BATTERY TERMINAL CRIMPING TOOL
MODEL NO: AK422
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these
instructions, and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY
WARNING! Ensure Health and Safety, local authority and general workshop practice regulations are adhered to when using tools.
8 DO NOT use tools if damaged.
9 Wear approved eye protection. A full range of personal safety equipment is available from your Sealey stockist.
9 Wear suitable clothing to avoid snagging. DO NOT wear jewellery and tie back long hair.
9 Maintain tool in good and clean condition for best and safest performance.
9 When not in use, clean and lubricate tool, and store in a safe, dry, childproof location.
IMPORTANT: This manual is provided as a guide only, refer to the vehicle manufacturer’s service instructions, or a proprietary manual,
to establish the current procedure and data.
WARNING! Failure to heed safety and warning instructions may result in damage and/or personal injury and will invalidate the warranty.
WARNING! The warnings, cautions and instructions referred to in this manual cannot cover all possible conditions and situations that
may occur. It must be understood that common sense and caution are factors which cannot be built into this product, but must be
applied by the operator.
2. INTRODUCTION
A quick and effective way of crimping battery terminals using either a hammer or vice. Wide
throat and spring controlled punch securely holds terminal in place for added security.
Compatible with battery terminals with a cross sectional area of 6, 10, 16, 25, 35 and 50mm².
3. SPECIFICATION
Model No: ............................AK422
Crimp Range: ............6, 10, 16, 25, 35, 50mm²
4. OPERATION
4.1. Select the appropriate sized terminal to t the cable being worked on. Strip off cable
insulation to a length approximately 3mm longer than the length of the terminal barrel.
4.2. Insert stripped cable fully into battery terminal (or connector).
4.3. Lift ram of tool and place terminal on anvil so bottom of ram rests on the middle of
terminal barrel.
4.4. Strike ram with a hammer (or put tool in a vice and tighten) until the line on the ram
corresponds to the cable size used and is even with the top of the tool.
AK422 | Issue 2 (H,F) 02/07/2019
Original Language Version
