SMART LOCK + VIDEO DOORBELL
USER MANUAL
DEADBOLT EDITION
VISION
™
Table of Contents
TABLE OF CONTENTS
2.1 Product Overview - Exterior
2.2 Product Overview - Interior
2.3 Understanding Your New Lock
2.4 Keypad Display Switch
2.5 Rebooting Your Lock
2.6 Low Battery
Section 1 - Product Highlights
Section 2 - Product Overview
Section 3 - Using Your Smart Lock
Section 4 - Locking and Unlocking
1.1 Product Features
4.2 Unlocking with Fingerprints
4.3 Locking/Unlocking with Physical Key
4.4 Locking/Unlocking with App
4.5 Locking/Unlocking with Voice Assistants
4.6 Safe Mode
4.7 Rain Mode
4.8 Shine Mode
4.9 Welcome Mode
4.10 Pairing to a New Mobile Device
Section 5- Advanced Features
1
2
3
4
5
6
7
8
13
14
15
16
17
18
20
21
21
22
23
27
28
Section 6 - Re-keying
31
30
32
4.1 Unlocking using Access Codes
29
For additional support,
visit http://Lockly.com/help or email
5.1 Video Doorbell
5.2 Offline Access Code
™
(OAC)
5.3 Sub-Admin Access
2.7 Changing The Battery
9
10
11
12
Section 7 - Important Notes
7.1 Important Notes
Section 8 - Cleaning
8.1 Cleaning
Section 9 - Safety Precautions
9.1 Safety Precautions
6.1 Re-keying
3.1 Configuring Access
3.2 Adding a Fingerprint
3.3 Fingerprint Scanning Directions
3.4 Fingerprint Scanning Tips & Troubleshoot
Video Monitoring and Recording
See who's at your front door with Live View camera streaming, real-time high-resolution video from
your smartphone. Video recordings are stored locally with no monthly fees.
Patented Hack-Proof PIN Genie Keypad
Digits are randomly displayed on the keypad ensuring access codes to be undetectable to
intruders after repeated use. Numbers are randomly distributed across 4 buttons, with 3 numbers
in each button. Users can press any button showing their number. Location of the numbers are
always different everytime someone uses the keypad, making it hard for prying eyes to guess the
correct code.
Multiple Access Codes & Monitoring
Store up to 16 Access Codes for family, friends and guests, as well as monitor entry and exit records.
Advanced 3D Fingerprint Recognition
Biometric Fingerprint Recognition protocol allows up to 99 registered fingerprints to be used and
accepts only actual fingerprints - preventing lifted prints from being used.
Live Monitoring and Voice Control
Through your smartphone, monitor door access from anywhere in the world and securely control
who comes and goes. You can also control your Lockly smart lock using voice with your Amazon
Alexa or Google Assistant-enabled devices.
Complete Privacy
The exterior displayed keypad can be locked and switched off using the simple ON/OFF toggle
from the inside panel. The owner can prevent others trying to input the passcode from the outside
and entering the home
Offline Access Code
TM
(OAC)
The offline access code can allow owners to issue access codes, set the allowed access duration,
all without Lockly ever connecting to the internet, so in case of power outage, you can still magically
and remotely issue Access Codes without any connection to the web.
Auto-Lock
Users no longer have to worry about forgetting to lock the door. With Auto Lock enabled, Lockly
will automatically auto-lock the door based on your customized timing set between 5-300 seconds.
Tamper Proof Keyhole and 9V Battery Socket
The door can be opened with physical backup keys. Receive notification whenever there's an
attempt to tamper your lock. There is also a 9V battery connection socket for emergency power
backup to access the keypad in case your smart lock runs out of battery.
1.1 Product Features
SECTION 1.11
SECTION 2.1 2
2.1 Product Overview- Exterior
9V Battery Emergency
Charging Socket
Reboot
OK Button
Battery Indicator
Fingerprint Sensor
Key Hole
Key Hole Cover
Video Camera
Microphone
Safe/Welcome Mode
Video Doorbell Button
Video Doorbell Light Indicator
Speaker
Bluetooth Icon
2.2 Product Overview - Interior
SECTION 2.2
3
Battery Compartment
(Operated by 2 x 4 x AA Batteries)
Battery Cover
Display Keypad Switch
Thumbturn
Program Button
Reset Button
Low Battery|Door Sensor LED
Doorbell
2.3 Understanding Your New Lock
After the installation of your new Lockly Vision
TM
, understanding some key functions of
operating your smart lock is important. The next sections will walk you through configuring
Access Codes, adding fingerprints, video doorbell recording, resetting, pairing, configuring
your Offline Access Code
™
(OAC) and other features of your lock.
For any questions you can always visit http://Lockly.com/help for assistance.
Don’t forget that in order for Lockly Vision
™
to work with full features, it is required to pair
it with the Lockly App available for both iOS and Android
™
smart devices. Please download
the app by visiting the link below.
SECTION 2.3
Scan or visit Lockly.com/app
4
SECTION 2.45
2.4 Keypad Display Switch
For your peace of mind, the exterior keypad screen can be locked and turned off by
using the ON/OFF switch at the back panel (PART G) of the smart lock. When it is switched
off, people who are outside cannot enter any access codes to unlock the door.
OFF
ON
2.5 Rebooting Your Lock
NOTICE
Reboot Lockly in case of dead battery or malfunction. No
settings will be changed and all Access Codes will still be
stored within Lockly.
Press and release the reboot button when you want to reboot the lock. Your Lockly will
beep once after reboot. Only reboot when necessary.
To reboot, find the reboot pin hole located on the bottom of the exterior side of Lockly
lock. The reboot button is located in the middle of the two 9V battery backup sockets.
You will need something small such as a paperclip, to press the reboot button. Insert
the paperclip and press down firmly and let go. Your screen should restart and the lock
should reboot automatically.
Reboot Button
SECTION 2.5 6
SECTION 2.6
7
2.6 Low Battery
When the battery is in seriously low condition, Lockly will make continuous beeping
sounds in addition to the flashing low battery icon on the touch screen. You should replace
batteries immediately to avoid your smart lock from shutting down.
When your smart lock low-battery warning alert finally dies, video doorbell and recording
will be disabled. You will have few more chances to unlock your smart lock either by a
password, Lockly APP or fingerprint. If the unlock was successful, the low-battery warning
alert will be on for 1 minute. After which, the smart lock will go to dead-battery mode
and will lock auto lock in 5 seconds and the screen will display a low-battery icon.
Dead Battery
Condition Indicator Solution
Low Battery
Battery Icon on the display
keypad will light up to indicate
low battery.
Replace batteries immediately
to avoid battery failure. Lockly
Vision can still operate up to 50
cycles in low battery condition.
When there is no display and
sounds; and screen is non-functional.
Replace batteries immediately.
Supplied physical backup keys
can be used to unlock the door.
Alternatively, use a 9V battery
as shown below to temporarily
activate the lock.
Your Lockly will automatically detect battery
polarity. So hold your 9V battery lead in
place against bottom of the Lockly to
temporarily activate the screen to enter
your Access Code. Be sure to hold the 9V
battery against the contact points located
at the bottom of the lock until you have
successfully unlocked your door with your
Access Code. Once unlocked, batteries
should be replaced immediately.
9V Battery
-
+
SECTION 2.7 8
2.7 Changing The Battery
Under normal use, the Lockly Vision
TM
battery will last up to 8 months. Please change your
batteries when the low battery notification is issued. For best practice, always use new
Alkaline batteries by a major brand.
Do not pull the ribbon. Remove top layer of batteries using
your finger tips. Push the batteries against the spring to
loosen and remove one by one.
Gently pull the ribbon to remove the bottom layer of
batteries.
Use ONLY new Alkaline batteries and do not mix new with
used batteries as replacement. First, place the ribbon
inside then insert 4 batteries on the bottom layer according
to polarity.
Continue to install the 4 batteries on the top layer, then
reinstall the battery cover and screw.
- Make sure the batteries are oriented correctly by matching the orientation displayed.
- Replacing the batteries do not reset stored Access Codes.
- To see a list of recommended brands, please visit http://Lockly.com/battery.
Be sure to unscrew the screw located on the top of the cover before sliding the cover
up.
Whenever batteries are replaced, reconnecting the smart lock to
your smartphone App is required. If you have not yet downloaded
the app, visit: Lockly.com/app
NOTICE
A
B
C
+
-
-
-
+
+
+
-
9
3.1 Configuring Access
The Default Access Code is
NOTICE
1 2 3 4 5 6
Your new Lockly Access Code can be any combination of 6 to 8 digits. Once a new
Access Code is entered, the Default Access Code of 123456 would be deleted. A maximum
of 16 sets of Access Codes can be stored for use at any given time. To add more than
16 sets of Access Codes, you must delete an existing Access Code before adding a new
code.
There are a total of five (5) buttons on the keypad as
shown in the example image to the left. The numbers
in each button may differ than what is shown on your
device than what is displayed here.
To enter your required digit, just simply press the circle
where your number is shown. You do not need to
press the actual number as anywhere within the circle
will suffice.
The button on the bottom is the OK button. You will be
pressing this button when you are done entering your
Access Code.
OK Button
Pair your lock to your smart phone to manage your access codes. Follow
the on screen instructions to complete the setup.
There are different types of Access Codes that can be generated using the Lockly App.
Each type of access code have different levels of permission you can select for your
guests, tenants, deliveries, helpers, etc., Get the latest updates on access codes, visit:
www.support.lockly.com/faq/accesscodes/
SECTION 3.1
3.2 Adding a Fingerprint
Scan your finger by lightly placing your designated finger on the sensor until you hear a
beep. Lift your finger and repeat the process slowly until the digit “6” shown on the
screen becomes “1”. If you have successfully scanned and registered your fingerprint,
you will hear a long beep, and the video doorbell light indicator will blink green.
PASS will be displayed on the keyboard and automatically return to the number pad. If
you did not successfully register your fingerprint, FAIL will show on the keypad. If FAIL is
displayed, return to the previous menu and rescan your finger.
OK Button
NOTICE
Please make sure your fingers are clean from dirt and oils before
scanning your fingerprint. Make sure the sensor is also clean by
taking a soft cloth and wiping the surface.
We are using an advanced biometric sensor, providing the most secure fingerprint
authentication. Your smart lock can register up to ninety-nine (99) fingerprints. Use the
Lockly app to add fingerprints.
SECTION 3.2 10
3.3 Fingerprint Scanning Directions
The fingerprint sensor equipped in your smart lock is loaded with powerful fingerprint
algorithms to extract only metadata from fingers, even in poor conditions. Placing your
finger on the sensor correctly helps consistency in fingerprint recognition. The following
directions and tips will guide you on how to scan an optimal fingerprint image.
Sensor
Core
Position your finger on the
center of the sensor
Top View
Side View
OK
OK
Correct
Incorrect
SECTION 3.3
11
3.4 Fingerprint Scanning Tips & Troubleshoot
Tips for Fingerprint Enrollment and Recognition
• Place your finger to completely cover the sensor with maximum contact surface.
• Position the center of your finger (core) to the center of the sensor.
• Hold your finger still for more than a second until you hear a beep.
• Scan a finger that is clean and free from dirt.
• Children ages 12 and under are not recommended to use fingerprint access due to
the constant changes of their fingers during growth.
• Elderly with fading fingerprints may have difficulty in recognition.
• If your finger has a cut, scar, or cracked skin due to dryness, try another finger.
Troubleshooting Fingerprints
In case of poor fingerprint conditions
• If wet - wipe excess moisture from finger before scanning
• If dirty - wipe stains and dirt off from finger before scanning
• Make sure the sensor is clean from dirt or smudges - wipe sensor with soft cloth regularly
For more troubleshooting help, visit http://Lockly.com/help
SECTION 3.4 12
4.1 Locking/Unlocking with Access Codes
Lockly Smart Lock can be unlocked using multiple ways - via your stored Access Code,
registered fingerprint, smartphone with Bluetooth, the physical key supplied with your lock,
or voice.
OK Button
Three consecutive wrong attempts will put Lockly in “Safe Mode”. (See Section 4.6)
Lock your Lockly by pressing the OK Button or by brushing your hand across the screen
anytime when the door is closed. The smart lock will also auto-lock after unlocking based
on your set auto-lock settings.
Slide your hand across the screen to activate
the keypad.
Enter your 6 to 8 digit Access Code followed
by the OK button. Press OK anytime to reset if
you entered the wrong digit.
If the Access Code entered is correct, the door
will unlock. If the Access Code entered is
incorrect, Lockly will flash red light.
Hold OK Button (3 sec)
You may toggle between two types of keypad
displays to enter your Access Code. The fixed digit
version and the PIN Genie version (Recommended).
Press and hold the OK Button for 3 seconds to
toggle back and forth between the two keypads.
(Sample display shown only)
PIN Genie
Fixed Digit
SECTION 4.113
4.2 Locking/Unlocking with Fingerprints
Place a registered finger to the fingerprint scanner
located on the exterior side of the lock to the right.
To register a fingerprint, please see Section 3.2.
If your fingerprint is registered and acknowledged,
you will hear a “beep” sound and a Green LED will
light up on the fingerprint scanner. You can then
open the door.
If you see a Red LED, it means your fingerprint is not
recognized. Try again or use another registered
fingerprint.
For best fingerprint scanning practices, see Section
3.3.
Unlocking
SECTION 4.2
14
4.3 Locking/Unlocking with Physical Key
Exterior View
We presumed you will not be using the key on a regular basis. To better protect you
from malicious lock bumping, video will start recording whenever a key or bumping
devices are used to unlock the door.
To unlock your lock using the physical key (included), open the key cover by sliding the
cover on either left or right direction to reveal the keyhole. Insert key and turn clockwise
(right swing door) or counterclockwise (left swing door) to unlock the door.
SECTION 4.315
4.4 Locking/Unlocking with App
You must have the Lockly iOS or Android
TM
app installed in order to lock and unlock with
smartphone, connect with voice assistants like Alexa or Hey Google and to access video
doorbell feature. Please download the app by visiting the link below or search “Lockly”
from the correct app store.
Scan or visit
Lockly.com/app
16
SECTION 4.4
Once your Lockly Vision
™
and Vision Connect has been installed and configured correctly,
make sure you enable the Lockly Action on Google or the Amazon Alexa Skill before you
can configure your voice to perform voice commands.
You can ask your questions such as door status or request for your door to be locked or
unlocked.
- “Hey Google, unlock the Back Door”
- “Hey Google, is the Back Door locked?”
- “Hey Google, lock the Back Door”
- “Hey Google, is the Back Door unlocked?”
Pre-setup is required in the Google Home app
in order for these queries to work. The user
would need to the name the lock "Back Door"
or as appropriate.
- Alexa, unlock my Front Door.*
- Alexa, is my Front Door locked?
- Hi Alexa, lock my Front Door.
- Alexa, is my Front Door unlocked?
*Unlock requests will require additional voice security codes.
You may configure it in the settings page.
Google, Android, Google Play and Google Home are trademarks of Google LLC.
4.5 Locking/Unlocking with Voice Assistants
SECTION 4.517
4.6 Safe Mode - Overview
Lockly will enter Safe Mode when three (3) consecutive wrong Access Codes are entered
within 5 minutes. A 15 second video will be recorded once the lock entered into Safe
Mode. When in Safe Mode, the lock status icon will start to flash.
To disable Safe Mode, you must unlock the door using the correct fingerprint or enter the
correct Access Code twice in a row. Activate the keypad by pressing and holding for
3 seconds.
Once the screen is activated, enter the correct Access Code
carefully twice, pressing
after every time.
If you enter the wrong code, the keypad will then be disabled for 10 minutes.
Countdown Prompt
(Displayed in Minutes)
Will start with 10 and
countdown until 0.
You will see a “10” on the screen, notifying the number of minutes that the keypad is
disabled for. After 10 minutes, you may attempt to enter the correct Access Code to
unlock the door. After the second incorrect attempt to unlock the lock with the wrong
Access Code, Lockly will disable the keypad for 20 minutes, displaying a “20” on the
screen. After the third wrong attempt to unlock the door with the correct Access Code,
the screen will be disabled for 30 minutes. (Example A and Example B above).
Note: In order to conserve power, the countdown prompt will only be displayed for 3 seconds.
You can reactivate the screen by sliding your hand across the screen.
Example A Example B
SECTION 4.6
18
Option 1 - Entering Correct Access Code
Activate the keypad by pressing and holding for 3 seconds. Enter the correct
Access Code twice (2) when the keypad is available, pressing after every time
the Access Code is entered.
Lockly will enter Safe Mode when three (3) consecutive wrong Access Codes are entered
within 5 minutes. A 15 second video will be recorded once the lock entered into Safe
Mode. When in Safe Mode, the lock status icon will start to flash.
To disable Safe Mode, you must unlock the door using the correct fingerprint or enter the
correct Access Code twice in a row. Activate the keypad by pressing and holding for
3 seconds.
Once the screen is activated, enter the correct Access Code carefully twice, pressing
after every time.
If you enter the wrong code, the keypad will then be disabled for 10 minutes.
4.6 Disabling Safe Mode
Option 2 - Lockly App
Use the app that is synced to your Lockly to disable Safe Mode by unlocking the door.
If you have not downloaded the app to use with your smart lock, you won’t be able
to use this option to disable Safe Mode.
Option 3 - Physical Key
There is a pair of keys supplied with your new lock. You may use the keys to manually
unlock the door and disable Safe Mode. To learn how to use your physical keys, see
Section 4.3.
Option 4 - Registered Fingerprint
Use any registered fingerprint to reactivate the keypad. The door will unlock and reactivate
the keypad once a registered fingerprint is used.
There are four (4) ways to disable Safe Mode.
SECTION 4.619
Like other digital electronic products water can trigger to activate the touchscreen and
fingerprint sensor which may cause the batteries to drain. To protect the lock and extend
battery life, you can setup your Lockly to enter Rain Mode to shut off keypad and fingerprint
reader whenever rain or water is detected.
Activate this feature on the Lockly app. While you are within the Bluetooth range or
remotely connected thru Wi-Fi hub (Secure Link), go to Settings > Rain Mode and toggle
the button to turn ON.
If you have not yet connected your device to Lockly App, follow below steps to activate
the rain mode feature:
To reactivate fingerprint and keypad access when
your lock has entered rain mode, turn the key cover.
When RAIN MODE is ON, the keypad and fingerprint
sensor cannot be used. Unlock via Lockly App,
physical key, or voice with your Amazon Alexa or
Google Assistant-enabled devices. Rain Mode auto
exits every 30-mins and re-enters if water or rain is still
present.
If you are using the Lockly app, you will be notified
when Lockly entered rain mode and it will be recorded
in your access history.
RAIN MODE ON
1. Long press to enter fixed digit keypad.
2.
Enter
access code +234+ .
3. You will hear a short beep and Bluetooth
indicator flashes green once Rain Mode is ON.
RAIN MODE OFF
1. Long press to enter fixed digit keypad.
2. Enter access code +890+ .
3. You will hear a long beep and Bluetooth
indicator flashes green once Rain Mode is OFF.
example: 135790 + 234 +
example: 135790 + 890 +
IMPORTANT
4.7 Rain Mode
20
SECTION 4.7
SECTION 4.821
4.8 Shine Mode
Lockly touchscreen keypad brightness was designed for optimum battery life. However,
some users may need to adjust the brightness to their convenience to enter access codes.
Swipe your fingers across the keypad to
light up to its normal brightness. To adjust
brightness, long press the upper left button
for 3 seconds.
The touchscreen keypad with
automatically return to normal
brightness after the screen
dimmed.
4.9 Welcome Mode
Welcome Mode temporarily disables auto locking, keeping the door open for a specified
period of time eliminating the need to enter access codes, fingerprint or using Mobile App.
Enable this feature through the Lockly App. Go to Settings > Enable Welcome Mode, then
slide button to enable and set the specific time you require your door unlocked.
SECTION 4.10 22
To pair your Vision to a new mobile phone, download the Lockly app on your new
mobile phone then use the same account to login to your Lockly App on the new mobile
device.
If you're pairing your Vision to a new Lockly app account, follow the steps below
1.
2.
3.
4.10 Pairing to a New Mobile Device
Scan to new Lockly
app account
3
1
2
Old Lockly app account
IMPORTANT:
DO NOT INSERT ANY PINS TO RESET HOLES OF VISION SMART LOCK OR
VISION CONNECT HUB without consulting our support team. If you
cannot remove your Lockly from the old account, please contact
Lockly support (669) 500 – 8835 or email: [email protected]
*Activation Code card can be found inside the packaging box flap. Store it for future use.
Once you have registered your lock on the Lockly app, you have the option to save it
on the PIN Genie Vault. To access details for future use, check your account information
and go to PIN Genie Vault.
SCAN & SAVE
LOCK SERIAL
PGDXXXXXXXXXX
ACTIVATION CODE
XXXXXXXX
On the old Lockly app account, go to Settings> Reset and pairing> Perform Factory Reset.
Download, register and log in to the new Lockly app account.
You will need to scan the ACTIVATION CODE* that comes with the lock to setup to a
new account.
See Step 9 & 10 of the Installation Guide to pair Vision on the new Lockly
app
account.
5.1 Video Doorbell
Lockly Vision
™
has a built-in HD video doorbell with real-time video streaming on your
smartphone and real-time 2-way voice interaction. Recordings are stored locally on the
TF card, with no monthly fees, and you can access video recordings from anywhere
using the Lockly app. To enjoy these features, make sure the below procedures are
done correctly:
REMINDER: Install the provided “Please Ring Doorbell on Door Lock” plate on a clean
and dry surface pointing the arrow to Lockly Vision
™
to remind guests.
- Vision is initiating the call. If the red light
flashes, it failed to connect to the hub or
network.
- Vision is sending App push notificatio and
waiting for response.
- Ready to Talk ( 3 blinks)
23
SECTION 5.1
Setup the Vision Connect Hub according to Installation Manual (See Step 10)
Download the Lockly App and connect Lockly Vision
™
according to on-screen
instructions
Allow your smartphone to receive push notifications or alerts from your Lockly
app. Please check on iOS or Android
TM
procedures for allowing push notifications
and alerts.
If you're an existing Lockly app user, make sure you have the latest firmware.
Go to Settings > Firmware Upgrade.
Doorbell
When someone press on the doorbell button,
the smart lock will ring. The LED lights indicate
the following:
5.1 Video Doorbell
When the doorbell is pressed, you will receive a notification through the Lockly app.
Once you tap on the notification, app will automatically open to allow you to see who's
at your door.
Enhanced Alert Notification
Lockly Vision
TM
has an enhanced alert notification feature. When someone rings your
doorbell and you were unable to answer, you will receive a 2nd alert notification.
We suggest you keep this feature ON if you expect to be in areas with unreliable internet
connection and you do not wish to miss any important visitors. You can switch off this
feature in the Lockly App, otherwise.
Tap the Call
icon to initiate
conversation.
SECTION 5.1 24
5.1 Video Doorbell
Vision enables you to attend to your door when you are not at home. While using the
app, you can use the icons below to view, initiate conversations and unlock door.
Live View
You can open the Lockly App and tap on the
camera to see what Vision sees at all times.
End Call
Tap icon to hang up without opening the door.
Microphone
Tap mic to mute or unmute.
TIP: Limit video interaction with guests to prolong battery life.
SECTION 5.1
25
Unlock
Tap icon to unlock door.
5.1 Video Doorbell
Video Recording
Lockly Vision
™
stores video recording on the local TF card and recording can be accessed
on the log history on your Lockly app.
1
Lockly Vision
TM
TF card with regular use can store up to 1-year worth of video recordings.
Vision automatically initiate video recording when
below conditions take place:
Use the keyboard to unlock
Doorbell button was pushed
Keyhole cover was opened
Offline Access Code™ was used*
eKey was used*
Wrong (PIN) access code was used and lock
entered in to Safe Mode
REMINDER:
- Video recordings can be customized through
the Lockly App settings*.
- Ensure the TF card is properly inserted on Vision
Connect to save the recordings
1
.
SECTION 5.1 26
5.2 Offline Access Code
TM
(OAC)
The Offline Access Code
TM
(OAC) is a unique feature of our smart lock. It allows you
to grant access to guests remotely without guests needing to download the app.
To use the OAC feature, make sure you download the Lockly app for iOS or Android
TM
first, and sync your smart lock to your mobile device. OAC can only be issued by the
administrative owner of the lock.
From there, you can then issue an Offline Access Code
TM
within the app.
Go to “Access” and choose “Add a New User, then select Offline Access Code
TM
(OAC)” and follow on screen instructions to generate your Offline Access Code
TM
.
Understanding Offline Access Code
TM
(OAC)
OAC are issued to the guest by asking them to enter 4-12 digit number after a double
-click on the . Your Lockly randomly generates the Offline Access Code
TM
which
can be shared to your guests together with the instructions generated using the
Lockly app.
After a double-click on the , touchscreen will
display numbers on Fixed Digit mode, then guest
the Offline Access Code
TM
will be entered twice.
27
SECTION 5.2
5.3 Sub-Admin Access
Sub-Admin Access can be created to grant access for others to be able to control your
lock and grant access to others via Bluetooth when within range of your Lockly smart
lock. The sub-admin permission can be setup through the Lockly App then write in bold.
You can select the Validity Period and User Permissions of the sub-admin.
Sub Admins will not be able to access the lock remotely but Sub Admin will be able to
grant limited access codes to users when within Bluetooth range. Once Sub Admin con-
trol is setup, you as the Admin will no longer be able to issue Offline Access Code™
(OAC).
The Sub-Admin access is ideal for long term property leasing and Airbnb tenants.
SECTION 5.3 28
6.1 Re-keying
Lockly smart lock comes with a 6-pin cylinder which can be replaced with regularly
purchased DIY re-keying kit available in the market.
If you are not familiar with this process, please contact a professional locksmith. For more
information, visit : http://support.Lockly.com/faq/rekeying/
SECTION 6.129
7.1 Important Notes
Auto Lock Feature
You can program the auto lock timing through the Lockly App. If auto-lock is not activated
and door is still open, the touch-screen will remain lit, simply press the on the keypad
to lock.
One-Touch Locking
You can always manually lock by touching anywhere on the touchscreen. Lockly smart
lock is shipped with this feature already activated. You may deactivate this feature
through the Lockly App.
9V Backup Access
When your Lockly is out of power, you can temporarily activate the keypad by connecting
a 9V battery to the bottom part of the side exterior assembly. Please see Section 2.6 for
more info.
Physical Keys / Tamper Proof Recording
Even though you have your fingerprints registered and Access Codes stored, it’s always
best practice to carry your physical keys with you at all times in case for any reason
your lock falls into Safe Mode. Your video recording will be triggered whenever a key is
used.
Activation Code
You may find an Activation Code Card with an Activation Code included in your package
.
It is very crucial that you do not lose this card. Please store this card safely as you will
need the default Activation Code on that card to master reset your lock in case, for any
reason, you have lost the phone paired to Lockly and also forgot your Access Code.
Troubleshooting
Please visit http://Lockly.com/help for troubleshooting and the most frequently asked
questions and answers.
SECTION 7.1 30
8.1 Cleaning
Making sure your Lockly is clean is best practice to ensure optimal product use. Follow
the DOs and DON’Ts below.
DO DON’T
• Rinse the touchscreen with
warm water prior to cleaning.
• Use the application of soap
with a damp, lukewarm cloth.
• Airdry or wipe dry with a soft
microfiber cloth to avoid
scratches.
• Don’t use abrasives, high
alkaline cleaners, or gasoline to
clean your lock.
• Don’t apply cleaning detergent
directly in sunlight or at high
temperatures.
• Don’t leave cleaning
detergent on the display keypad
for long periods of time - wash
immediately.
• Don’t use scrapers, squeegees,
or razors.
31
SECTION 8.1
9.1 Safety Precautions
Please read all instructions carefully. Remind all Lockly users of the safety precautions.
Read the following instructions for your own safety
Do not attempt to disassemble the smart lock by yourself. It can cause product
damage, void warranty, and cause injuries.
Do not use any inappropriate tools that can cause damages or malfunction to
your lock.
Always make sure your door is securely closed and locked when you leave your
house to prevent unwanted entry.
Please keep your Access Codes safe. Restrict access to the back panel of your
smart lock and check your settings regularly to ensure Access Codes have not
been changed without your knowledge.
Always dispose of used batteries according to your local laws. DO NOT BURN.
Unauthorized changes and modifications may void your product warranty. If you
have questions or any problems while using your Lockly Vision
™
, contact our
customer service department at [email protected] or visit http://Lockly.com/help
for technical assistance.
SECTION 9.1 32
FCC Warning：
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) This device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may cause undesired
operation.
NOTE 1: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver
is connected.
- Consult the dealer or an experienced radio/TV technician for help.
NOTE 2: Any changes or modifications to this unit not expressly approved by the party
responsible for compliance could void the user's authority to operate the equipment.
FCC Radiation Exposure Statement
Lockly Vision complies with FCC radiation exposure limits set forth for an uncontrolled envi-
ronment. It should be installed and operated with minimum distance 20cm between the
radiator & your body.
IC WARNING
This device contains licence-exempt transmitter(s) that comply with Innovation, Science
and Economic Development Canada’s licence-exempt RSS(s). Operation is subject to the
following two conditions:
(1) This device may not cause interference.
(2) This device must accept any interference, including interference that may cause
undesired operation of the device.
L’émetteur/récepteur exempt de licence contenu dans le présent appareil est conforme
aux CNR d’Innovation, Sciences et Développement économique Canada applicables
aux appareils radio exempts de licence. L’exploitation est autorisée aux deux conditions
suivantes:
1. L’appareil ne doit pas produire de brouillage;
2. L’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est
susceptible d’en compromettre le fonctionnement.
IC Radiation Exposure Statement
This equipment meets the exemption from the routine evaluation limits in section 2.5 of
RSS-102. It should be installed and operated with a minimum distance of 20cm between
the radiator and any part of your body.
Cet équipement est conforme à l'exemption des limites d'évaluation habituelle de la section
2.5 de lanorme RSS-102. Il doit être installé et utilisé à une distance minimale de 20 cm
entre le radiateur et toute partie de votre corps.
WARNING:This product can expose you to chemicals including Lead, which
is known to the State of California to cause cancer. For more information go
to www.P65Warnings.ca.gov.
SECTION 2.8 9
For digital versions and instructional videos, please visit the following link:
http://Lockly.com/help
© Copyright 2022 Lockly All rights reserved
USA Patent No. US 9,881,146 B2 | USA Patent No. US 9,853,815 B2 | USA Patent No.
US 9,875,350 B2 | USA Patent No. US 9,665,706 B2 | USA Patent No. US 11,010,463 B2
| AUS Patent No. 2013403169 | AUS Patent No. 2014391959 | AUS Patent No.
2016412123 | UK Patent No. EP3059689B1 | UK Patent No. EP3176722B1 |
The Bluetooth
®
word mark and logos are registered trademarks owned by the
Bluetooth SIG, Inc. , and any use of such marks by Lockly is under license. Other
trademarks and trade names are those of their respective owners. Google,
Android, Google Play and Google Home are trademarks of Google LLC.
Amazon, Alexa and all related logos are trademarks of Amazon.com, Inc., or its
affiliates.
10
To ensure you have access to the most updated and newly added features of your
Lockly smart lock, please subscribe to our newsletters, follow us on our social media
channels, update your Lockly app when prompted, or visit: www.Lockly.com/newfeatures
