the original battery,
charger and accessories that are included in the kit received
with the device.
Neither the manufacturer nor the distributor is responsible for
the use of third-party accessories.
The functions that are presented in this manual may vary
between models, as the manual is a general description of
smartwatches. Some models may deviate from the standard.
Before using the device for the first time, charge it for a
minimum of 2 hours. Before using the device, you must
download and install the app and accept all consents that the
smartwatch asks for. If this is not done fully, not all features of
the device will be available. The smartwatch will only ask for
access to functions that are necessary for the smartwatch to
function properly.
The company reserves the right to change the content of this
manual.
Additional information
7
How to wear a smartwatch?
The strap for this watch model is 22 mm wide. It is
interchangeable and additional straps can be purchased in
a different colour or material.
Wearing the watch
When you're not exercising, wear the smartwatch as you
would a regular watch, i.e. one finger above your wrist bone.
To take full advantage of the heart rate monitoring function
during exercise, try wearing the device above your wrist
(2 fingers above your wrist bone) to improve comfort and
stability. Many exercises, such as cycling or weightlifting, can
cause the smartwatch's placement to change by bending the
wrist, for example. If the watch sits lower on the wrist bone
measurements can be intermittent, so correct placement
is important.
8
Belt change
Attach the original strap to the watch before using it. When
carrying out this operation, take careful care and watch out
for your fingernails when attaching the telescopes to the
watch.
Insert one end of the strap together with the telescope
into the recess of the watch envelope.
1.
With the other end, insert the telescope into the centre of
the cavity and attach it to the watch.
2.
Wearing the belt
Removing the belt
With one hand, press the wheel on the telescope and
gently push inwards.
1.
Then, pull upwards until the telescope detaches from the
watch.
2.
The app for the WF800 smartwatch model is "SmartHealth".
Download the app from the Google Play / App Store or via
the QR code below. The app is in English.
9
Google Play App Store
Once the app is installed, turn on Bluetooth on your phone and go
to the app. Create an account or log in anonymously. For the app
to work properly, you need to give all the consents the app asks
for. Fill in your personal data - go to "Settings" in the bottom right
corner, then select the icon with your email address. To connect
the watch, in the bottom corner click: "Settings" and then "Device
status". Your phone will search for Bluetooth devices and you
should select the appropriate model (F800).
Applications and functions
Installing applications
Features available on the Smartwatch
Time, date, day of the week
The display shows the time, date and day of the week. The
data is displayed on the main screen of the watch.
Pedometer
Counts the steps taken on a given day (data resets each day
from 00:00). The number of steps taken can be seen in the app
or in the first tab to the right of the main screen.
3-step backlight brightness adjustment
The three-stage brightness adjustment helps protect your eyes
from a screen that is too bright at night and saves the watch's
battery. You can find this function in the drop-down menu from
the main screen and select the appropriate brightness of the
display.
Calorie counter
Calculates the number of calories burnt in a given day. The
data on calories burned can be found in the first tab to the right
of the main screen in the app.
Distance travelled
Information on how much distance was covered during the day.
The distance travelled can be found in the first tab to the right
of the home screen.
10
Blood pressure (BP)*
Blood pressure is the force with which the blood pushes against
the arterial walls during systole and diastole of the heart muscle.
The accepted norm for systolic blood pressure is 120 mm Hg,
while for diastolic blood pressure it is 80 mm Hg. On the watch, the
function for measuring blood pressure is located in the menu to the
left of the home screen under the name BP. To calibrate your
blood pressure measurement, go to the app. More on page 15.
Oxygen saturation (BO)*
This function indicates the oxygenation level of the blood. As a
norm, the result should be between 95 and 100%. When the
oxygenation level drops, it can be dangerous for our health. On the
watch, the function for measuring saturation is located in the menu
to the left of the home screen under the name Blood oxygen.
Heart rate (HR)*
Heart rate, or pulse: it is the number of beats of the heart muscle
per 1 minute. The accepted norm is a limit between 60 and 100
beats per minute. When the pulse is elevated we speak of
tachycardia, while when it is reduced we speak of bradycardia.
Both conditions can be dangerous to our health. On the watch, the
function for measuring heart rate can be found in the menu to the
left of the home screen under the name HR.
*Do not make health decisions based solely on smartwatch results. For measurements to be accurate, users should measure
health functions at rest as they would with traditional medical devices and refrain from measuring during exercise, smoking or
alcohol consumption. The smartwatch is not a medical device and the measurement results are for illustrative purposes only.
Features available on the Smartwatch
Body temperature*
This function allows the current body temperature to be
measured. The normal body temperature of an adult is
considered to be 36.6 degrees Celsius. When the temperature
level rises to 38 degrees we speak of a fever.
On the watch, the temperature measurement function is located
in the menu to the left of the home screen under the name
Temp.
ECG*
The electrocardiogram measures the electrical activity of the
heart. It allows the detection of many cardiovascular diseases.
Hold the metal plate on the side of the watch during the
measurement. The electrodes of the watch must be completely
against the skin.
To perform an ECG test, it is necessary to connect the watch to
an app on your smartphone. The result of the measurement is
only visible in the app. On the watch, the function for ECG
measurement is located in the 5th tab to the right of the home
screen. To view the result, go to the app and select "ECG test".
Then click the three dots at the top. Select 'Synchronise' next to
the date the test was taken. To diagnose the result, select "AI
diagnosis". You can save and share the result. You can also
take the test from within the app. See page 18 for more.
*Do not make health decisions based solely on smartwatch results. For measurements to be accurate, users should measure
health functions at rest as they would with traditional medical devices and refrain from measuring during exercise, smoking or
alcohol consumption. The smartwatch is not a medical device and the measurement results are for illustrative purposes only.
Features available on the Smartwatch
Sports modes
The watch's 5 sports modes allow you to control your training
goals by monitoring steps, heart rate, calories and distance.
Workout data can be found in the app after synchronisation.
Available sports modes: running, cycling, basketball, walking,
climbing. On the watch, the sports modes function can be found
in the menu to the left of the home screen under the name
'Workout'.
Laser therapy**
Laser therapy involves emitting a beam of light (of a fixed
intensity: length and power) onto a section of the body for a set
period of time. Laser radiation has analgesic, anti-inflammatory,
anti-oedema effects, increases microcirculation, influences
immunological and hormonal processes, facilitates nerve
regeneration, accelerates bone growth and stimulates muscle
fibre synthesis.
The duration of the therapy is 60 seconds. The recommended
daily dose is 3 treatments of 60 seconds each.
To activate the function, press the bottom button on the side of
the envelope.
**Contraindications to laser therapy include cancer, hyperthyroidism, epilepsy, skin conditions (bacterial, viral or fungal
infections). It should also not be used by pregnant women.
Features available on the Smartwatch
Stopwatch
A function that is used to check and measure short intervals of
time. On the watch, the stopwatch function is located in the
menu to the left of the main screen.
Sleep monitor
A function that helps to analyse a person's sleep. The watch
shows the number of hours slept and the phases of sleep, in
which we distinguish between shallow and deep sleep. You will
find the sleep data in the second tab to the right of the home
screen.
Changing the dial theme
There are several dials to choose from on the watch. To
change dials, long press the main screen (about 3 seconds)
Settings
In the settings, you can:
-adjust the brightness of the screen
-select power and duration of laser therapy
-switch the device off
14
Features available on the Smartwatch
Functions available in a dedicated application
Measurement history
In the app, you will find the history of the measurements taken
by the watch. To check the history, select "Main" in the app.
Blood pressure monitor calibration
Calibrating the blood pressure monitor makes the results even
more accurate. The watch checks how much the blood volume
has changed compared to when the calibration was performed.
To perform calibrations, go to "Main" in the app, click "Blood
pressure" and select "Calibrate blood pressure measurement".
Sports modes
In the app, you can use the sports modes and have a preview
on your phone of the route taken, pace, calories burned and
duration of activity. You can choose from the available sports
modes: running, cycling, basketball, walking, climbing. At the
end of the activity, the map in the app will show the route
covered. You can share or upload your results.
15
Care function
In the watch wearer's application, a 'friend' must be added via
account name/e-mail. Once correctly added, he or she can
check what measurements the watch wearer has. To add a
person, go to 'Care' in the app.
Movement reminder
In the app, it is possible to set cyclical reminders every 15-60
minutes, whereby the watch, when it detects that the person
remains motionless for a prolonged period of time, reminds
them to perform an activity. You can also set on which days
and at what times the function should be active. To activate this
function, in the app, select "Settings", then "Device status" and
select "Movement reminder".
Automatic monitoring of health functions
In the app, heart rate, pressure, saturation and temperature can
be measured on a cyclic basis.
Cyclic measurement can be switched on or off in the app and
set to take automatic measurements every 10-60 minutes.
Automatic measurement is performed without our intervention.
To enable the function, select "Settings" in the app, then
"Device status" and "Health monitoring".
Setting automatic measurements reduces battery life.
16
Functions available in a dedicated application
Notifications
The notification function allows you to read the beginning of a
message on the smartwatch screen. Notifications can come
from apps such as SMS, QQ, WeChat, LinkedIn, Skype,
Facebook, WhatsApp, Instagram and Messenger. To enable
this feature, go to 'Settings', then 'Device Status' and
'Notifications'.
Incoming call notifications
Notifications of an incoming call with the name of a contact
from your smartphone's phonebook. From the watch, the call
can be rejected. To enable this function, go to "Settings", then
"Device status" and "Notifications".
"Do not disturb" mode
A mode that causes any notifications to not appear. To enable
this mode, go to "Settings", then "Device status" and "Do not
disturb". You can set the range of hours you want the mode to
be active.
Alarm clock
To set an alarm on the watch, select an alarm time and time in
the app. To do this in the app, select "Settings", then "Device
status" and select "Alarm clock".
17
Functions available in a dedicated application
Fever alarm
When the watch detects abnormalities related to temperature
during measurements, it will notify you. In the app we have the
option to set an alert when your body temperature reaches
38℃, this is an automatically set value. You can change the
alert from a temperature of 37℃ or higher. To set the alarm,
select "Settings", then "Device status" and select "Temperature
alarm".
Alarm for too high a heart rate
When the watch detects irregularities related to your heart rate
during measurements, it will notify you. To enable this function,
go to "Settings" in the app, then "Device status" and select
"Heart rate alert". Set from which BPM level the watch should
notify you of irregularities.
ECG
An ECG test can also be performed via the app. To do this, go
to the app and click "ECG test" and then the start button. Place
your finger on the metal plate on the side of the watch and
select "Start test" in the app. After the test, the result will be
displayed in the app.
Find your phone
In the app, selecting "Anti-lost function" will trigger a vibration
signal on your phone to help locate your device.
18
Functions available in a dedicated application
19
Wrist movement screen wake-up (G-Sensor)
To enable the watch screen wake-up function with a flick of the
wrist, select "Settings" in the app, then "Device status" and "Lift
wrist to resume screen".
3-step screen backlight brightness adjustment
The three-step brightness adjustment helps protect your eyes
from a screen that is too bright at night and saves the watch
battery. You can find this function in the app. Select "Settings",
then "Device status" and "Screen brightness".
Reset to factory settings
Resetting to factory settings allows you to reset the watch and
erase all data and settings. To reset, go to "Settings" in the app,
then "Device status" and "Reset to factory settings".
Functions available in a dedicated application
Waterproof to IP67***.
Allows you to use the watch
while washing your hands or
on a rainy day.
280mAh battery
The lithium-polymer battery
will allow you to use the
smartwatch for a long time.
Classic design
Due to its classic design, the
watch goes with any style.
Texas Instruments and
OSRAM processor
High performance and
precision measurements.
***The IP67 standard allows a water temperature of +10 to +35 degrees Celsius and immersion to a depth of 1m for up to 30min. The watch
cannot be used in hot baths or saunas as it is not steam resistant. It is not designed for swimming, it has been designed to help look after
your health.
General Information
Specifications
