1. SAFETY
9 Always load evenly with the centre of gravity of the load as near the centre and rear of the plate
as possible.
9 Obtain additional support for large or wide loads to prevent tipping.
8 DO NOT overload the truck - see Specification.
8 DO NOT leave unattended, especially when loaded, unless the wheels are chocked or the truck is
otherwise secured.
8 DO NOT use truck on curbs or steps - use a ramp.
8 DO NOT allow others to ride on the truck.
8 DO NOT use the truck if any part is damaged, paying particular attention to the wheels.
2. INTRODUCTION
Extra-strong tubular steel frame construction. Steel centred pneumatic wheels allow transport
over the roughest terrain. Load protection rails to prevent damage. Features P-handle design to
improve at loading and enables one-handed operation.
3. SPECIFICATION
Model No: ............................................................ CST998
Capacity: ..................................................................300kg
Height(s): ..............................................................1300mm
Overall Width: .........................................................550mm
Platform Depth: ......................................................230mm
Wheel Size: .........................................................Ø250mm
Wheel Width: ............................................................90mm
4. ASSEMBLY
4.1. WHEELS
4.1.1. Ensure axle is clean from dust and dirt to allow free movement of the wheel.
4.1.2. Slide the wheel (Fig.1.2) onto the axle (Fig.1.1), followed by the washer
(Fig.1.3), complete by pushing the split pin (Fig.1.4) through the hole in the
end of the axle and bending over to retain.
4.1.3. Repeat for the other side.
300KG SACK TRUCK WITH PNEUMATIC TYRES
MODEL NO: CST998
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
Refer to
instruction
manual
CST998 Issue 3 (H,2,3,F) 29/06/23
Original Language Version
© Jack Sealey Limited
g.1g.1
CST998 Issue 3 (H,2,3,F) 29/06/23
Original Language Version
© Jack Sealey Limited
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 sales@sealey.co.uk www.sealey.co.uk
Note: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior notice.
Important: No Liability is accepted for incorrect use of this product.
Warranty: Guarantee is 12 months from purchase date, proof of which is required for any claim.
Parts support is available for this product. Please log on to www.sealey.co.uk, email sales@sealey.co.uk or telephone 01284 757500
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be sorted,
taken to a recycling centre and disposed of in a manner which is compatible with the environment. When the product
becomes completely unserviceable and requires disposal, drain any fluids (if applicable) into approved containers and
dispose of the product and fluids according to local regulations.
