MAD861D8ADKL
USER MANUAL
Warning notices: Before using this product, please read this manual carefully and keep it for future reference.
The design and specifications are subject to change without prior notice for product improvement.
Consult with your dealer or manufacturer for details.
The diagram above is just for reference. Please take the appearance of the actual product as the standard.
TWO-ZONE AIR FRYER
THANK YOU LETTER
Thank you for choosing Midea! Before using your new Midea product, please read
this manual thoroughly to ensure that you know how to operate the features and
functions that your new appliance offers in a safe way.
CONTENTS
01
0
02
1
09
10
1 1
THANK YOU LETTER
SAFETY INSTRUCTIONS
SPECIFICATIONS
PRODUCT OVERVIEW
OPERATING INSTRUCTIONS
CLEANING AND MAINTENANCE
TROUBLESHOOTING
1 YEAR LIMITED WARRANTY
TRADEMARKS, COPYRIGHTS AND LEGAL STATEMENT
DATA PROTECTION NOTICE
22
23
25
26
27
02
Danger
This symbol indicates that there are dangers to the life and health of
persons due to extremely flammable gas.
Warning of electrical voltage
This symbol indicates that there is a danger to life and health of
persons due to voltage.
Warning
The signal word indicates a hazard with a medium level of risk which, if
not avoided, may result in death or serious injury.
Caution
The signal word indicates a hazard with a low degree of risk which, if
not avoided, may result in minor or moderate injury.
Attention
The signal word indicates important information (e.g. damage to
property), but not danger.
Observe instructions
This symbol indicates that a service technician should only operate and
maintain this appliance in accordance with the operating instructions.
The following safety guidelines are intended to prevent unforeseen risks or damage from
unsafe or incorrect operation of the appliance. Please check the packaging and appliance
on arrival to make sure everything is intact to ensure safe operation. If you find any
damage, please contact the retailer or dealer. Please note modifications or alterations to
the appliance are not allowed for your safety concern. Unintended use may cause
hazards and loss of warranty claims.
Read these operating instructions carefully and attentively before using/commissioning the
unit and keep them in the immediate vicinity of the installation site or unit for later use!
Intended Use
Explanation of Symbols
IMPORTANT SAFEGUARDS
CAUTION
03
●
●
●
●
●
●
●
●
●
To protect against the risk of electric shock, DO NOT
immerse power cord, plug, or the appliance in water or
other liquid.
DO NOT rinse the appliance under a faucet or other
water source.
This appliance is NOT to be used by children or by
persons with reduced physical, sensory, or mental
capabilities. Close supervision is necessary when this
appliance is used near children and these individuals.
Children should not use or play with this appliance.
Turn off and unplug when not in use and before cleaning.
Allow to cool before putting on or taking off parts or
accessories. To turn off, press Cancel. To unplug, grasp
the plug and pull from the outlet. Never pull from the
power cord.
Avoid making contact with moving parts.
Inspect the appliance and power cord regularly. DO NOT
operate any appliance with a damaged cord or plug. DO
NOT operate after the appliance malfunctions, or is
dropped or damaged in any manner.
DO NOT use any accessories or attachments not
authorized by MIDEA. The use of attachments not
recommended by the manufacturer may cause injury, fire
or electric shock.
For household countertop use only. DO NOT use
outdoors. Not for commercial use.
DO NOT place the appliance or any of its parts on any
kind of stovetop, near gas or electric burners, or in a
heated oven; heat from an external source will damage
the appliance.
●
Read all instructions
04
●
●
●
●
●
●
●
●
●
●
●
●
●
●
DO NOT use appliance for anything other than intended
use.
DO NOT attempt to repair, replace, alter, or modify
components of the appliance. This may cause electric
shock, fire and/or injury, and will void the warranty.
DO NOT tamper with any of the safety mechanisms.
DO NOT leave the appliance unattended while in use.
DO NOT store any materials, other than the included
accessories, in the cooking cavity when not in use.
DO NOT place any combustible materials in the cooking
cavity; such as paper, cardboard, plastic, styrofoam or
wood.
Use extreme caution when moving an appliance
contaning hot oil or other hot liquids.
Keep your air fryer away from flammable materials
(curtains, tablecloths, etc). Use on a stable and
heat-resistant surface away from heat sources or liquids.
To avoid the risk of fire, property damage and personal
injury, DO NOT spray cooking oil into the cooking cavity.
Do not place any objects on top of air fryer at any time.
The air fryer’s cooking cavity contains electrical
components. To avoid electric shock, DO NOT put liquid
of any kind into the cooking cavity.
Proper maintenance is recommended after each use.
Refer to CLEANING AND MAINTENANCE.
Let the appliance cool to room temperature before
cleaning or storage.
Do not clean with metal scouring pads. Pieces can break
off the pad and touch electrical parts, creating a risk of
electric shock.
05
WARNING
●
●
●
●
●
●
●
●
●
The appliance's outer surfaces may become hot during
use. DO NOT touch hot surfaces. Only use the air fryer
basket handle to lift and carry the air fryer basket. Wear
proper hand protection when handling hot components.
Extreme caution must be used when moving the
appliance.
Let the appliance cool to room temperature before
handling or moving.
WARNING: Spilled food can cause serious burns. Keep
appliance and cord away from children.
NEVER drape cord over edge of table or counter or touch
hot sufaces, NEVER use power outlet below counter.
DO NOT overfill the appliance or accessories. Overfilling
may cause food to contact the heating element, which
may result in fire and/or personal injury.
DO NOT cover the air inlet, air outlet (upper) or air outlet
(lower) while the appliance is in operation. Doing so will
prevent even cooking and may cause damage to the
appliance.
An air fryer works with hot air only. NEVER pour or spray
oil into the cooking cavity. This could result in fire and/or
personal injury.
While cooking, the internal temperature of the appliance
reaches several hundred degrees. To avoid personal
injury, NEVER place unprotected hands inside the
appliance until it has cooled to room temperature.
When cooking, DO NOT place the appliance against a
wall or against other appliances. Leave at least 5in (13cm)
of free space on the back, front, sides, and above the
appliance. DO NOT operate the appliance on or near
combustible materials such as tablecloths and curtains.
DO NOT place anything on top of the appliance.
06
●
●
●
●
●
●
●
●
●
●
●
●
●
DO NOT put food in the drip tray.
DO NOT dish wash the drip tray.
When in operation, hot air is released through the air
outlets. Keep your hands and face at a safe distance from
the vents and take extreme caution when removing the
accessories from the appliance.
Should the unit emit black smoke, press Cancel and
unplug the appliance immediately. Wait for smoking to
stop before removing the basket and then clean the
appliance thoroughly. If the cause was not burnt food,
contact our Customer Service Center .
NEVER connect this appliance to an external timer
switch or separate remote-control system.
Use extreme caution when removing hot baskets from
the appliance, or disposing of hot grease.
Without proper cleaning, food and grease splatter may
build up around the heating element.
This can cause smoke, fire, and/or personal injury.
Oversized foods and/or metal foil packages, or utensils
must not be inserted into the cooking cavity as they may
cause risk of fire and/or personal injury.
DO NOT use appliance accessories in any other appliance
including microwave ovens, toaster ovens, convection or
conventional ovens, ceramic, electric, induction or gas
cooktops, or outdoor grills.
DO NOT place paper, cardboard, non-heat-resistant
plastic, or similar materials, into your air fryer.
You may use parchment paper or foil.
Never put baking or parchment paper into the air fryer
without food on top. Air circulation can cause paper to
lift and touch heating coils.
Always use heat-safe containers. Be extremely cautious if
using containers that aren't metal or glass.
DO NOT cover crumb tray or any part of the oven with
07
PLUG & CORD
●
●
●
●
●
This appliance has a polarized plug (one blade is wider
than the other). To reduce the risk of electric shock, this
plug is intended to fit into a polarized outlet only one
way. If the plug does not fit fully into the outlet, reverse
the plug. If it still does not fit, contact a qualified
electrician.
DO NOT attempt to modify the plug in any way.
A short power-supply cord is provided to reduce the risk
resulting from becoming entangled in or tripping over a
longer cord.
Extension cords are available and may be used if care is
exercised in their use.
If an extension cord is used:
1. The marked electrical rating of the extension cord
should be at least as great as the electrical rating of
the appliance (see page 9).
2. The cord should be arranged so that it will not drape
over the countertop or tabletop where it can be pulled
on by children or tripped over unintentionally.
3. DO NOT share the extension cord with other appliances.
DO NOT use the appliance in power outlets other than
120V~ (60Hz). DO NOT use with power converters or
adapters.
DO NOT let the power cord contact hot surfaces or open
flames, including stovetop.
IMPORTANT SAFEGUARDS
metal foil. This will cause overheating of the oven.
08
●
●
●
●
Read this manual carefully and completely and retain for
future reference. Failure to adhere to safety instructions
may result in serious injury or damage.
To avoid injury, read and understand the instructions in
this user manual before attempting to use this appliance.
The failure to follow any of the important safeguards
and/or the instructions for safe use is a misuse of your
appliance that can void your warranty and create the risk
of serious injury.
To disconnect, turn any control to "off", then remove
plug from wall outlet.
SAVE THESE INSTRUCTIONS
SPECIFICATIONS
MAD861D8ADKLProduct Model
Voltage
Frequency
Rated Power
120V~
60Hz
1650W
Capacity 8.4QT
09
How To Find The Model Name And Serial Number
Both the model name and serial number can be found on the rating label that is located
on the bottom of the air fryer.
PRODUCT OVERVIEW
10
Parts and Accessories
Control panel
Air Vent
Power cord
storage wrap
Before using your new air fryer, make sure that all parts and accessories are included.
Grill tray
Right basket
Right cavity
Left cavity
Grill tray
Left basket
Window
11
OPERATING INSTRUCTIONS
Control Panel
DescriptionName
• Any of the 9 functions can be used in the the left or
right basket to cook a large variety of meals. The
temperature and time can be adjusted for each
function.
• Touch in the left panel to operate the left basket.
• Touch in the right panel to operate the right
basket.
1 Functions
• The cook time, set temperature, reminder messages,
and error messages are shown here.
2
3
Display
• Touch to enter quick menu.
• Touch to select the time or temperature.Then
touch to adjust the value.
5 AIR FRY
Function
Selection
TEMP/TIME
6
Basket Selection
4
3 3
2
7
2
7
• Touch or to select the function for the
corresponding basket. Then touch to start the
cooking cycle.
LIGHT7
• Touch to turn light on.
6
8 1
9
6
44
55
12
DescriptionName
8
• Touch for the other basket, then touch
to copy the same program.
• The sync finish function will make both baskets finish
cooking at the same time. After programming both
baskets, touch to start cooking. The cavity
with less cook time will display “HoLd” until both
cavities have the same remaining cook time.
9
SYNC FINISH
MATCH COOK
13
DescriptionMessage
• While programming, the display will show the set cook time.
While cooking, the display will show the remaining cook
time.
• Cooking is complete and the left or right basket can be
removed.
• Left cavity upper sensor open circuit protection, entering
fault mode, please disconnect the plug from the power outlet
and wait thirty seconds, then reconnect power to reset the
unit or contact customer service center for repair.
• The left basket or right basket was removed.
Note: No buttons for that cavity can be used while open.
• While the sync finish function is activated, the cavity with
less cook time will show “HoLd” until both cavities have the
same remaining cook time.
• Communication exception: Both left and right display display
EU. The buzzer enters the fault mode after 10 rings. After
normal communication is restored, you can press any key to
return to the standby state.
• The display shows the set temperature.
Display Messages
• Right cavity upper sensor open circuit protection, entering
fault mode, please disconnect the plug from the power outlet
and wait thirty seconds, then reconnect power to reset the
unit or contact customer service center for repair.
• Left cavity upper sensor short circuit protection, entering
fault mode, please disconnect the plug from the power outlet
and wait thirty seconds, then reconnect power to reset the
unit or contact customer service center for repair.
• Right cavity upper sensor short circuit protection, entering
fault mode, please disconnect the plug from the power outlet
and wait thirty seconds, then reconnect power to reset the
unit or contact customer service center for repair.
14
Left Cavity Cooking
1.
Place the Grill tray into the basket and evenly place food onto the Grill tray.
2.
Insert the left basket into the left cavity.
3.
Plug the air fryer into an appropriate power outlet and the air fryer will now be in
standby mode.
5.
After selecting the function, touch on the left to enter time setting. Touch
to adjust the value, then touch again to enter temperature setting.
When adjustment is completed, touch to begin the cycle.
4.
Touch to start the left basket. Then touch to choose different functions
or touch to enter Air Fry function.
15
6.
During the cooking process, if you want to adjust the temperature or time, first touch
, and then touch .
7.
When the cooking cycle is complete, the left digital screen displays END, the unit
beeps five times, and all other indicator lights turn off. Touch to enter standby
mode. Removing and replacing the basket will enter standby mode.
Note: No buttons for that cavity can be used while basket is removed.
16
Right Cavity Cooking
1.
Place the Grill tray into the basket and evenly place food onto the Grill tray.
2.
Insert the right basket into the right cavity.
3.
Plug the air fryer into an appropriate power outlet and the air fryer will now be in
standby mode.
4.
Touch to start the right basket. Then touch to choose different functions
or touch to enter Air Fry function.
5.
After selecting the function, touch on the right to enter time setting. Touch
to adjust the value, then touch again to enter temperature setting.
When adjustment is completed, touch to begin the cycle.
17
6.
During the cooking process, if you want to adjust the temperature or time, first touch
, and then touch .
7.
When the cooking cycle is complete, the left digital screen displays END, the unit
beeps five times, and all other indicator lights turn off. Touch to enter standby
mode. Removing and replacing the basket will enter standby mode.
Note: No buttons for that cavity can be used while basket is removed.
18
Two-Zone Cavity Cooking
1.
Place the Grill tray into the basket and evenly place food onto the Grill tray.
2.
Insert left basket into the left cavity and right basket into the right cavity.
3.
Plug the air fryer into an appropriate power outlet and the air fryer will now be in
standby mode.
4.
Touch on either side, Select the menu and set the temperature and time,
Then touch on the other side, select the menu, and set the temperature and
time.
If you want to run independently, touch on each cavity to start cooking.
If you want to start at the same time and cook the food at the same time, touch
. At this time The cavity with less cook time will display “HoLd” until both
cavities have the same remaining cook time.
5.
During the cooking process, if you want to adjust the temperature or time, first touch
at this time,the synchronization completion function has been canceled,
and then touch to adjust temperature or time, after setting up, cooking will
continue without stopping midway.
If you touch to adjust the temperature and time, and then touch again
to start after setting.
19
During the cooking process, if you want to adjust the temperature or time, first touch
6.
To synchronize cooking settings for both cavities:
Step 1: Set the first cavity to your desired cooking settings. Note: don't touch
for this cavity.
Step 2: On the other cavity touch to activate the controls.
Step 3: Touch to copy the cooking settings to the other cavity.
Step 4: Touch on either cavity to start an individual cavity cycle or touch
to start both cavities simultaneously.
7.
When the cooking cycle is completed, the both digital screens displays END, the unit
beeps five times, and all other indicator lights turn off. Touch to enter standby
mode. Removing and replacing the basket will enter standby mode. Note: No buttons
for that cavity can be used while basket is removed.
When a basket is removed while SYNC FINISH is illuminated, both cavities will pause
cooking. When the basket is inserted back into the unit both cavities will resume
cooking at the same time. Note: If the unit is paused for too long it may be necessary
to add more cooking time at the end of the cycle for proper results.
20
Steak
Setting
Ingredient
Recommended
function
Amount Cooking Temp
Time
• These cooking options give your meals all the rich and crispy flavor of deep frying with
with little to no oil.
• The default time and temps are a starting point that you can experiment with to get
the results you like best.
• The function listed for each food is a recommendation for optimal cooking. Any
function can be used in either cavity.
Cooking
Frozen french fries
10.6oz 27min355°F
Chicken wings
6 piece 16min
375°F
5.3oz 14min
25min
400°F
AIR FRY
AIR FRY
AIR FRY
AIR FRY
AIR FRY
AIR FRY
AIR FRY
GRILL
8.8oz
8.8oz
7oz
7oz
6 piece
7oz
7oz
14min355°FShrimp BROIL
6 pieceCake BAKE
BAKE
15min340°F
Bread slice
Bagel
Leftovers
Asparagus
Chicken breasts
Root vegetables
Cookies
Frozen shrimp
Frozen fish
Frozen chicken breast
ROAST
ROAST
BAGEL
REHEAT
2 piece 10min
19min
20min
340°F
340°F
340°F
320°F
340°F
2 piece
5.3oz
3.5oz
5.3oz 12min355°FFish GRILL
1.3oz 90min195°FDried fruit DEHYDRATE
Chicken leg BROIL 375°F
375°F
390°F
390°F
14oz 20min
Pizza BROIL 1 piece 8min
17min
14min
15min
8min
10min
10min
355°F
355°F
355°F
21
• Always place food evenly on the crisper plate and grill tray for best cooking results.
• Overlapping food may result in uneven cooking performance.
• To increase crispiness, small amounts of oil can be sprayed or brushed onto the food
before cooking.
• If the air fryer has been paused for more than 10 minutes, it will return to standby mode
and clear all the existing settings.
• For most foods, turning, shaking, or flipping half-way through cooking will achieve the
best cooking results.
• Time and Temp can be adjusted at any time during cooking process.
Tips
CAUTION
• To avoid the risk of fire, property damage and personal injury, DO NOT spray cooking
oil into the cooking cavity.
• DO NOT place any objects on top of air fryer at any time.
22
CLEANING AND MAINTENANCE
• Clean the basket, crisper plate and grill tray after each use.
• Always unplug the air fryer and let it cool to room temperature before cleaning. Never
use harsh chemical detergents, scouring pads, or powders on any of the parts or
components.
• Let all surfaces dry thoroughly before use, and before storage.
Cleaning methodPart or accessory
• Clean the air fryer basket with a sponge or cloth and warm
water and dish soap. Then rinse well. Ensure that all grease
and food debris are removed.
• DO NOT immerse the barrel in water or any other liquid.
• DO NOT clean in the dishwasher.
Left basket/
Right basket
• Clean the grill tray with a cloth or sponge and warm water
with dish soap.
• The grill tray has non-stick coating. To avoid damage to the
non-stick coating, DO NOT use metal cleaning utensils.
• DO NOT clean in the dishwasher.
• Clean the cooking cavity with a sponge or soft cloth and
warm water and dish soap.
• To remove baked-on grease and food residue from cooking
cavity, spray with a mixture of baking soda and vinegar and
wipe clean with a damp cloth.
• For stubborn residue, allow the mixture to sit on the affected
area for several minutes before scrubbing clean.
• Check the heating element for oil spatter and food debris.
Clean the heating element with a damp cloth as needed.
Ensure the heating element is completely dry before next use.
• DO NOT clean in the dishwasher.
• Clean the internal and external side of the windows with a
cloth or sponge and warm water with dish soap. DO NOT use
metal cleaning utensils.
• Clean with a soft and damp cloth or sponge and wipe dry.
Grill tray
Left cavity/
Right cavity
Window
Exterior
Any other servicing must be performed by an authorized representative.
WARNING
• Without proper cleaning, food and grease splatter may build up around the heating
element. This can cause smoke, fire, and personal injury.
• If you see or smell smoke, touch Cancel, unplug the appliance, and allow it to cool.
Remove food residue or grease with a soft cloth and dish soap.
• The silicone pad on the baking tray cannot be removed for use to avoid scratching the
coating.
23
TROUBLESHOOTING
Problem Cause Solution
OPEN displayed
Pull out the frying bucket and
push it back to the machine to
assemble it in place
Contact the Customer Service
Center
Contact the Customer Service
Center
Contact the Customer Service
Center
Contact the Customer Service
Center
The fan does
not run
Fan noise
Unable to push
the fryer into the
product smoothly
White smoke emitted from the
cavity while cooking greasy
food is a normal occurrence.
White smoke
Be sure to clean the air fryer
after baking each time
• Frying basket isn't assembled
in place
No power
Check that the power cord is
firmly plugged into outlet. If this
cannot solve the problem,
please contact the Customer
Service Center
• Power isn’t connected
• The motor is damaged or other
components are short-circuited
• Fan blade deformed
• Fryer edge deformed
• Greasy food is being baked
• The fryer still has grease
residue from the previous bake
• Improper power cord and
outlet connection
This section summarizes the most common problems you may encounter while operating
the unit. If the solution listed does not resolve the issue, contact the Midea Customer
Service Center.
• Both the left basket and right
have not been programmed
Sync Finish will not activate
until both cavities have been
set to a cooking function
• Sync Finish is activated
Cannot pause
single cavity
Touch or to
cancel the Sync Finish function
and perform a single cavity
operation
Cannot
activate Sync
Finish
Possible Reasons SolutionsProblem
• Food not placed in an even
layer
For best cooking performance,
place food in an even layer with no
overlapping. See COOKING.
Food
undercooked
24
Clean the interior and exterior of
windows after each use. See
CLEANING AND MAINTENANCE.
• Improper window cleaning
• Light not activated
Difficult to see
through
windows
Before looking through a window,
be sure to activate the lights by
touching .
Do not pile food too high or the
food will contact top . This can
result in difficulty inserting and
removing the basket and may cause
food to burn.
Remove all debris from the basket
exterior . See CLEANING AND
MAINTENANCE.
• Too much food within basket
• Debris on basket exterior
Difficult to
remove or
insert basket
25
1 YEAR LIMITED WARRANTY
This is the only express warranty for this product and is in lieu of any other warranty or
condition. This product is warranted to be (1) year from the date of original purchase.
During this period, your exclusive remedy is repair or replacement of this product or any
component found to be defective, at our option; however, you are responsible for all
costs associated with returning the product to us and our returning the product or
component under this warranty to you. If the product or component is no longer
available, we will replace with a similar one of equal or greater value. This warranty does
not cover wear from normal use, and damages to the product resulting from accident,
alteration, abuse, or misuse. This warranty extends only to the original consumer
purchaser or gift recipient. Keep the original sales. This warranty is void if products is
used for other than single family household use or subjected to any voltage and
waveform. We exclude all claims for special, incidental, and consequential damages by
breach of express or implied warranty. All liability is limited to amount of the purchase
price. Every implied warranty, including any statutory warranty or condition of
merchantability prohibited by law, in which case such warranty or condition is limited to
the duration of this written warranty. Legal rights that vary depending on where you live.
Some states or provinces do not allow limitations on implied warranties or special,
incidental consequential damages, so the foregoing limitations may not apply to you.
Please note that failure to complete and submit this form does not diminish your
warranty.
In the event of a warranty period claim, question, comments or if service is required for
this product, please contact the Customer Service Center:
1-866-646-4332
26
logo, word marks, trade name, trade dress and all versions there of are
trademarks, copyrights and other intellectual property rights, and all goodwill derived
valuable assets of Midea Group and/or its affiliates (“Midea”), to which Midea owns
from using any part of an Midea trademark. Use of Midea trademark for commercial
purposes without the prior written consent of Midea may constitute trademark
infringement or unfair competition in violation of relevant laws.
This manual is created by Midea and Midea reserves all copyrights thereof. No entity or
individual may use, duplicate, modify, distribute in whole or in part this manual, or
bundle or sell with other products without the prior written consent of Midea.
All the described functions and instructions were up to date at the time of printing this
manual. However, the actual product may vary due to improved functions and designs.
TRADEMARKS, COPYRIGHTS
AND LEGAL STATEMENT
DATA PROTECTION NOTICE
For the provision of the services agreed with the customer,
we agree to comply without restriction with all stipulations of applicable data protection
law, in line with agreed countries within which services to the customer will be delivered,
as well as, where applicable, the EU General Data Protection Regulation (GDPR).
Generally, our data processing is to fulfil our obligation under contract with you and for
product safety reasons, to safeguard your rights in connection with warranty and
product registration questions. In some cases, but only if appropriate data protection is
ensured, personal data might be transferred to recipients located outside of the
European Economic Area.
Further information are provided on request. You can contact our Data Protection
Officer via [email protected]. To exercise your rights such as right to object your
personal date being processed for direct marketing purposes, please contact us via
[email protected]. To find further information, please follow the QR Code.
27
2022
