5W COB & 3W SMD LED FLEXI
RECHARGEABLE INSPECTION LIGHT
MODEL NO: LEDFLEXG
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETYi
1.1. GENERAL
9 Ensure the lamp is fully charged before initial use.
8 DO NOT turn the lamp on when it is being charged.
8 DO NOT shine directly into your, another person’s or an animal’s eyes.
8 DO NOT allow children to use the lamp.
8 DO NOT use the lamp if you suspect that the battery or the lamp casing is damaged.
8 DO NOT leave battery in a discharged state, recharge battery immediately. Before storage, fully recharge the battery, subsequently
recharge the battery at least once every six months of non-use.
1.2. BATTERY SAFETY
WARNING! To reduce the risk of burns or re:
8 DO NOT attempt to open, disassemble, modify or service the battery pack.
8 DO NOT crush, puncture, short external contacts or dispose of in re or water.
8 DO NOT expose to temperatures above 60°C (140°F).
9 If the electrolyte in the cells gets on your skin, thoroughly wash with soap and water. If it gets in your eyes, rinse thoroughly with cool
water and seek immediate medical attention
2. INTRODUCTION
Unique new 360° design made from high-impact materials. High power 5W COB LED produces up to 500 lumens in tight spaces like engine
compartments. Features a 160mm heavy-duty exible neck with the ability to hold its position wherever you need it. 3W SMD Top light produces up
to 120 lumens. Features a sturdy base which means it can also be used as a desk lamp. Base includes a strong magnet and 90° folding hook. One
switch controls top light, side light and dimmer function. Features LED battery charge level indicator. Supplied with USB Type-C Cable.
3. SPECIFICATION
Model no: ...........................................................LEDFLEXG
Battery: ..............................................3.7V 2.6Ah Lithium-ion
Charging time:...................................................................4hr
IP Rating: ........................................................................IP54
LED Type: ..............................................5W COB + 3W SMD
Length: .......................................................................425mm
Lumen Output: ................................ Side: 50-500/Top: 120lm
Operating Time: .................................Side: 2-16hr/Top: 9.5hr
4. OPERATION
4.1. CHARGING
4.1.1. Lift rubber cover and connect micro USB cable to socket on rear of handle (g2).
4.1.2. The unit has 3 LEDs to indicate charge level (g.2). Whilst charging the LEDs will
ash. Once fully charged all LEDs will be permanently lit.
4.2. LIGHTING MODES
4.2.1. The unit has four lighting modes, LED, COB, COB Dimmer or O. To select LED
press and hold Mode Selector switch (g.1). To change to COB mode press and hold
Mode Selector once more. To dim COB mode rotate Mode Selector switch to achieve
desired light level. To turn unit o, press and hold Mode Selector once more.
LEDFLEXG Issue 5 (H,2,3,F) 27/04/23
Original Language Version
© Jack Sealey Limited
Refer to
instruction
manual
fig.
1
fig.
2
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 sales@sealey.co.uk www.sealey.co.uk
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be sorted,
taken to a recycling centre and disposed of in a manner which is compatible with the environment. When the product
becomes completely unserviceable and requires disposal, drain any fluids (if applicable) into approved containers and
dispose of the product and fluids according to local regulations.
Note: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior
notice.
Important: No Liability is accepted for incorrect use of this product.
Warranty: Guarantee is 12 months from purchase date, proof of which is required for any claim.
WEEE REGULATIONS
Dispose of this product at the end of its working life in compliance with the EU Directive on Waste Electrical and Electronic Equipment
(WEEE). When the product is no longer required, it must be disposed of in an environmentally protective way. Contact your local solid
waste authority for recycling information.
BATTERY REMOVAL
Under the Waste Batteries and Accumulators Regulations 2009, Jack Sealey Ltd are required to inform potential purchasers of products
containing batteries (as defined within these regulations), that they are registered with Valpak’s registered compliance scheme. Jack
Sealey Ltd’s Batteries Producer Registration Number (BPRN) is BPRN00705.
