Specications
Model EKS-L422-VUS
Weight Capacity 353 oz / 22 lb / 10 kg / 10000 mL
Units
oz / lb:oz / g / mL (water/milk) /
’oz (water/milk)
Increments 0.05 oz / 1 g
Auto-Off 180 seconds
Battery 300mAh Li-ion Battery
Input 5.0V
500mA (USB Type-C Charging)
Dimensions 9.5 x 6.6 x 0.8 in / 242 x 167.5 x 19.5 mm
5
Scale
Important Safety Information
• Do not exceed the 22 lb / 10 kg weight capacity, as it will damage
the scale. An error indicator will appear on the LED display if the
limit is exceeded.
• The scale is IPX6 water resistant, which means it can withstand
most liquid spills without permanent damage. However, we still
recommend wiping the scale dry with a soft cloth after any spills
to keep it in optimal condition.
• Handle with care. This scale is not intended for commercial or
heavy-duty use.
• Keep the scale in a cool, dry place. Avoid exposure to damp
environments or extreme temperatures.
• Household use only.
To avoid damage to this scale, please read and follow all
instructions and safety guidelines in this manual.
READ AND SAVE THESE INSTRUCTIONS
6
Battery
When the scale is in use, will ash if the scale is running low on
battery. The scale’s display will show “Lo” when the battery needs to
be charged immediately. Follow the steps to recharge the battery.
1. Insert the USB charging cable into the USB charging socket.
2. Plug the USB charging cable into a DC 5V adapter and plug
into an outlet. You can also plug the cable into a powered USB
outlet.
3. When charging,
will ash. Once the battery is fully charged,
will stop ashing.
Note: The scale can’t be used while charging, so it is recommended to
charge the battery when ashes, indicating low battery.
9
Using Your Scale
General Operation
1. Place the scale on a hard, at surface.
2. Tap
to turn on the scale. Make sure the display reads
“0.00”. If the screen does not display “0.00” automatically, tap
to adjust to zero.
3. Tap UNIT to select your desired measuring unit, which will
show on the bottom of the display.
4. Place your item on the scale.
5. Wait for the reading on the display to stabilize.
6. When you’re done, reset the scale by removing all items
from the scale. If the display doesn’t read “0.00”, press
to reset the weight to zero.
Note:
• For accurate results, always place the scale on a hard, at surface, and
keep the scale away from dirt, dust, vibrations, wind, air currents, and
electromagnetic interference.
• When you turn on the scale, choose units, or use the tare function, wait
for the display to read “0.00” before measuring.
10
1. Tap to turn on the scale. Make sure the display reads
“0.00”. If the screen does not display “0.00” automatically, tap
to adjust to zero.
2. Place the container on the center of the scale.
3. Wait for the reading on the display to stabilize. The display will
show the container’s weight.
4. Tap
to tare the weight of the container. The screen will
now display “0.00”.
5. Place the liquid or items into the container. The scale will
measure the contents without including the weight of the
container.
6. When you’re done, reset the scale by removing all weight and
tapping
again.
Whenever you measure items inside a container, you can use
the tare function to remove the container’s weight from the nal
measurement.
Zero / Tare Function
11
a. Place your item on the scale. Tap HOLD to lock the
measurement reading. Tap HOLD again to unlock the display.
b. Tap HOLD and place your item on the scale. Wait 3 seconds
for the reading to stabilize. The scale will automatically lock the
measurement reading. Tap HOLD again to unlock the display.
Unit Conversion
Hold Function
Automatic Power Off
Manual Power Off
To change the unit of measurement, tap UNIT until the display
shows your desired unit of measurement.
There are two ways to use the hold function:
To save battery power, the scale will automatically power off after
180 seconds of inactivity.
Press and hold
for 2 seconds to turn off the scale.
Note: In hold mode, will not work. You can still use UNIT to switch
between units.
12
Troubleshooting
If your problem is not listed, please contact Customer Support
(see page 16).
Problem Possible Solution
Scale does not turn on.
The scale may need to be charged. Plug in the USB
power cord to charge.
Reading is inaccurate.
Place scale on a level surface.
Keep scale away from dirt, dust, vibrations, wind, air
currents, and electromagnetic interference.
Make sure the screen displays “0.00” before measuring
(see Zero / Tare Function, page 10).
Battery Charging
Indicator is ashing
When the scale is in use,
will ash if the scale is
running low on battery. Plug in the USB power cord to
charge.
will ash when the battery is charging. Once the
battery is fully charged, will stop ashing.
Display shows “Err”
Item is too heavy. Remove item from scale to protect its
weight sensor. Use a different scale with a higher weight
range.
Display shows “Lo”
The battery is out of power and needs to be charged
immediately. Plug in the USB power cord to charge the
scale (see Battery, page 6).
13
Federal Communication Commission Interference
Statement – Part 15
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received, including interference that
may cause undesired operation.
NOTE: This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not occur
in a particular installation. If this equipment does cause harmful interference to radio
or television reception, which can be determined by turning the equipment off and on,
the user is encouraged to try to correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
FCC Caution: Any changes or modications not expressly approved by the party
responsible for compliance could void the user’s authority to operate this equipment.
Etekcity Corporation hereby declares that this equipment is in compliance with FCC
requirements. The declaration of conformity may be consulted in the support section
of our website, accessible from www.etekcity.com.
FCC SDOC SUPPLIER’S DECLARATION OF CONFORMITY
14
Warranty Information
Product Luminary™ Lite Kitchen Scale
Model EKS-L422-VUS
For your own reference, we strongly recommend that you record your order ID and
date of purchase.
Order ID
Date of Purchase
TERMS & POLICY
Etekcity Corporation (“Etekcity”) warrants this product to the original purchaser
to be free from defects in material and workmanship, under normal use and
conditions, for a period of 2 years from the date of original purchase.
Etekcity agrees, at our option during the warranty period, to repair any defect
in material or workmanship or furnish an equal product in exchange without
charge, subject to verication of the defect or malfunction and proof of the date of
purchase.
There is no other express warranty. This warranty does not apply:
• If the product has been modied from its original condition;
• If the product has not been used in accordance with directions and
instructions in the user manual;
• To damages or defects caused by accident, abuse, misuse or improper or
inadequate maintenance;
• To damages or defects caused by service or repair of the product performed
by an unauthorized service provider or by anyone other than Etekcity;
• To damages or defects occurring during commercial use, rental use, or any
use for which the product is not intended;
• To damages or defects exceeding the cost of the product.
15
Etekcity will not be liable for indirect, incidental, or consequential damages in
connection with the use of the product covered by this warranty.
This warranty extends only to the original consumer purchaser of the product and
is not transferable to any subsequent owner of the product regardless of whether
the product is transferred during the specied term of the warranty.
This warranty does not extend to products purchased from unauthorized sellers.
Etekcity’s warranty extends only to products purchased from authorized sellers
that are subject to Etekcity’s quality controls and have agreed to follow its quality
controls.
All implied warranties are limited to the period of this limited warranty.
This warranty gives you specic legal rights and you may also have other rights
which vary from state to state. Some states do not allow the exclusion or limitation
of incidental or consequential damages, so the above limitation or exclusion may
not apply to you.
If you discover that your product is defective within the specied warranty period,
please contact Customer Support via support@etekcity.com.
DO NOT dispose of your product before contacting us. Once our Customer
Support Team has approved your request, please return the product with a copy of
the invoice and order ID.
Every Etekcity product automatically includes a 2-year warranty. To make the
customer support process quick and easy, register your product online at
www.etekcity.com/warranty.
This warranty is made by:
Etekcity Corporation
1202 N. Miller St., Suite A
Anaheim, CA 92806
16
Customer Support
If you have any questions or concerns about your new product,
please contact our helpful Customer Support Team.
Etekcity Corporation
1202 N. Miller St., Suite A
Anaheim, CA 92806
Email: support@etekcity.com
Toll-Free: (855) 686-3835
Support Hours
Mon–Fri,
9:00 am–5:00 pm PST/PDT
*Please have your order invoice and order ID ready before contacting
Customer Support.
