1
Mini Chopper
Model No. SDA2732
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
2
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Mini Chopper
Model No. SDA2732
User Manual
Contents
Page No.
2 Contents
3 Reading and Storing the User Manual
3 Important Safety Instructions for Proper Use
6 Explanation of Symbols
7 Description of Parts
7 Before First Use of Your Mini Chopper
8 Using Your Mini Chopper
9 Food Chopping Guide
10 Care and Maintenance
10 Technical Specification
10 Plug Wiring Information
10 Recycling Information
13 Customer Support
Back Page Warranty Information
3
Mini Chopper
Model No. SDA2732
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
READING AND STORING THE USER MANUAL
Before using this product, please read through this
manual carefully paying particular attention to the
safety instructions. Failure to do so may result in
personal injury or damage to the product.
Carefully save this instruction manual for future reference.
Ensure the user manual is included when passing the product
on to any third parties.
IMPORTANT SAFETY INSTRUCTIONS FOR PROPER USE
When using electrical appliances, safety precautions should
always be followed.
Only use the product as described in this user manual. Any other
use is considered improper and may result in damage to
property or persons.
The manufacturer or vendor cannot be held liable for damages
or injury incurred through improper or incorrect use.
• Read and familiarise yourself with all operating
instructions before using this Mini Chopper.
• Before plugging your unit into the mains supply, visually
check that it is intact and has not suffered any transit
damage.
• DO NOT use this product with a programmer, timer,
separate remote-control system or any other device.
• Check that the voltage indicated on the data plate
corresponds with that of the local network before
connecting the appliance to the mains power supply.
• DO NOT immerse this appliance in water or any other
liquids.
• Close supervision is required when using this appliance
near children.
• Never leave this appliance within reach of children.
• This appliance shall not be used by children.
• Keep the appliance and its cable out of the reach of
4
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Mini Chopper
Model No. SDA2732
User Manual
children.
• Appliances can be used by persons with reduced physical,
sensory or mental capabilities or lack of experience and
knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe way
and understand the hazards involved.
• Children shall not play with the appliance.
• Cleaning and user maintenance shall not be made by
children.
• DO NOT leave the appliance unattended during use.
• DO NOT leave the appliance unattended whilst connected
to the mains supply.
• Always use this appliance on a solid, level, non-flammable
surface.
• Protect the unit from moisture whilst using this appliance
outdoors.
• Repairs to electrical appliances should only be performed
by qualified personnel. Improper repairs may place user at
serious risk.
• It is imperative to unplug the mains cable after the
appliance has been used, before it is cleaned and whilst
being repaired.
• Regular, periodic checks should be carried out on the
mains cable to ensure no damage is evident. Should there
be any signs of damage the appliance should not be used.
• DO NOT operate this appliance with a damaged plug or
mains cable, after a malfunction or after being dropped or
damaged in any way.
• DO NOT allow the mains cable to hang over sharp edges
or come in contact with hot surfaces.
• DO NOT allow the mains cable to hang over sharp edges
or come in contact with hot surfaces.
5
Mini Chopper
Model No. SDA2732
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
• DO NOT use this appliance for anything other than its
intended use.
• DO NOT push objects into any openings as damage to the
appliance and/or electric shock may occur.
• This appliance is intended for household use only and
should not be used for industrial or commercial purposes.
• Switch off the appliance and disconnect from the mains
supply before changing accessories or approaching parts
that move in use.
• Grasp the plug, not the cord.
• DO NOT touch the blades whilst the appliance is
connected to the mains.
• Wash the blades in warm soapy water, rinse and dry
thoroughly.
• WARNING! The blades on this appliance are very sharp;
extreme caution should be taken whilst cleaning.
6
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Mini Chopper
Model No. SDA2732
User Manual
Explanation of Symbols
The following warning symbols or words are used in this instruction manual:
-
Products labelled with UK Conformity Assessment identifies
products conforming to UK statutory requirements.
Products labelled with this symbol conform to applicable
provisions of the European Economic Area.
This Class 2 symbol indicates that the product is electrically
double insulated and does not require an earth connection.
You should now recycle your waste electrical goods and in
doing so help the environment. This symbol means waste
electrical products at the end of their useful life should not be
disposed of with normal household waste and not sent to land
fill. Please ensure it is taken to a suitable facility for disposal.
Check with your Local Authority or retailer for recycling advice
or visit www.recycle-more.co.uk, enter your postcode to find
out your nearest recycling site.
This symbol provides useful additional information on the use
of this product.
WARNING!
This designates a hazard with moderate risk, which may result
in severe injury if not adhered to.
7
Mini Chopper
Model No. SDA2732
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Description of Parts
Before First Use of Your Mini Chopper
• Remove all packing materials and discard responsibly.
• Ensure all parts are present see Description of Parts above.
• Remove the Bowl Cover (3), the Bowl (4) and the Blades (5) and wash in warm
soapy water, rinse and dry thoroughly.
• Do not immerse the Motor Unit (2) in water or any other liquids.
• Do not use harsh or abrasive cleaners.
• Not Dishwasher safe, do not clean any part of your Jug Blender in a dishwasher.
Hand wash only.
WARNING! The blades on this Mini Chopper are very sharp, extreme
caution should be taken whilst cleaning the blades.
2
3
1
1. Pulse Button
2. Motor Unit
3. Bowl Cover
4. Bowl
5. Blades
4
5
8
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Mini Chopper
Model No. SDA2732
User Manual
Using Your Mini Chopper
1. Place the Bowl (4) on a solid level surface, then slide the Blades (5) down over
the shaft in the Bowl (4).
WARNING! Be careful whilst handling the blades as they are extremely sharp.
2. Place food to be chopped into the Bowl (4).
3. Place the Bowl Cover (3) onto the Bowl (4), position the Motor Unit (2) onto the
Bowl Cover (3) such that the embossment on the bowl cover lines up with the
hole in the motor unit, line up the motor unit locking tabs with the bowl locking
slots until the motor unit locks in place.
4. Insert the mains plug into the nearest
socket and switch the socket on (if
applicable).
5. Steady the unit with one hand with the other press the Pulse Button (1) on the
top of the unit to operate the Mini Chopper and to chop the ingredients – see
Food Chopping Guide below.
This Mini Chopper has a pulse button. Avoid running the motor continuously for
a period of over 30 seconds.
The longer the pulse, the finer the texture. For coarsely chopped foods, use
short pulses.
9
Mini Chopper
Model No. SDA2732
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
6. After use, ensure the Blades (5) have completely stopped rotating before
removing the blended contents.
7. Remove the plug from the mains socket.
8. Remove the Motor Unit (2) and grasp the plastic blade hub at the top of the
Blades (5) and pull the Blades out then remove the Bowl Cover (3). Empty the
blended contents from the Bowl (4). Not use the Bowl (4) to store food.
Food Chopping Guide
Type of food
Method
Fresh bread
Use 80g (size: 100 mm x 100 mm x 10 mm) at a
time, torn into several pieces. Process 20
seconds ON 2 min OFF until pureed as desired.
Carrot
Drain up to 150g (size: 15 mm x 15 mm x15 mm)
and process 20 seconds ON 2 min OFF until
pureed as desired.
Almonds
Pulse or process up to 100g ON 20 seconds OFF 2
min until desired chop is reached.
Cookies, crackers
Pulse or process up to 150g cookies (size: 40 mm
x 40 mm x 5 mm) or crackers (size: 40 mm x 40
mm x 5 mm) ON 20 seconds OFF 2 min until
desired chop is reached.
Fresh beef or pork
Cut into
60mm*20mm*20mm bulk
Pulse or process up to 100g beef or pork ON 20
seconds OFF 2 min until desired chop is reached.
Honey,
Malt sugar (20-22℃)
Put in 50g of honey and 50g of malt sugar,ON 5
seconds OFF 2 min, until desired effect.
10
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Mini Chopper
Model No. SDA2732
User Manual
Care and Maintenance
• Always disconnect the Mini Chopper from the mains power supply before
cleaning.
• Wash the Bowl Cover (3), the Bowl (4) and the Blades (5) in warm soapy water,
rinse and dry thoroughly.
• Do not immerse the Motor Unit (5) in water or any other liquids.
• Do not use harsh or abrasive cleaners.
WARNING! The blades on this Mini Chopper are very sharp; extreme caution
should be taken whilst cleaning.
Technical Specification
Model No.
SDA2732
Voltage
220-240V~ 50-60Hz
Power
500W
Capacity
1L
Class
II
Non-Rewireable Mains Plug
If your appliance is supplied with a non-rewireable plug fitted to the mains lead
and should the fuse need replacing, you must use an ASTA approved one
(conforming to BS 1362 of the same rating). If in doubt, consult a qualified
electrician. Never use a mains plug with the fuse cover missing.
If you need to remove the plug – DISCONNECT FROM THE MAINS – and then cut it
off the mains lead and immediately dispose of it safely. Never attempt to reuse
the plug or insert it into a socket outlet as there is a danger of electric shock.
Recycling Information
Disposal of the Packaging
Dispose of paper and cardboard in appropriate paper re-cycling facilities.
Dispose of recyclable plastics in appropriate plastic re-cycling facilities.
Dispose of non-recyclable plastics in the appropriate plastics collection service.
Disposal of the Product
You should now recycle your waste electrical goods and in doing so
help the environment. This symbol means waste electrical products
at the end of their useful life should not be disposed of with normal
household waste and not sent to landfill. Please ensure it is taken to
a suitable facility for disposal. Check with your Local Authority or
retailer for recycling advice or visit www.recycle-more.co.uk, enter
your postcode to find out your nearest recycling site.
11
Mini Chopper
Model No. SDA2732
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
12
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Mini Chopper
Model No. SDA2732
User Manual
WARRANTY
Thank you for purchasing your Daewoo product.
As part of our commitment to quality, we are offering you an extra 2 years warranty in
addition to your 1 year guarantee
Your Daewoo product is guaranteed for 1 year from the date of original purchase, with proof
of purchase or receipt. If any defect should occur due to faulty workmanship or material, your
faulty product should be returned to the place of purchase, replacement or refund is at the
discretion of the retailer.
The guarantee is subject to the following provisions:
•
The product must be correctly installed and operated in accordance with the
requirements contained in the instruction manual.
•
The product must be used solely for domestic purposes.
•
It does not cover general wear and tear, damage, misuse or any consumable parts.
•
The guarantee will be rendered invalid if the product is re-sold or has been damaged through
inexpert repair.
•
The guarantee is only valid within the UK and Eire.
Your standard 1 year guarantee will only be extended to the maximum available for your
individual product upon registration. (Note: products must be registered individually and
covers the main body and housing). If you do not register your product within 28 days of the
original purchase date, your product will only be guaranteed for 1 year.
To validate your extended 2 year warranty*please register your purchase online within 28
days of the original purchase date by registering at
https://help.daewooelectricals.com
or
Contact Us (daewooelectricals.com)
*Your extended warranty is only valid with proof of purchase receipt and subject to the
conditions outlined above.
Daewoo is a registered trademark.
Produced and imported under license by
Eurosonic Group Limited
Brightgate House
1 Brightgate Way
Manchester M32 0TB UK
EU Rep: EuroSonic Magppie (ESM) Ltd. Ireland D05 X006
www.esgltd.com
