3W SMD LED FLEXI RECHARGEABLE
MAGNETIC PICK-UP TOOL LIGHT
MODEL NO: LEDFLEXPT
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these
instructions, and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY
1.1. GENERAL SAFETY
9 Ensure the lamp is fully charged before initial use.
8 DO NOT turn the lamp on when it is being charged.
8 DO NOT shine directly into your, another person’s or an animal’s eyes.
8 DO NOT allow children to use the lamp.
8 DO NOT handle or move the lamp whilst it is being charged.
8 DO NOT use the lamp if you suspect that the battery or the lamp casing is damaged.
8 DO NOT leave battery in a discharged state, recharge battery immediately. Before storage, fully recharge the battery, subsequently
recharge the battery at least once every six months of non-use.
1.2. BATTERY SAFETY
WARNING! To reduce the risk of burns or re:
8 DO NOT attempt to open, disassemble, modify or service the battery pack.
8 DO NOT crush, puncture, short external contacts or dispose of in re or water.
8 DO NOT expose to temperatures above 60°C (140°F).
9 Recycle or dispose of used battery as stipulated by local regulation.
9 If the electrolyte in the cells gets on your skin, thoroughly wash with soap and water. If it gets in your eyes, rinse thoroughly with cool
water and seek immediate medical attention.
2. INTRODUCTION
High power 3W SMD LED produces up to 280 lumens in tight spaces like engine compartments. Features a 300mm heavy-duty
exible neck with the ability to hold its position wherever you need it. Magnetic ring around light for use as a pick-up tool.
Features a magnetic base with an adjustable hook for storage. On/o switch controls two lighting options. Supplied with USB Type-C
Cable. Over charge and over discharge protection.
3. SPECIFICATION
Model No: ....................................................LEDFLEXPT
Battery: .................................3.7V 2200mAh Lithium-ion
Charging time: .......................................................3-4hrs
LED Type: .........................................................3W SMD
Length: ................................................................530mm
Lumen Output: ...................................................... 280lm
Operating Time: ..................................................3-20hrs
4. OPERATION
4.1. Connect the USB lead to the port on the bottom of the torch.
4.2. The red LED on the front face of the unit will light whilst the torch
is charging.
4.3. When the unit is fully charged the green LED on the torch front
face will light.
4.4. Two dierent operational modes are available. By depressing the
torch on/o switch once a low level white light will be seen
4.5. Push a second time and higher level white light will occur.
4.6. A third will turn the torch o.
4.7. There is a storage hook within the handle for storage purposes.
LEDFLEXPT Issue 1 18/05/23
Original Language Version
© Jack Sealey Limited
Refer to
instructions
Lens removable cover
On/O Switch
Charging light LED
Storage hook
USB Charging point
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 sales@sealey.co.uk www.sealey.co.uk
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be
sorted, taken to a recycling centre and disposed of in a manner which is compatible with the environment. When the
product becomes completely unserviceable and requires disposal, drain any fluids (if applicable) into approved containers
and dispose of the product and fluids according to local regulations.
WEEE REGULATIONS
Dispose of this product at the end of its working life in compliance with the EU Directive on Waste Electrical and Electronic Equipment
(WEEE). When the product is no longer required, it must be disposed of in an environmentally protective way. Contact your local solid
waste authority for recycling information.
Note: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior
notice.
Important: No Liability is accepted for incorrect use of this product.
Warranty: Guarantee is 12 months from purchase date, proof of which is required for any claim.
LEDFLEXPT Issue 1 18/05/23
Original Language Version
© Jack Sealey Limited
5. MAINTENANCE
5.1. Keep the torch clean by wiping with a damp cloth.
5.2. Keep battery fully charged if left over long periods of time.
5.3. Store torch and batteries in a dry childproof area.
5.4. Lamp assembly can be disassembled to clean lens. Simply unscrew cap and wipe clean the lens.
g.1
