COSTWAY NP10768+ 7-in-1 Stable A-shaped Outdoor Swing Set User Manual

THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.

USA office: Fontana AUS office: Truganina

GBR office: Ipswich FRA office: Saint Vigor d'Ymonville

NP10768

Swing

Balançoire

02 03

The product must be installed and used under the supervision of an adult.

Read through each step carefully and follow the proper order.

Remove all packaging, separate and count all parts and hardware.

Please ensure that all parts are correctly installed, incorrect installation can lead to a

danger.

We recommend that, where possible, all items are assembled near the area in which

they will be placed in use, to avoid moving the product unnecessarily once assembled.

Ensure a secure surface during installation, and place the product always on a flat,

steady and stable surface.

Please check and maintain it regularly, and the most important part needs to be

suspended, fixed, or anchored to the ground.

Attention: For home use only.

Attention: Children should use this product under the parental supervision.

Danger: Keep all small parts and packaging materials for this product away from

babies and children, otherwise they may pose a choking hazard.

Danger: Lack of attachment may cause a risk of tipping or falling hazard.

Before You Start

Please read all instructions carefully and keep it for future reference.

General Warnings

Warnings

Attention : Pour l’usage domestique seulement.

Attention : Les enfants doivent utiliser ce produit sous la surveillance de leurs parents.

Danger : Gardez toutes les petites pièces et les matériaux d’emballage de ce produit hors

de portée des bébés et des enfants pour éviter un risque d’étouffement.

Danger : La manque de la fixation pourrait entraîner un risque de basculement ou de chute.

Avant de Commencer

Veuillez lire attentivement toutes les instructions et les conserver pour la référence ultérieure.

Avertissements Généraux

Avertissements

Le produit doit être installé et utilisé sous la surveillance d’un adulte.

Lisez attentivement chaque étape et suivez l’ordre correct.

Retirez tous les emballages, séparez et comptez toutes les pièces et le matériel.

Veuillez vous assurer que toutes les pièces soient correctement installées, une

installation incorrecte peut entraîner un danger.

Nous recommandons que, dans la mesure du possible, tous les articles soient

assemblés à proximité de la zone dans laquelle ils seront utilisés, afin d’éviter de

déplacer inutilement le produit une fois assemblé.

Assurez-vous que la surface soit solide pendant l’assemblage et placez toujours le

produit sur une surface plane et stable.

Veuillez vérifier et entretenir régulièrement les pièces les plus importantes pour la

suspension, la fixation, l’ancrage au sol.

02 03

The product must be installed and used under the supervision of an adult.

Read through each step carefully and follow the proper order.

Remove all packaging, separate and count all parts and hardware.

Please ensure that all parts are correctly installed, incorrect installation can lead to a

danger.

We recommend that, where possible, all items are assembled near the area in which

they will be placed in use, to avoid moving the product unnecessarily once assembled.

Ensure a secure surface during installation, and place the product always on a flat,

steady and stable surface.

Please check and maintain it regularly, and the most important part needs to be

suspended, fixed, or anchored to the ground.

Attention: For home use only.

Attention: Children should use this product under the parental supervision.

Danger: Keep all small parts and packaging materials for this product away from

babies and children, otherwise they may pose a choking hazard.

Danger: Lack of attachment may cause a risk of tipping or falling hazard.

Before You Start

Please read all instructions carefully and keep it for future reference.

General Warnings

Warnings

Attention : Pour l’usage domestique seulement.

Attention : Les enfants doivent utiliser ce produit sous la surveillance de leurs parents.

Danger : Gardez toutes les petites pièces et les matériaux d’emballage de ce produit hors

de portée des bébés et des enfants pour éviter un risque d’étouffement.

Danger : La manque de la fixation pourrait entraîner un risque de basculement ou de chute.

Avant de Commencer

Veuillez lire attentivement toutes les instructions et les conserver pour la référence ultérieure.

Avertissements Généraux

Avertissements

Le produit doit être installé et utilisé sous la surveillance d’un adulte.

Lisez attentivement chaque étape et suivez l’ordre correct.

Retirez tous les emballages, séparez et comptez toutes les pièces et le matériel.

Veuillez vous assurer que toutes les pièces soient correctement installées, une

installation incorrecte peut entraîner un danger.

Nous recommandons que, dans la mesure du possible, tous les articles soient

assemblés à proximité de la zone dans laquelle ils seront utilisés, afin d’éviter de

déplacer inutilement le produit une fois assemblé.

Assurez-vous que la surface soit solide pendant l’assemblage et placez toujours le

produit sur une surface plane et stable.

Veuillez vérifier et entretenir régulièrement les pièces les plus importantes pour la

suspension, la fixation, l’ancrage au sol.

04 05

WARNING: ONLY FOR DOMESTIC OUTDOOR USE.

To guarantee safety, please give special attention to the assembly, safety, and

care instructions detailed in this document.

AVERTISSEMENT : UNIQUEMENT POUR UNE UTILISATION

DOMESTIQUE EN EXTÉRIEUR.

Pour garantir la sécurité, veuillez prêter une attention particulière aux

instructions de montage, de sécurité et d'entretien détaillées dans ce document.

M8*60

X34+2

X44+4

X8+1

X38+2

G1 L6 D6

X48+2

X34+6

X40+12

K10K13

M8*78

X8+1

M8*55

M6*38 M8*50

M6*20

M6*35

X20+2

M6*50

X32+2

YD2

M6*25

Z13

X4+1

M6*45

Swing

Balançoire

04 05

WARNING: ONLY FOR DOMESTIC OUTDOOR USE.

To guarantee safety, please give special attention to the assembly, safety, and

care instructions detailed in this document.

AVERTISSEMENT : UNIQUEMENT POUR UNE UTILISATION

DOMESTIQUE EN EXTÉRIEUR.

Pour garantir la sécurité, veuillez prêter une attention particulière aux

instructions de montage, de sécurité et d'entretien détaillées dans ce document.

M8*60

X34+2

X44+4

X8+1

X38+2

G1 L6 D6

X48+2

X34+6

X40+12

K10K13

M8*78

X8+1

M8*55

M6*38 M8*50

M6*20

M6*35

X20+2

M6*50

X32+2

YD2

M6*25

Z13

X4+1

M6*45

Swing

Balançoire

06 07

P21

P20

P23

P24

x 1

P25

P10

P22

P26

x 1

BH20 x 2

P27

x 2

x 1

P17

P19

BH19 x 2

YB22 x 2

S19

C40

x 2

C51

x 2

C50

x 2

C52

x 2

X19

S16

x 2

x 1

YC3

P12

x 1

25* 1.2

22*1

45*2

22*1

P13

x 2

YC27

x 1

P11

x 4

G2 X 20

X 20

X 12

X 8

P19

X 1

P25

X 1

P21

X 2

X 1

S16

S19

P9 X 4

X 1X2

P17

X 1

S19

S16

P17

P25

P19

P21

two holes

faces down

P17

P25

P19

/deux trous

face vers le bas

06 07

P21

P20

P23

P24

x 1

P25

P10

P22

P26

x 1

BH20 x 2

P27

x 2

x 1

P17

P19

BH19 x 2

YB22 x 2

S19

C40

x 2

C51

x 2

C50

x 2

C52

x 2

X19

S16

x 2

x 1

YC3

P12

x 1

25* 1.2

22*1

45*2

22*1

P13

x 2

YC27

x 1

P11

x 4

G2 X 20

X 20

X 12

X 8

P19

X 1

P25

X 1

P21

X 2

X 1

S16

S19

P9 X 4

X 1X2

P17

X 1

S19

S16

P17

P25

P19

P21

two holes

faces down

P17

P25

P19

/deux trous

face vers le bas

08 09

G1 X 8

X 8

X 6

X 4

P10

X 2

Z13 X 2

P10

P22

P20

C40

P12

P11

P13

DW X 2

X 6

P20

X 1

P11

X 4

P12

X 1

P13

X 2

C40

X 1

P22

X 2

S5 X 6

Z13

YC3

YB22

BH20

BH19

Z13

P24

P23

BH19

BH20

T1 x4

YB22

Z8 x2

x12

x18

YC3

X 8

X 2

P23

P24

X 4

Z13

X 2

x14

x12

x14

Z3 X 8

08 09

G1 X 8

X 8

X 6

X 4

P10

X 2

Z13 X 2

P10

P22

P20

C40

P12

P11

P13

DW X 2

X 6

P20

X 1

P11

X 4

P12

X 1

P13

X 2

C40

X 1

P22

X 2

S5 X 6

Z13

YC3

YB22

BH20

BH19

Z13

P24

P23

BH19

BH20

T1 x4

YB22

Z8 x2

x12

x18

YC3

X 8

X 2

P23

P24

X 4

Z13

X 2

x14

x12

x14

Z3 X 8

10 11

Z13

X 6

X 2

X 8

X 2

X 1

P26

X 1

P27

X 2

YC27

X 1

Z13

X 8

P20

X 2

P27

YC27

P26

C50

YD2

C51

C52

C50

C51

C52

G1 x18

x10

YD2

EN: After assembling the swing,

please stretch the length of the

swing to the longest possible length

when fixing the ground nails to keep

it in a taut state, and then fix the

ground nails and pour cement to make

the swing more stable.

FR: Après avoir assemblé la balançoire, veuillez étirer la

longueur de la balançoire à la longueur la plus longue

possible lors de la fixation des clous au sol pour la

maintenir dans un état tendu, puis fixez les clous au sol

et versez du ciment pour rendre la balançoire plus stable.

10 11

Z13

X 6

X 2

X 8

X 2

X 1

P26

X 1

P27

X 2

YC27

X 1

Z13

X 8

P20

X 2

P27

YC27

P26

C50

YD2

C51

C52

C50

C51

C52

G1 x18

x10

YD2

EN: After assembling the swing,

please stretch the length of the

swing to the longest possible length

when fixing the ground nails to keep

it in a taut state, and then fix the

ground nails and pour cement to make

the swing more stable.

FR: Après avoir assemblé la balançoire, veuillez étirer la

longueur de la balançoire à la longueur la plus longue

possible lors de la fixation des clous au sol pour la

maintenir dans un état tendu, puis fixez les clous au sol

et versez du ciment pour rendre la balançoire plus stable.

12 13

ASSEMBLY INSTRUCTIONS

To be retained for future reference.

WARNING: Only for domestic outdoor use.

Dear Customer,

To guarantee safety, please give special attention to the assembly,

safety, and care instructions detailed in this document.

ASSEMBLY ADVICE

Please follow the assembly instructions exactly as given.

1)This product must be assembled by an adult.

2)Keep a copy of your assembly instructions for future reference.

This can be particularly handy for identification

of parts if any after sales service is required.

3)Requiring a 40 cm/16” minimum distance between the ground and a 2

person swing and a 35 cm/14” minimum distance between the ground and

swings. These distances are important for safe use. After having

assembled the playground, check these distances.

4)We advise that the swing set is not faced towards the sun

5)Before commencing, check that none of the parts are missing.

6)Dispose of packaging thoughtfully.

7)Do not allow children to play with packaging.

SAFETY ADVICE

1)This product must not be used by children under the age of 36

months. It is suitable only for children between the

ages of 3 and 12 years with a maximum weight of 50 kg/110 lbs. It must be

used under adult supervision.

2)Only 7 children may safely use the equipment simultaneously

3)As this product contains small parts that could be swallowed,

please keep parts away from children under 36 months.

4)This product is only for private use at home and must never be

used in parks and public gardens, in schools,camp sites, hotels,

public leisure areas, etc.

FIXING INTO THE GROUND

1)Assemble the swing set completely and place it in the desired place.

2)Locate and mark the position for the sealing legs.

3)Check the dimensions showed on the diagram, and correct

if necessary.

4)Under the four feet, mark a square of 350 x 350 mm/14” x 14” and dig a

350 mm/14” deep hole.

5)Fill these holes with concrete following the diagram of the recto. The top

of the concrete should not exceed ground level.

6)Place the sealing legs in the concrete in the located place (see point 2).

Make sure the drilled end of the sealing legs is above the level of the

concrete.

4)This product is only for private use at home and must never be used in

parks and public gardens, in schools, camp sites, hotels, public leisure

areas, etc.

5)The swing set should be set up on a flat surface 2 m/6.6 ft away from all

other things, structures or obstacles(walls, fences, trees, washing lines or

electric cables etc.)that could cause injury during use.

6)This product must not be set up over hard surfaces such as concrete,

asphalt or other hard surfaces.We recommend installation over grass or

other such soft surfaces.

7)This swing set must be embedded firmly into the ground. Please follow

the instructions carefully for doing so. Only use this product when the

concrete is dry.

8)Anchors should be placed level with or below ground level in order to

reduce tripping hazards

9)The anchorage must be checked regularly, in addition to the hooks and

fixtures.

10)Dispose of packaging thoughtfully.

11)Do not allow children to play with packaging.

12)During the assemble, keep children away the toy to avoid child swallow

the small accessories.

12 13

ASSEMBLY INSTRUCTIONS

To be retained for future reference.

WARNING: Only for domestic outdoor use.

Dear Customer,

To guarantee safety, please give special attention to the assembly,

safety, and care instructions detailed in this document.

ASSEMBLY ADVICE

Please follow the assembly instructions exactly as given.

1)This product must be assembled by an adult.

2)Keep a copy of your assembly instructions for future reference.

This can be particularly handy for identification

of parts if any after sales service is required.

3)Requiring a 40 cm/16” minimum distance between the ground and a 2

person swing and a 35 cm/14” minimum distance between the ground and

swings. These distances are important for safe use. After having

assembled the playground, check these distances.

4)We advise that the swing set is not faced towards the sun

5)Before commencing, check that none of the parts are missing.

6)Dispose of packaging thoughtfully.

7)Do not allow children to play with packaging.

SAFETY ADVICE

1)This product must not be used by children under the age of 36

months. It is suitable only for children between the

ages of 3 and 12 years with a maximum weight of 50 kg/110 lbs. It must be

used under adult supervision.

2)Only 7 children may safely use the equipment simultaneously

3)As this product contains small parts that could be swallowed,

please keep parts away from children under 36 months.

4)This product is only for private use at home and must never be

used in parks and public gardens, in schools,camp sites, hotels,

public leisure areas, etc.

FIXING INTO THE GROUND

1)Assemble the swing set completely and place it in the desired place.

2)Locate and mark the position for the sealing legs.

3)Check the dimensions showed on the diagram, and correct

if necessary.

4)Under the four feet, mark a square of 350 x 350 mm/14” x 14” and dig a

350 mm/14” deep hole.

5)Fill these holes with concrete following the diagram of the recto. The top

of the concrete should not exceed ground level.

6)Place the sealing legs in the concrete in the located place (see point 2).

Make sure the drilled end of the sealing legs is above the level of the

concrete.

4)This product is only for private use at home and must never be used in

parks and public gardens, in schools, camp sites, hotels, public leisure

areas, etc.

5)The swing set should be set up on a flat surface 2 m/6.6 ft away from all

other things, structures or obstacles(walls, fences, trees, washing lines or

electric cables etc.)that could cause injury during use.

6)This product must not be set up over hard surfaces such as concrete,

asphalt or other hard surfaces.We recommend installation over grass or

other such soft surfaces.

7)This swing set must be embedded firmly into the ground. Please follow

the instructions carefully for doing so. Only use this product when the

concrete is dry.

8)Anchors should be placed level with or below ground level in order to

reduce tripping hazards

9)The anchorage must be checked regularly, in addition to the hooks and

fixtures.

10)Dispose of packaging thoughtfully.

11)Do not allow children to play with packaging.

12)During the assemble, keep children away the toy to avoid child swallow

the small accessories.

14 15

7)Once the concrete is set, screw the feet into the sealing legs.

8)Ensure that the concrete is completely dry before using the swing.

9)Cover the concrete with soil. We strongly advise checking this

anchoring periodically

MAINTENANCE

11)Sand rusted areas and tubular members and repaint using a non-lead

based paint when required.

12)Check swing seats, chains, ropes and other means of attachment for

evidence of deterioration.

PRACTICAL ADVICE

Frequent questions and observations

SAFETY

Safety checks should be carried out regularly on this product.These

checks should include, if necessary, removing any sharp edges,

replacing missing screw covers, and tightening the nuts and bolts.

These checks should be done to avoid any danger or upturning of

the swing set through normal wear and tear.

Comfort

1)If the swing set develops a squeak apply a suitable gel lubricant.

Do not use liquid lubricant as it will run down the fixings and

apparatus. The height of the swing can be adjusted using the plastic

eyelet fixture. By pulling the rope through the fixture, the height of

the seat can be adjusted to suit the user .

The dimensions given are indicative only, they may vary according

to the assembly method.

2)This Swing Set must be used under adult supervision. Keep any

additional components, they may be useful for later operation of

maintenance.

3)When a child is playing on the device, other children can not run in

the area of movements of elements to impact.

CAUTION !Fall danger

1)All metal parts are galvanized steel and powder coated for rust

protection; however, in certain areas close to the sea we advise that

additional rust prevention treatment may be necessary.

2)The surfaces of all the parts should be checked at least once a month,

especially for the fixtures such as hooks on the overhead beam. If the

fixtures and hooks show wear over 10% of their original thickness, then

they should be replaced with the same fixtures as those originally

provided.

3)To check all nuts and bolts for tightness and tighten when required.

4)To check all coverings for bolts and sharp edges and replace when

required.

5)Toys may collapse or be dangerous if they don't check regularly.

6)All parts that are under constant friction should be oiled regularly with a

suitable lubricant.

7)The ground on which the product is placed should be controlled

regularly. All elements such as stones or other objects that could cause

injury in the case of a fall should be removed. It is advised to remove the

apparatus during the winter period, when not in use, to avoid any

deterioration due to bad weather conditions.

8)Check for signs of wear, especially where swinging apparatus’ plastic

ring attaches to the metal swing hooks on the upper beam. As soon as the

plastic ring shows signs of deterioration, the apparatus should be

replaced.

9)All used apparatuses and/or parts must be replaced by a part delivered

by qualified technician.

10)If any modifications made by consumer to the original activity toy shall

be carried out according to the instructions of the manufacturer.

14 15

7)Once the concrete is set, screw the feet into the sealing legs.

8)Ensure that the concrete is completely dry before using the swing.

9)Cover the concrete with soil. We strongly advise checking this

anchoring periodically

MAINTENANCE

11)Sand rusted areas and tubular members and repaint using a non-lead

based paint when required.

12)Check swing seats, chains, ropes and other means of attachment for

evidence of deterioration.

PRACTICAL ADVICE

Frequent questions and observations

SAFETY

Safety checks should be carried out regularly on this product.These

checks should include, if necessary, removing any sharp edges,

replacing missing screw covers, and tightening the nuts and bolts.

These checks should be done to avoid any danger or upturning of

the swing set through normal wear and tear.

Comfort

1)If the swing set develops a squeak apply a suitable gel lubricant.

Do not use liquid lubricant as it will run down the fixings and

apparatus. The height of the swing can be adjusted using the plastic

eyelet fixture. By pulling the rope through the fixture, the height of

the seat can be adjusted to suit the user .

The dimensions given are indicative only, they may vary according

to the assembly method.

2)This Swing Set must be used under adult supervision. Keep any

additional components, they may be useful for later operation of

maintenance.

3)When a child is playing on the device, other children can not run in

the area of movements of elements to impact.

CAUTION !Fall danger

1)All metal parts are galvanized steel and powder coated for rust

protection; however, in certain areas close to the sea we advise that

additional rust prevention treatment may be necessary.

2)The surfaces of all the parts should be checked at least once a month,

especially for the fixtures such as hooks on the overhead beam. If the

fixtures and hooks show wear over 10% of their original thickness, then

they should be replaced with the same fixtures as those originally

provided.

3)To check all nuts and bolts for tightness and tighten when required.

4)To check all coverings for bolts and sharp edges and replace when

required.

5)Toys may collapse or be dangerous if they don't check regularly.

6)All parts that are under constant friction should be oiled regularly with a

suitable lubricant.

7)The ground on which the product is placed should be controlled

regularly. All elements such as stones or other objects that could cause

injury in the case of a fall should be removed. It is advised to remove the

apparatus during the winter period, when not in use, to avoid any

deterioration due to bad weather conditions.

8)Check for signs of wear, especially where swinging apparatus’ plastic

ring attaches to the metal swing hooks on the upper beam. As soon as the

plastic ring shows signs of deterioration, the apparatus should be

replaced.

9)All used apparatuses and/or parts must be replaced by a part delivered

by qualified technician.

10)If any modifications made by consumer to the original activity toy shall

be carried out according to the instructions of the manufacturer.

16 17

Consumer information sheet for playground surfacing materials

The US Consumer Product Safety Commission (CPSC)estimates that

about 100000 playground equipmentrelated injuries resulting from falls

to the ground surface are treated annually in US hospital emergency

rooms. Injuries involving this hazard pattern tend to be among the most

serious of all playground injuries, and have the potential to be fatal,

particularly when the injury is to the head. The surface under and

around playground equipment can be a major factor in determining the

injury-causing potential of a fall. It is self-evident that a fall on to a

shock-absorbing surface is less likely to cause a serious injury than a

fall onto a hard surface. Playground equipment should never be placed

on hard surfaces, such as concrete or asphalt, and while grass may

appear to be acceptable, it may quickly turn to hard-packed earth in

areas of high traffic. Shredded bark mulch, wood chips, fine sand or fine

gravel are considered to be acceptable shock absorbing surfaces when

installed and maintained at a sufficient depth under and around

playground equipment.

Table B.1 lists the maximum height from which a child would not be

expected to sustain a life-threatening head injury in a fall on to four

different loose-fill surfacing materials if they are installed and maintained

at depths of 150 mm/6”, 225 mm/9” and 300 mm/12”.

Table B.1--Fall height in millimeters from which a life-treatening head injury

would not be expected

Type of material

Double shredded

bark much

Wood chips

Fine sand

Fine gravel

Depth of surfacing material

150mm

225mm

300mm

1800 mm/6 ft

1500 mm/5 ft

1800 mm/6 ft

3000 mm/10 ft

2100 mm/7 ft

1500 mm/5 ft

2100 mm/7 ft

3300 mm/11 ft

3600 mm/12 ft

2700 mm/9 ft

3000 mm/10 ft

However, it should be recognised that all injuries due to falls cannot be

prevented, no matter what surfacing material is used.

It is recommended that a shock absorbing material extend a minimum of

1800 mm/6 ft in all directions from the perimeter of stationary equipment such

as climbing frames and slides. However, because children may deliberately

jump from a moving swing, the shock absorbing material should extend in

the front and rear of a swing a minimum distance of twice the height of the

pivot point measured from a point directly beneath the pivot on the

supporting structure.

This information is intended to assist in comparing the relative

shock-absorbing properties of various materials. No particular material is

recommended over another. However, each material is only effective when

properly maintained. Materials should be checked periodically and

replenished to maintain correct depth as determined necessary for the

equipment in question. The choice of a material depends on the type and

height of the playground equipment, the availability of the material in a

particular area, and its cost.

INSTRUCTIONS DE MONTAGE

À conserver pour référence future.

AVERTISSEMENT : Uniquement pour un usage domestique en extérieur.

Cher client,

Pour garantir la sécurité, veuillez prêter une attention particulière aux instructions de

montage, de sécurité et d'entretien détaillées dans ce document.

CONSEILS DE MONTAGE

Veuillez suivre les instructions de montage exactement comme indiqué.

1) Ce produit doit être assemblé par un adulte.
