1. SAFETY
WARNING! DO NOT open torch whilst in hazardous locations.
WARNING! DO NOT mix new and used batteries, nor mix dierent types nor mix from dierent manufacturers.
WARNING! Remove the batteries when unused for a period of time to prevent battery leakage in the device.
8 DO NOT charge NiMH batteries in the torch.
8 DO NOT shine directly into your, another person’s or an animal’s eyes.
8 DO NOT allow children to use the light.
8 DO NOT use the light if you suspect that the battery or the light casing is damaged.
9 Remove batteries when storing torch for any period.
2. INTRODUCTION
Single high power 3.6W SMD LED produces extremely bright, white light with an output of 120/32 lumens (high/low) and a working
range up to 172m. Operating time 6/69 hours. Three mode push-button for high, low and o settings. Intrinsically safe for use in
hazardous locations. Lightweight, tough and durable casing which will sustain high impacts and drops. Screw fastener prevents
inadvertent opening of battery container in hazardous environments. Built-in gas release vent. Features wrist lanyard connection.
Powered by 4 x AA batteries (not included).
3. SPECIFICATION
Model No: .......................................................LED452IS
Battery: .......................................... 4 x AA (not included)
IP Rating: .................................................................IP67
LED Type: ....................................................3.6W 1SMD
Lumen Output: ............................Low: 32lm, High:120lm
Operating Time: ..............................Low; 69hr, High; 6hr
Product Dimensions: ............................47 x 174 x 47mm
Range: ........................................ Low; 85m, High; 172m
4. OPERATION
4.1. BATTERY INSTALLATION
4.1.1. Undo light retaining screw (g.1), unscrew light unit and remove it.
4.1.2. Load batteries as indicated by the internal label.
4.1.3. Replace light unit and reassemble.
4.2. TORCH
4.2.1. The light ON/OFF/MODE button is located on the rear of the light (g.1).
4.2.2. The operation sequence is as follows:
A). one press provides 100% light.
B). two presses provides approx. 25% light.
C). third press will turn the torch o.
5. MAINTENANCE
5.1. Keep the torch clean by wiping with a damp cloth.
5.2. Store torch in a dry, childproof area.
FLASHLIGHT 3.6W SMD LED INTRINSICALLY
SAFE ATEX/IECEX APPROVED
MODEL NO: LED452IS
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these
instructions, and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
Refer to
instructions
g.1
Retaining
Screw
ON/OFF
Button
HT452IS Issue 3 (H,2,3,4,F) 21/06/23
Original Language Version
© Jack Sealey Limited
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 sales@sealey.co.uk www.sealey.co.uk
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be sorted,
taken to a recycling centre and disposed of in a manner which is compatible with the environment. When the product
becomes completely unserviceable and requires disposal, drain any fluids (if applicable) into approved containers and
dispose of the product and fluids according to local regulations.
WEEE REGULATIONS
Dispose of this product at the end of its working life in compliance with the EU Directive on Waste Electrical and Electronic Equipment
(WEEE). When the product is no longer required, it must be disposed of in an environmentally protective way. Contact your local solid
waste authority for recycling information.
Note: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior
notice.
Important: No Liability is accepted for incorrect use of this product.
Warranty: Guarantee is 12 months from purchase date, proof of which is required for any claim.
