VTB192
3
size:105x148mm
Universal Bracket Mount 192 degree Wide View Camera
① The red wire is the monitor reversing trigger cable
② Connnecting the red wire with the reversing lamp 12V power
③ The Red (+) Wire reverse backup lights
④ The Black Wire chassis ground
⑤ Parking Line Loop (Green)
⑥ Reverse Image Loop (White)
3.Wiring Guide
For technical support, contact 888-941-3060 or email info@visiontechamerica.com
WWW.VISIONTECHAMERICA.COM
VTB192
Universal Bracket Mount 192 degree Wide View Camera
21
1.Bill of Material 2.Specifications
Technical Parameters
ASX 340
DC 12V(DC/DC)
34 mA
0.4 W
728(H)X560(V)
400K PIXELS
Auto
1.5 Lux
46 dB
330 TV Line
NTSC ,Color
192°
1Vp-p 75Ω
IP 68
AUTO
AUTO
AUTO
-40°~85°C
-40°~85°C
Technical term
Images sensors
Power Supply(DCV)
Current Consumption
Power
Effective pixel Array
Electionic shutter
Minimum illumination
Resolution(TV Lines)
TV System
Lens Angle(Deg.)
Video output
IP rating
AWB
AGC
BLC
Operating Tem
Storage Temperature
S/N Ratio
Technical Parameters
Item Description
Camera
Video Single Cable
Conversion Connector
Power Cable
3M Tape
Screw
User's manual
①
②
③
④
⑤
⑥
①
②
③
⑦ ⑧
Warranty Card
Registration Card
④
⑤
⑥
⑦
⑧
⑨
⑨
