3W COB & 3W SMD LED RECHARGEABLE
INSPECTION LIGHT
MODEL NO: LED317
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY
1.1. GENERAL SAFETY
9 Ensure the lamp is fully charged before initial use.
8 DO NOT turn the lamp on when it is being charged.
8 DO NOT shine directly into your, another person’s or an animal’s eyes.
8 DO NOT allow children to use the lamp.
8 DO NOT handle or move the lamp whilst it is being charged.
8 DO NOT use the lamp if you suspect that the battery or the lamp casing is damaged.
8 DO NOT leave battery in a discharged state, recharge battery immediately. Before storage, fully recharge the battery, subsequently
recharge the battery at least once every six months of non-use.
1.2. BATTERY SAFETY
WARNING! To reduce the risk of burns or re:
8 DO NOT attempt to open, disassemble, modify or service the battery pack.
8 DO NOT crush, puncture, short external contacts or dispose of in re or water.
8 DO NOT expose to temperatures above 60°C (140°F).
9 Recycle or dispose of used battery as stipulated by local regulation.
9 If the electrolyte in the cells gets on your skin, thoroughly wash with soap and water. If it gets in your eyes, rinse thoroughly with cool
water and seek immediate medical attention.
2. i INTRODUCTION
Mini, lightweight light. Featuring a super bright 3W COB LED, which gives an even and constant spread of light, producing up to 250 lumens. 3W
High power SMD LED torch producing up to 100 lumens. Integral hanging hook/belt clip and a magnetic base which can rotate through 180° for
hands-free applications. Features a battery level indicator. Rechargeable 3.7V 1.2Ah lithium-ion battery for longer life. Supplied with micro USB
cable.
3. i SPECIFICATION
Model No:.................................................................LED317
Battery ...............................................3.7V 1.2Ah Lithium-ion
Charging Time ................................................................2.5hr
IP Rating ........................................................................IPX4
LED Qty .................................................3W COB + 3W SMD
Length ........................................................................155mm
Lumen Outputs ..................................................... 250/100lm
Operating time ..................................................................3hr
4. OPERATION
4.1. CHARGING THE LAMP
4.1.1. Connect the USB lead to the socket on the rear of the lamp.
4.1.2. Plug the USB lead into a power supply and turn on.
4.1.3. When the battery has fully charged, the LEDs will turn GREEN.
4.2. OPERATING THE LAMP
WARNING! Direct the lens away from your eyes before switching on the lamp.
4.2.1. Toggle the lamp between the end light and side light using the mode selector switch (g.1).
4.2.2. The lamp may be suspended by the hook or attached to any ferrous surface by using the magnet.
5. MAINTENANCE
9 Keep the torch clean by wiping with a damp cloth.
9 Store torch in a dry childproof area.
5.1. IMPORTANT WARRANTY INFORMATION
5.1.1. The battery tted to this lamp is considered to be a consumable item and its ability to accept a charge will reduce over time.
5.1.2. We will provide warranty against mechanical and electrical defect for a period of one year - this DOES NOT cover fair wear and tear.
Refer to
instruction
manual
Original Language Version
© Jack Sealey Limited
LED317 Issue 2 (ALL) 24/05/23
5.1.3. If the battery is not properly charged before rst use, or regularly conditioned, its capacity will diminish.
5.1.4. Under these circumstances we will not replace the battery regardless of whether it is less than one year old.
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 sales@sealey.co.uk www.sealey.co.uk
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be sorted,
taken to a recycling centre and disposed of in a manner which is compatible with the environment. When the product
becomes completely unserviceable and requires disposal, drain any fluids (if applicable) into approved containers and
dispose of the product and fluids according to local regulations.
Note: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior
notice.
Important: No Liability is accepted for incorrect use of this product.
Warranty: Guarantee is 12 months from purchase date, proof of which is required for any claim.
Original Language Version
© Jack Sealey Limited
LED317 Issue 2 (ALL) 24/05/23
WEEE REGULATIONS
Dispose of this product at the end of its working life in compliance with the EU Directive on Waste Electrical and Electronic Equipment
(WEEE). When the product is no longer required, it must be disposed of in an environmentally protective way. Contact your local solid
waste authority for recycling information.
BATTERY REMOVAL
Under the Waste Batteries and Accumulators Regulations 2009, Jack Sealey Ltd are required to inform potential purchasers of products
containing batteries (as defined within these regulations), that they are registered with Valpak’s registered compliance scheme. Jack
Sealey Ltd’s Batteries Producer Registration Number (BPRN) is BPRN00705.
fig.
1
fig.
2
