16” Chrome Pedestal Fan
Model No. COL1608
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
2
16” Chrome Pedestal Fan
Model No. COL1608
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
READING AND STORING THE USER MANUAL
Before using this product, please read through this manual
carefully paying par�cular a�en�on to the safety instruc�ons.
Failure to do so may result in personal injury or damage to the
product.
Carefully save this instruc�on manual for future reference. Ensure the
user manual is included when passing the product on to any third par�es.
Only use the product as described in this user manual. Any other use is
considered improper and may result in damage to property or persons.
The manufacturer or vendor cannot be held liable for damages or injury
incurred through improper or incorrect use.
Read and familiarise yourself with all opera�ng
instruc�ons before using this 16” Copper Pedestal Fan.
Before plugging your unit into the mains, visually check that
the unit is intact and has not suffered any transit damage.
DO NOT use this product with a programmer, �mer,
separate remote control system or any other device.
Check that the voltage indicated on the data plate
corresponds with that of the local network before
connec�ng the appliance to the mains power supply.
This appliance can be used by children aged from 8 years
and above and persons with reduced physical sensory or
mental capabili�es or lack of experience and knowledge if
they have been given supervision or instruc�on concerning
use of the appliance in a safe way and understand the
hazar
ds involved. Children shall not play with the
appliance. Cleaning and user maintenance shall not be
made by children without supervision.
Close supervision is required when using this appliance
near children.
Never leave this appliance within reach of children.
Children of less than 3 years should be kept away unless
con�nuously supervised.
DO NOT immerse the appliance or its cord in water or any
other liquids.
3
16” Chrome Pedestal Fan
Model No. COL1608
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
DO NOT leave the appliance una�ended during use.
DO NOT leave the appliance una�ended whilst connected
to the mains supply.
Always use this appliance on solid, level, surface.
DO NOT use this appliance outdoors.
DO NOT use any accessories or a�achments with this
appliance other than those supplied or recommended by
the supplier.
It is impera�ve to unplug the power cord a�er the
appliance has been used, before it is cleaned and whilst
being repaired.
Repairs to electrical appliances should be performed by
qualified personnel. Improper repairs may place user at
serious risk.
DO NOT operate this appliance with a damaged plug or
cord, a�er a malfunc�on or a�er being dropped or
damaged in any way.
Regular, periodic checks should be carried out on the
mains cable to ensure no damage is evident. Should there
be any signs of damage the appliance should not be used.
If the power cable is damaged, it should only be replaced
by suitably qualified personnel in order to avoid a hazard.
DO NOT allow the mains cable to hang over sharp edges or
come into contact with hot surfaces.
DO NOT run the mains cable under carpets, rugs etc.
This appliance is intended for household use only and
should not be used for industrial purposes.
DO NOT use this appliance for anything other than intended
use.
DO NOT push objects (including fingers) into the fan grill or
any openings as this could risk injury or damage to the
appliance.
Unplug a�er each use. Grasp the plug not the cord.
THIS APPLIANCE MUST BE EARTHED
4
16” Chrome Pedestal Fan
Model No. COL1608
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Explanaon of Symbols
The following warning symbols or words are used in this instruc�on manual:
Products labelled with UK Conformity Assessment iden�fies
products conforming to UK statutory requirements.
Products labelled with this symbol conform to applicable provisions
of the European Economic Area.
You should now recycle your waste electrical goods and in doing so
help the environment. This symbol means waste electrical products
at the end of their useful life should not be disposed of with normal
household waste and not sent to landfill. Please ensure it is taken
to a suitable facility for disposal. Check with your Local Authority or
retailer for recycling advice or visit www.recycle-more.co.uk or
www.weeeireland.ie enter your postcode to find out your nearest
recycling site.
This symbol indicates that the supply uses an alterna�ng current
mains supply.
Before first use of Your Pedestal Fan
Remove all packing materials and discard responsibly.
Ensure all parts are present - see Descripon of Parts below.
Check that there is no transit damage to the mains cable or product.
5
16” Chrome Pedestal Fan
Model No. COL1608
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Descripon of Parts
Assembling Your Pedestal Fan – Fing the Base (15)
1. A�ach the Stand (6) to the Base (15)
as follows:
Place the Weight (16) and Clamping
Washer (17) on the underside of the
Base (15) as shown le�.
Thread the L - Shaped Screw (18)
through the assembly and into the
thread in the Stand (6). Tighten firmly
but do not over�ghten.
1 Front Guard
2 Front Guard Screw (x1)
3 Acrylic Fan Blade
4 Rear Guard
5 Front Guard Nut (x1)
6 Stand
7 Pivot Screw
8 Tilt Screw
9 Motor Housing
1
0 On/Off/Speed Control
1
1 Oscilla�ng Control
1
2 Motor Spindle
1
3 Fan Blade Retaining Nut
1
4 Guard Clips
1
5 Stand Base
1
6 Weight
1
7 Clamping Washer
1
8 L – Shaped Screw
1
9 Locking Screw (not shown)
2
0 Pivot Bolt (not shown)
6
4
5
3
1
9
13
2
7
11
10
12
8
14
6
15
16
17
18
15
16
6
17
18
6
16” Chrome Pedestal Fan
Model No. COL1608
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
2. Place the stand onto its Base (15)
and a�ach the Motor Housing
(9) to the top of the Stand (6) as
follows:
3. Remove all the screws, etc. (7, 8,
19 & 20) from the motor housing
bracket as shown right:
4. Hold the Motor Housing (9) and carefully
place it on top of the Stand (6) such that the
holes in the motor bracket align with the
holes in the Stand (6).
5. Thread the Pivot Bolt (20) through the motor
bracket and screw in the Locking Screw (19)
into the hole in the motor bracket but do not
fully �ghten.
6. Fit the Pivot Screw (7) onto the end of the
Pivot Bolt (20) and screw in the Tilt Screw (8).
Hold the Motor Housing (9) upright and
�ghten the Pivot Screw (7) and the Tilt Screw
(8).
Fing the Fan Guard and Fan Blade
1. Remove any protec�ve sleeving (if fi�ed) from
the Motor Spindle (12) and discard responsibly.
2. Remove the four screws from the front of the
Motor Housing (9).
3. A�ach the Rear Guard (4) to the Motor Housing (9) using the four screws
removed. Ensure the carry handle on the Rear Guard (4) is uppermost.
7
6
9
19
20
8
20
19
8
7
7
16” Chrome Pedestal Fan
Model No. COL1608
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
4. Place the Fan Blade (3) over the Motor
Spindle (12) ensuring that the spline in the
motor spindle aligns with the notch (arrowed
le�) in the fan blade as it is pushed onto the
spindle.
5. Screw on the Fan Blade Retaining Nut
(13 – arrowed right) and �ghten.
NB the Fan Blade Retaining Nut (13) is reverse
threaded, i.e. it screws on an�clockwise.
6. Remove the Front Guard Nut & Screw (5 & 2) from the Front Guard (1).
7. Turn the Guard Clips (14) around the
outside edge of the Front Guard (1)
outwards.
8. Hang the Front Guard (1) by its hook
(arrowed right) over the top of the
Rear Guard (4).
9. Bring the Front Guard (1) down to meet
the Rear Guard (4) and push the Guard
Clips (14) inwards un�l the Front Guard
(1) is fastened to the Rear Guard (4).
8
16” Chrome Pedestal Fan
Model No. COL1608
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
10. Finally fit the Guard Nut and Screw (5 &
2) through the holes in the bo�om edge
of the guard and �ghten with a suitable
pozidrive screwdriver (not supplied).
NB this nut and screw must be fi�ed so that
the guard cannot be removed accidentally.
Using Your Pedestal Fan – Adjusng the Tilt Angle
Place the fan in the desired posi�on and ensure that it is ver�cal and stable.
The fan guard can be �lted up and down to alter the
direc�on of the airflow. To do this, slacken the Pivot
Screw (7) and the Tilt Screw (8). Set the posi�on of the fan
and then �ghten the two knobs (7 & 8)
NB do not adjust the fan whilst connected to the mains.
Using Your Pedestal Fan – Adjusng the Fan Height
Before adjus�ng the height, hold the Motor Housing (9)
to prevent it dropping down.
Loosen the height locking screw (a - le�) and raise or
lower the height of the fan to the desired posi�on and
re�ghten the screw.
NB do not adjust the fan whilst connected to the mains.
Seng the Fan Speed
To operate the fan, ensure that the On/Off/Speed Control (10) is in the ‘0’
posi�on.
Insert the mains plug into the nearest socket.
Rotate the On/Off/Speed Control (10) as follows:
I for the low speed,
II for the medium speed
III for the high speed.
Return the control to the 0 posi�on to switch the fan off.
Oscillaon Mode
Press the Oscilla�on Control (11) down to enable the fan to oscillate from side to
side.
Pull the control up to stop the fan oscilla�ng.
7
8
a
10
11
9
16” Chrome Pedestal Fan
Model No. COL1608
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Care and Maintenance
Ensure that the fan is switched off and it is not connected to the
mains supply before cleaning.
Wipe the fan clean with a clean, so� damp cloth.
Do not immerse the fan or its cord in water or any other liquid.
Non-Rewireable Mains Plug
If your appliance is supplied with a non-rewireable plug fi�ed to the mains lead
and should the fuse needed replacing, you must use an ASTA approved one
(conforming to BS 1362 of the same ra�ng). Never use a plug with the fuse cover
missing. If in doubt, consult a qualified electrician.
If you need to remove the plug -DISCONNECT FROM THE MAINS- and then cut
it off the mains lead and immediately dispose of it safely. Never a�empt to
reuse the plug or insert it into a socket outlet as there is a danger of electric
shock.
Technical Specificaon
Model No.
COL1608
Voltage
220-240V~ 50-60Hz
Rated Power
50W
Protec�on Class
I (This Appliance Must be Earthed)
Disposal of the Packaging
Dispose of paper and cardboard in appropriate paper re-cycling facili�es.
Dispose of recyclable plas�cs in appropriate plas�c re-cycling facili�es.
Dispose of non-recyclable plas�cs in the appropriate plas�cs collec�on service.
Disposal of the Product
You should now recycle your waste electrical goods and in doing so
help the environment. This symbol means waste electrical products
at the end of their useful life should not be disposed of with normal
household waste and not sent to landfill. Please ensure it is taken to
a suitable facility for disposal. Check with your Local Authority or
retailer for recycling advice or visit www.recycle-more.co.uk enter
your postcode to find out your nearest recycling site.
10
16” Chrome Pedestal Fan
Model No. COL1608
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
WARRANTY
Thank you for purchasing your Daewoo product.
As part of our commitment to quality, we are offering you an extra 2 years warranty in
addion to your 1 year guarantee
Your Daewoo vacuum product is guaranteed for 1 year from the date of original purchase,
with proof of purchase or receipt. If any defect should occur due to faulty workmanship or
material, your faulty vacuum should be returned to the place of purchase, replacement or refund is
at the discre�on of the retailer.
The g
uarantee is subject to the following provisions:
•
The product must be correctly installed and operated in accordance with the
requirements contained in the instruc�on manual.
•
The product must be used solely for domes�c purposes.
•
It does not cover general wear and tear, damage, misuse or any consumable parts.
•
The guarantee will be rendered invalid if the product is re-sold or has been damaged through
inexpert repair.
•
The guarantee is only valid within the UK and Eire.
Your standard 1 year guarantee will only be extended to the maximum available for your
individual product upon registra�on. (Note: products must be registered individually and
covers the main body and housing). If you do not register your product within 28 days of the
original purchase date, your product will only be guaranteed for 1 year.
To validate your extended 2 year warranty*please register your purchase online within 28
days of the original purchase date by registering at:
hps://help.daewooelectricals.com
or
Contact Us (daewooelectricals.com)
*Your extended warranty is only valid with proof of purchase receipt and subject to the
condi�ons outlined above.
Daewoo is a registered trademark.
Produced and imported under licence by
Eurosonic Group Limited
Brightgate House
1 Brightgate Way
Manchester M32 0TB UK
EU Rep: EuroSonic Magppie (ESM) Ltd. Ireland D05 X006
www.esgltd.com
