USER MANUAL
AIR FRYER
Warning notices: Before using this product, please read this manual carefully and keep it for future
reference. The design and specifications are subject to change without prior notice for product
improvement. Consult with your dealer or manufacturer for details.
The diagram above is just for reference. Please take the appearance of the actual product as the standard.
MAD50109APK
THANK YOU LETTER
Thank you for choosing Midea! Before using your new Midea product, please read
this manual thoroughly to ensure that you know how to operate the features and
functions that your new appliance offers in a safe way.
CONTENTS
0
02
1
06
07
1 4
1 2
1 5
1 1
08
THANK YOU LETTER
SAFETY INSTRUCTIONS
SPECIFICATIONS
PRODUCT OVERVIEW
OPERATION INSTRUCTIONS
CLEANING AND MAINTENANCE
TROUBLESHOOTING
TRADEMARKS, COPYRIGHTS AND LEGAL STATEMENT
DATA PROTECTION NOTICE
1 6
1 YEAR LIMITED WARRANTY
01
Danger
This symbol indicates that there are dangers to the life and health of
Warning of electrical voltage
This symbol indicates that there is a danger to life and health of
persons due to voltage.
Warning
The signal word indicates a hazard with a medium level of risk which, if
not avoided, may result in death or serious injury.
Caution
The signal word indicates a hazard with a low degree of risk which, if
not avoided, may result in minor or moderate injury.
Attention
The signal word indicates important information (e.g. damage to
property), but not danger.
Observe instructions
This symbol indicates that a service technician should only operate and
maintain this appliance in accordance with the operating instructions.
Read these operating instructions carefully and attentively before using/commissioning the
unit and keep them in the immediate vicinity of the installation site or unit for later use!
Intended Use
Explanation of Symbols
SAFETY INSTRUCTIONS
02
The following safety guidelines are intended to prevent unforeseen risks or damage from
unsafe or incorrect operation of the appliance. Please check the packaging and appliance on
arrival to make sure everything is intact to ensure safe operation. If you find any damage,
please contact the retailer or dealer. Please note modifications or alterations to the appliance
are not allowed for your safety concern. Unintended use may cause hazards and loss of
warranty claims.
persons due to extremely flammable gas.
03
IMPORTANT SAFEGUARDS
When using electrical appliances, basic safety
precautions should always be followed including the
following:
• Read all instructions.
• Do not operate any appliance with a damaged cord
or plug or after the appliance malfunctions or has
been damaged in any manner. Return appliance to
the nearest authorized service facility for
examination, repair, or adjustment.
• To protect against electrical shock do not immerse
cord, plugs, or other live parts in water or other
liquid.
• WARNING: To prevent electric shock, unplug before
cleaning
• Do not touch hot surfaces. Use handles or knobs.
• Extreme caution must be used when moving an
appliance containing hot oil or other hot liquids.
• Close supervision is necessary when any appliance is
used by or near children.
• Do not use outdoors.Household use only.
• Unplug from outlet when not in use and before
cleaning. Allow to cool before putting on or taking
off parts.
• The use of accessory attachments not
recommended by the appliance manufacturer may
cause injuries.
• Do not let cord hang over edge of table or counter,
or touch hot surfaces.
• Do not place on or near a hot gas or electric burner,
or in a heated oven.
• Always attach plug to appliance first, then plug cord
into the wall outlet. To disconnect, turn any control
to “off”, then remove plug from wall outlet.
• Do not use appliance for other than intended use.
• Caution ：To reduce the risk of electric shock, cook
only in removable container
• Use extreme caution when removing tray or
disposing of hot grease.
• Oversize foods or metal utensils must not be
inserted in a toaster-oven as they may create a fire
or risk of electric shock.
• A fire may occur if the toaster-oven is covered or
touching flammable material, including curtains,
draperies, walls, and the like, when in operation. Do
not store any item on top of the appliance when in
operation.
• Do not clean with metal scouring pads. Pieces can
break off the pad and touch electrical parts
involving a risk of electric shock.
• Extreme caution should be exercised when using
containers constructed of other than metal or glass.
• Do not store any materials, other than
manufacturers recommended accessories, in this
oven when not in use.
• Do not place any of the following materials in the
oven: (List all materials – that is, paper, cardboard,
plastic, and the like).
• Do not cover crumb tray or any part of the oven
with metal foil. This will cause overheating of the
oven.
• A short power-supply cord is provided to reduce the
risk resulting from becoming entangled in or
tripping over a longer cord.
• Make sure the frying basket is locked into the front
of the drawer – both frying basket handle tabs must
be fully inserted into the notches on the top of the
basket drawer.
• Always make sure frying basket drawer is fully
closed, with frying basket handle locked securely in
the drawer, while Air Fryer is in operation.
• WARNING: Air Fryer will not operate unless frying
basket drawer is fully closed.
• CAUTION: After hot air frying, the frying basket and
frying basket drawer and the cooked foods are hot.
Extreme caution must be used when handling the
hot Air Fryer basket/drawer.
• WARNING: After air frying, make sure to place the
frying basket drawer on a flat, heat-resistant surface
before pressing the basket release button.
• Do not cover the air inlet and the air outlet openings
while the appliance is operating.
• Longer detachable power-supply cords or extension
cords are available and may be used if care is
exercised in their use.
If a longer detachable power-supply cord or
extension cord is used:
- The marked electrical rating of the cord set or
extension cord should be at least as great as the
electrical rating of the appliance;
- The cord should be arranged so that it will not
drape over the countertop or tabletop where it can
be pulled on by children or tripped over
unintentionally; and
- If the appliance is of the grounded type, the cord
set or extension cord should be a grounding-type
3-wire cord.
• CAUTION: Hot surface when be used.
• This appliance has a polarized plug (one blade is
wider than the other). To reduce the risk of electric
shock, this plug is intended to fit into a polarized
outlet only one way. If the plug does not fit fully into
the outlet, reverse the plug. If it still does not fit,
contact a qualified electrician. Do not attempt to
modify the plug in any way.
04
When using electrical appliances, basic safety
precautions should always be followed including the
following:
• Read all instructions.
• Do not operate any appliance with a damaged cord
or plug or after the appliance malfunctions or has
been damaged in any manner. Return appliance to
the nearest authorized service facility for
examination, repair, or adjustment.
• To protect against electrical shock do not immerse
cord, plugs, or other live parts in water or other
liquid.
• WARNING: To prevent electric shock, unplug before
cleaning
• Do not touch hot surfaces. Use handles or knobs.
• Extreme caution must be used when moving an
appliance containing hot oil or other hot liquids.
• Close supervision is necessary when any appliance is
used by or near children.
• Do not use outdoors.Household use only.
• Unplug from outlet when not in use and before
cleaning. Allow to cool before putting on or taking
off parts.
• The use of accessory attachments not
recommended by the appliance manufacturer may
cause injuries.
• Do not let cord hang over edge of table or counter,
or touch hot surfaces.
• Do not place on or near a hot gas or electric burner,
or in a heated oven.
• Always attach plug to appliance first, then plug cord
into the wall outlet. To disconnect, turn any control
to “off”, then remove plug from wall outlet.
• Do not use appliance for other than intended use.
• Caution ：To reduce the risk of electric shock, cook
only in removable container
• Use extreme caution when removing tray or
disposing of hot grease.
• Oversize foods or metal utensils must not be
inserted in a toaster-oven as they may create a fire
or risk of electric shock.
• A fire may occur if the toaster-oven is covered or
touching flammable material, including curtains,
draperies, walls, and the like, when in operation. Do
not store any item on top of the appliance when in
operation.
• Do not clean with metal scouring pads. Pieces can
break off the pad and touch electrical parts
involving a risk of electric shock.
• Extreme caution should be exercised when using
containers constructed of other than metal or glass.
• Do not store any materials, other than
manufacturers recommended accessories, in this
oven when not in use.
• Do not place any of the following materials in the
oven: (List all materials – that is, paper, cardboard,
plastic, and the like).
• Do not cover crumb tray or any part of the oven
with metal foil. This will cause overheating of the
oven.
• A short power-supply cord is provided to reduce the
risk resulting from becoming entangled in or
tripping over a longer cord.
• Make sure the frying basket is locked into the front
of the drawer – both frying basket handle tabs must
be fully inserted into the notches on the top of the
basket drawer.
• Always make sure frying basket drawer is fully
closed, with frying basket handle locked securely in
the drawer, while Air Fryer is in operation.
• WARNING: Air Fryer will not operate unless frying
basket drawer is fully closed.
• CAUTION: After hot air frying, the frying basket and
frying basket drawer and the cooked foods are hot.
Extreme caution must be used when handling the
hot Air Fryer basket/drawer.
• WARNING: After air frying, make sure to place the
frying basket drawer on a flat, heat-resistant surface
before pressing the basket release button.
• Do not cover the air inlet and the air outlet openings
while the appliance is operating.
• Longer detachable power-supply cords or extension
cords are available and may be used if care is
exercised in their use.
If a longer detachable power-supply cord or
extension cord is used:
- The marked electrical rating of the cord set or
extension cord should be at least as great as the
electrical rating of the appliance;
- The cord should be arranged so that it will not
drape over the countertop or tabletop where it can
be pulled on by children or tripped over
unintentionally; and
- If the appliance is of the grounded type, the cord
set or extension cord should be a grounding-type
3-wire cord.
• CAUTION: Hot surface when be used.
• This appliance has a polarized plug (one blade is
wider than the other). To reduce the risk of electric
shock, this plug is intended to fit into a polarized
outlet only one way. If the plug does not fit fully into
the outlet, reverse the plug. If it still does not fit,
contact a qualified electrician. Do not attempt to
modify the plug in any way.
05
When using electrical appliances, basic safety
precautions should always be followed including the
following:
• Read all instructions.
• Do not operate any appliance with a damaged cord
or plug or after the appliance malfunctions or has
been damaged in any manner. Return appliance to
the nearest authorized service facility for
examination, repair, or adjustment.
• To protect against electrical shock do not immerse
cord, plugs, or other live parts in water or other
liquid.
• WARNING: To prevent electric shock, unplug before
cleaning
• Do not touch hot surfaces. Use handles or knobs.
• Extreme caution must be used when moving an
appliance containing hot oil or other hot liquids.
• Close supervision is necessary when any appliance is
used by or near children.
• Do not use outdoors.Household use only.
• Unplug from outlet when not in use and before
cleaning. Allow to cool before putting on or taking
off parts.
• The use of accessory attachments not
recommended by the appliance manufacturer may
cause injuries.
• Do not let cord hang over edge of table or counter,
or touch hot surfaces.
• Do not place on or near a hot gas or electric burner,
or in a heated oven.
• Always attach plug to appliance first, then plug cord
into the wall outlet. To disconnect, turn any control
to “off”, then remove plug from wall outlet.
• Do not use appliance for other than intended use.
• Caution ：To reduce the risk of electric shock, cook
only in removable container
• Use extreme caution when removing tray or
disposing of hot grease.
• Oversize foods or metal utensils must not be
inserted in a toaster-oven as they may create a fire
or risk of electric shock.
• A fire may occur if the toaster-oven is covered or
touching flammable material, including curtains,
draperies, walls, and the like, when in operation. Do
not store any item on top of the appliance when in
operation.
• Do not clean with metal scouring pads. Pieces can
break off the pad and touch electrical parts
involving a risk of electric shock.
• Extreme caution should be exercised when using
containers constructed of other than metal or glass.
• Do not store any materials, other than
manufacturers recommended accessories, in this
oven when not in use.
• Do not place any of the following materials in the
oven: (List all materials – that is, paper, cardboard,
plastic, and the like).
• Do not cover crumb tray or any part of the oven
with metal foil. This will cause overheating of the
oven.
• A short power-supply cord is provided to reduce the
risk resulting from becoming entangled in or
tripping over a longer cord.
• Make sure the frying basket is locked into the front
of the drawer – both frying basket handle tabs must
be fully inserted into the notches on the top of the
basket drawer.
• Always make sure frying basket drawer is fully
closed, with frying basket handle locked securely in
the drawer, while Air Fryer is in operation.
• WARNING: Air Fryer will not operate unless frying
basket drawer is fully closed.
• CAUTION: After hot air frying, the frying basket and
frying basket drawer and the cooked foods are hot.
Extreme caution must be used when handling the
hot Air Fryer basket/drawer.
• WARNING: After air frying, make sure to place the
frying basket drawer on a flat, heat-resistant surface
before pressing the basket release button.
• Do not cover the air inlet and the air outlet openings
while the appliance is operating.
• Longer detachable power-supply cords or extension
cords are available and may be used if care is
exercised in their use.
If a longer detachable power-supply cord or
extension cord is used:
- The marked electrical rating of the cord set or
extension cord should be at least as great as the
electrical rating of the appliance;
- The cord should be arranged so that it will not
drape over the countertop or tabletop where it can
be pulled on by children or tripped over
unintentionally; and
- If the appliance is of the grounded type, the cord
set or extension cord should be a grounding-type
3-wire cord.
• CAUTION: Hot surface when be used.
• This appliance has a polarized plug (one blade is
wider than the other). To reduce the risk of electric
shock, this plug is intended to fit into a polarized
outlet only one way. If the plug does not fit fully into
the outlet, reverse the plug. If it still does not fit,
contact a qualified electrician. Do not attempt to
modify the plug in any way.
SAVE THESE INSTRUCTIONS
SPECIFICATIONS
MAD50109APKProduct Model
Rated voltage
Rated frequency
Rated power
120V～
60Hz
1500W
06
PRODUCT OVERVIEW
Part Name
NOTE
The figure below is for reference only, and the details are subject to the actual objects in
the packaging box.
0
The product is subject to the actual product and configuration.
Main unit
Base assembly
Tray
Basket
0
1. Place the tray in the basket, and then add the ingredients; Push the basket into the
main unit, make sure that the basket is fully pushed into the main unit;
2. In the off-screen state, only the START/PAUSE button blinks. Click
START/PAUSE to enter the standby state. Click the desired menu function, and click
TEMP+, TEMP-, TIME+, and TIME- to adjust the time and temperature. Click the
START/PAUSE key to start the menu cooking, and the cooking countdown is
displayed;
3. During cooking, click CANCEL to cancel the cooking state and return to standby; Click
the “START/PAUSE” key to enter the cooking pause; Click TEMP+, TEMP-, TIME+,
TIME- to enter the cooking menu parameter selection.
4. After cooking is finished, the display screen shows “START/PAUSE” button indicator
flashing prompt, all other indicators off; At this point, the ingredients can be removed
from basket.
OPERATION INSTRUCTIONS
Instructions for Use
Please carefully take it out. Do put it place down on counter so as to avoid being
scalded by steam or topping over the basket which may lead to scalding by oil or
high temperature food. In addition, the cooking tongs are suggested to be used in
the process of taking out food.
Menu Functions
Preparation
The product should be stably placed on a flat surface (Figure 1), so that the power cord
has a sufficient length to be plugged into the socket, and the air around the product
should be kept in circulation, and should not be close to flammable items.
Figure 1
Menu
function
Temperature (F) Time (Min)
The default menu pre-sets the heating temperature and time:
Pre-setting
Adjustment
Pre-setting
range
Adjustment
390 Air Fry 20 300~400 1~90
Grill 400 15 300~400 1~30
Bake 325 15 250~400 1~240
Roast 375 15 250~400 1~240
Broil 400 10 300~400 1~30
Bagel 350 6 300~400 1~30
Reheat 350 15 300~400 1~30
FAV 390 20 100~400 1~90
150 Dehydrate 6h 105~195 1h~12h
170 Keep Warm 20 170~200 1~90
range
10
• The first use requires 10 minutes of dry burning. A small amount of white smoke or
odor may appear during the dry burning process, which is normal.
• Before the product works, please check whether the bakeware is in place to avoid
malfunction.
• If you find that the product is malfunctioning, please stop using it and contact our
service department immediately.
• Please use the bakeware and basket together in the whole machine, and avoid using
them separately.
• After using, unplug the power plug and allow the air fryer to cool completely before
moving.
Reminder
11
CLEANING AND MAINTENANCE
• Please clean the air fryer to prevent it from being burned.
• After using, please clean the bakeware and basket in time to avoid the damage of the
coating due to the erosion of food residue oil.
• Do not use strong abrasive cleaners to prevent damage to the machine and your
health.
• Use a soft, clean cloth to wipe the air fryer. Please do not use an over-wet cloth to
clean the air fryer, to prevent water from entering the air fryer, which may cause short
circuit and fire.
• Please do not use other cleaning equipment such as a dishwasher to clean the air fryer,
otherwise it may cause damage and affect the use.
• Use neutral detergent or clean water to clean the tray and basket.
• Please do not use hard and sharp items (such as wire balls, blades, etc.) to clean the
bakeware or tray and basket to prevent scratching.
• Any other servicing should be performed by an authorized service representative.
12
TROUBLESHOOTING
Cause SolutionProblem
The appliance is not plugged
in.
Put the mains plug in an
earthed wall socket.
Turn the timer knob to the
required preparation time to
switch on the appliance.
Slide the pan into the appliance
properly.
Put smaller batches of ingredi-
ents in the basket.Smaller
batches are fried more evenly.
Turn the temperature control
key to the required tempera-
ture setting (see section
'settings' in chapter 'Using the
appliance').
Turn the timer key to the
required preparation time (see
section 'Settings' in chapter
'Using the appliance').
Ingredients that lie on top of or
across each other (e.g.fries)
need to be shaken halfway
through the preparation time.
See section'Settings' in chapter
"Using the appliance'.
Use oven snacks or lightly
brush some oil onto the snacks
for a crispier result.
DO NOT fill the basket beyond
in full, refer to the "Setting"
table above.
Push the basket down into the
pan until you hear a click.
●
You have not set the timer.
●
The pan is not put into the
appliance properly.
●
The amount of ingredients
in the basket is too big.
●
The set temperature is too
low.
●
The preparation time is too
short.
●
Certain types of ingredients
need to be shaken halfway
through the preparation
time.
●
There are too much
ingredients in the basket.
●
You used a type of snacks
meant to be prepared in a
traditional deep fryer.
●
The basket is not placed, in
the pan correctly.
●
The air fryer does
not work
The ingredients
fried with the air
fryer are not done.
The ingredients
are fried unevenly
in the air fryer.
Fried snacks are
not crispy when
they come out of
the air fryer.
I cannot slide the
pan into the
appliance properly.
Operation of your appliance can lead to errors and malfunctions. The following tables
contain possible causes and notes for resolving an error message or malfunction. It is
recommended to read the tables carefully below in order to save your time and money
that may cost for calling to the service center.
13
Cause SolutionProblem
When you fry greasy ingredi-
ents in the air fryer, a large
amount of oil will leak into the
pan. The oil produces white
smoke and the pan may heat
up more than usual. This does
not affect the applianceor the
end result.
Use fresh potatoes and make
sure they stay firm, during
frying.
Make sure you dry the potato
sticks properly before you add
the oil.
Cut the potato sticks smaller
for a crispier result.
Add slightly more oil for a
crispier result.
Rinse the potato sticks
properly to remove starch
from the outside of the sticks.
White smoke is caused by
grease heating up the pan.
Make sure you clean the pan
properly after each use.
You are preparing greasy
ingredients.
●
You did not use the right
potato type.
●
The crispiness of the fries
depends on the amount of oil
and water in the fries.
●
You did not rinse the potato
sticks properly before you
fried them.
●
The pan still contains grease
residues from previous use.
●
White smoke
comes out of the
appliance.
Fresh fries are
fried unevenly
in the air fryer.
Fresh fries are
not crispy when
they come out
of the air fryer.
14
-
logo, word marks, trade name, trade dress and all versions there of are
trademarks, copyrights and other intellectual property rights, and all goodwill derived
valuable assets of Midea Group and/or its affiliates (“Midea”), to which Midea owns
from using any part of an Midea trademark. Use of Midea trademark for commercial
purposes without the prior written consent of Midea may constitute trademark
infringement or unfair competition in violation of relevant laws.
This manual is created by Midea and Midea reserves all copyrights thereof. No entity or
individual may use, duplicate, modify, distribute in whole or in part this manual, or
bundle or sell with other products without the prior written consent of Midea.
All the described functions and instructions were up to date at the time of printing this
manual. However, the actual product may vary due to improved functions and designs.
TRADEMARKS, COPYRIGHTS
AND LEGAL STATEMENT
DATA PROTECTION NOTICE
For the provision of the services agreed with the customer,
we agree to comply without restriction with all stipulations of applicable data protection
law, in line with agreed countries within which services to the customer will be delivered,
as well as, where applicable, the EU General Data Protection Regulation (GDPR).
Generally, our data processing is to fulfil our obligation under contract with you and for
product safety reasons, to safeguard your rights in connection with warranty and
product registration questions. In some cases, but only if appropriate data protection is
ensured, personal data might be transferred to recipients located outside of the
European Economic Area.
Further information are provided on request. You can contact our Data Protection
Officer via [email protected]. To exercise your rights such as right to object your
personal date being processed for direct marketing purposes, please contact us via
[email protected]. To find further information, please follow the QR Code.
15
1 YEAR LIMITED WARRANTY
This is the only express warranty for this product and is in lieu of any other warranty or
condition. This product is warranted to be (1) year from the date of original purchase.
During this period, your exclusive remedy is repair or replacement of this product or any
component found to be defective, at our option; however, you are responsible for all
costs associated with returning the product to us and our returning the product or
component under this warranty to you. If the product or component is no longer
available, we will replace with a similar one of equal or greater value. This warranty does
not cover wear from normal use, and damages to the product resulting from accident,
alteration, abuse, or misuse. This warranty extends only to the original consumer
purchaser or gift recipient. Keep the original sales. This warranty is void if products is
used for other than single family household use or subjected to any voltage and
waveform. We exclude all claims for special, incidental, and consequential damages by
breach of express or implied warranty. All liability is limited to amount of the purchase
price. Every implied warranty, including any statutory warranty or condition of
merchantability prohibited by law, in which case such warranty or condition is limited to
the duration of this written warranty. Legal rights that vary depending on where you live.
Some states or provinces do not allow limitations on implied warranties or special,
incidental consequential damages, so the foregoing limitations may not apply to you.
Please note that failure to complete and submit this form does not diminish your
warranty.
In the event of a warranty period claim, question, comments or if service is required for
this product, please contact the Customer Service Center:
1-866-646-4332
16
