1
NOV23V1
OWNER’S GUIDE
serial number:
MCA: 15A
MOP: 27A
MODEL NUMBER: UGP-325L W, UGP-325L B
325L / 12 cu. ft.
SOLAR POWERED
BOTTOM MOUNT REFRIGERATOR
FROST FREE
2
NEED HELP?
WELCOME
TABLE OF CONTENTS
Congratulations! You have purchased one of the most ecient refrigeration products available
on the market today. The Unique 325L solar powered DC fridge is designed to provide years of
ecient, trouble-free operation. The design is optimized for energy savings with an ecient DC
compressor and ecient insulation.
Before using the appliance, read through this manual carefully including all the information on
safety, installation, operation, and cleaning. These guidelines do not cover every possible condition
or situation that may occur. Be safe using common sense and caution when installing, operating
and cleaning this appliance. If you are unsure about any of these instructions or warnings, contact
your local product dealer or Unique Appliances for assistance.
Before you call for service, here are a few things you can do to help us serve you better.
Read this owner’s manual: It contains instructions to help you use and maintain your appliance
properly.
Visit out website: Our website www.UniqueAppliances.com will give you access to self service
tools, FAQs and much more.
If you receive a damaged appliance: Immediately contact the retailer that sold you the
appliance.
Save time and money: Check the troubleshooting section at the end of this manual before
calling. This section will help you solve common problems that may occur.
03
Important safety notes
05
Set-Up Dimensions
06
Door Reversal Instructions
Product features
08
DC Power Connection
Electrical Diagram
Operation
16 Care & Maintenance
17 Food Storage
17
Troubleshooting
Warranty
Appliance Info
Product Registration
Contact Us
IMPORTANT: After transit where the fridge has been on its side or
back, ensure that the fridge is in a level, upright position for 12 hours
to allow compressor fluids to redistribute evenly before use.
19
2
0
2
0
0
2
1
2
1
0
Initial Set-Up
09
1
3
3
IMPORTANT SAFETY NOTES
• This fridge is designed to operate on 12 or 24 volts DC ONLY. DO NOT CONNECT THIS FRIDGE
TO AN AC (alternating current) POWER SOURCE DIRECTLY - YOU CAN PURCHASE AN AC/DC
CONVERTOR IF NEEDED (sold seperately.)
• This fridge is designed for domestic use only! It is intended for the storage of edible/consumable
food and drinks. It is not intended for commercial or industrial use.
• Never use excessive force on the handle to open the door.
• If the room/ambient temperature approaches the fridge’s operating temperature, the fridge may
not function correctly. If the room/ambient temperature exceeds 100˚F (38˚C) the fridge may
not function correctly.
• A DC powered fridge has a lower cooling capacity than typical AC powered appliances. Because
the compressor is small, the fridge/freezer runs more eciently but lacks the ability to cool
larger warm loads as quickly as typical AC-powered appliances.
GENERAL SAFETY
• Before cleaning or repositioning the fridge/freezer, always disconnect from the electrical power
supply.
• Service the fridge/freezer only if you are a trained or authorized refrigeration technician.
• This appliance contains refrigerant R-600a and a polyolester compressor oil in its refrigerant
circuit. Take utmost care when handling your fridge so as to not cause damage to the refrigerant
circuit with consequent possible leakage.
• Do not use other electrical appliances (such as ice cream makers) inside of the refrigerating
appliance.
CHILD SAFETY
• Do not allow children to play in, on or around the fridge. It is not a toy. THERE IS A DANGER
OF SUFFOCATION IF A CHILD BECOMES TRAPPED INSIDE.
• When the appliance is not in use, secure or remove the doors to prevent children from playing
inside the cabinets. DANGER OF SUFFOCATION - Keep children away from all packaging
material.
DANGER
Risk of child entrapment. Before throwing away an old appliance:
• Remove the door or lid.
• Leave shelves in place so that children may not easily climb inside.
• Cleaning and use/maintenance shall not be made by children without supervision.
• Do not spray or flush the refrigerator with water, or place the refrigerator in an area exposed to
water or direct moisture. Failing to follow such requirements may lead to electric shock and fire,
or other damages.
• Do not hang, swing or pull down on the refrigerator door or handle.
• To avoid a tipping hazard, the appliance must be fixed in accordance with the instructions.
• Avoid cold injuries: when the appliance is fully operating, never touch its inner surface with wet
hands as skin may freeze and stick to the surface, causing injury.
PROP 65 WARNING
CALIFORNIA PROPOSITION 65 WARNING
CAUTION
Cancer and Reproductive Harm - www.P65Warnings.ca.gov.
4
CAUTION
• Consult repair manual or owner’s guide before attempting to service this product. All safety
precautions must be followed. Service the fridge/freezer only if you are a trained or authorized
refrigeration technician.
• Follow handling instructions carefully.
DISPOSING OF THE APPLIANCE
Dispose of your fridge properly, in accordance with federal or local regulations, at an authorized
disposal site. The refrigerant must be completely drained and collected by an authorized
technician for recycling prior to disposal. Check with your local Environmental Agency for
recommendations on recycling this appliance in your area. Before disposal remove the electrical
connection wiring and also ensure that the doors are removed to prevent children from being
trapped inside - Danger of suocation!
This marking indicates that this product should not be disposed with other household wastes
throughout North America. To prevent possible harm to the environment or human health from
uncontrolled waste disposal, recycle it responsibly to promote the sustainable reuse of material
resources. Recycle all packing materials where/when possible.
REFRIGERANT
This appliance uses isobutane (R600a) refrigerant, a natural gas with a high level of environmental
compatibility. As this refrigerant is flammable, take care to ensure that none of the components of
the refrigerant circuit are damaged during transportation and installation.
If the refrigerant circuit is damaged:
• Avoid open flames and sources of ignition
• Thoroughly ventilate the room where the appliance is situated.
USE
• This appliance is intended for household use only. It is not designed for outside
installation, including anywhere that is not temperature controlled (garages, porches, vehicles,
etc.)
• Do not store any containers with flammable vapors or liquids in or around the appliance,
such as organic solvents, spray cans, gas cans, etc. Danger of explosion!
IMPORTANT SAFETY NOTES
5
SET-UP DIMENSIONS
The refrigerator is designed for freestanding installation.
Ensure the following:
• Doors have space to open freely, and that there is
adequate ventilation on all sides.
• A minimum spacing of 3 inches (75 mm) to the top
and the two sides is highly recommended.
• The space must be not less than the instruction
dimensions, otherwise the refrigerator’s operation
may be adversely aected.
LEVELING INSTRUCTIONS
There are adjustable legs on the bottom of the front
of the appliance that can be turned up or down to ensure
that the appliance is level.
1. Turn the leveling leg counter-clockwise as far as it will
go, until the top of the foot is touching the bottom of
the cabinet.
2. Slowly turn the leveling leg clockwise until the
appliance is level.
≥
≥ 3”/7.6 cm
73”/185.5 cm
≥
≥
≥
≥
27”/68.6 cm
24”/61 cm
48.6”/123.4 cm
≥49.4”/125.5 cm
23.4”/59.5 cm
≥3”/7.6 cm
40”/101.6 cm
>41”/104.1 cm
≥3”
7.6
cm
135˚
6
DOOR REVERSAL INSTRUCTIONS
TOOLS REQUIRED:
Slot head screwdriver, cross head screwdriver
IMPORTANT:
Please disconnect the power plug from the electrical outlet.
Remove the glass shelves, crisper and trays from the unit.
Tilt the appliance backwards to an angle of 45° or more and securely support it.
Removing the doors – Drawing A
Disassemble the door components 1 through 12 one by one, as shown in drawing A;
• 1 - Remove the top right hinge cap
• 2 - Unscrew the hinge screws
• 3 - Remove the top right hinge
• 4 - Remove the fridge door (be careful not to damage or scratch the door)
• 5 - Unscrew the middle hinge screws
• 6 - Remove the middle hinge
• 7 - Remove the freezer door (be careful not to damage or scratch the door)
• 8 - Unscrew the high adjustable feet (height 26 mm) (8,11)
• 9 - Unscrew the low adjustable feet (height 21 mm)
• 10 - Unscrew the lower freezer door hinge on the right side
• 12 - Unscrew the plastic cap-top on the left side
DRAWING A
DRAWING B
12
1
2
18
3
19
4
6
5
7
13
10
9
8
11
14
15
16
12
18
4
7
6
5
11
17
9
8
13
7
DOOR REVERSAL INSTRUCTIONS
Reattaching the doors – Drawing B
NOTE: Items 14, 16, 17 and 19 are enclosed in your manual bag and not fixed on the fridge.
• Fix part 17 as shown (lower hinge - left)
• Install the
screws that hold the bottom hinge in place
• Install part 8 (high adjustable foot - 26mm)
• Install part 11 (high adjustable foot - 26mm)
• Install part 9 (low adjustable foot - 21 mm)
• Position part 7 (freezer door)
• Install part 6 (middle hinge)
• Install part 5 (screw)
• Fix part 19 (door stopper) to the bottom of the fridge door and install fridge door (fig.1)
• Make sure that the door is in the vertical position and can be closed easily.
• Install
part 16 (top left hinge)
• Install part 15 (screws)
• Install part 14 (left hinge cover)
• Install part 15 (screws) and part 13 (plastic cover - middle)
• Position part 12 (screw covers)
• Replace the glass shelves, crisper and trays back to their original positions
IMPORTANT : After reversing the door hinge, the door gasket may be loose. If you notice a gap
between the gasket and the cabinet, use a hair dryer or heat gun and gently heat the gasket in
place until it has expanded to meet the cabinet. Allow 30 minutes for the gasket to cool before
opening the appliance. Proper gasket positioning and seal is the key to prevent refrigerated air
from escaping.
FRIDGE DOOR LEFT HINGE
- Supplementary Instructions -
CHARNIÈRE GAUCHE DE LA PORTE DU RÉFRIGÉRATEUR
- Instructions supplémentaires -
fig. 1
8
PRODUCT FEATURES
FEATURES:
1. Control panel
2. LED light
3. Light switch
4. Glass shelf
5. Crisper
6. Plastic drawer
7. Door rack
8. Power cord
9. DC adapter
(*sold seperately)
10. Ice tray
12. Egg tray
6
5
4
3
2
7
1
PART
DESCRIPTION
QUANTITY
SUPPLIED
Glass shelf 3
Door rack 4
Crisper 1
Wine rack 1
Freezer drawer 3
Power cord 1
DC adapter
sold
seperately
Ice tray 1
Egg tray 1
User manual 1
TECHNICAL PARAMETERS
MODEL UGP-325L DC
Rated voltage DC12V/24V
Climate type N/ST
Volume 330L
Freezer Volume 96L
Fridge Volume 234L
Defrost Power 140W
Lamp Power 1W
Refrigerant Type / Charging R600a / 54g
Insulation Blowing Gas Cyclopentane
Dimensions (mm) w 595 x d 686 x h 185
Not
e: The information about the climate type is provided on the nameplate of the refrigerator.
“N/
ST” indicates this appliance is intended to be used at ambient temperatures ranging from
16 °C to 38 °C.
9
8
10
11
9
INITIAL SET-UP
PRIOR TO INSTALLATION
At delivery, please check that the fridge is complete and has not been damaged during transport.
It is not advised to connect an appliance that has been damaged, especially if there is damage to
the electrical supply cable or refrigerant circuit. In the event of damage please contact your local
product dealer or Unique Appliances for assistance.
UNPACKING AND CLEANING
Remove all packaging and securing tapes from the appliance. To avoid personal injury and damage
to the appliance, be extremely cautious when using sharp or pointed tools to remove packaging.
Keep children away from the packaging material - DANGER OF SUFFOCATION! Wash the inside
and outside of the appliance with lukewarm water and a mild soap or detergent. Abrasive or
corrosive cleaning agents, steel wool, scouring sponges, or chemical cleaning agents should not
be used under any circumstances. A sponge, soft brush or towel is recommended. After cleaning,
thoroughly wipe away residue and allow to dry. You may want to leave the doors open allowing
the compartments to ventilate for 20-30 minutes to get rid of residual odors. Check with your local
Environmental Agency for recommendations on recycling packaging materials in your area.
INSTALLATION
• This appliance is heavy. Care should be taken when moving it.
• Be sure that the appliance does not stand on the electrical supply cable. Also, be sure the
electrical cable is not squeezed or bent when the appliance is being installed or moved.
• Do not install the appliance near water, for example, in a wet basement or near a sink.
• Installation work and adjustments on the appliance must be carried out by qualified personnel
only. Work performed by persons with inadequate technical knowledge may adversely eect the
performance of the appliance, causing damage to the equipment, and void the warranty.
• It is dangerous to make alterations or attempt to modify this product in any way. Product
alterations will void the warranty.
POSITIONING THE APPLIANCE
The area in which the fridge is to be installed must be relatively cool, dry, and suitably ventilated.
The area must be protected against any inclement weather (rain, snow) and excessive surface dust.
To ensure proper function, the appliance must be placed on a flat, firm, and stable surface resting
level on all four supports. The floor must be strong enough to support a fully loaded cabinet. Use
wood or metal shims to level the fridge if necessary.
Do not place the fridge close to heat sources (heater, stove, boiler, chimney, etc.), and avoid
prolonged exposure to direct sunlight. This appliance uses the exterior walls to transfer heat from
the inside of the cabinet. Ensure that there is adequate space between the fridge and neighboring
walls or large objects. Normal spacing of 3 inches (7.5 cm) is highly recommended. This will
provide sucient airflow around the appliance resulting in more ecient operation and longer
appliance lifetime. Always keep the air vent openings of the compressor housing cover free from
dust and obstructions.
THIS FRIDGE MUST NEVER BE CONNECTED DIRECTLY TO ANY AC
(alternating current) POWER SOURCE!
THE FRIDGE MUST ONLY BE CONNECTED TO A 12V OR 24V DC
POWER SOURCE, SUCH AS A SOLAR BATTERY SYSTEM OR CHARGE
CONTROLLER.
THE FRIDGE WILL AUTOMATICALLY OPERATE ON EITHER 12V OR 24V DC.
THE USER DOES NOT NEED TO MAKE ANY ADJUSTMENT.
ATTENTION: Polarity is important in wiring this DC appliance. Be sure that the positive terminal
of the battery or charge controller coincides with the positive wire to the compressor, and the
negative terminal of the battery or charge controller coincides with the negative wire to the
compressor. The leads should be connected using cable shoes and screwed connections. Joined
leads should be avoided.
+ to + and - to -
positive to positive / negative to negative
(red wire) / (black wire)
DC POWER CONNECTION
+
GND
-
BLACK
RED
10
CABLE SIZE
12V CABLE LENGTH 24V CABLE LENGTH
SIZE AWG
mm/inch gauge m ft m ft
2.5 / 3/32” 14 2.5 8 5 16
4 / 5/32” 12 4 13 8 26
6 / 14” 10 6 19.5 12 39
10 / 24” 6 10 32.8 20 65.6
OPERATING VOLTAGE FUSE
12 V / 24 V 30 A
12 V OPERATION 24 V OPERATION
SHUT OFF
9.7 V 21.5 V
RESTART
11.6 V 23.4 V
IN-LINE FUSE
A 30A in-line fuse is provided with this fridge in order to protect the wiring. For 12V operation,
use a 30A fuse. A standard automobile fuse is recommended and the fuse should be wired to the
positive (“+”) side of the system close to the positive battery terminal.
ATTENTION
If a longer connection cable is necessary, the cable cross section (or gauge) must be equal to or
greater than the cable sizes recommended on the following table. Be careful that the input voltage
at the appliance does not drop below the cut-out voltage of the compressor.
LOW VOLTAGE DISCONNECT
The compressor electronics includes a low voltage disconnect feature. If the input voltage to the
appliance falls below 10.4V (in 12 V mode) or 22.8V (in 24 V mode), the compressor will shut-o.
Once the voltage increases above 11.7V (in 12V mode) or 24.2V (in 24V mode), the compressor will
resume normal operation. This feature is designed to protect the system battery from experiencing
too low a depth of discharge.
DC POWER CONNECTION (continued)
11
ELECTRICAL DIAGRAM
1. Fuse 30A
2. Driver Board
3. Compressor Grounding
4. Fuse 10A
5. Frosting Heater
6. Fan
7. Damper
8. Main Control Board
9. Display Panel
10. Fridge LED Light
11. Lamp Light
12. No Frost Sensor
13. Freezer Sensor
14. Fridge Sensor
15. Ambient Sensor
12
OPERATION
FUNCTIONS
POWER
Press and hold the Power button for seconds to turn the appliance o (the compressor, light, fan
and display will all turn o.) Press and hold the Mode button for 5 seconds to turn the appliance on
(operation and display will function normally.)
FRIDGE +/- TEMPERATURE ADJUSTMENT
Press this button to cycle through fridge temperature settings between +1˚C and +7˚C.
Temperature increases by 1˚C ; the cycle restarts at 1˚C.
FREEZER +/- TEMPERATURE ADJUSTMENT
Press this button to cycle through freezer temperature settings between -18˚C and -12˚C.
Temperature increases by 1˚C ; the cycle restarts at -18˚C.
Once the temperature is chosen, the “88” display will flash 5 times, at one second intervals, after
which that temperature is automatically set.
CELCIUS & FAHRENHEIT SELECTION
Press and hold both “Fridge” and “Freezer” buttons simultaneously for 3 seconds to switch
between Celsius and Fahrenheit.
BATTERY MONITOR
The refrigerator automatically detects voltage. According to its real-time voltage identication,
the control panel will display the following:
Power supply voltage 12V DC 24V DC
Normal voltage range 10.9V ~ 15V 22.8V~28V
Under voltage alarm <10.9V <22.8V
Over voltage alarm >15V >28V
Your Unique fridge, like any battery-powered refrigerating appliance, requires dierent care than
appliances plugged into an electric utility. Prudent operation is the key to extended service.
STARTING THE FRIDGE
After the fridge has been properly connected to the 12 or 24 VDC power source, the compressor
will automatically turn on and the cabinet will begin cooling. Allow the cabinet to cool for at least
4 hours prior to adding foodstu.
13
OPERATION (continued)
DOOR ALARM
Press and hold the “Mode” button for 3 seconds to activate/deactivate the door alarm function.
Note: the door alarm function will be reactivacted if the door is left open for more then 3 minutes
and will beep 3 times every 3 minutes until the door is closed. The sound will stop after 10 minutes
if the door is not closed.
INTERIOR LIGHT
The interior LED light is situated on the inside ceiling of the fridge compartment, it will turn on
when the door of the appliance is opened and will turn o when the door is closed. If the interior
light burns out, contact a certified service technician to have it replaced. Note: The functionality of
the appliance is not aected if the light is not working.
When the alarm LED is lit, a 3-minute beep will sound and the display will show an error code.
The refrigerator has a low-voltage shut-o function intended to protect your battery from exces-
sive drain.
• When power supply is 12V DC, the refrigerator will shut o if the voltage drops below 9.7V.
UV alarm will resume normal status when voltage reaches 11.6V.
• When power supply is 24V DC, the refrigerator will shut o if the voltage drops below 21.5V.
UV alarm will resume normal status when voltage reaches 23.4V.
ERROR CODES
Operational errors will be indicated according to the following chart:
ERROR CODE ERROR DESCRIPTION
E1 Ambient temperature sensor failure
E2 Fridge sensor failure
E3 Freezer sensor failure
E4 Frosting sensor failure
HI Over voltage alarm
LO Under voltage alarm
Ed The fridge door is not closed well. Check and fix it.
EC The appliance has internal communication failure.
E6 Fan failure
EP Power voltage is over 29V; the refrigerator ceases the compressor starting.
E7 Compressor failure.
E8 Compressor starting failure for overload protection.
E9 Compressor starting failure for overheat protection.
14
OPERATION (continued)
OPENING AND CLOSING THE DOOR
The doors are fitted with uniform sealing strips to prevent warm air and moisture from entering the
fridge and freezer compartments.
Be sure that the doors and door seals are free from obstructions and form a complete seal around
the rim of the fridge/freezer cabinets. Over-stung and/or unlevel installation of the appliance will
prevent a good seal. It might be hard to open the door immediately after the door is closed. This
is due to air contraction in the fridge/freezer cabinets. This pressure dierence will equalize in a
few seconds, making the doors easy to open once again.
LOADING THE FRIDGE AND FREEZER
Avoid packing food too tightly around the cooling plates located on the back wall of the fridge/
freezer. Allow air flow around these plates to ensure proper operation.
When adding unfrozen food to the freezer for the first time, fill the freezer only 1/3 full and wait
until that food is suciently frozen before adding more. Food that is packaged in smaller contain-
ers will cool faster; food packages more than 2 inches thick will cool slowly. Avoid placing warm
food in contact with cold food.
REPOSITIONING/REMOVING SHELVES AND DRAWERS
• To position shelf: slide the shelf out and back in to the desired position, taking care not to drop it.
• To remove drawer: slide the drawer out and slightly upwards to remove it. To reinstall the draw-
er, tilt the drawer slightly downwards to position it on its rails and then push it all the way in.
• To remove or reposition door racks: Lift the door rack up and out to remove, and slide it into its
new position from the top.
NORMAL OPERATING SOUNDS
• When the compressor is on, you may hear faint gurgling or bubbling sounds as the refrigerant is
being pumped through the refrigerant coils, and you will hear a whirring or pulsing sound from the
compressor.
• A thermostat controls the compressor and you may hear a ‘click’ when the thermostat cuts in
and out.
WATER CATCH BASIN
Your appliance is “Frost Free” and does not require defrosting. With frost-free operation, any
defrosted water will flow from the walls of the fridge compartment through a drain to the water
catch basin located at the back of the fridge where it will evaporate.
Note: If the fridge has to be moved, remove any water from the catch basin to eliminate the
chance of spills or splashes.
water catch basin
15
INTERNAL CLEANING
Wash the inside of the appliance with luke warm water and a mild soap. Never use abrasive or cor-
rosive cleaning agents, steel wool, scouring sponges, chemical cleaning agents, or highly perfumed
cleaning products to clean the interior as these will damage the surface and leave behind a strong
odor. A sponge, towel, or soft brush is recommended. Wash with a mixture of two tablespoons
(30ml) of baking soda to 1 quart (1.14L) warm water. After cleaning, wipe all surfaces with a soft
cloth and clean water to rinse, and allow the fridge/freezer to dry.
EXTERNAL CLEANING
Wash the outside of the cabinet with warm water and a mild soap or detergent. Do not use abra-
sive or corrosive cleaning agents, chemical cleaning agents, steel wool or scouring sponges to
clean the fridge as it may cause damage to the surfaces. Keep the door gasket clean and dry to
ensure a good seal and ecient operation.
POWER FAILURE
Most power failures are corrected within a few hours and should not aect the internal tempera-
ture of the appliance if opening the door is kept to a minimum. If the power is going to be o for a
longer period of time, take the proper steps to protect the contents.
Note: Wait 3 to 5 minutes before attempting to restart the refrigerator if operation has been inter-
rupted.
VACATION
• Short vacations: Leave the appliance operating during vacations of less than three weeks.
• Long vacations: If the appliance will not be used for several months, remove all items and discon-
nect the appliance from its power source. Clean and dry the interior thoroughly. To prevent odor
and mold growth, leave the door open slightly, blocking it open if necessary.
MOVING
• Remove all items.
• Tape down shelves inside the appliance.
• Turn the adjustable legs up to the base to avoid damage.
• Tape the door shut.
• Be sure the appliance stays in the upright position during transportation. Protect the outside of
the appliance with a blanket.
• If the appliance is placed on its back or side during transportation, upon reaching the destination,
allow it to remain upright for 6 hours before plugging in to avoid damage to internal compo-
nents.
CUSTOMER RESPONSIBILITIES
The following items are the responsibility of the customer and are not covered by the warranty:
• Proper care and use of the appliance as described in this manual.
• Damage to the interior or exterior finish or components after delivery.
• Proper power supply, circuit breaker, wiring, and connections.
• Replacement of LED lights. - Contact Unique’s technical service department for instructions on
how to fix the issue.
• Service required as a result of alteration, misuse, abuse, flooding, fire, lightning, or other acts of
God.
CARE AND MAINTENANCE
16
17
FOOD STORAGE
FOOD STORAGE TIPS
• To ensure freshness and reduce odors, make sure that food is properly wrapped or packaged
before placing it in the refrigerator.
• For better eciency, allow hot foods to cool down before putting them in the refrigerator.
• Shelves can be pulled forward to facilitate organizing and accessing food. Slide them back into
place before closing the door.
• Do not store bottled food or liquid in the freezer chamber; it expands as it freezes and may cause
the bottle to burst.
• The crisper drawer is specially designed to keep fruits and vegetables fresher for longer.
IMPORTANT
This refrigerator is for food use only. It is not designed to store any material requiring a
strict temperature requirement, such as medicine, blood, vaccines, etc.
TROUBLESHOOTING
PROBLEM SOLUTION
Appliance is
connected
to power,
but does not
operate
• Check if 12V or 24V DC is present at the appliance. If not, check all connections and
the system battery voltage.
• Check that the polarity is correct: positive (+) is connected to positive (+), and
negative (-) is connected to negative (-).
• Check the fuse. If blown, replace with a new one (see page 11 for details).
• The primary problem with a non-functioning appliance is due to a voltage drop to
the compressor, which causes the unit to fail to start due to “low voltage”. Typically
a connection is not as tight as it should be, or the wire size to the compressor is too
small. The low voltage problem occurs instantly at start-up and can be dicult to
detect with a volt meter because it happens so quickly (<100ms)
Appliance is
operating, but
the interior
(cabinet) is
not cold
• Allow the appliance at least 4 hrs to cool down once turned on.
• Check that the thermostat control knob is turned to the correct setting relevant to
the room/ambient temperatures.
• Check that the room/ambient temperature is not approaching the internal
operating temperature and does not exceed to 100˚F (38˚C).
• Has too much warm food been added to the fridge/freezer recently? If so, it will
take some time for the appliance to return to temperature.
• Does the cabinet have adequate ventilation around the side walls, allowing it to
transfer heat properly? (See Installation section)
The door will
not open
• Has the door just been opened? If so, leave the appliance closed for a few minutes
to allow the air pressure to equalize and try again.
Before contacting a service technician, your local product dealer or Unique Appliances, please
check the following points. If you contact a technician to repair a fault listed below, or to repair a
fault caused by misuse, abuse, or faulty installation, a charge will be made even if the appliance is
under warranty.
TROUBLESHOOTING (continued)
Excessive
frost and ice
has built up
• Is the weather hot and humid? If so, this will increase the rate of frost build-up in
the cabinet.
• Ensure that stored food is properly packaged.
• Check that the door is closed and has a good seal, and that nothing is preventing
the door from closing properly.
• Large quantities of food have recently been placed in the fridge/freezer, and/or the
door is frequently opened.
• Ensure that proper care and maintenance of the appliance has been performed
(cleaning, defrosting, etc...)
Noise
• Refer to “Normal Operating Sounds” (page 9)
• Ensure that the refrigerator is level - an unlevel fridge may produce noise during
operation.
• Make sure that the fridge is not touching anything; ensure the fridge has been
installed with proper clearances.
Light does not
work
• Contact Unique’s technical service department for instructions on how to fix the
issue.
Heat
dissipation
• There is an anti-condensate tube on the front frame which will vent heat during
refrigerator operation - this is normal.
Moisture
forms on the
outside of the
fridge
• The door has been opened too frequently, or for too long. Ensure door is properly
shut.
• The external environment is very humid.
• The fridge temperature is set too low - increase fridge temperature.
The door
doesn’t seal
properly, or
there is a cool
air leak
• The door seal may be hardened or deformed. Soften the door seal by applying a
hot towel to the deformed surface or warming it with the hot air from a hair dryer,
and then close the door tightly to reshape the seal.
The fridge
is not cool
enough
• The fridge is exposed to sunshine or a heat source - ensure fridge is positioned
correctly.
• Temperature is set too high - decrease fridge temperature.
• A large amount of warm or hot food was recently stored. Wait for the fridge to cool
back down to its set temperature.
• Bottles and food packages are impairing cool air circulation - arrange bottles and
food with more space to allow for better circulation.
• The fridge is frequently opened, has been open too long, or is not properly closed.
Food is
freezing in
the fridge
compartment
• The fridge temperature is set too low - increase fridge temperature.
• Is food placed too close to the sensor?
• Is food placed too close to the air outlets?
There is an
odor in the
fridge
• A new fridge may give o the odor of the insulation or its construction materials.
This smell will dissipate with use.
• Check if there is any spoiled food in the fridge. Clean the fridge on a regular basis.
• Thoroughly package and seal strong smelling food.
18
19
Unique Appliances Ltd. (hereafter “Unique”) warrants that this UNIQUE freezer is free from manufacturer’s defects in
material and workmanship under normal usage and service under the following terms.
TERMS OF WARRANTY
Plastic parts are warranted for thirty (30) days from the date of purchase, with no extensions provided.
Parts Warranty
This appliance has been designed for domestic household use. If properly installed, adjusted and operated under normal conditions in
accordance with printed instructions, it will satisfactorily perform the functions that are generally expected of this type of appliance. If
the appliance fails to do so because of a defect in material or workmanship within one year from the original date of purchase: Unique
will at our option, repair, exchange, or correct by other means Unique consider appropriate, any part(s) Unique finds to be defective
except for the surface finish.
Ownership
This Warranty is made only to the first purchaser (”original purchaser”) who acquires this freezer for his/her own use and will be
honored by Unique Appliances Ltd. and by the Seller. Purchaser must retain their receipt as proof of purchase date.
Warranty Conditions
This warranty does not apply to any appliance that has been subjected to alterations, misuse, abuse (including damage by foreign
agents or chemicals), accident, improper installation or service, delivery damage, or other than normal household use and service.
This UNIQUE appliance must be serviced regularly as outlined in the Owner’s Manual. Neither Unique Appliances Ltd. nor the selling
dealer will be liable for direct or indirect loss of foods caused by failure in operation. In case of damage, the owner must provide proof
of purchase, Model, and Serial Number to the selling dealer or Unique Appliances Ltd. This warranty is LIMITED STRICTLY to the terms
indicated herein, and no other expressed warranties or remedies thereunder shall be binding on Unique.
Purchaser’s Responsibilities
The purchaser will be responsible for the costs of any service calls requested to demonstrate or confirm the proper operation of the
appliance, the installation, or to correct malfunctions in the appearance created by the operation of the appliance in a manner not
prescribed by or cautioned against in the use and care instructions.
Model and Serial Number
The appliance model number and serial number can be found on a rating plate attached inside the freezer. The purchaser should always
refer to the model and serial number when talking to or contacting the dealer from whom the appliance was purchased.
EXCLUSIONS
Save as herein provided, by Unique, there are no other warranties, conditions, representations or guarantees, express or implied, made
or intended by Unique or its authorized distributors and all other warranties, conditions, representations or guarantees, including any
warranties, conditions, representations or guarantees under any Sale of Goods Act or like legislation or statute is hereby expressly
excluded. Save as herein provided, Unique shall not be responsible for any damages to persons or property, including the unit itself,
howsoever caused or any consequential damages arising from the malfunction of the unit and by the purchase of the unit, the
purchaser does hereby agree to indemnify and hold harmless Unique from any claim for damages to persons or property caused by the
unit.
Removal or disfigurement of the serial plate will void the warranty. The purchaser will be responsible for any expenses involved in
making the refrigerator readily accessible for servicing. The purchaser will be responsible for any extra charges where the installation is
in a remote location such as un-assumed roads, islands, areas known as cottage country, more than 75 km outside a metropolitan area,
or where a technician is not available. Freight damage is not covered by this warranty.
GENERAL PROVISIONS
No warranty or insurance herein contained or set out shall apply when damage or repair is caused by any of the following:
1) Power failure.
2) Damage in transit or when moving the appliance.
3) Improper power supply such as low voltage, defective house wiring or inadequate fuses.
4) Accident, alteration, abuse or misuse of the appliance such as inadequate air circulation in the room or abnormal operating
conditions (ie. extremely high or low room temperature).
5) Use for commercial or industrial purposes (ie. If the appliance is not installed in a domestic residence).
6) Fire, water damage, theft, war, riot, hostility, acts of God such as hurricanes, floods etc.
7) Service calls resulting in customer education.
8) Improper Installation (ie. Building-in of a free standing appliance or using an appliance outdoors that is not approved for outdoor
application, including but not limited to: garages, patios, porches or anywhere that is not properly insulated or climate controlled).
Proof of purchase date will be required for warranty claims; retain bills of sale. In the event that warranty service is required, present the
proof of purchase to our authorized service depot.
Nothing within this warranty shall imply that Unique will be responsible or liable for any spoilage or damage to food or other
contents of this appliance, whether due to any defect of the appliance, or its use, whether proper or improper.
Factory Assistance
If the purchaser is unable to locate an authorized dealer/service agent, or if the purchaser does not receive satisfaction from the dealer,
they may contact Unique Appliances Customer Service directly at Toll Free 1-877-427-2266 or 905-827-6154.
WARRANTY
For questions related to the operation, safety or the purchase of your fridge, please contact your
dealer for more information. For general information, contact our customer service department:
NOTES
(Manual copy - Keep with your records)
To make care and servicing of your fridge easy and ecient, please record the following
information for future reference:
Model:
Serial Number:
Purchased From:
Date Purchased:
APPLIANCE INFORMATION
CONTACT US
Toll-free
1-877-427-2266 or 1-905-827-6154
available during regular business hours,
8:30 am to 4:30 pm, EST.
Website
www.uniqueappliances.com
Email
info@UniqueAppliances.com
Please visit our website at https://uniqueappliances.com/product-registration/
to register your product.
PRODUCT REGISTRATION
