3W COB & 2W SMD LED RECHARGEABLE
INSPECTION LIGHT WITH 180° MAGNETIC STAND
MODEL NO: LED301
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
1. SAFETY
1.1. GENERAL
8 DO NOT shine directly into your, another person’s or an animal’s eyes.
8 DO NOT allow children to use the torch.
8 DO NOT use the torch if you suspect that the battery or the torch casing is damaged.
8 DO NOT attempt to repair/disassemble the light yourself.
8 DO NOT leave batteries in a discharged state. Before storage remove batteries.
8 DO NOT use/store the product in extreme temperatures.
9 Protect this product from water, humidity or any liquids.
1.2. BATTERY SAFETY
WARNING! To reduce the risk of burns or re:
8 DO NOT attempt to open the batteries.
8 DO NOT crush, puncture, short contacts or dispose of in re or water.
8 DO NOT expose to temperatures above 60°C (140°F).
9 Replace only with the batteries designed for this product.
9 Recycle or dispose of used batteries as stipulated by local regulation.
9 If the electrolyte in the batteries gets on your skin, rinse thoroughly with water. If it gets in your eyes, rinse thoroughly with cool water
and seek immediate medical attention.
2. INTRODUCTION
Lightweight light featuring a super bright 3W COB LED, which gives an even and constant spread of light, producing up to 200 lumens.
2W High power SMD LED torch producing up to 100 lumens. Integral hanging hook/belt clip and a magnetic base which can rotate
through 180° for hands-free applications. Rechargeable 3.7V 1.2Ah lithium-ion battery for longer product life. Supplied with 300mm USB
TYPE-C charging cable.
3. SPECIFICATION
MODEL NO: LED301
Battery: 3.7V 1200mAh Li-Battery
Charging Time: 4hr
IP Rating: IP20
LED Type: 3W COB + 2W SMD LED
Length: 165mm
Lumen Output: 100lm (SMD)
200lm (COB)
Operating Time: 2-4hr
Length: 165mm
Lumen Output: 100lm (SMD)
200lm (COB)
Operating Time: 3-4hr
4. OPERATION
4.1. CHARGING
4.1.1. Use the USB cable provided to charge the product.
4.2. Press ON/OFF:
4.2.1. Once to turn on the torch.
4.2.2. Twice to turn on the COB LED.
4.2.3. Three times to turn OFF.
5. MAINTENANCE
9 Clean this product with a soft, slightly damp cloth.
8 DO NOT use any abrasive agents to clean the product.
8 DO NOT attempt to repair/disassemble the light yourself.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS,
WARNINGS & CAUTIONS. USE THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT
IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR PERSONAL INJURY AND WILL INVALIDATE THE
WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
LED301 Issue 2 31/10/23
Original Language Version
© Jack Sealey Limited
ON/OFF
(BACK OF UNIT)
USB CHARGING PORT
LIGHT SOURCE
ROTATABLE STAND
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 sales@sealey.co.uk www.sealey.co.uk
Note: It is our policy to continually improve products and as such we reserve the right to alter data, specications and component parts without prior notice.
Important: No Liability is accepted for incorrect use of this product.
Warranty: Guarantee is 12 months from purchase date, proof of which is required for any claim.
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be
sorted, taken to a recycling centre and disposed of in a manner which is compatible with the environment. When
the product becomes completely unserviceable and requires disposal, drain any uids (if applicable) into approved
containers and dispose of the product and uids according to local regulations.
REGISTER YOUR
PURCHASE HERE
BATTERY REMOVAL
Under the Waste Batteries and Accumulators Regulations 2009, Jack Sealey Ltd are required to inform potential purchasers of products
containing batteries (as defined within these regulations), that they are registered with Valpak’s registered compliance scheme. Jack
Sealey Ltd Batteries Producer Registration Number (BPRN) is BPRN00705.
WEEE REGULATIONS
Dispose of this product at the end of its working life in compliance with the EU Directive on Waste Electrical and Electronic Equipment
(WEEE). When the product is no longer required, it must be disposed of in an environmentally protective way. Contact your local solid
waste authority for recycling information.
