Portable Basketball Hoop
SP37609
USER’S MANUAL
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.
US office: Fontana UK office: Ipswich
02 03
Packing list
Remarks:
A.The screws 、 、 、 and all are packed in one polybag.
B.The adjustable screw is already installed on the Mid-tube .
8 9
7 4
10 14 15
L
R
1 x1 2 x1 3 x1
4 x1 5 x1 6 x2
7 x1 8 x1 9 x1
Backboard Hoop Upper tube
Mid-tube Lower tube Tripod
Adjustable screw
M8×15 M8×50 M8×55
Link screw Bracket screw
10 x4 11 x2 12 x1
Backboard screw
M6×20
Wheel Stand base
13 x1
14 x2 15 x2
Axle
φ8×440 M8×20
Base screw Spanner
Before You Start
General Warnings:
The product must be installed and used under the supervision of an adult.
Read through each step carefully and follow the proper order.
Remove all packaging, separate and count all parts and hardware.
Please ensure that all parts are correctly installed, incorrect installation can lead to a
danger.
We recommend that, where possible, all items are assembled near the area in
which they will be placed in use, to avoid moving the product unnecessarily once
assembled.
Ensure a secure surface during installation, and place the product always on a flat,
steady and stable surface.
Please check and maintain it regularly, and the most important part needs to be
suspended, fixed, or anchored to the ground.
Warnings:
Attention: For home use only.
Attention: The product is not suitable for the children under 6 years
Danger: Keep all small parts and packaging materials for this product away from babies
and children, otherwise they may pose a choking hazard.
Danger: Lack of attachment may cause a risk of tipping or falling hazard.
Please read all instructions carefully and keep it for future reference.
02 03
Packing list
Remarks:
A.The screws 、 、 、 and all are packed in one polybag.
B.The adjustable screw is already installed on the Mid-tube .
8 9
7 4
10 14 15
L
R
1 x1 2 x1 3 x1
4 x1 5 x1 6 x2
7 x1 8 x1 9 x1
Backboard Hoop Upper tube
Mid-tube Lower tube Tripod
Adjustable screw
M8×15 M8×50 M8×55
Link screw Bracket screw
10 x4 11 x2 12 x1
Backboard screw
M6×20
Wheel Stand base
13 x1
14 x2 15 x2
Axle
φ8×440 M8×20
Base screw Spanner
Before You Start
General Warnings:
The product must be installed and used under the supervision of an adult.
Read through each step carefully and follow the proper order.
Remove all packaging, separate and count all parts and hardware.
Please ensure that all parts are correctly installed, incorrect installation can lead to a
danger.
We recommend that, where possible, all items are assembled near the area in
which they will be placed in use, to avoid moving the product unnecessarily once
assembled.
Ensure a secure surface during installation, and place the product always on a flat,
steady and stable surface.
Please check and maintain it regularly, and the most important part needs to be
suspended, fixed, or anchored to the ground.
Warnings:
Attention: For home use only.
Attention: The product is not suitable for the children under 6 years
Danger: Keep all small parts and packaging materials for this product away from babies
and children, otherwise they may pose a choking hazard.
Danger: Lack of attachment may cause a risk of tipping or falling hazard.
Please read all instructions carefully and keep it for future reference.
04 05
WARNING:
Recommend to install this product by two adults.
Installation Steps:
Pay attention:
After completing the third step, please fill the base with water or sand
immediately, and then install the other parts of the basketball hoop.
■ The basketball stand is suitable for children over 6 years old.
■ Children must use the basketball hoop under the supervision of an
adult.
■ IMPROPER INSTALLATION OR SWINGING ON THE
RING MAY CAUSE SERIOUS INJURY OR DEATH.
■ During play,do not wear jewellery(rings,
watches,necklaces,etc)Objects may become
entangled in the net.
■ Check the product before each use for instability.
■ Never put the stand on the base without water or sand, otherwise
it may cause serious injury or death.
1. Check the accessories as per packing list.
2. Insert the axle
13 through the base 12 to hold the two wheels 11
and
the lower tube
3. Please fix the tripod ⑥ L and ⑥ R on the left and right sides of the
base
respecti
v
ely with screws M8x20, and then fix the the other
tripod
⑥
L and
⑥ R to the lower tube ⑤ with screw ⑨
M8x55.
4. Connect the mid-tube 4 to the lower tube 5 with a link screw
(M8x50) .
5. Assemble the hoop 2 , backboard 1 and the upper tube 3 together
with the backboard screw
10 (M6x20).
6. Insert the upper tube 3 into the mid-tube 4 , align the screw holes
of the two tubes according to the required size, tighten the adjustable
screw
7 , and then complete the installation.
7. Tighten all bolts with spanners
15 .
L
R
2
3
7
4
8
5
9
6
6
1
10
14 14
13
12
11
Product SPEC.:
MODEL:
XY-BS218A
Product dimension:
46.8”L x 28”W x 77.5”-101.5”H
Backboard size:
28"L x 18”W
Hoop size:
Ф15.3”
Basketball stand base size:
28.7”L x 17.7”W x 5.5”H
Capacity of base:
30 Liters
Adjustable Height:
62.2”- 85.8”
(From basketball hoop to ground)
Please read the instruction carefully and follow it to use.
5
6
6
6 5
4
2
3
7
4
1 3
5
8
9
6
13 12
12
14
10
15
end of
.
