Before using your new product, please read these instructions to prevent any damage.
USER GUIDE
24 in. Outdoor Compact
Refrigerator
NS-OCF55SS2
www.insigniaproducts.com
2
Contents
IMPORTANT SAFETY INSTRUCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Package contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Components. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Dimensions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Control and display panels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Setting up your refrigerator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Before using your refrigerator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Finding a suitable location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Installing the handle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Installing the casters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Front vent . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Building in your refrigerator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Preparing your refrigerator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
Leveling your refrigerator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
Providing a proper power supply . . . . . . . . . . . . . . . . . . . . . . . . . . .15
Connecting to power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
Using your refrigerator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Turning on your refrigerator. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Setting the temperature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Changing the temperature display . . . . . . . . . . . . . . . . . . . . . . . . .17
Lighting your refrigerator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Memory function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Positioning beverages in your refrigerator . . . . . . . . . . . . . . . . . .18
Removing a shelf . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Replacing a shelf. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Maintaining your refrigerator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Cleaning the interior of your refrigerator. . . . . . . . . . . . . . . . . . . .19
Defrosting your refrigerator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
Alarms. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
Door ajar alarm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
Temperature alarms and error codes. . . . . . . . . . . . . . . . . . . . . . . .20
Storing your refrigerator. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
Moving your refrigerator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
Power failure. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
Tips on saving energy . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
Error codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
ONE-YEAR LIMITED WARRANTY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
3
24 in. Outdoor Compact Refrigerator
www.insigniaproducts.com
IMPORTANT SAFETY INSTRUCTIONS
WARNING
To reduce the risk of fire, electrical shock, or injury follow these basic
precautions when using your refrigerator:
• Read all instructions before using the refrigerator.
• Never allow children to operate, play with, or crawl inside the appliance.
• Refrigerants: All refrigeration products contain refrigerants. Under the
guidelines of federal law, refrigerants must be removed before the
disposal of the product. It is the consumer’s responsibility to comply with
federal and local regulations when disposing of this product.
• Never clean the appliance with flammable fluids. The fumes can create a
fire hazard or explosion.
• Do not store or use gasoline or any other flammable vapors and liquids in
the vicinity of this or any other appliance. The fumes can create a fire
hazard or explosion.
• Do not store explosive substances, such as aerosol cans with a flammable
propellant, in this appliance.
SAVE THESE INSTRUCTIONS
DANGER: Risk of fire or explosion. Flammable refrigerant used.
• Do not puncture refrigerant tubing.
• Do not use mechanical devices to defrost your
refrigerator.
• Ensure that servicing is done by factory authorized service personnel, to
minimize product damage or safety issues.
• Consult repair manual or owner's guide before attempting to service this
product. All safety precautions must be followed.
• Dispose of properly in accordance with federal or local regulations.
• Follow handIing instructions carefully.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
This symbol indicates that
dangerous voltage constituting a
risk of electric shock is present
within your refrigerator.
This symbol indicates that there
are important operating and
maintenance instructions in the
literature accompanying your
refrigerator.
4
www.insigniaproducts.com
WARNING
Electric Shock Hazard
Failure to follow these instructions can result in
electric shock, fire, or death.
1 WARNING–Keep ventilation openings in the
appliance enclosure or in the built-in structure
clear of obstruction.
2 WARNING–Do not touch the interior of the chiller
compartment with wet hands. This could result in
frost bite.
3 WARNING–Do not use mechanical devices or other means to
accelerate the defrosting process, other than those recommended by
the manufacturer.
4 WARNING–Do not damage the refrigerant circuit when handling,
moving, or using your refrigerator.
5 WARNING–Do not use electrical appliances inside the storage
compartment of your refrigerator, unless they are of the type
recommended by the manufacturer.
6 WARNING–DANGER—Never allow children to play with, operate, or
crawl inside your refrigerator.
Risk of child entrapment. Before you throw away your old refrigerator:
1) Take off the door
2) Leave the shelves in place so that children may not easily climb
inside
7 Unplug your refrigerator before carrying out user maintenance on it.
8 This appliance is not intended for use by persons (including children)
with reduced physical, sensory, or mental capabilities, or lack of
experience and knowledge, unless they have been given supervision
or instruction concerning use of the appliance by a person responsible
for their safety. Children should be supervised to ensure that they do
not play with the appliance.
9 Please dispose of the refrigerator according to local regulations as the
refrigerator contains flammable gas and refrigerant.
10 Follow local regulations regarding disposal of the refrigerator due to
flammable refrigerant and gas. All refrigeration products contain
refrigerants, which under the guidelines of federal law must be
removed before disposal. It is the consumer's responsibility to comply
with federal and local regulations when disposing of this product.
5
24 in. Outdoor Compact Refrigerator
www.insigniaproducts.com
11 This refrigerator is intended to be used in household and similar
environments, such as:
• Staff kitchen areas in shops, offices, and other working
environments
• Farm houses and by clients in hotels, motels, and other residential
environments
• Bed and breakfasts
• Catering and similar non-retail applications
12 Do not store or use gasoline or any flammable liquids inside or in the
vicinity of this refrigerator.
Grounding Instructions
This appliance must be grounded. Grounding reduces the risk of electrical
shock by providing an escape wire for the electrical current.
This appliance has a cord that has a grounding wire with a 3-prong plug. The
power cord must be plugged into on outlet that is properly grounded. If the
outlet is a 2-prong wall outlet, it must be replaced with a properly grounded
3-prong wall outlet. The serial rating plate indicates the voltage and
frequency the appliance is designed for.
WARNING: Improper use of the grounding plug can result in a risk of electric
shock. Consult a qualified electrician or service agent if the grounding
instructions are not completely understood, or if doubt exists as to whether
the appliance is properly grounded.
Do not connect your appliance to extension cords or together with
another appliance in the same wall outlet. Do not splice the power cord.
Do not, under any circumstances, cut or remove the third ground prong from
the power cord. Do not use extension cords or ungrounded (two prong)
adopters. If the power supply cord is damaged, it must be replaced by the
manufacturer or its service agent or similar qualified person in order to avoid
hazard.
Features
• The main compartment stores up to 90, 12 oz. (355 ml) beverage cans and
the door compartments store up to 24 standard beverage cans
• Electronic temperature control with LED control panel adjusts the
temperature from 34°–50° F (1°–10° C)
• Stainless steel foam-core door
• Interchangeable glass shelves
• Internal light helps you select the beverage you want
6
www.insigniaproducts.com
Package contents
• 24 inch Outdoor Compact Refrigerator
• Glass shelves (3)
•Handle
• Hardware Bag
•User Guide
Components
Notes:
• For your refrigerator to operate normally, avoid placing it in areas with high
magnetic fields or high humidity.
• When you put several beverage bottles in your refrigerator at one time, the
temperature in your refrigerator may rise temporarily.
• After unplugging your refrigerator, to prolong the service life of the
compressor, wait for at least five minutes before plugging it back in.
Stainless steel
door
Bottom vent
Circulation fan
Glass shelves
Door switch
Control panel and display
Door lock
Temperature sensor
Milk shelves
Shelf
7
24 in. Outdoor Compact Refrigerator
www.insigniaproducts.com
Dimensions
34.1 in. (86.7 cm)
23.6 in. (60 cm)
23.8 in. (60.5 cm)
8
www.insigniaproducts.com
Control and display panels
BUTTON FUNCTION
Press to turn the power on or off. Press and hold for approximately three
seconds to go to “Standby” mode. Press the key once to restart your
refrigerator.
Press to turn the interior light on or off. The light turns on automatically
when the door is open, and turns off when the door is closed.
Press to raise the temperature.
Press to lower the temperature.
Press and hold both buttons simultaneously to switch between °F and °C.
INDICATOR DESCRIPTION
Lights to indicate that cooling mode is on.
Indicates which temperature mode is being displayed.
Notes:
• Touch the control panel lightly when pressing the keys.
• To avoid scratching the control panel, do not touch it with sharp objects.
Up and down buttons
Light button DisplayPower button
Hold 3 Sec
°C/°F
Hold 3 Sec
On/Off
button
Interior light
button
Display
screen
Power
indicator
Tem pe rat ure
scale indicator
Increase/
decrease
buttons
9
24 in. Outdoor Compact Refrigerator
www.insigniaproducts.com
Setting up your refrigerator
Before using your refrigerator
• Remove the exterior and interior packing.
• Let your refrigerator stand upright for approximately six hours before
connecting it to power. This reduces the possibility of a malfunction in the
cooling system from improper handling during transportation.
• Clean the exterior surface of your refrigerator with a soft, dry cloth and
clean the interior surface with lukewarm water using a soft cloth.
Finding a suitable location
• Your refrigerator is designed to be built-in or free standing.
• Place your refrigerator on a floor, countertop, or cabinet that is strong
enough to support it when it is fully loaded.
• Locate your refrigerator away from direct sunlight and sources of heat
(stove, heater, radiator, and so on). Direct sunlight may affect the acrylic
coating and heat sources may increase electrical consumption.
• Avoid locating your refrigerator in moist areas.
Finding a suitable location outside
If you decide to place your refrigerator outside and exposed to the elements:
• You should routinely clean the area around the refrigerator pump that is
vented.
• Prevent dust and debris from building up, as they can shorten the life of
your refrigerator.
• Keep your refrigerator dry to prevent rust or damage.
• Place your refrigerator up on blocks, if flooding is possible, to avoid
damage or electrical hazards.
• To prevent damage from high winds, place the back of your refrigerator
against a solid surface to keep the compressor and coils safe from flying
debris.
• In extremely humid, very dry, or consistently cold and dry locations, the
refrigerator's seals and gaskets may dry or break up. This cannot be
avoided.
CAUTION: This appliance is heavy. We suggest having two people set up or
move.
10
www.insigniaproducts.com
Installing the handle
1 Remove the door handle and hardware bag from your refrigerator. The
hardware bag contains a hex key and two extra screws.
2 Place your refrigerator carefully on its back.
3 Place the handle on the mounting studs. The set screws are
pre-installed in the handle and should face down when installed
correctly.
Notes:
• We recommend having two people complete the installation.
• To avoid scratching the front panel, place a soft cloth or towel against the
panel while installing the door handle.
Handle
Mounting stud
Set screw
Handle
11
24 in. Outdoor Compact Refrigerator
www.insigniaproducts.com
4 Push the door handle tightly against the door.
5 Insert the short end of the hex key into the set screw and tighten until
snug (do not overtighten). The set screw is not recessed into the
handle.
6 Repeat Step 5 for the other set screw.
7 Keep the hex key with these installation instructions for future use.
Installing the casters
1 Lay out a towel or blanket on the floor, then place your refrigerator on
its back.
2 Remove the four leveling feet and keep them in a safe place for future
use.
CAUTION:
• To reduce the risk of personal injury or property damage, unplug the
appliance and use two people to complete the caster installation.
Hex key
12
www.insigniaproducts.com
3 Install the non-locking casters on the back of the appliance.
4 Install the locking casters on the front of the appliance.
CAUTIONS:
• After installing the casters, the refrigerator must be allowed to stand upright
for six hours before plugging it in to avoid damage to internal components.
• To avoid damage to the power cord, put the cord on top of the refrigerator
when moving it.
Power cord
13
24 in. Outdoor Compact Refrigerator
www.insigniaproducts.com
Using the locking casters
To lock the wheels, push down on the caster tab. To unlock the wheel, push
up on the caster tab.
Front vent
Your refrigerator is front vented. Do not block the front air vent. Doing so will
result in high operating temperatures, higher energy usage, and possible
system overheating and failure.
Building in your refrigerator
Required tools
Preparing the enclosure
We do not recommend that you install your refrigerator into a corner or
directly beside a wall. If it is necessary to place the unit next to a wall or in a
corner, leave at least 2.4 - 4 in. (6-10 cm) between the wall and the appliance
to allow for the door opening 90° for full extension of the shelves. In order to
remove a shelf, the door must be opened at least 120°, which requires at least
25.6 in. (65 cm) between the wall and the appliance.
CAUTION: Wear gloves and safety goggles during installation.
Lock
Unlock
Vents
Safety goggles
Gloves
Electric drill with
1 1/2” hole bit
Flashlight
Carpenter
square
Level
Tape measure
14
www.insigniaproducts.com
If you are installing your refrigerator between frameless cabinets, a 0.5 in.
(1.3 cm) wide filler strip or side panel may be needed on both sides of your
refrigerator. The filler strip provides a space between the appliance case and
the adjacent cabinet door swing. The width of the opening must include the
filler panels. The door should extend at least 1 in. (2.6 cm) beyond the
surrounding cabinets.
Preparing your refrigerator
If your refrigerator will be built into an enclosure the compressor cover must
be removed to allow air flow around the compressor, so that it does not
overheat. Keep the cover and screws in a safe place so that they can be used
again in the future if necessary.
Notes:
• The indicated depth requirement assumes that the electrical outlet is located
in the adjacent cabinet or is flush mounted (not surface mounted) in the rear
wall of the enclosure.
• If the electrical outlet is located inside an adjacent cabinet, cut a 1.5 in.
(3.8 cm) diameter hole to route the power cord. If the cabinet wall is metal,
the hole edge must be covered with a bushing or grommet to protect the
cord.
1.5 in. (3.8 cm) diameter
(if electrical outlet is in adjacent
cabinet)
2 in. (5 cm)
25 in. (63.5 cm) min.
35 in. (88.9 cm) min.
6 in. (15.2 cm)
90°
24 in. (61 cm) min.
15
24 in. Outdoor Compact Refrigerator
www.insigniaproducts.com
• Remove the four screws and compressor cover from the back of your
refrigerator.
Leveling your refrigerator
It is very important for your refrigerator to be level in order to function
properly. If your refrigerator is not leveled during installation, the door may
not close or seal properly, causing cooling, frost, or moisture problems.
1 Move your refrigerator to its final location.
2 Rotate the front leveling foot clockwise (to raise) or counter-clockwise
(to lower) your refrigerator until it is level.
Providing a proper power supply
Check your local power source. Your refrigerator requires a 110V-120V, 60 Hz
power supply.
Back of refrigerator
Compressor cover
Screws
Lower Raise
16
www.insigniaproducts.com
Your refrigerator should be properly grounded for your safety. The power
cord of this refrigerator is equipped with a three-prong plug which plugs into
a standard three-prong wall outlet to minimize the possibility of electrical
shock.
• Do not, under any circumstances, cut or remove the third ground prong
from the power cord supplied.
• Your refrigerator is not designed to be used with an inverter.
• The cord should be secured behind your refrigerator, and not left exposed
or dangling, to prevent accidental injury.
• Never unplug your refrigerator by pulling on the power cord. Always grip
the plug firmly and pull straight out from the receptacle.
Connecting to power
• Plug your refrigerator into a dedicated, properly installed grounded wall
outlet. Your refrigerator should be operated on a separate electrical circuit
from other appliances. Any questions concerning power and/or
grounding should be directed toward a certified electrician or an
authorized service center.
• Plug in and run your refrigerator for three to four hours before making any
temperature adjustments and before adding food or beverages. This
allows your refrigerator to reach a stable temperature.
WARNING: ELECTRICAL SHOCK HAZARD
Failure to follow these instructions can result in death, fire, or electrical shock.
• A 15-20 amp fused, grounded electrical supply is required. This provides the best
performance and also prevents overloading wiring circuits which could cause a
fire hazard from overheated wires.
• The refrigerator should always be connected to its own individual electrical
branch leading directly to the main voltage source or distribution panel.
• Immediately discontinue use if the main power supply line has been damaged. If
the supply line is damaged, it must be repaired by a qualified service professional.
• When removing the refrigerator away from the wall, be careful not to roll over or
damage the main power supply line.
CAUTION: Your refrigerator is not designed to be installed in an RV or used with
an inverter.
3-prong receptacle
Receptacle box cover
3-prong plug
Grounding lead
Grounding adapter
Receptacle box cover
Screw
Receptacle
Using a 3-prong plug and outlet
Using a grounding adapter
17
24 in. Outdoor Compact Refrigerator
www.insigniaproducts.com
• Do not use an extension cord with your refrigerator. If the power cord is
too short, have a qualified electrician install an outlet near your
refrigerator. Use of an extension cord can negatively affect your
refrigerator’s performance.
Using your refrigerator
Turning on your refrigerator
Your refrigerator turns on automatically the first time you plug it in. An
audible beep will be heard, then the compressor starts working.
You can manually set your refrigerator to “Standby” mode (plugged in but
power off) by pressing and holding the button for approximately three
seconds, provided that no other setting is in effect (the display is not
blinking). Press the key once to restart your refrigerator.
Setting the temperature
Under normal conditions, the display always shows the set temperature.
The default temperature setting is 43° F (6° C), and the default temperature
scale is ° F.
When the or buttons are pressed, the temperature increases or
decreases in increments of one degree.
The actual temperature inside your refrigerator can vary, based on ambient
temperature, how often the door is opened, and how much warm food and
beverages have recently been added.
Changing the temperature display
To switch the display between °F and °C, press and hold the and
buttons at the same time for approximately three to five seconds.
Lighting your refrigerator
The light can be switched on or off by pressing the button on the control
panel. Energy-efficient LEDs are used for long-term durability.
Memory function
If you experience a power outage while your refrigerator is on, when the
power is restored, your refrigerator will resume the same temperature that
was set when the power went off.
Notes:
• A large number of bottles or cans will lower the cooling efficiency of your
refrigerator.
• Adjust the thermostat setting by one increment at a time. Allow several hours
for the temperature to stabilize between adjustments.
18
www.insigniaproducts.com
Positioning beverages in your refrigerator
This refrigerator can hold a total of 114, 12 oz. (355 ml) aluminum cans. To do
this:
• Position the beverage cans vertically on the upper three shelves. The
upper three shelves can hold a total of 77 cans.
• Position 13 cans on their sides in the bottom of the main refrigerator
compartment.
• Position the beverage cans vertically in the door. This allows for 24
beverages total to be stored in the door.
Six cans
Six cans
Twelve cans
Fifty six
cans
Twenty one
cans
Thirteen
cans
19
24 in. Outdoor Compact Refrigerator
www.insigniaproducts.com
Removing a shelf
Shelves can be removed to accommodate larger containers.
1 Remove all food and beverages from the shelves.
2 Tilt one side of the shelf up as far as it will go, then gently pull out the
shelf.
Replacing a shelf
• To reinstall the shelf, make sure that it is resting securely on the support
brackets, then push inward until it clicks into place.
Maintaining your refrigerator
Your refrigerator is designed for year-round use with only minimal cleaning
and maintenance.
When you first receive it, wipe the cabinet with a mild detergent and warm
water, then wipe dry with a dry cloth. Do this periodically to keep your
refrigerator looking new.
Cleaning the interior of your refrigerator
1 Turn off your refrigerator and unplug it from the wall outlet.
2 Remove all food and beverages.
3 Wash the inside with a warm, damp cloth soaked in a solution of one
quart of lukewarm water and two tablespoons of baking soda.
CAUTION: Make sure that the tabs are firmly engaged in the supporting guides
before storing any beverage containers.
CAUTION: To prevent damage to the finish, do not use:
• Gasoline, benzine, thinner, or other similar solvents
• Ammonia or alcohol
• Abrasive cleaners
• Sharp objects or blades
20
www.insigniaproducts.com
4 Be sure to keep the door gasket (seal) clean to keep your refrigerator
running efficiently.
5 Dry the interior and exterior with a soft cloth.
Defrosting your refrigerator
Your refrigerator is equipped with an automatic defrost function and does
not require manual defrosting. Defrost water from your refrigerator is
channeled into a drip tray located above the compressor. Heat transfer from
the compressor causes the defrost water to evaporate.
Alarms
Door ajar alarm
If the door is not closed completely for five minutes, an alarm sounds. Close
the door to silence the alarm.
If the door is closed and the alarm continues to sound, make sure that the
actuator at the bottom of the door is making contact with the switch on your
refrigerator.
If the door alarm sounds when filling your refrigerator, it can be silenced by
pressing the power button once.
Temperature alarms and error codes
If the inner cabinet temperature is higher than 73° F (23° C) for one hour, the
error code "HI" shows on the display and an alarm sounds.
If the inner cabinet temperature is lower than 32° F (0° C), the error code "LO"
shows on the display and an alarm sounds.
If the inner cabinet temperature remains at 32° F (0° C) for more than 30
minutes, the error code "CL" shows on the display, an alarm sounds, and your
refrigerator turns off to prevent the contents from freezing.
Storing your refrigerator
1 Turn off your refrigerator and unplug it from the wall outlet.
2 Remove all food and beverages.
3 Clean your refrigerator.
4 Leave the door open slightly to avoid possible formation of
condensation, mold, or odor.
CAUTION: Use extreme caution with children. Your refrigerator should not be
accessible to child's play.
21
24 in. Outdoor Compact Refrigerator
www.insigniaproducts.com
Moving your refrigerator
1 Turn off your refrigerator and unplug it from the wall outlet.
2 Remove all food and beverages.
3 Securely tape down all loose items inside your refrigerator.
4 Turn the leveling foot up to avoid damage.
5 Tape the door shut.
6 Protect the outside of your refrigerator with a blanket or similar item.
7 To avoid damage to the power cord, put the cord on top of the
refrigerator.
8 Make sure that your refrigerator stays in the upright position during
transportation.
If that is not possible and your refrigerator must be placed on its back
or side during transportation, upon reaching the destination allow it
to remain upright for six hours before plugging it in to avoid damage
to internal components.
Power failure
Most power failures are corrected within a few hours and should not affect
the temperature of your appliance, if you minimize the number of times the
door is opened. If the power is going to be off for a longer period of time, take
the proper steps to protect the contents of your refrigerator.
Disposal
Your refrigerator should not be treated as regular household waste. It should
be taken to an appropriate waste collection point for recycling of electrical
components. For information on local waste collection points, contact your
local waste removal agency or government office.
Tips on saving energy
• Locate your refrigerator in the coolest area of the room, away from heat
producing appliances or heating ducts and out of direct sunlight.
• Overloading your refrigerator forces the compressor to run longer.
• Do not open the door too often, especially if the weather is very hot. Close
the door as soon as possible to prevent cool air from escaping.
• Make sure that your refrigerator is sufficiently ventilated, with adequate
air circulation behind it.
• If your refrigerator is not being used, turn it off.
• If your refrigerator is outside, place it out of direct sunlight so the cooling
element doesn't have to fight against the sun to stay cold.
Note: Wait three to five minutes before attempting to restart the
appliance if operation has been interrupted.
22
www.insigniaproducts.com
Troubleshooting
Error codes
If the “HI”, “LO”, or “CL” error codes appear on the display for more than five
minutes, a power reset may rectify the issue (see Temperature alarms and
error codes on page 20). Unplug your refrigerator, wait five minutes, then
plug it back in. If the error code persists, contact consumer care or an
authorized service agent.
CAUTION: Do not try to repair your refrigerator yourself. Doing so invalidates
the warranty.
PROBLEM SOLUTION
Your refrigerator does not
operate.
• Make sure that your refrigerator is plugged in and that
the plug is pushed completely into the outlet.
• Check the house fuse/circuit breaker box and replace
the fuse or reset the circuit breaker.
• If a power failure occurs, your refrigerator turns off.
Wait until the power is restored, then turn it on again.
• The refrigerator is in standby mode. Press the
(power) key once to restart your refrigerator.
Your refrigerator door does not
close completely.
• Adjust the shelf properly.
• Clean the door gaskets.
• Level your refrigerator with the leveling feet.
Your refrigerator is not cold
enough.
• Make sure that the door is closed properly.
• Allow time for new beverages to cool, then check
again.
• Set the control to a colder setting.
Your refrigerator makes
unusual noises or vibrates.
• Level your refrigerator with the leveling feet.
• Move your refrigerator out from the wall.
• This is normal.
Moisture is building up on the
interior walls and door of your
refrigerator.
• Make sure that the door is closed properly.
• Door is left open too long or opened too frequently.
Moisture is building up on the
exterior of your refrigerator.
• Make sure that the door is closed properly. Cold air
from inside your refrigerator may be leaking.
• Make sure that the door and gasket are properly
aligned.
• Weather is hot and humid (this is normal).
• Move your refrigerator to a dryer location.
Your refrigerator turns on and
off frequently.
• Cool the room or move your refrigerator to a cooler
location.
• Make sure that the door is closed properly.
• Clean the door gaskets.
• Set the control to a colder setting.
The display shows an error
code and an alarm sounds.
• See Temperature alarms and error codes
on page 20.
23
24 in. Outdoor Compact Refrigerator
www.insigniaproducts.com
Specifications
Dimensions (HxWxD) 34.1 × 23.8 × 23.6 in. (86.7 × 60.5 × 60 cm)
Net Weight 94 lbs. (43 kg)
Capacity 90 standard (12 oz. [355 ml]) beverage cans
Power requirements 115V~60 Hz
Current 1.2A
Operating temperature 34° F to 50° F (1° C to 10° C)
Refrigerant type R600a
Humidity level in your
refrigerator (normal)
50% - 80%
Noise (Db) level 42
Annual energy cost $33.00 dollars
Cord length 70.8 in. (180 cm)
24
www.insigniaproducts.com
ONE-YEAR LIMITED WARRANTY
Definitions:
The Distributor* of Insignia branded products warrants to you, the original purchaser of this new
Insignia-branded product (“Product”), that the Product shall be free of defects in the original
manufacturer of the material or workmanship for a period of one (1) year from the date of your
purchase of the Product (“Warranty Period”).
For this warranty to apply, your Product must be purchased in the United States or Canada from a
Best Buy branded retail store or online at www.bestbuy.com
or www.bestbuy.ca and is packaged
with this warranty statement.
How long does the coverage last?
The Warranty Period lasts for 1 year (365 days) from the date you purchased the Product. Your
purchase date is printed on the receipt you received with the Product.
What does this warranty cover?
During the Warranty Period, if the original manufacture of the material or workmanship of the
Product is determined to be defective by an authorized Insignia repair center or store personnel,
Insignia will (at its sole option): (1) repair the Product with new or rebuilt parts; or (2) replace the
Product at no charge with new or rebuilt comparable products or parts. Products and parts replaced
under this warranty become the property of Insignia and are not returned to you. If service of
Products or parts are required after the Warranty Period expires, you must pay all labor and parts
charges. This warranty lasts as long as you own your Insignia Product during the Warranty Period.
Warranty coverage terminates if you sell or otherwise transfer the Product.
How to obtain warranty service?
If you purchased the Product at a Best Buy retail store location or from a Best Buy online website
(www.bestbuy.com or www.bestbuy.ca), please take your original receipt and the Product to any
Best Buy store. Make sure that you place the Product in its original packaging or packaging that
provides the same amount of protection as the original packaging.
To obtain warranty service, in the United States and Canada call 1-877-467-4289. Call agents may
diagnose and correct the issue over the phone.
Where is the warranty valid?
This warranty is valid only in the United States and Canada at Best Buy branded retail stores or
websites to the original purchaser of the product in the country where the original purchase was
made.
What does the warranty not cover?
This warranty does not cover:
• Food, beverage, and or medicine loss/spoilage.
• Customer instruction/education
•Installation
•Set up adjustments
• Cosmetic damage
• Damage due to weather, lightning, and other acts of God, such as power surges
• Accidental damage
•Misuse
•Abuse
•Negligence
• Commercial purposes/use, including but not limited to use in a place of business or in
communal areas of a multiple dwelling condominium or apartment complex, or otherwise used
in a place of other than a private home.
• Modification of any part of the Product, including the antenna
• Display panel damaged by static (non-moving) images applied for lengthy periods (burn-in).
• Damage due to incorrect operation or maintenance
25
24 in. Outdoor Compact Refrigerator
www.insigniaproducts.com
• Connection to an incorrect voltage or power supply
• Attempted repair by any person not authorized by Insignia to service the Product
• Products sold “as is” or “with all faults”
• Consumables, including but not limited to batteries (i.e. AA, AAA, C etc.)
• Products where the factory applied serial number has been altered or removed
• Loss or Theft of this product or any part of the product
• Display panels containing up to three (3) pixel failures (dots that are dark or incorrectly
illuminated) grouped in an area smaller than one tenth (1/10) of the display size or up to five (5)
pixel failures throughout the display. (Pixel based displays may contain a limited number of
pixels that may not function normally.)
• Failures or Damage caused by any contact including but not limited to liquids, gels or pastes.
REPAIR REPLACEMENT AS PROVIDED UNDER THIS WARRANTY IS YOUR EXCLUSIVE REMEDY FOR
BREACH OF WARRANTY. INSIGNIA SHALL NOT BE LIABLE FOR ANY INCIDENTAL OR CONSEQUENTIAL
DAMAGES FOR THE BREACH OF ANY EXPRESS OR IMPLIED WARRANTY ON THIS PRODUCT,
INCLUDING, BUT NOT LIMITED TO, LOST DATA, LOSS OF USE OF YOUR PRODUCT, LOST BUSINESS OR
LOST PROFITS. INSIGNIA PRODUCTS MAKES NO OTHER EXPRESS WARRANTIES WITH RESPECT TO
THE PRODUCT, ALL EXPRESS AND IMPLIED WARRANTIES FOR THE PRODUCT, INCLUDING BUT NOT
LIMITED TO ANY IMPLIED WARRANTIES OF AND CONDITIONS OF MERCHANTABILITY AND FITNESS
FOR A PARTICULAR PURPOSE, ARE LIMITED IN DURATION TO THE WARRANTY PERIOD SET FORTH
ABOVE AND NO WARRANTIES, WHETHER EXPRESS OR IMPLIED, WILL APPLY AFTER THE WARRANTY
PERIOD. SOME STATES, PROVINCES AND JURISDICTIONS DO NOT ALLOW LIMITATIONS ON HOW
LONG AN IMPLIED WARRANTY LASTS, SO THE ABOVE LIMITATION MAY NOT APPLY TO YOU. THIS
WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS, AND YOU MAY ALSO HAVE OTHER RIGHTS, WHICH
VARY FROM STATE TO STATE OR PROVINCE TO PROVINCE.
Contact Insignia:
1-877-467-4289
www.insigniaproducts.com
INSIGNIA is a trademark of Best Buy and its affiliated companies.
*Distributed by Best Buy Purchasing, LLC
7601 Penn Ave South, Richfield, MN 55423 U.S.A
©2022 Best Buy. All rights reserved.
www.insigniaproducts.com
1-877-467-4289 (U.S. and Canada)
INSIGNIA is a trademark of Best Buy and its affiliated companies.
Distributed by Best Buy Purchasing, LLC
7601 Penn Ave South, Richfield, MN 55423 U.S.A
©2022 Best Buy. All rights reserved.
V2 ENGLISH
22-0136
