健康氣炸
烤焗爐
TL2-AC25GZC(GR)
請在操作前仔細檢查本說明書。
TL2-AC25GZC(GR)
請在操作前仔細檢查本說明書。
使用說明書
內容
重要保障措施
基本安全防範措施
.............................................................................................................................................
注意
放置注意
...............................................................................................................................................
操作
如何使用
..........................................................................................................................................
01
04
07
安全防範措施
使用注意事項
.......................................................................................................................................
02
保養注意事項
.......................................................................................................................................
02
清潔保養注意事項
..............................................................................................................................
03
首次使用
............................................................................................................................................
06
產品說明
結構/配件說明
......................................................................................................................................
05
關於烤架放置位置
.............................................................................................................................
08
控制面板
...............................................................................................................................................
08
功能操作步驟
使用過程
...............................................................................................................................................
09
氣炸自動功能操作
.............................................................................................................................
09
氣炸自動功能示意圖
.......................................................................................................................
10
控制面板-主要功能操作
..................................................................................................................
12
上下管烤焗
薄餅
曲奇
貝果
翻熱
保溫
發酵
慢煮
...............................................................................................................................................
..........................................................................................................................................................
...............................................................................................................................................................
...........................................................................................................................................................
..........................................................................................................................................................
..........................................................................................................................................................
..........................................................................................................................................................
..................................................................................................................................................................
..................................................................................................................................................................
15
16
17
18
18
19
20
20
21風乾
..................................................................................................................................................................
21靜音
氣炸
多士
下管烤焗
上管烤焗
......................................................................................................................................................
.....................................................................................................................................................
..............................................................................................................................................
....................................................................................................................................................
13
13
14
15
清潔與維護
清潔注意事項
...........................................................................................................................................
22
產品規格
..................................................................................................................................................
22
故障排除
....................................................................................................................................................
23
請仔細閱讀並妥善保存，供以後参考
使用過程中表面容易發熱。
當設備不使用時，在打開或拆
卸部件之前，以及在清潔之前，
從插座上拆卸插頭。在遞送之
前允許冷卻。
使用其他金屬或玻璃製成的容
器時，應格外小心。
不要在烤箱中放置以下任何
材料：紙、紙板、塑料等。
不使用時，請勿在此烤箱內存
放任何材料，除廠家推薦的附
件外。
本裝置適用於家用和類似的
應用，如：
-商店、辦公室和其他工作
環境中的員工廚房區域；
-由客戶在酒店、汽車旅館
和其他居住類型的環境；
-農舍；
-床和早餐類型的環境。
重要保障措施
在使用電器時，應始終遵循基本的安全預防措施，包括：
本用具不適用於身體、感官或
智力能力下降或缺乏經驗和知
識的人（包括兒童），除非他
們已由負責其安全的人就用具
的使用給予監督或指導。
孩子們應該受到監督，以確保
他們不玩器具。
如果電源線損壞，必須由製造
商、其服務代理或具有類似資
質的公司更換。
人們為了避免危險。
警告：確保電器斷開觸電。
這些設備不能通過外部定時
器或單獨的遙控器來操作-
控制系統。
當設備運行時，可接觸表面
的溫度可能很高。
易接近的部件在使用過程中
可能會變熱。幼兒應遠離。
該設備打算獨立使用。
01
避免接觸運動部件。
基本安全防範措施
烤箱在工作過程中或剛使用時，完成後表面溫度較高，請勿觸摸。
小心開門
如果產品的門或門封損壞，必須經東芝的維修人員修理後方可再次使用。
高溫表面防止燒傷
產品在使用過程中會發熱。注意避免接觸產品中的加熱單元。
使用時，可觸及部分可能很熱，兒童應遠離。標有“ 熱表面”在表面，
在使用過程中會變熱。
拿取食物請小心，器皿不要碰撞腔體、門體玻璃
加熱液態食物時，容器要留出足夠的空間，防止液體沸騰。
移動或清洗電烤箱時，應先拔掉電源線插頭，待烤箱冷卻後再進行。
定期清潔烤箱，防止油脂着火。
擺放在小孩觸摸不到的地方
只有在已經提供充分的指導，以致於兒童能夠採用安全的方法使用產品，並且
明白不正確的使用會造成危險時，才能允許兒童在無人監控的情況下使用產品。
不要使用蒸氣清潔劑。
安全防範措施
Note
保養注意事項
內有高壓電源，切勿拆開外罩，進行修理和改造
對於合格的維護以外的任何人來說都是危險的人員執行維護操作。如果您在
使用過程中遇到任何障礙，請與我們的服務中心聯繫。
嚴禁非專業人員拆卸和修理本產品，否則可能導致危險
如果門或門封條損壞，在由合格的修理工修理之前不要再使用。
如果電源線損壞，必須由製造商、其維修部門或類似部門的專業
人員更換，以避免危險。
●
●
●
●
使用注意事項
●
●
●
●
●
●
●
●
02
清潔保養注意事項
可以蘸一種軟性洗滌劑（如洗碗精）布擦拭外殼，再用濕布擦拭乾
凈，最後用乾布擦乾，嚴禁使用鋼絲刷等硬物擦拭產品。不要清潔
爐門安全鎖系統
不要用粗糙的磨料清潔劑或鋒利的金屬刮刀清潔門玻璃，以免造成門玻璃
表面刮傷，刮傷後可能導致玻璃破碎。
經常保持爐門與爐身接合處清潔。
烹飪過程中產生的油脂會腐蝕爐腔，影響加熱效果，從而改變食物的口感。因
此，使用後請及時清理爐腔。
經常用溫水清洗配件。注意在長期烹飪後，不要用冷水立即清潔。
請勿使用不良洗滌劑及帶有腐蝕性、揮發性的化學溶劑清洗爐身，以免爐身損
壞了。
●
●
●
●
●
03
放置注意
1.
把烤箱放在一個平坦的、絕緣的表面上，離烤箱至少10-15厘米
2. 電烤箱應放置在乾燥的環境中，請勿在戶外使用本產品
3. 為避免產品中的油煙污染 或發熱引起火災，產品應與牆壁、櫥櫃保持一
定距離。
4. 為避免烹調過程中，排氣口排出的油、煙、蒸氣等污染傢俱，甚至過熱引起
火災。焗爐要和牆壁、櫥櫃保留一定距離。
牆
烤箱背面有安全屏障組件，防止烤箱與
牆壁等物體接觸，保持安全距離。
後方空間≥1cm
注意: 產品頂面、背面和
玻璃門等表面高溫
上方空間≥5cm
左右方空間≥1cm
開放空間
後方空間≥1cm
烤箱
示意圖
安全注意事項
注意
04
傢俱
05
用於氣炸模式
烤盤
取物夾
說明書
炸籃
烤架
置於發熱管下方，
用於接屑
（放置時，請將凸面向上）
屑盤
注意
由於產品是不斷更新的，如實物與圖片不符，請以實物為準。
散熱孔
旋鈕
爐門
門柄
顯示屏
電源線
爐腳
用於取烤盤與烤架
結構說明
使用說明
產品說明書
附件說明
凹面
凸面
首次使用
空燒提示：
首次使用前先燒空15分鐘，以便去除發熱管和爐內中的防腐保護層。
操作方法：
在斷電狀態下，用濕布擦拭烤箱一次（不要擦拭發熱管）。
將屑盤放在發熱管下面，烤架、烤盤、炸籃放入烤箱中，插上電源。
使用“上下管烤焗”功能，並將溫度調至最高溫度，空燒15分鐘。
注意事項：空燒時有異味或冒煙是正常現象。
空燒結束：拔掉電源線，打開爐門快速散熱。烤箱完全冷卻後，取下烤盤和烤架正常使用。
1
烤架
炸籃
第三層
第二層
第一層
烤盤
屑盤
3
2
1
确定
开始
06
2
3
操作
說明
將烤架/烤盤放在適合擺放食物的位置。
食物必須放在烤架/烤盤上，以避免因食物碎屑積聚
在加熱元件上而引起的火災。
確保你在烤箱中始終使用適合的烤箱用具，切勿在
烤箱中使用塑料或紙製用具。
保持發熱器的乾淨。
4
勿使用玻璃或陶瓷平底鍋或蓋子。
不要讓果汁或油滴到烤箱底部。烹飪時使用屑盤。
按食譜建議或所需設置溫度。
在開始操作烤箱之前，請關好門並設定烹飪時間。
注意事項
烤箱表面在使用過程中和使用後都是熱的。
當燒烤/烘焙時，請將烤架放在合適的水平上。
當烤箱工作完畢時，請不要拔掉電源線。風扇會保持運轉1分鐘。
如何使用
07
1
2
3
4
5
6
4
7
8
9
當烤箱通電時，蜂鳴器會響一次。默認功能是氣炸。
在烹飪的過程中，可以按“ ”暫停烹飪。
08
控制面板
熱風對流 時間/溫度
爐內燈
確定/開始/暫停旋鈕
返回/
取消/
靜音
氣炸自動功能
烤架有三種擺放方式，擺放在不同的烘烤層，適合烘烤不同的食物。
1. 第1層的機架凹面，
適合烤嫩雞肉。
2. 第2層的架子凹面，
適合烤吐司。
3. 第3層的架子凸面，
適合用黑胡椒烤牛排。
關於烤架放置位置
旋轉“ ”旋鈕，你可以在自動功能中A01-A11中，選擇所需功能。
默認功能是A01（急凍炸薯條）。
按一次“ ”鍵，就會進入氣炸自動功能。
“AIR FRY”、“A01”和“ ”將顯示在顯示屏上。
按下“ ”，旋轉“ ”來調節溫度。A01的默認溫度為
200°C。這是預熱後的烹調溫度。
1. 使用烤盤時，在食物下面放置錫紙或烘培紙，以便清潔。
2. 烘焙時，請安裝屑盤。
3. 烤箱採用間歇加熱原理工作，工作過程中，發熱管突然亮起，突然熄滅，
屬於正常現象。
4. 機器在工作時或工作後，機身、玻璃、烤架、烤盤溫度較高，請勿直接觸摸。
5. 使用錫紙時，請勿接觸發熱管。以免錫紙溶解，粘在發熱管上，可能造成故
障。
6.
食材烘烤後容易收縮、變形或出油。 在烤架上烹飪時，建議將烤盤放在第1
層，用於盛接食物油渣。
7. 取出零件和食物，請注意防燙。
8. 烘烤時，爐門周圍有輕微的蒸氣，是正常現象。
注意
功能說明書
09
使用過程
氣炸自動功能
按下“ ”，旋轉“ ”設置烹飪時間。 A01的默認
烹飪時間是18分鐘。這是預熱後的烹調時間。
4
1
2
3
4
你可以按下“ ”，旋轉“ ”來調節溫度以及烹飪
過程中的時間。
按“ ”進行預熱。(A01/A11不需要預熱）
預熱後，將食物放入烤箱，關上門。 按“ ”鍵開始
烹飪。 （如果選擇A01，將炸薯條放入氣炸籃。 建議
使用默認溫度和烹飪時間，亦可以開始烹調後，調整烹調
的溫度和時間。如果選擇A04，蜂鳴器會在還剩10min的時
候鳴響3次提醒你翻身。）
10
A01
急凍炸薯條
氣炸自動功能示意圖
A03
急凍炸雞塊
A04
急凍雞腿
A02
雞翼
A05
鱈魚片
A06
炸魚柳
A07
炸魷魚圈
A08
炸芝士薯條
A09
蔬菜
A10
炸薯角
A11
春卷
5
6
4
7
11
功能
功能名稱
數量/重量
預熱 預設溫度 預設時間 可選擇溫度
放置位置
A01
急凍炸薯條 350g
X 200°C 18分鐘 100°C-200°C
A02
雞翼
A03
急凍炸雞塊 560g
V 200°C 17分鐘 100°C-200°C
A04
急凍雞腿 6 隻/876g
V
500g
V 200°C 10分鐘 100°C-200°C
190°C 25分鐘 100°C-200°C
A05
鱈魚片 2 塊
V 200°C 10分鐘 100°C-200°C
A06
炸魚柳 8 塊
V 200°C 14.5分鐘 100°C-200°C
A07
炸魷魚圈 16 個
V 200°C 11分鐘 100°C-200°C
A08
炸芝士薯條 平鋪
V 200°C 10分鐘 100°C-200°C
A09
蔬菜 平鋪
V 180°C 5分鐘 100°C-200°C
A10
炸薯角 平鋪
V 200°C 11分鐘 100°C-200°C
A11
春卷 15 個
X 200°C 16分鐘 100°C-200°C
炸籃+凸烤架 2層；
1層
炸籃+凸烤架 2層；
層
炸籃+凸烤架 2層；
層
炸籃+凹烤架 2層；
層
烤盤 2層
炸籃+凸烤架 2層
炸籃+凸烤架 2層
炸籃+凸烤架 2層
烤盤 3層
炸籃+凸烤架 2層
炸籃+凸烤架 2層；
層
炸籃+凸烤架 2層；
1層
炸籃+凹烤架 2層；
可選擇時間
1-30分鐘
1-30分鐘
1-30分鐘
1-30分鐘
1-30分鐘
1-30分鐘
1-30分鐘
1-30分鐘
1-30分鐘
1-30分鐘
1-30分鐘
2
1
3
2
1
3
2
1
3
3層
2
1
3
炸籃+凸烤架 2層
炸籃+凸烤架
烤盤
1
烤盤
1
烤盤
1
烤盤
1
烤盤
烤盤 1層烤盤
控制面板-主要功能操作
功能名稱
風扇選擇
預熱
預設溫度
預設時間
適用於
氣炸
NA V
200°C
15 分鐘
下管
烤焗
按 開始
X
175°C
25 分鐘
上管
烤焗
X
多士
上下管
烤焗
X
曲奇
NA V 190°C 10
分鐘
100-200°C
70-180°C
可選擇溫度
任何需要氣炸食物，可選擇
合適的溫度及時間
NA X
4 片(230°C
)
程度:4(4分
鐘50秒)
1-6 片
適合烤製1-6片多士，7種酥
脆程度可供選擇
適合烤焗多種類食物，特別
是酥皮點心，可選擇開啟風
扇
適合烤製薄切肉類和魚類，
也適合為麵包和砂鍋菜表面
增加金黃，可選擇開啟風扇
175
°C
10 分鐘
70-180°C
適合烤製各種肉類，可選擇
開啟風扇
175°C
10 分鐘
70-230 °C
薄餅
V
適合新鮮或冷凍薄餅焗製，
可選擇開啟風扇
9 寸
（165°C ）
9 寸：
11.5 分鐘
6/9/12 寸
（70-230°C）
適合烤任何類型的曲奇餅
70-230°C
貝果
NA
X
程度:4
程度:4
(4分鐘15秒)
適合烤任何類型的貝果
程度: 2/4/6
翻熱
X
175°C
3分鐘
70-230°C
適合快速加熱食物
保溫
X
80°C
60分鐘
35-150°C
保溫模式下，上下管恆定溫
度使食物保持在最佳食用溫
度
NA
發酵
X
35°C
50分鐘
25-45°C
保溫模式下，上下管恆定溫
度發酵麵包或牛奶
NA
慢煮
X
適合燉煮肉類至軟爛
100°C
60分鐘
35-110°C
NA
風乾 X
適合製作乾果等食物
70°C
4小時
35-100°C
NA
12
1-30 分鐘
1-120 分鐘
可選擇時間
程度: 1-7
1-120 分鐘
1-120 分鐘
1-30 分鐘
1-120
分鐘
程度: -6
(1-30 分鐘)
1-20 分鐘
1分鐘 -
4小時
1分鐘 -
9小時
1分鐘 -
8小時
1分鐘 -
24小時
按 開始
按 開始
按
按 開始
3
關 閉
多士
將“ ”旋鈕向右旋轉1次。顯示屏顯示“TOAST”和“ ”。
烤箱將進入吐司功能。
按下“ ”旋轉“ ”選擇多士片數。
默認的數量是4片。
按下“ ”旋轉“ ”選擇烤多士的程度。默認的
程度是
等級4。
13
氣炸
通電進入待機狀態，默認功能為氣炸。 顯示屏顯示“AIR FRY”和“ ”
按下“ ”，旋轉“ ”來調節溫度。默認溫度為
200°C。這是預熱後的烹調溫度。
按下“ ”，旋轉“ ”來調節時間。默認時間為
15分鐘。這是預熱後的烹調時間。
按“ ”進行預熱。
預熱後，將食物放入烤箱，關上門。 按“ ”鍵開始
烹飪。
你可以按下“ ”，旋轉“ ”來調節溫度以及烹飪
過程中的時間。
烹飪結束後，機器會發出3次嗶嗶聲，顯示屏顯示"End"。取出食物時，
請小心焗爐及食物的高溫，以免燙傷。
4
1
2
3
4
5
6
4
7
1
2
3
下管烤焗
烹飪結束後，機器會發出3次嗶嗶聲，顯示屏顯示"End"。
取出食物時，請小心焗爐及食物的高溫，以免燙傷。
按下“ ”，旋轉“ ”來調節溫度。默認溫度為
175°C。這是預熱後的烹調溫度。
14
將“ ”旋鈕向右旋轉2次。顯示屏顯示“BAKE”和“ ”
風扇關閉（默認）。您可以選擇開啟風扇“ ”，之後顯示屏顯示
“ BAKE ”和“ ”。
按“ ”開始烹飪。 默認溫度/烹飪時間為230°C/4mins50s，
烹飪過程中溫度和時間不能調節。
烹飪結束後，機器會發出3次嗶嗶聲，顯示屏顯示"
End"。取出食物時，
請小心焗爐及食物的高溫，以免燙傷。
按下“ ”，旋轉“ ”來調節時間。默認時間為
25分鐘。這是預熱後的烹調時間。
按“ ”開始烹飪。
在烹飪過程中，按“ ”和“ ”，便以調節溫度
和烹飪時間。
4
4
5
4
1
2
3
4
5
6
上管烤焗
上下管烤焗
15
按下“ ”，旋轉“ ”來調節溫度。默認溫度為
175°C。這是預熱後的烹調溫度。
按下“ ”，旋轉“ ”來調節溫度。默認溫度為
175°C。這是預熱後的烹調溫度。
將“ ”旋鈕向右旋轉3次。顯示屏顯示“BROIL”和“ ”
風扇關閉（默認）。您可以選擇開啟風扇“ ”，之後顯示屏顯示
“BROIL ”和“ ”。
將“ ”旋鈕向右旋轉4次。顯示屏顯示“ROAST”和“ ”
風扇關閉（默認）。您可以選擇開啟風扇“ ”，之後顯示屏
顯示“ROAST ”和“ ”。
烹飪結束後，機器會發出3次嗶嗶聲，顯示屏顯示"End"。取出食物時，
請小心焗爐及食物的高溫，以免燙傷。
按下“ ”，旋轉“ ”來調節時間。默認時間為
10分鐘。這是預熱後的烹調時間。
按“ ”開始烹飪。
在烹飪過程中，按“ ”和“ ”，便以調節溫度
和烹飪時間。
4
1
2
3
4
5
6
1
2
16
薄餅
烹飪結束後，機器會發出3次嗶嗶聲，顯示屏顯示"End"。取出食物時，
請小心焗爐及食物的高溫，以免燙傷。
按下“ ”，旋轉“ ”來調節時間。默認時間為
10分鐘。這是預熱後的烹調時間。
按“ ”開始烹飪。
將“ ”旋鈕向右旋轉5次。顯示屏顯示“
在烹飪過程中，按“ ”和“ ”，便以調節溫度
和烹飪時間。
按下“ ”，旋轉“ ”來設置薄餅的大小（6英寸，
9英寸和12英寸）。默認尺寸為9英寸。
按下“ ”，旋轉“ ”來調節時間，然後時間閃爍。
9英寸默認時間為11分30秒。
按下“ ”，旋轉“ ”來調節溫度。默認溫度為
165°C（9英寸）
4
3
4
5
6
4
1
2
3
4
PIZZA ”
和“ ”
風扇 （默認）。
打開
。
，
將“ ”旋鈕向右旋轉6次。顯示屏顯示“COOKIES”和“ ”。
顯示屏顯示“COOKIES”。
按下“ ”，旋轉“ ”來調節溫度。默認溫度為
190°C。
按“ ”開始預熱， 閃爍。
預熱後，把食物放進去，關上烤箱門。按“ ”開始烹飪。
曲奇
17
按“ ”開始預熱， 閃爍。
按下“ ”，旋轉“ ”來調節時間。默認時間為
10分鐘。
預熱後，把食物放進去，關上烤箱門。按“ ”開始烹飪。
在烹飪過程中，按“ ”和“ ”，便以調節溫度
和烹飪時間。
烹飪結束後，機器會發出3次嗶嗶聲，顯示屏顯示"End"。取出食物時，
請小心焗爐及食物的高溫，以免燙傷。
5
6
4
7
4
8
4
1
2
3
4
5
18
將“ ”旋鈕向右旋轉7次。顯示屏顯示“BAGEL”和“ ”。
顯示屏顯示“BAGEL”。
按下 按鈕，旋轉 來設置數量（2,4和6）。
默認值為4個。
將“ ”旋鈕向右旋轉8次。顯示屏顯示“REHEAT”和“ ”
風扇關閉（默認）。您可以選擇開啟風扇“ ”，之後顯示屏
顯示“REHEAT”和“ ”。
按下“ ”，旋轉“ ”來調節溫度。默認溫度為
175°C。
烹飪結束後，機器會發出3次嗶嗶聲，顯示屏顯示"End"。取出食物時，
請小心焗爐及食物的高溫，以免燙傷。
翻熱
貝果
按下 ，旋轉 來設置烤焗程度。 默認烤焗程度為4。
按“ ”開始烹飪。默認溫度/時間為200°C/4分鐘15秒。
烹調時間可調，溫度不可調。
烹飪結束後，機器會發出3次嗶嗶聲，顯示屏顯示"End"。取出食物時，
請小心焗爐及食物的高溫，以免燙傷。
在烹飪過程中，按“ ”和“ ”，便以調節溫度
和烹飪時間。
6
4
7
4
1
2
3
4
5
1
2
19
按“ ”開始烹飪。
烹飪結束後，機器會發出3次嗶嗶聲，顯示屏顯示"End"。取出食物時，
請小心焗爐及食物的高溫，以免燙傷。
烹飪結束後，機器會發出3次嗶嗶聲，顯示屏顯示"End"。取出食物時，
請小心焗爐及食物的高溫，以免燙傷。
按下“ ”，旋轉“ ”來調節溫度。默認溫度為
80°C。
按“ ”開始烹飪。
保溫
將“ ”旋鈕向右旋轉9次。顯示屏顯示“WARM”和“ ”。
顯示屏顯示“WARM”。
按下“ ”，旋轉“ ”來調節時間。默認時間為
3分鐘。
在烹飪過程中，按“ ”和“ ”，便以調節溫度
和烹飪時間。
在烹飪過程中，按“ ”和“ ”，便以調節溫度
和烹飪時間。
按下“ ”，旋轉“ ”來調節時間。默認時間為
1小時。
4
3
4
5
6
4
1
2
3
4
5
6
20
烹飪結束後，機器會發出3次嗶嗶聲，顯示屏顯示"End"。取出食物時，
請小心焗爐及食物的高溫，以免燙傷。
按“ ”開始烹飪。
將“ ”旋鈕向右旋轉10次。顯示屏顯示“PROOF”和“ ”。
顯示屏顯示“PROOF”。
按下“ ”，旋轉“ ”來調節溫度。默認溫度為
35°C。
將“ ”旋鈕向右旋轉11次。顯示屏顯示“SLOW COOK”和“ ”。
顯示屏顯示“SLOW COOK”。
發酵
慢煮
在烹飪過程中，按“ ”和“ ”，便以調節溫度
和烹飪時間。
按下“ ”，旋轉“ ”來調節時間。默認時間為
1小時。
按下“ ”，旋轉“ ”來調節時間。
默認時間為
50分鐘。
按下“ ”，旋轉“ ”來調節溫度。默認溫度為
100°C。
4
1
2
3
4
5
6
1
2
3
21
按“ ”開始烹飪。
烹飪結束後，機器會發出3次嗶嗶聲，顯示屏顯示"End"。取出食物時，
請小心焗爐及食物的高溫，以免燙傷。
烹飪結束後，機器會發出3次嗶嗶聲，顯示屏顯示"End"。取出食物時，
請小心焗爐及食物的高溫，以免燙傷。
按“ ”開始烹飪。
將“ ”旋鈕向右旋轉12次。顯示屏顯示“DEHYDRATE”和“ ”。
顯示屏顯示“DEHYDRATE”。
按下“ ”，旋轉“ ”來調節溫度。默認溫度為
70°C。
風乾
靜音
當你想讓烤箱靜音時，長按“ ”3秒。顯示屏顯示“ ”。這時機器將處於靜音
功能。長按“ ”3秒，靜音功能將被取消。顯示屏顯示“ ”。
在烹飪過程中，按“ ”和“ ”，便以調節溫度
和烹飪時間。
在烹飪過程中，按“ ”和“ ”，便以調節溫度
和烹飪時間。
按下“ ”，旋轉“ ”來調節時間。默認時間為
4小時。
4
4
5
6
4
1
2
3
4
5
6
oFF
on
清潔前，拔掉插頭，等待電烤箱完全冷卻後再進行
用中性清潔劑清潔所有附件，包括烤架、烤盤和屑
盤，清潔後讓其徹底乾燥。
1
2
3 用含有中性清潔劑的軟濕布擦拭電烤箱內部，再用
擰乾的布等擦掉洗滌劑成分。
1. 不要使用鋒利的清潔工具、刷毛、鋼絲刷和腐蝕性清潔用品，以免損壞機身和附件。
2. 請勿將電烤箱浸入水或其他液體中，以防損壞烤箱。
3. 請務必等到機身冷卻後再清洗保養。
4. 平時請保持屑盤整潔，以免在污垢或碎屑殘留的狀態下使用時導致起火或火災。
5. 清潔保養後請勿忘記安裝屑盤，以免導致放置本品的位置受熱過度引起焦糊。
6. 切勿將食材或污物留在爐內，以防起火或引起火災。
7. 烘烤時，油煙會引起面板顏色輕微發黃，屬於正常現象。
8. 請勿使用清潔劑、刷子、水或汽油清潔產品。
清潔注意事項
注意
清潔與維護
22
其他提示
產品規格
名稱
TL2-AC25GZC(GR)
容量 25L
電壓
交流頻率 50/60Hz
動力 1500-1600W
待機模式
在待機模式下：
1. 如果烤箱閑置5分鐘，整個顯示屏將關閉。
2. 按“ ”。
回到待機模式:扭“ ”或者輕觸任何按鈕。
選擇過程
在功能選擇過程中，如果烤箱閑置5分鐘，選擇過程將被取消，顯示屏將顯示“00:00”。
220-230V~
如果在使用過程中出現異常，請在送修前仔細閱讀本說明書，並檢查是否由以下
原因引起。
總結：
1. 不得擅自拆卸、修理、修改。
2. 如故障仍無法整改，請及時與售後服務聯繫。
常見故障
旋轉定時旋鈕後，發熱管不亮
煙或氣味
黃斑或燒焦的殘渣
原因 解決方案
電源插頭插不牢插座
請將電源插頭牢牢插入插座。
請清理屑盤。
請清理屑盤。
請安裝芯片托盤。
第一次使用時一定要空燒。反覆使用後有
時會有異味，殘留物將被消除。
爐內溫度升高時，恆溫器開始運行，可能
導致發熱管不亮。
連續烹飪，導致爐內溫度過高
板材燃燒時的粘渣現象碎片或污物
屑盤安裝不到位
第一次使用時沒有空燒
附在渣盤上的碎屑和污物正在燃燒
不需要任何操作。
不需要任何操作。
定時器是彈簧，所以有時會出錯
中間烤不透
烘烤時外面燒焦了
定時器誤差
計時器未運行
設置在10以下，請先轉到多於10分鐘後再
轉回來。
當計時器設置為小於10分鐘時，計
時器有時不正常運行
烘烤時發熱管燈不亮或時而亮時而滅
恆溫器，正在調節烘烤溫度
烤的時候請想辦法切開，切成小塊等。
請延長烘烤時間。
烘烤時間太短
請縮短烘烤時間。
烘烤時間過長
這是很難烤的東西穿過中間
故障排除
23
HEALTHY AIR FRY
TL2-AC25GZC(GR)
Please review this instruction
manual before operating.
USER MANUAL
TOASTER OVEN
TL2-AC25GZC(GR)
Please review this instruction
manual before operating.
TOASTER OVEN
CONTENTS
IMPORTANT SAFEGUARDS
Basic safety precautions ......................................................................................................................................
ATTENTION
Attention in placement
......................................................................................................................
OPERATION
How to use
.....................................................................................................................................
01
05
08
SAFETY PRECAUTIONS
Precautions for use
.............................................................................................................................
03
Maintenance matters needing attention
.........................................................................................
04
Precautions for cleaning and maintenance
.....................................................................................
04
.............................................................................................................................
07
PRODUCT INSTRUCTION
Names of parts
......................................................................................................................................
06
About rock levels
................................................................................................................................
09
Control panel
.......................................................................................................................................
09
FUNCTION INSTRUCTION
Using process
......................................................................................................................................
10
Air fry auto menu
................................................................................................................................
10
Description of auto menu
..................................................................................................................
11
Control panel-Description of major features
..................................................................................
13
The rst time to use
Roast function
Pizza function
Cookies function
Bagel function
Reheat function
Warm function
Proof function
Slow cook function
......................................................................................................................................
.....................................................................................................................................
.....................................................................................................................................
......................................................................................................................................
.....................................................................................................................................
.....................................................................................................................................
.....................................................................................................................................
.....................................................................................................................................
.....................................................................................................................................
17
18
19
20
20
21
22
23
23Dehydrate function
Airfry function
Mute function
Toast function
Bake function
Broil function
.....................................................................................................................................
..............................................................................................................................................
....................................................................................................................................
....................................................................................................................................
.....................................................................................................................................
14
24
15
15
16
CLEANING AND MAINTENACE
Cleanliness precautions
.......................................................................................................................
25
...........................................................................................................................................
26
Troubleshooting
..................................................................................................................................
26
Speciction
IMPORTANT SAFEGUARDS
BASIC SAFETY PRECAUTIONS
When using electrical appliance, basic safety precautions should always
be followed, including the following:
This appliance is not
intended for use by persons
(including children) with
reduced physical, sensory or
mental capabilities, or lack
of experience and
knowledge,unless they have
been given supervision or
instruction concerning use
of the appliance by a person
responsible for their safety.
Children should be
supervised to ensure that
they do not play with the
appliance.
If the supply cord is
damaged, it must be
replaced by the
manufacturer,its service
persons in order to avoid a
hazard.
The appliances are not
intended to be operated
by means of an external
timer or separate remote
-control system.
The temperature of
accessible surfaces may
be high when the
appliance is operating.
Accessible parts may
become hot during use.
Young children should
be kept away.
The appliance is intended
to be used freestanding.
01
Avoid contacting moving
parts.
READ CAREFULLY AND KEEP FOR FUTURE REFERENCE
The surfaces are liable
to get hot during use.
Remove plug from outlet
when the appliance is not
in use,before on or taking
cleaning.Allow to cool
before handing.
Extreme caution should be
exercised when using
containers constructed of
other metal or glass.
Do not place any of the
following materials in the
oven:paper, carboard,
plastic, and the like.
Do not store any materials,
other than manufacturers
recommended accessories
in this oven when not in use.
02
This appliance is intended
to be used in household
and similar applications
such as:
working environments;
-by clients in hotels,
motels and other residential
type environments;
-farm houses;
-bed and breakfast type
environments.
WARING: Ensure that the
electric shock.
The oven in the course of work or just use, after the completion
of the surface temperature is higher, do not touch.
Open the door carefully
If the door or door seal of the product is damaged, it shall not be
used again until repaired by qualied maintenance personnel.
High temperature surface to prevent burns
The product will heat during use. Pay attention to avoid contact with
the heating unit in the product.
Children should be kept away from palpable parts that may become
hot when in use. Temperatures on some surfaces are very high
during appliance operation. Surfaces labeled " hot surface" will
become hot during use.
Please be careful when you take the food. Do not collide with the
chamber or door glass
When heating liquid food, the container should leave enough space
to prevent the liquid from boiling over.
When moving or cleaning toaster oven, should unplug the power
Put in the place where children can't touch
Only have to provide adequate guidance so that the children can
use the products adopt the method of safety, and understand that
incorrect use will cause danger, to allow children under the
condition of the unmanned monitoring use products.
Do not use steam cleaners.
SAFETY PRECAUTIONS
Note
●
●
●
●
Precautions for use
●
●
●
●
●
03
Maintenance matters needing attention
There are high voltage power supply, do not open cover, repair
and renovation
personnel to perform maintenance operations. If you encounter
any obstacles during use, please contact our service center.
It is strictly prohibited for non-professional personnel to disasse-
mble and repair this product, otherwise it may lead to danger
If the door or door seal is damaged, do not use it again until it is
If the supply cord is damaged, it must be replaced by a
professional from the manufacturer, its maintenance department,
or similar department to avoid danger.
●
●
●
Precautions for cleaning and maintenance
Can be dipped in a soft detergent (such as dishwashing essence)
dry with a dry cloth, it is strictly prohibited to use steel wire brush
and other hard objects to wipe the product. Do not clean the stove
door safety lock system
Don't use coarse abrasive cleaner or sharp metal scraper cleaning
door glass, lest cause the door glass surface scratch, scratch could
lead to the glass shattered.
Always try to keep the oven door shaft joint clean.
The grease produced during cooking will corrode the furnace
food. Therefore, please clean the furnace cavity in time after use.
Often warm water cleaning accessories. Be careful not to use cold
water to clean immediately after cooking for a long time.
Please do not use bad detergent and with corrosive, volatile chemical
solvent cleaning furnace body, lest the furnace body is damaged.
●
●
●
●
●
04
Attention in placement
wall
There are safety barrier components on the
back of the oven to prevent the oven from
contacting with the wall and other objects
and keep a safe distance.
Rear spacing≥1cm
Note: High temperature surfaces
Top, back and glass doors, etc
above spacing≥5cm
Left and right
spacing≥1cm
Open space
Rear spacing≥1cm
oven
Schematic diagram
Security considerations
ATTENTION
05
1. Place the oven on a at, insulated surface，Keep at least 10-15cm
away from the oven
2. The toaster oven should be placed in a dry environment，Do not
use this product outdoors
3. In order to avoid the lampblack in the product work pollution f
urniture or heat cause re, the product should keep a certain
distance with walls and cabinets.
4. It is strictly prohibited to place the toaster oven in the vicinity of
combustible or heat source, should pay attention to stay away from
curtains and other similar items, in order to prevent re.
06
For "AIR FRY" mode
Baking Tray
Grabber Instruction manualAir Fry Basket
Grill Rack
Used to receive the
residue of food.
Please use it under the
heating tube
Place the convex upward
Crumb Tray
NOTE
Because the product is constantly updated, such as the
physical objects and pictures do not match, please refer
to the physical objects.
Heat sink
Knob
Oven door
The handle
Display
The power cord
Furnace foot
Use for baking tray and grills rack
Structure description
NAMES OF PARTS
PRODUCT INSTRUCTION
Attachment description
concave side
convex side
Empty burn prompt：
protective coating in the heating tube and the chamber.
Operation method:
Put crumbs tray heat pipes below, grill rack, baking tray, air fry
basket in the oven, plugged in.
Use "Roast" functions and adjust the temperature to the highest
level to burn empty for 15 minutes.
Notes: It is normal to have odor or smoke during empty burning.
End of empty burning: Unplug the power cord and fully open the oven door for quick heat dissipation.
After the oven has cooled down completely, remove the baking tray and the grill rack for normal use.
Grill rack
Air Fry Basket
Layer 3
Layer 2
Layer 1
Baking tray
Crumb tray
3
2
1
确定
开始
07
The ÿrst time to use
Wipe the oven once with a damp cloth in power-o state (do not
wipe theheating tube).
1
2
3
OPERATION
How to use
INSTRUCTIONS
Place the grill rack/baking tray in position that will accommodate
the height of the food to be cooked.
The food must be put onto the grill rack/baking tray to avoid
fire havzzard, caused by food chipping accumulated on the
heating elements.
Make sure that you always use the oven right proof container
in the oven, never use plastic or cardboard containers in the
Oven.
Keep the heating elements periodically clean.
.
Never use glass or ceramic pans or lids.
DO NOT let juices or oil drip down on to the bottom of the oven. Use the Crumb Tray
when cooking.
Set the temperature as suggested by the recipe or as desired.
Securely close the door and set the cooking time before begining to operating the oven.
THE OVEN SURFACES ARE HOT DURING AND AFTER USE.
When you use the grill /baking
, please put the rack on the suitable level.
cooking 1 minutes.
08
4
1
2
3
4
5
6
4
7
8
9
When the oven is electrified, the buzzer will ring once. The default
function is AIRFRY. In the process of cooking, you can press
" " to pause cooking.
09
CONTROL PANEL
Fan of
Convection
Time/ Temperature
button
Light button
Start/Pause knob
Back/
Cancel/
Mute
button
Airfry menu button
About Rack Levels
1. The concave side
of the rack on the
layer 1,which is
suitable for baking
tender chicken.
2. The concave side
of the rack on the
layer 2,which is
suitable for baking
lava toast.
3. The convex side
of the rack on the
layer 3,which is
suitable for baking
steak with black
pepper.
Rack has three placing modes,which can place dierent baking layers, and
is suitable for baking dierent foods.
Rotate the “ ” knob and you can choose functions
from A01-A11 in the menu. The default function is
A01 (Frozen French fries).
When the function is Air Fry, press the “ ” button once, it will
into the Air Fry menu. “ AIR FRY”, A01” and “ ” will display
on the display screen.
Press the “ ” button and rotate the “ ”knob to adjust the
temperature. The default temperature of A01 is 200°C.
This temperature is the cooking temperature after preheating.
1. When using a baking tray, place foil or baking paper under food to clean it.
2. Install a chip tray when baking.
3. The oven uses intermittent heating principle to work. During the working
process, the heat pipe suddenly lights up and suddenly goes out, which is a
normal phenomenon.
4. After the machine is working or work, the fuselage, glass, grill, baking
temperature is higher, please note that do not directly touch.
5. When using aluminum foil, do not contact the heating pipe. Otherwise, the
aluminum foil will dissolve and stick to the heating pipe, which may cause faults.
6. Food materials are easy to shrink, deformation or oil after baking. When baking
on a grill rack, it is recommended to place the baking tray on Layer 1 for
7. Take out the attachment and food, please pay attention to prevent hot.
8. When baking, there is slight steam around the door, is a normal phenomenon.
NOTE
Using the process
FUNCTION INSTRUCTION
10
Air Fry Auto Menu
1
2
3
connecting the oil residue.
You can press the “ ” button and rotate the
“ ” knob to adjust the temperature
and the time during cooking process.
Press the “ ” button to preheat.( A01/A11does not need
to preheat)
After preheating, put the food into the cooking machine
and close the door. Press the “ ” button to start cooking.
(If A01 is selected, put french fries in the Air Fry basket. It is
recommended to use the default temperature and cooking
time, or you can adjust the temperature and cooking time after
start. If A04 is selected, the buzzer will sound 3 times to remind
you to turn over when there is 10min left.)
11
A01
Frozen french
Description of Air Fry Auto Menu
Press the “ ” button and rotate the “ ” knob to set the
cooking time. The default cooking time of A01 is 18 minutes.
This time is the cooking time after preheating.
A03
Chicken nuggets
A04
Chicken leg
A02
Chicken wings
A05
A06
A07
Squid rings
A08
Potato cheese
strips
A09
Vegetables
A10
Potato wedges
A11
Spring rolls
4
4
5
6
4
7
12
Function
Function Name
Quantity
/weight
Preheat
Preset
temperature
Preset time
Optional
temperature
Place
A01
Frozen french
350g
X
200°C
18 mins
100°C-200°C
A02
Chicken wings
A03
Chicken nuggets
560g
V
200°C
17 mins
100°C-200°C
A04
Chicken leg
6 pieces
/876g
V
500g
V
200°C
10 mins
100°C-200°C
190°C
25 mins
100°C-200°C
A05
2 pieces
V
200°C
10 mins
100°C-200°C
A06
8 pieces
V
200°C
14.5 mins
100°C-200°C
A07
Squid rings
16 pieces
V
200°C
11 mins
100°C-200°C
A08
Potato cheese
strips
spread
evenly
V
200°C
10 mins
100°C-200°C
A09
Vegetables
spread
evenly
V
180°C
5 mins
100°C-200°C
A10
Potato wedges
spread
evenly
V
200°C
11 mins
100°C-200°C
A11
Spring rolls
15 pieces
X
200°C
16 mins
100°C-200°C
Air fry basket + Grill rack
(convex side) on layer 2;
Baking tray on layer 1
Air fry basket + Grill rack
(convex side) on layer 2;
Baking tray on layer 1
Air fry basket + Grill rack
(convex side) on layer 2;
Baking tray on layer 1
Air fry basket + Grill rack
(concave side) on layer 2;
Baking tary on layer 1
Baking tray on layer 2
Air fry basket + Grill rack
(convex side) on layer 2
Air fry basket + Grill rack
(convex side) on layer 2
Air fry basket + Grill rack
(convex side) on layer 2
Baking tray on layer 3
Air fry basket + Grill rack
(convex side) on layer 2
Air fry basket + Grill rack
(convex side) on layer 2;
Baking tray on layer 1
Air fry basket + Grill rack ( convex side) on layer 2
Baking tray on layer 1
Air fry basket + Grill rack(concave side)on layer 2 ;
Baking tray on layer 1
Air fry basket + Grill rack(convex side) on layer 2
Optional
time
1-30 mins
1-30 mins
1-30 mins
1-30 mins
1-30 mins
1-30 mins
1-30 mins
1-30 mins
1-30 mins
1-30 mins
1-30 mins
2
1
3
2
1
3
2
1
3
Air fry basket + Grill rack(convex side) on layer 3
2
1
3
;
Control Panel – Description of Major Features
Function Name
Fan
selection
Preheat
Preset
temperature Preset time
Apply to
Air Fry
NA
V
200°C
15 mins
Bake
:Press
to run on
X
175°C
25 mins
Broil
X
Toast
Roast
X
Cookies
NA
V
190°C
10 mins
100-200°C
70-180°C
Optional
temperature
For any food that requires air
fry; you may choose desired
temperature and time
NA
X
4 slices
(230℃)
degrees:4
(4mins
50ses)
1-6 slices
For toasting 1-6 slices of
bread; 7 degrees toastiness
are available
For baking a variety of food,
especially pastries; convection
function is available
:Press
to run on
For cooking thin, tender cuts
brown breads and casseroles;
convection function is
available
175°C
10 mins
70-180°C
:Press
to run on
For cooking meat and poultry
that are less tender-cut;
convection function is
available
175°C
10 mins
70-230 °C
Pizza
V
:Press
to run o
For baking fresh or frozen
pizza; convection function is
available
9 inches
（165°C ）
9 inches：
11.5mins
inches
（70-230°C）
For baking any type of cookie
70-230°C
Bagel
NA
X
Quantity：4
degrees: 4
(4mins15ses)
For baking any type of bagel
Quantity：
2/4/6
Reheat
X
175°C
3mins
70-230°C
For preheating food in a quick
manner
:Press
to run on
Warm
X
80°C
60mins
35-150°C
In warm function, the upper
and bottom heating elements
maintain at 80°C to keep food
at the proper serving
temperature
NA
Proof
X
35°C
50mins
25-45°C
In proof function, the upper
and bottom heating elements
maintain at a low temperature
to proof bread or milk
NA
Slow Cook
X
For gentle and slow cooking
of tender meat
100°C
60mins
35-110°C
NA
Dehydrate
X
For dehydrating fresh pieces
of fruit
70°C
4 hrs
35-100°C
NA
13
1-30 mins
1-120 mins
Optional
time
Degrees:
1-7
1-120 mins
1-120 mins
1-30 mins
1-120 mins
degrees:
(1-30 mins)
1-20 mins
1mins -
4hrs
1mins -
9hrs
1mins -
8hrs
1mins -
24hrs
ff
6/9/12
3-6
14
AIR FRY FUNCTION
Power on to enter initial state, the default function is Air Fry.
The screen displays “AIR FRY” and “ ”.
Press “ ”button rotate “ ” knob to adjust the
temperature. The default temperature is 200°C. This
temperature is the cooking temperature after preheating.
Press “ ” button, rotate “ ” knob to adjust cooking
time. The default cooking time is 15 minutes. This time
is the cooking time after preheating.
Press “ ” button to preheat.
After preheating, put the food into the cooking machine
and close the door. Press the “ ” button to start cooking.
You can press the “ ” button and rotate the
“ ” knob to adjust the temperature and the
time during cooking process.
After the cooking nishes, the machine will beep 3 times and the
display screen will show “End”. Pay attention to the high temperature
of both the food and the machine when you take out the food.
4
1
2
3
4
5
6
4
7
BAKE FUNCTION
Press “ ”button, rotate the “ ” knob to set
temperature. The default temperature is 175°C.
15
TOAST FUNCTION
Rotate the “ ” knob to the right once. The screen
displays “TOAST”and “ ”. The oven will enter the TOAST function.
Press “ ”button, rotate the “ ” knob to choose
the slice number of toast. The default number is 4 slices.
Press “ ” to start cooking. The default temperature
/cooking time is 230°C/4mins 50ses. The temperature
and time can’t be adjusted during cooking.
Press “ ” button, rotate “ ” knob to choose the
degrees of toastiness. The default setting is 4.
Press “ ” button, rotate “ ” knob to set
cooking time. The default cooking time is 25min.
The buzzer will sound 3 times to remind you when cooking
is nished, the screen displays “End”. Always pay attention
when taking out food, because the food and oven are very hot.
Rotate the “ ” knob to the right twice. The screen displays“BAKE”
and “ ”and the fan is o (default). You can choose to turn on
fan “ ”. After that, the screen displays “BAKE ” and “ ”.
4
1
2
3
4
5
1
2
3
BROIL FUNCTION
16
Press “ ” to start cooking.
During cooking, press “ ” and rotate “ ”
to adjust temperature and cooking time.
Press “ ” button, rotate “ ” knob to set
temperature. The default temperature is 175°C.
Press “ ” button, rotate “ ” knob to set
cooking time. The default cooking time is 10min.
Press “ ” to start cooking.
During cooking, press “ ” and rotate “ ”
to adjust temperature and cooking time.
The buzzer will sound 3 times to remind you when cooking is
nished, the screen displays “End”. Always pay attention when
taking out food, because the food and oven are very hot.
Rotate the “ ” knob to the right three. The screen
displays“BROIL” and “ ”and the fan is o (default). You can choose
to turn on fan “ ”. After that, the screen displays “BROIL ” and “ ”.
4
4
5
6
4
1
2
3
4
5
17
ROAST FUNCTION
Press“ ”button, rotate “ ” knob to select
temperature. The default temperature is 175°C.
Press “ ” button, rotate “ ” knob to set
cooking time. The default cooking time is 10min.
Press “ ” to start cooking.
During cooking, press “ ” and rotate “ ”
to adjust temperature and cooking time.
The buzzer will sound 3 times to remind you when cooking is
nished, the screen displays “End”. Always pay attention when
taking out food, because the food and oven are very hot.
The buzzer will sound 3 times to remind you when cooking is nished, the screen
displays “End”. Always pay attention when taking out food, because the food and
oven are very hot.
Rotate the “ ” knob to the right four times, the screen displays
“ROAST” and “ ” and the fan is o (default). You can choose
to turn on fan “ ”. After that, the screen displays “ROAST ” and “ ”.
6
4
1
2
3
4
5
6
PIZZA FUNCTION
18
Press “ ” button, rotate “ ” knob to set the size of pizza
(6 inches, 9 inches, and 12 inches). The default size is 9 inches.
After preheating, put the food in and close the oven door.
Press “ ”to start cooking.
During cooking, press “ ” and rotate “ ” to adjust
temperature and cooking time.
The buzzer will sound 3 times to remind you when cooking is
nished, the screen displays “End”. Always pay attention
when taking out food, because the food and oven are very hot.
Rotate the “ ” knob to the right ve times, the fan “ ” displays
(default), and the screen displays“PIZZA ” and “ ”. The oven
will enter the PIZZA function.
Press “ ” button, rotate the “ ” knobto set temperature,
temperature ashes. The default temperature is 165°C for
9 inches.
Press “ ” button, rotate “ ” knob to adjust cooking
time, then the time ashes. The default cooking time for
9 inches is 11min30sec.
Press “ ” to start preheating, and preheat icon ashes.
4
1
2
3
4
5
6
7
8
Rotate the “ ” knob to the right six times, the
screen displays “COOKIES” and “ ”,the oven will
enter COOKIES function.
Press“ ”button, rotate “ ” knob to set temperature.
The default temperature is 190°C.
19
After preheating, put the food in and close the oven door.
Press “ ”to start cooking.
COOKIES FUNCTION
Press “ ” button, rotate “ ” knob to set cooking time.
The default cooking time is 10min.
During cooking, press “ ” and rotate “ ” to adjust
temperature and cooking time.
Press “ ” to start preheating, and preheat icon ashes.
The buzzer will sound 3 times to remind you when cooking
is nished, the screen displays “End”. Always pay attention when
taking out food, because the food and oven are very hot.
4
1
2
3
4
5
6
7
20
Rotate the “ ” knob to the right seven times,the screen
displays “BAGEL” and “ ”. The oven will enter BAGEL function.
Press “ ”button, rotate “ ” knob to set the
quantity (2, 4 and 6). The default value is 4.
Press “ ” button, rotate “ ” knob to set
temperature. The default temperature is 175°C.
REHEAT FUNCTION
BAGEL FUNCTION
Press “ ” button, rotate “ ” knob to set power
level. The default power level is 4.
Press “ ” button, rotate “ ” knob to set
cooking time. The default cooking time is 3min.
Press “ ” to start cooking. The default temperature
/cooking time is 200°C/4mins 15ses. The cooking time
is adjustable and the temperature is not adjustable.
The buzzer will sound 3 times to remind you when cooking is nished,
the screen displays “End”. Always pay attention when taking out food,
because the food and oven are very hot.
Rotate the “ ” knob to the right eight times,the screen
displays “REHEAT” and “ ”and the fan is o (default). You can choose
to turn on fan “ ”. After that, the screen displays “REHEAT” and “ ”.
4
1
2
3
4
5
1
2
3
21
Press “ ” to start cooking.
Press “ ” button, rotate “ ” knob to set
temperature. The default temperature is 80°C.
Press “ ” to start working.
WARM FUNCTION
Rotate the “ ” knob to the right nine times, the screen
displays “WARM” and “ ”. The oven will enter WARM function.
During cooking, press “ ” and rotate “ ” to
adjust temperature and cooking time.
During cooking, press “ ” and rotate “ ” to
adjust temperature and cooking time.
Press “ ” button, rotate “ ” knob to set
cooking time. The default cooking time is 1hour.
The buzzer will sound 3 times to remind you when cooking is nished,
the screen displays “End”. Always pay attention when taking out food,
because the food and oven are very hot.
4
4
5
6
4
1
2
3
4
5
22
Press “ ” to start working.
Rotate the “ ” knob to the right ten times, the screen
displays “PROOF” and “ ”. The oven will enter PROOF function.
Press “ ” button, rotate “ ” knob to set
temperature. The default temperature is 35°C.
PROOF FUNCTION
During cooking, press “ ” and rotate “ ” to
adjust temperature and cooking time.
Press “ ” button, rotate “ ” knob to set
cooking time. The default cooking time is 50min.
The buzzer will sound 3 times to remind you when cooking is nished,
the screen displays “End”. Always pay attention when taking out food,
because the food and oven are very hot.
The buzzer will sound 3 times to remind you when cooking is nished,
the screen displays “End”. Always pay attention when taking out food,
because the food and oven are very hot.
6
4
1
2
3
4
5
6
Press “ ” to start working.
Rotate the “ ” knob to the right eleven
times, the screen displays “SLOW COOK” and “ ”.
The oven will enter SLOW COOK function.
Rotate the “ ” knob to the right twelve
times, the screen displays “DEHYDRATE” and “ ”.
Then the oven will enter DEHYDRATE function.
23
DEHYDRATE FUNCTION
SLOW COOK FUNCTION
During cooking, press “ ” and rotate “ ” to
adjust temperature and cooking time.
Press “ ” button, rotate “ ” knob to set
cooking time. The default cooking time is 1hour.
Press “ ” button, rotate “ ” knob to set temperature.
The default temperature is 100°C.
The buzzer will sound 3 times to remind you when cooking is nished,
the screen displays “End”. Always pay attention when taking out food,
because the food and oven are very hot.
4
1
2
3
4
5
6
1
Press “ ” to start cooking.
Press “ ” button, rotate “ ” knob to set
temperature. The default temperature is 70°C.
24
MUTE FUNCTION
When you want the oven to go silent, long press “ ” for 3 seconds. The display
screen will show “oFF”. Then the machine will be in the mute function. Long
press “ ” 3 seconds, the mute function will be canceled. The display screen will
show “on”.
During cooking, press “ ” and rotate “ ”
to adjust temperature and cooking time.
Press “ ” button, rotate “ ” knob to set
cooking time. The default cooking time is 4hours.
The buzzer will sound 3 times to remind you when cooking is nished,
the screen displays “End”. Always pay attention when taking out food,
because the food and oven are very hot.
4
2
3
4
5
6
Before cleaning, unplug and wait for the toaster
oven cool completely before
Clean all attachments including grill rack, baking
1.
2.
3.
4.
5.
6.
7.
8.
Cleanliness precautions
NOTE
CLEANING AND MAINTENACE
25
OTHER INDICATION
Standby Mode
In the standby mode:
1. If the oven is left idle for 5 minutes, the whole panel will be off.
2. Press " ".
To activate the oven to the standby mode, Twist " " or touch any button lightly.
Selection process
During the function selection process, if the oven is left idle for 5 minutes, the selection process will be canceled
and the screen will display "00:00"
Do not use sharp cleaning tools, bristles, wire brushes, and corrosive cleaning
supplies to avoid damage to the body and accessories.
Do not immerse the toaster oven in water or other liquids to prevent damage
to the oven.
Please be sure to wait until the body cooling cleaning and maintenance.
Please keep the crumb tray clean at ordinary times to avoid re or re when
used in the state of dirt or debris residue.
Do not forget to install the crumb tray after cleaning and maintenance, so as not
to cause the place where the product is placed to burn.
Do not leave the food materials or dirt in the furnace in case of re or cause re.
Baking, the lampblack may cause slight yellow color panel, belongs to the
normal phenomenon.
Do not use detergent, brush, water or gasoline to clean the product.
Use the soft wet cloth that is dipped in neutral
cleaner to wipe toaster oven interior, wait with
the cloth that wring dries again to wipe o
detergent composition.
4
1
2
3
dry thoroughly after cleaning.
tray and crumb tray with a neutral cleaner and let
Speciÿction
MODEL
TL2-AC25GZC(GR)
CUBAGE 25L
VOLTAGE 220-230V~
AC FREQUENCY 50/60Hz
POWER 1500-1600W
If there is an exception during use, please read this instruction carefully before
sending it to repair, and check whether it is caused by the following reasons.
Comment:
1. Do not disassemble, repair or modify without authorization.
2. If the fault still cannot be rectied, please contact the after-sales service in time.
Common faults
After rotating the timing knob, the
heating tube does not light up
Smoke or smell
Yellow spots or burnt product
placement
Cause Solution
The power plug is not rmly inserted
into the socket
Please insert the power plug rmly into the
socket.
Please clean the crumb tray.
Please clean the crumb tray.
Please install the chip tray.
Be sure to burn empty when rst using. After
repeated use sometimes peculiar smell,
residual will be eliminated.
Furnace temperature, the thermostat starts
running, may not result in heating tube lights.
Continuous baking furnace temperature
is too high
Slag adhesion on the plate burning
debris or dirt
The crumb tray is not installed properly
It was not burned when it was rst used
Debris and dirt attached to the crumb
No action is required.
No action is required.
The timer is a spring, so errors
sometimes occur
It won't bake through in the middle
Scorched on the outside when baking
Timer error
Timer is not running
Set below 10, please rst turn to 11 and then
turn back.
When the timer is set to less than 10
minutes, the timer sometimes does not
run properly
During baking, the heating tube lamp is
not bright or sometimes bright and
sometimes o
Thermostat, are adjusting the baking
temperature
When baking, please nd a way to cut open,
cut into small pieces, etc.
Please extend the baking time.
Baking time is too short
Please shorten the baking time.
Baking time is too long
It's something that's hard to bake
through the middle
Troubleshooting
26
tray are burning
PN:16171000A14591
