3M Glue pad(2pcs)
Thank you for choosing
VTB1000 User' s Manual
We have 2 types of installation methods:
(A) without Bracket, (B) with Bracket.
Before installation, please check carefully
and follow the steps below:
Main Part(1pcs)
User Manual (1pcs)
"L"wrench Φ 3.0 mm (1pcs)
"L"wrench Φ 5.0 mm (1pcs)
2.Size
4.Connection Diagram
Host Wiring Diagram:
CAMERA
MONITOR
Mobile DVR
CAMERA
Video Output:
Aviaon Plug Connector
3.Installation steps
Before you use this product,please read the introduction
Image Sensor
TV System
Minimum Illumination
Effective Resolution
Effective Pixel
S/N Ratio
Day & Night Mode
Auto Gain Control
Back Light Comp
White Banlance
Digital Noise Reduction
Lens
IR Leds Qty
IR Distance
Waterproof
Operating Temperature
Power Supply
Power Consumption
IP 68
-20°C~+70°C
DC12V±10%
≤2.5W
Electronic Shutter
AUTO/1/50（1/60）-1（100，000Sec）
10 PCS
5 m
AUTO
AUTO
AUTO
2D
960（H）*576（V）
PAL/NTSC
Color 0.05Lux; IR ON 0 Lux
50dB（AGC OFF)
EXT(AUTO Color B/W)
1/3 " CMOS
2.8/3.6 mm
1000 TVL
Suitable installaon pipe diameters are 22mm,26mm,and max 27mm.The other small
ones require that the pipe diameter match with the customized 3M silicone pad well.
9
7
4
8
6
5
3
1
2
10
11
12
13
14
15
16
17
18
19
19
A
B
1.Main Parts & Accessories
Power Cable(1pcs)
Serial number Part name Quantity
No.3-No.4 Tapping screw CA5x14mm 2
No.8-No.9 Cup head screw M4*10mm 2
No.10-No.11 Screw nut M6 2
No.13 Cup head screw M6*10mm 1
No.12/No.17-No.18 Antivibration gasket M6 3
Cup head screw M6*12mm 2
Cup head screw M6*16mm 2
No.19-No.20
