Quick Start
Guide
Cordless Stick
Vacuum Cleaner
ASSEMBLING YOUR
VACUUM CLEANER
Assembly
For normal operation, all accessories must be attached securely.
Assembly for cleaning ceilings, floors and corners:
click
click
click
Assembly for cleaning furniture surfaces:
Assembly for cleaning in a flexible way:
click
click
CHARGING YOUR
VACUUM CLEANER
Fully charge your new vacuum before first use. You can connect to charger
either directly or on the dock.
Installing the Battery
Charging
When battery level is below 20%, the vacuum will switch to
Turbo mode automatically.
To install, slide the battery
into the slot in the back of
the main body.
To remove, press and hold
the Battery Release Button
then slide out the battery.
Tip:
1
2
• Install on concrete load-bearing walls only.
• Do not drill into any damp walls like bathroom and kitchen walls.
Charging Directly
Flip open the charging cap on the main body and charge directly.
Charging on the Dock
1. Find an ideal height between 50 and 60 inches (125 and 150 cm). Apply
the sticker on the wall and drill through the holes, then install the plastic
anchors.
2. Align the holes in the docking station with the anchors and drill the
screws into place.
3. Connect the charger into the charging port at the bottom of the station.
4. Rest the vacuum cleaner and accessories onto the docking station.
50-60 in
1 2 3 4
