HD Pro Projector
Quick Start Guide
Your Miroir HD Pro Projector
A
Battery Indicator Lights - Lights flash in turn as the device
charges. The battery is fully charged when all the lights
illuminate and no longer flash.
Projection Lens - Turns power on.
Audio Out (3.5mm) - (Optional) Connect an external speaker
or headphones.
HDMI Video Input - Connect an HDMI cable to a device that
supports HDMI video output.
USB Power Output - Connect a USB power cable to provide
power to a HDMI streaming stick or to charge a smartphone
battery. Cannot be used for video input.
USB-C Video/Charge Input - Connect the supplied USB-C
video cable to a device that supports USB-C video output,
or connect to a power adapter. Fully charge battery before
the first use (approx. 4-5 hours).
Reset Button - Press to reset projector.
Power Port - Connect included AC Adapter/Charger for power.
Fully charge battery before the first use (approx. 4-5 hours).
Mode Button - Press for eco-mode to extend battery life.
Volume Controls - Increase/decrease the volume output of the
projector.
Focus Controls - Turn wheel to adjust focus.
Rubber Foot Pads - Provides stability and proper airflow to
cooling vents.
Tripod Mount - Will fit a standard sized tripod screw. Tripod
not included.
Cooling Vent - IMPORTANT: Do not cover or block airflow to
the vent.
Kick Stand - Kick Stand out to elevate front.
B
A
C
D
E
F
G
H
I
J
K
L
M
N
O
AUD IO
HDM I
USB Typc -C
Res et
DC IN
AUD IO
HDM I
USB Typc -C
Res et
DC IN
J
K
I
NML
AUD IO
HDM I
USB Typc -C
Res et
DC IN
AUD IO
HDM I
USB Typc -C
Res et
DC IN
C FD E
B
G H
O
Your Miroir HD Pro Projector
A
Battery Indicator Lights - Lights flash in turn as the device
charges. The battery is fully charged when all the lights
illuminate and no longer flash.
Projection Lens - Turns power on.
Audio Out (3.5mm) - (Optional) Connect an external speaker
or headphones.
HDMI Video Input - Connect an HDMI cable to a device that
supports HDMI video output.
USB Power Output - Connect a USB power cable to provide
power to a HDMI streaming stick or to charge a smartphone
battery. Cannot be used for video input.
USB-C Video/Charge Input - Connect the supplied USB-C
video cable to a device that supports USB-C video output,
or connect to a power adapter. Fully charge battery before
the first use (approx. 4-5 hours).
Reset Button - Press to reset projector.
Power Port - Connect included AC Adapter/Charger for power.
Fully charge battery before the first use (approx. 4-5 hours).
Mode Button - Press for eco-mode to extend battery life.
Volume Controls - Increase/decrease the volume output of the
projector.
Focus Controls - Turn wheel to adjust focus.
Rubber Foot Pads - Provides stability and proper airflow to
cooling vents.
Tripod Mount - Will fit a standard sized tripod screw. Tripod
not included.
Cooling Vent - IMPORTANT: Do not cover or block airflow to
the vent.
Kick Stand - Kick Stand out to elevate front.
B
A
C
D
E
F
G
H
I
J
K
L
M
N
O
AUD IO
HDM I
USB Typc -C
Res et
DC IN
AUD IO
HDM I
USB Typc -C
Res et
DC IN
J
K
I
NML
AUD IO
HDM I
USB Typc -C
Res et
DC IN
AUD IO
HDM I
USB Typc -C
Res et
DC IN
C FD E
B
G H
O
Connect To Your Device
AUD IO
HDM I
USB Typc -C
Res et
DC IN
Connect To Your Apple Device Lightning
HDMI Cable
(Included)
Apple Lightning
Digital AV Adapter is
required for iPhone.
(not included)
Connect To Your Laptop HDMI
AUD IO
HDM I
USB Typc -C
Res et
DC IN
HDMI Cable
(Included)
Connect To Your MacBook USB-C
AUD IO
HDM I
USB Typc -C
Res et
DC IN
USB-C Video Cable
(Included)
IMPORTANT! Not all USB – C cables will support video.
The USB-C cable that comes with the projector will support
video and charging.
AUD IO
HDM I
USB Typc -C
Res et
DC IN
HDMI Cable
(Included)
HDMI Adapter
may be required
for your device.
(not included)
Connect To Your Device
AUD IO
HDM I
USB Typc -C
Res et
DC IN
Connect To Your Apple Device Lightning
HDMI Cable
(Included)
Apple Lightning
Digital AV Adapter is
required for iPhone.
(not included)
Connect To Your Laptop HDMI
AUD IO
HDM I
USB Typc -C
Res et
DC IN
HDMI Cable
(Included)
Connect To Your MacBook USB-C
AUD IO
HDM I
USB Typc -C
Res et
DC IN
USB-C Video Cable
(Included)
IMPORTANT! Not all USB – C cables will support video.
The USB-C cable that comes with the projector will support
video and charging.
AUD IO
HDM I
USB Typc -C
Res et
DC IN
HDMI Cable
(Included)
HDMI Adapter
may be required
for your device.
(not included)
Troubleshooting
The image is blurry
• Adjust the projected image’s focus by rolling the focus wheel
forwards or backwards.
• Check that the surface you are projecting on is smooth and
non-reflective.
• Check that the projector’s lens is clean and free of debris.
The image is not square
• Check that the projector’s lens is parallel to your projection
surface and that your projection surface is flat.
No sound
• Check the volume control on your source device to ensure
the volume is turned up.
• Check the volume control on the projector to ensure the
volume is turned up.
• If you are using an adapter, verify that the adapter
supports audio.
• Check that the HDMI cable is fully plugged into the
HDMI port.
Learn More
To learn more about your Miroir HD Pro Projector and
its operations, to review specs, and find answers to
frequently asked questions,
please visit: www.miroirusa.com/M289
Troubleshooting
No Signal Message
• Check that you are using the required cable and/or adapter.
• If you are using a digital AV adapter, check that the adapter is
an authentic Apple adapter and is compatible with your model
phone or tablet.
• If you are connecting via USB-C, check that you are using the
USB-C video cable that came with the projector – this cable is
labeled “USB-C Video Connector.” Some USB-C cables do not
support video.
• If you are connected to a laptop or computer, check your
computer display settings to ensure a multiple display option is
selected (such as “duplicate these displays”).
• Check that your source device supports HDMI video out or
USB-C video out.
Projector will not power on, or stay powered on
• Check the battery life of the projector by briefly pressing the
power button on the projector. If one or fewer lights illuminate,
charge the battery with the USB-C cable or power adapter.
• Check that you are plugging the USB-C cable into the USB-C power
Input port and not the USB-C Video input port on the projector.
Troubleshooting
The image is blurry
• Adjust the projected image’s focus by rolling the focus wheel
forwards or backwards.
• Check that the surface you are projecting on is smooth and
non-reflective.
• Check that the projector’s lens is clean and free of debris.
The image is not square
• Check that the projector’s lens is parallel to your projection
surface and that your projection surface is flat.
No sound
• Check the volume control on your source device to ensure
the volume is turned up.
• Check the volume control on the projector to ensure the
volume is turned up.
• If you are using an adapter, verify that the adapter
supports audio.
• Check that the HDMI cable is fully plugged into the
HDMI port.
Learn More
To learn more about your Miroir HD Pro Projector and
its operations, to review specs, and find answers to
frequently asked questions,
please visit: www.miroirusa.com/M289
Troubleshooting
No Signal Message
• Check that you are using the required cable and/or adapter.
• If you are using a digital AV adapter, check that the adapter is
an authentic Apple adapter and is compatible with your model
phone or tablet.
• If you are connecting via USB-C, check that you are using the
USB-C video cable that came with the projector – this cable is
labeled “USB-C Video Connector.” Some USB-C cables do not
support video.
• If you are connected to a laptop or computer, check your
computer display settings to ensure a multiple display option is
selected (such as “duplicate these displays”).
• Check that your source device supports HDMI video out or
USB-C video out.
Projector will not power on, or stay powered on
• Check the battery life of the projector by briefly pressing the
power button on the projector. If one or fewer lights illuminate,
charge the battery with the USB-C cable or power adapter.
• Check that you are plugging the USB-C cable into the USB-C power
Input port and not the USB-C Video input port on the projector.
© 2019 Miroir USA, LLC. All rights reserved. Miroir and the Miroir
logo are owned by Miroir USA, LLC. All other trademarks are the
property of their respective owners. Miroir USA, LLC assumes
no responsibility for any errors that may appear in this manual.
Information contained herein is subject to change without notice.
