Sealey SA92 Air Tyre Buffer User Manual

1. SAFETY

9 Followallworkshopsafetyrules,regulations,andconditionswhenusingthebufngkit.

 WARNING!Disconnectfromairsupplybeforechangingaccessoriesorservicing.

9 Maintainthebufngkitingoodconditionandreplaceanydamagedorwornparts.Use genuine parts only. Unauthorised parts may be

dangerous and will invalidate the warranty.

 WARNING!Checkcorrectairpressureismaintainedandnotexceeded.Werecommend90psi.

9 Keepairhoseawayfromheat,oilandsharpedges.

9 Checkairhoseforwearbeforeeachuseandensurethatallconnectionsaresecure.

9 Wearapprovedsafetyeye/faceshield,eardefenders,andhandprotection.

 WARNING! Due to the possible presence of asbestos dust from brake linings, when working around vehicle brake systems we

recommendyouwearsuitablerespiratoryprotection.

9 Maintaincorrectbalanceandfooting.Ensuretheoorisnotslipperyandwearnon-slipshoes.

9 Keepchildrenandnonessentialpersonsawayfromtheworkingarea.

8 DO NOTusethebufngkitforataskitisnotdesignedtoperform.

 WARNING! DO NOTusebufngkitifdamagedorthoughttobefaulty.(ContactServiceAgent).

8 DO NOTusebufngkitunlessyouhavebeeninstructedinitsusebyaqualiedperson.

8 DO NOTcarrythebufngkitbytheairhose,oryankthehosefromtheairsupply.

8 DO NOToperatebufngkitifyouaretiredorundertheinuenceofalcohol,drugsorintoxicatingmedication.

8 DO NOTcarrybufngkitwithyourhandonthepowertriggerinordertoavoidunintentionalstarting.

8 DO NOTdirectairfromtheairhoseatyourselforothers.

9 Whennotinusedisconnectfromairsupplyandstoreinasafe,dry,childprooflocation.

2. INTRODUCTION

AluminiumcasedairmotorwithselectionofØ6mmshankedgrindingpoints,Ø10mmchuckandtyrebuffingcone.Kitalsoincludesspanners,

chuckkeyandairhoseadaptors.

3. SPECIFICATION

Model No:................................................................. SA92.V3

Air Consumption:............................................................ 5cfm

ChuckSize:............................................................... Ø10mm

Consumable Parts:........................... SA651/C-BufngCone

FreeSpeed:........................................................... 22000rpm

InletSize:..................................................................1/4”BSP

Noise Power/Pressure:...................................... 101/90dB(A)

Operating Pressure:...................................................... 90psi

Vibration/Uncertainty:......................................... 1.5/0.64m/s²

AIR TYRE BUFFING KIT

MODELNO:SA92.V3

Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,

and properly maintained, give you years of trouble free performance.

IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE

THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR

PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.

Refer to

instruction

manual

Weareye

protection

Wearear

protection

SA92.V3Issue2(H,F)23/03/23

Original Language Version

©JackSealeyLimited

Wearaface

mask

Wearprotective

gloves

Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR

01284 757500 sales@sealey.co.uk www.sealey.co.uk

4. ASSEMBLY & INSTALLATION

4.1. AIR SUPPLY

4.1.1. Ensurebufferairvalve(ortrigger)isinthe“off”positionbeforeconnectingtotheairsupply.

4.1.2. Youwillrequireanairpressureof90psi,andanairflowaccordingtospecification.

 WARNING! Ensuretheairsupplyiscleananddoesnotexceed90psiwhileoperatingthebuffer.Toohighanairpressureanduncleanair

 willshortentheproductlifeduetoexcessivewear,andmaybedangerouscausingdamageand/orpersonalinjury.

4.1.3. Draintheairtankdaily.Waterintheairlinewilldamagethebuffingkit.

4.1.4. Cleanairinletfilterweekly.Recommendedhook-upprocedureisshowninfig1.

4.1.5. Linepressureshouldbeincreasedtocompensateforunusuallylongairhoses(over8metres).Theminimumhosediametershouldbe

 1/4”I.D.andfittingsmusthavethesameinsidedimensions.

4.1.6. Keephoseawayfromheat,oilandsharpedges.Checkhoseforwear,andmakecertainthatallconnectionsaresecure.

4.2. COUPLINGS

  Vibrationmaycausefailureifaquickchangecouplingisconnecteddirectlytothebuffingkit.Toovercomethis,connectaleaderhoseto

  thebuffingkit.Aquickchangecouplingmaythenbeusedtoconnecttheleaderhosetotheairlinerecoilhose.Seefig.1&2.

4.3.

5. OPERATION

 WARNING! Ensure you read, understand and apply safety instructions before use.

   Note:Numbersshowninbracketsrefertoitemnumbersinthepartslist.

 WARNING! Disconnectfromairsupplybeforechangingaccessoriesorservicing.

5.1.  Thebufngwheel(34)attachesdirectlytothearbor(28)andshouldbetightenedusingthewrench(33).

5.2.  Tousethegrindingstones(39)screwthe10mmdrillchuck(35)ontothearbor(28).Inserttherequiredgrindingstoneintothechuck

 andsecureusingthechuckkeyprovided.Remembertoremovethechuckkey.

5.3.  Depressthetriggertooperatethebufngkit.

6. MAINTENANCE

 WARNING! Disconnect buffer from air supply before changing accessories, servicing or performingmaintenance. Replace or repair

 damagedparts.Use genuine parts only. Unauthorised parts may be dangerous and will invalidate the warranty.

6.1.  LubricatethebufferdailywithafewdropsofSealeyairtooloildrippedintotheairinlettoprolongitslife.

6.2.  Cleanthebuffingkitafteruse.DO NOTusedamagedstonewheels.

6.3.  Lossofpowerorerraticactionmaybeduetothefollowing:

a) Excessivedrainontheairline.Moistureorrestrictionintheairpipe.Incorrectsizeortypeofhoseconnectors.Toremedy

   checktheairsupplyandfollowinstructionsinsection4.

b)Gritorgumdepositsinthebuffingkitmayalsoreduceperformance.Ifyourmodelhasanairstrainer(locatedintheareaof

   theairinlet),removethestrainerandcleanit.FlushthebufferoutwithgumsolventoiloranequalmixtureofSAENo10oil

   andparaffin.

   Allowtodrybeforeuse.

6.4.  ForafullservicecontactyourlocalSealeyserviceagent.

6.5.  Whennotinuse,disconnectfromairsupply,cleanbufferandstoreinasafe,dry,childprooflocation.

fig.

Original Language Version

fig.

PURCHASE HERE

Note: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior

notice.Pleasenotethatotherversionsofthisproductareavailable.Ifyourequiredocumentationforalternativeversions,pleaseemailorcall

ourtechnicalteamontechnical@sealey.co.ukor01284757505.

Important:NoLiabilityisacceptedforincorrectuseofthisproduct.

Warranty:Guaranteeis12monthsfrompurchasedate,proofofwhichisrequiredforanyclaim.

ENVIRONMENT PROTECTION

Recycleunwantedmaterialsinsteadofdisposingofthemaswaste.Alltools,accessoriesandpackagingshouldbesorted,

takentoarecyclingcentreanddisposedofinamannerwhichiscompatiblewiththeenvironment.Whentheproduct

becomescompletelyunserviceableandrequiresdisposal,drainanyfluids(ifapplicable)intoapprovedcontainersand

disposeoftheproductandfluidsaccordingtolocalregulations.

SA92.V3Issue2(H,F)23/03/23
