SACK TRUCK WITH PNEUMATIC TYRES
300KG CAPACITY
MODEL NO: CST999.V2
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY
9 Always load evenly with the centre of gravity of the load as near the centre and rear of the plate as possible.
9 Obtain additional support for large or wide loads to prevent tipping.
8 DO NOT overload the truck - see Specification.
8 DO NOT leave unattended, especially when loaded, unless the wheels are chocked or the truck is otherwise secured.
8 DO NOT use truck on curbs or steps - use a ramp.
8 DO NOT allow others to ride on the truck.
8 DO NOT use the truck if any part is damaged, paying particular attention to the wheels.
9 Ensure tyres are correctly inflated.
2. INTRODUCTION
Extra-strong tubular steel frame construction. Steel centred
pneumatic wheels allow transport over the roughest terrain.
Features composite handgrips for added comfort and control.
3. SPECIFICATION
Model No. ............................................................ CST999
Capacity: ..................................................................300kg
Height(s): .......................................................... 1300mm
Overall Width: ..................................................... 500mm
Platform Depth: ...................................................280mm
Wheel Size: ...................................................... Ø250mm
Wheel Width: .........................................................90mm
4. ASSEMBLY
4.1. WHEELS
4.1.1. Ensure each axle is clean from dust and dirt to allow free movement of the wheel.
4.1.2. Slide the wheel (fig.1.2) onto the axle (fig.1.1), followed by the washer (fig.1.3) and complete by pushing the split pin (fig.1.4) through the
hole in the end of the axle and bending over to retain.
4.1.3. Repeat for the other side.
g.1
Refer to
instructions
CST999.V2
CST999.V2 Issue 2 (H,F) 28/06/23
Original Language Version
© Jack Sealey Limited
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 sales@sealey.co.uk www.sealey.co.uk
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be sorted,
taken to a recycling centre and disposed of in a manner which is compatible with the environment. When the product
becomes completely unserviceable and requires disposal, drain any fluids (if applicable) into approved containers and
dispose of the product and fluids according to local regulations.
Note: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior
notice. Please note that other versions of this product are available. If you require documentation for alternative versions, please email or call
our technical team on technical@sealey.co.uk or 01284 757505.
Important: No Liability is accepted for incorrect use of this product.
Warranty: Guarantee is 12 months from purchase date, proof of which is required for any claim.
Parts support is available for this product. To obtain parts, please log on to
www.sealey.co.uk, email sales@sealey.co.uk or telephone 01284 757500
