COMPRESSOR WINE COOLER
OPERATING INSTRUCTION
MODEL: JC-150WD
We continue to be committed to provide you tools with competitive price.
"Save Half", "Half Price" or any other similar expressions used by us only represents an
estimate of savings you might benefit from buying certain tools with us compared to the major
top brands and doses not necessarily mean to cover all categories of tools offered by us. You
are kindly reminded to verify carefully when you are placing an order with us if you are
actually saving half in comparison with the top major brands.
- 1 -
JC-150WD
Have product questions? Need technical support? Please feel free to
contact us:
CustomerService@vevor.com
NEED HELP? CONTACT US!
This is the original instruction, please read all manual instructions
carefully before operating. VEVOR reserves a clear interpretation of our
user manual. The appearance of the product shall be subject to the
product you received. Please forgive us that we won't inform you again if
there are any technology or software updates on our product.
Compressor Wine Cooler
JC-150WD
- 2 -
BEFORE USE, PLEASE READ AND FOLLOW ALL SAFETY RULES AND OPERATING
INSTRUCTION.
IMPORTANT SAFETY INSTRUCTIONS
WARNING
To reduce the risk of fire, electrical shock, or injury when using
your appliance, follow these basic precautions:
• Before using the appliance, please read this user manual to ensure that you gain the
maximum benefit from it.
WARNING:
1)This appliance is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge, unless they
have been given supervision or instruction concerning use of the appliance by a person
responsible for their safety.
2)Children should be supervised to ensure that they do not play with the appliance.
3)This appliance can be used by children aged from 8 years and above and persons with
reduced physical, sensory or mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning use of the appliance in a safe
way and understand the hazards involved. Children shall not play with the appliance.
Cleaning and user maintenance shall not be made by children without supervision.
4)If the supply cord is damaged, it must be replaced by the manufacturer, its service agent
or similarly qualified persons in order to avoid a hazard.
5)To avoid a hazard due to instability of the appliance, it must be fixed in accordance with
the instructions.
6)When positioning the appliance, ensure the supply cord is not trapped or damaged.
7)Do not locate multiple portable socket-outlets or portable power supplies at the rear of the
appliance.
8)Keep the ventilation holes in the equipment enclosure or built-in structure free of
obstructions.
9)Do not use mechanical devices or other means to accelerate the defrosting process,
other than those recommended by the manufacturer.
10)Do not damage the refrigerant circuit.
- 3 -
11)Do not use electrical appliances inside the drink storage compartments of the appliance,
unless they are of the type recommended by the manufacturer.
12)Do not store explosive substances such as aerosol cans with a flammable propellant in
this appliance.
13)This appliance is intended to be used in household and similar applications such as
-staff kitchen areas in shops, offices and other working environments;
-farm houses and by clients in hotels, motels and other residential type environments;
-bed and breakfast type environments;
-catering and similar non-retail applications.
14)Children aged from 3 to 8 years are allowed to load and unload refrigerating appliances.
15)To avoid contamination of drink, please respect the following instructions:
-Opening the door for long periods can cause a significant increase of the temperature in
the compartments of the appliance.
-Clean regularly surfaces that can come in contact with drink and accessible drainage
systems.
-Clean water tanks if they have not been used for 48 h; flush the water system connected to
a water supply if water has not been drawn for 5 days.
-If the refrigerating appliance is left empty for long periods, switch off, defrost, clean, dry,
and leave the door open to prevent mould developing within the appliance.
• Note: This appliance contains flammable refrigerant R600a and foaming agent
cyclopentane.
Please avoid contact fire when you transport and use it.
Please ask professional for servicing when the machine broke down. Please send it to your
local appointed disposal station when you discard it.
-Save these instructions-
During using, service and disposal the appliance, please pay
attention to symbol similar as left side, which is located on rear of
appliance (rear panel or compressor) and with yellow or orange color.
It’s risk of fire warning symbol. There are flammable materials in
refrigerant pipes and compressor.
Please be far away fire source during using, service and disposal.
- 4 -
INSTALLATION INSTRUCTIONS
• This appliance is designed to be recessed or built-in.
• Place your appliance on a floor that is strong enough to support the appliance when it is
fully loaded. To level your appliance, adjust the leveling legs at the bottom of the appliance.
• Ensure that there are no obstructions around equipment or in recessed structures and that
ventilation is maintained.
• Locate the appliance away from direct sunlight and sources of heat (stove, heater, radiator,
etc.). Direct sunlight may affect the acrylic coating and heat sources may increase electrical
consumption. Extreme cold ambient temperatures may also cause the unit not to perform
properly.
• Avoid locating the appliance in moist areas.
• Plug the unit into an exclusive, properly installed-grounded wall outlet. Do not under any
circumstances cut or remove the third (ground) prong from the power cord. Any questions
concerning power and/or grounding should be directed toward a certified electrician or an
authorized products service center.
• After plugging the appliance into a wall outlet, allow the appliance to cool down for 2-3
hours before placing any items in the compartment.
PARTS AND FEATURES
1: Upper Hinge
2: Control Panel
3: Door Handle
4: Door Gasket
5: Shelves
6: Bottom Hinge
- 5 -
INSTALLATION SPACE REQUIREMENTS
Front size
Lateral size
Use required space
- 6 -
OPERATING YOUR UNIT
Setting the Temperature Control
Key Function
①Switch key: Long ammonium 3 seconds on/off, short press to select the upper/lower
temperature zone
②Light/CF key: Short press on or off the light, long press 3s Fahrenheit Celsius function
conversion
③Add key: temperature setting
④Minus key: temperature setting
⑤Lock/Unlock key: Press the "^" and "V" keys simultaneously for 3s to lock or unlock.
Automatic locking function
When all the key no operation for 20 seconds, the key will be locked automatically. After
locking, the plus and minus keys cannot be operated. The unlock key and light / CF key
operate normally
Auto light off function
When all the key no operation for 10 minutes, the lamp will turn off automatically
Adjustable range
Upper room:
lowest value: 5°C / 41°F
Maximum value: 22°C /71.6°F
Lower chamber:
lowest value: 5°C / 41°F
Maximum value: 22°C /71.6°F
- 7 -
Display range
Control panel temperature display range: 0~37°C / 32~99°F
Display stability
In the Celsius state: When the temperature measured by the temperature probe is within ±
1 ° C of the set temperature, the temperature display will display the set temperature value
In the Fahrenheit state: When the temperature measured by the temperature probe is within
± 2 ° F of the set temperature, the temperature display will display the set temperature value
Error code
EE: "EE" is displayed when the temperature probe is short-circuited or disconnected,
flashes, and cooling is stopped
LL: When the temperature measured by the temperature probe is lower than 0 degrees
Celsius, "LL" is displayed, flashing, and the cooling is stopped
HH: When the temperature measured by the temperature probe is higher than 37 degrees
Celsius, "HH" is displayed, flashing, and cooling is stopped
-- : When the communication between the display board and the power board fails, the nixie
tube will display "--", blink, and stop refrigeration
Forced defrosting function
When the compressor works for 12 hours, the compressor will stop working for 30 minutes
Memory function
The control board is re-energized after each power-off, the temperature setting value,
Fahrenheit/Celsius state will be the same as before the power-off, and the length of
power-off time is not limited
GENERAL FAULT DESCRIPTION
If the product is not working properly, please check and handle according to the following
methods. If the situation can not be changed, please contact the local after-sales service
center in time, and be sure to provide the model name and product number in detail.
- 8 -
The refrigerator doesn’t work
Is the power on?
Is the power supply voltage too low?
It's noisy
Whether the ground is flat and whether
the product is placed stably.
Is the product in contact with external
objects or walls.
THE INTERNAL TEMPERATURE IS NOT LOW
Improper setting
temperature, please
select the
appropriate
temperature.
The door is not
closed tightly or
opened frequently,
and the opening
time is too long.
Is the location
exposed to direct
sunlight or too
close to the
furnace and other
heat sources.
Poor heat
dissipation,
please check
whether there is
enough cooling
space around
the product.
- 9 -
WIRING DIAGRAM
Correct disposal of this product
This symbol on the product, or in its packaging, indicates that this product
may not be treated as household waste. Instead, it should be taken to the
appropriate waste collection point for the recycling of electrical and electronic
equipment. By ensuring this product is disposed of correctly, you will help
prevent potential negative consequences for the environment and human
health, which could otherwise be caused
by the inappropriate waste handling of this product. For more detailed
information about the recycling of this product, please contact your local
council, your household waste disposal service, or the shop where you
purchased the product.
