BDPF350
www.blackanddecker.co.nz
40cm Pedestal Fan
2
Thank you for choosing this Black & Decker product. This appliance has been designed and
manufactured to high standards of engineering and with proper use and care, as described in this
leaflet, will give you years of useful service. Please read these instructions carefully and keep them
for future reference.
1. This appliance is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless they have been
given supervision or instruction concerning use of the appliance by a person responsible for
their safety.
2. Children should be supervised to ensure that they do not play with the appliance.
3. If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or
similarly qualified persons in order to avoid a hazard.
4. Ensure that the fan is switched off from the supply mains before removing the guard.
5. Use only the voltage specified on the rating plate of the appliance.
6. Keep all objects at least 1 Metre from the front, sides and rear of the appliance
7. This appliance is intended for household use only and not for commercial or industrial use.
8. Use this appliance only as described in this manual. Any other use is not recommended by
the manufacturer and may cause fire, electric shock or injury.
9. The common cause of overheating is deposits of dust or fluff in the appliance. Ensure these
deposits are removed regularly by unplugging the appliance and vacuum cleaning the air
vents and grills.
10. Always unplug appliance when not in use.
11. When the appliance has been unpacked, check it for transport damage and ensure all parts
have been delivered. If parts are missing or the appliance has been damaged, contact the
Black & Decker Customer Services Team.
12. If your appliance does not work, or is not working properly, contact the place of purchase.
Repair work on the appliance by unqualified persons can cause serious risk to the user.
13. Ensure hands are dry before handling the plug or the main unit.
14. Carry out regular checks of the supply cord to ensure no damage is evident.
15. Ensure that the cord is fully extended (not coiled) while in use.
16. Avoid contact with the moving parts. Keep hands, hair, clothing, away from blade of the fan
during operation to reduce the risk of injury to person and/or damage to the unit.
17. Switch off and use handles provided when moving.
18. It is recommended that this fan is plugged directly into the wall socket.
19. A correctly specified, undamaged extension cord may be used with this fan provided it is
used in a safe manner.
General Care and Safety Guide
3
20. Never place appliance close to radiant heat source.
21. Never operate in areas where petrol, paint or other flammable liquids are used or stored.
22. Never use the appliance to dry clothes.
23. Never insert or allow foreign objects to enter any ventilation or exhaust opening, as this may
cause an electric shock, fire or damage to the appliance.
24. Never use abrasive cleaning products on this appliance. Clean with a damp cloth (not wet)
rinsed in hot soapy water only. Always remove plug from the mains supply before cleaning.
25. Never connect the appliance to mains supply until completely assembled and adjusted.
26. Never remove plug from power socket until the appliance has been switched off.
27. Never remove plug from power socket by pulling cord – always grip plug.
28. Never twist, kink or wrap the cord around the appliance, as this may cause the insulation to
weaken and split. Always ensure that all cord has been removed from any cord storage area
and is unrolled before use.
29. Never use this appliance in the immediate surrounds of a bath, a shower, or a swimming pool
or other liquids. The appliance must not be immersed in any liquids.
30. Due to the risk of injury, never use this appliance for any purpose other than its intended use.
This appliance is intended for use in household and similar applications such as staff kitchen
areas in shops, offices and other working environments; farm houses, by clients in hotels,
motels, bed and breakfast type environments and other residential type environments
31. Never use this appliance outdoors.
32. Never operate the appliance with a damaged cord or plug, after it malfunctions, or if it has
been damaged in any manner. Have the appliance checked and repaired by a qualified
electrician if repair is necessary.
33. Never place the unit in wardrobes or other enclosed spaces as this may cause fire hazards.
General Care and Safety Guide
4
1.Front grill
2.Grill protective ring
3.Blade knob
4.Blade
5.Rear grill mounting nut
6.Rear grill
7.Shaft
8.Motor assembly
9.Oscillating pin
10.Remote storage
11.Control panel
12.Inner pole
13.Height adjuster
14.Outer pole
15.Base
16.Base locking mechanism
17.Remote control
18.Fasten clip
Components
Assembly
Place the base on a flat surface. Remove the locking mechanism
from the pole and insert the pole onto the base.
Turn over the base with the pole inserted and secure by turning
the locking mechanism clockwise until completed fastened.
Place the motor assembly and control panel onto the extension
pole and secure by turning the assembly knob clockwise.
Remove the rear grill mounting nut by turning it counter-clockwise.
Place the rear grill onto the motor housing aligning the 3
raised knobs on the top of the motor housing with the 3
holes on the grill.
Place the rear grill mounting nut and tighten
turning clockwise.
5
Fix the front grill and the rear grill with the fastening
ring around the grill.
You will hear it click into place around the grill.
Assembly
Then use a screwdriver to tighten the fastening ring.
Align the blade onto the shaft and secure it by
tightening the blade knob counter-clockwise.
6
Operating your Fan
7
Always choose a safe location for the fan, keeping in mind the safety precautions outlined.
Ensure all packaging has been removed from the unit before use. This appliance requires no
installation, it should be used solely as a portable appliance.
WARNING: Keep all objects at least 1 metre from the front, sides and rear of
the appliance
Place the fan on a dry, level and sturdy surface.
Plug the power cord into the socket ensuring the fan switch is in the off position.
This Fan may be operated by the Manual Controls located on top of the
unit or by the Remote Control.
On/Off: To turn fan on, press the Power button.
The fan will start on high speed.
Speed Control: Press the Fan button repeatedly
to change speed.
Auto-off Timer: This setting will automatically
turn your fan off after 1, 2, 4, or 8 hours.
1 hour: Press one time
2 hours: Press two times
4 hours: Press three times
8 hours: Press four times
Turn Timer off: Press five times or press power
button
To turn off, press the Power button.
To activate Oscillation, press the knob on the back of the motor housing.
To turn off Oscillation, pull the knob back out again.
Remote Control
Install 2 x AAA batteries (not supplied) into the back of the remote control .
All the functions performed with the Remote-Control work identically to the
Manual Controls.
Do not mix old and new batteries. Do not mix alkaline, standard (carbon-
zinc) or rechargeable (nickel- cadmium) batteries.
DO NOT DISPOSE OF BATTERIES IN FIRE. BATTERIES MAY
EXPLODE OR LEAK.
IMPORTANT! NEVER COVER THIS APPLIANCE!
Cleaning
The fan requires regular cleaning to ensure trouble free operation.
Ensure that the fan is switched off from the supply mains before removing the guard.
Unplug the fan from the mains supply before cleaning.
Use a damp cloth (not wet) to wipe the exterior of the fan to remove dust and dirt.
Use a vacuum cleaner to remove dust and fluff from around the grills.
Ensure the fan is dry before plugging back into the mains supply.
Do not attempt to dismantle the fan. There are no user serviceable parts. For service or repair,
contact an authorised electrical service technician.
8
Thank you for purchasing this Black & Decker product. Your product is warranted against faults and manufacture when used in normal
domestic use for a period of one year. In non-domestic use Black & Decker limits the voluntary warranty to three months.
Black & Decker undertake to repair or replace this product at no charge if found to be defective due to a manufacturing fault during the
warranty period.
This warranty excludes damage caused by misuse, neglect, shipping accident, incorrect installation, or work carried out by anyone other
than a qualified electrical service technician.
PLEASE KEEP YOUR RECEIPT AS THIS WILL HELP VERIFY YOUR WARRANTY.
The benefits to you given by this warranty are in addition to other rights and remedies available to you under a law in relation to the goods
or services to which this warranty relates.
In Australia, our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled to a
replacement or refund for a major failure and compensation for any other reasonably foreseeable loss or damage. You are also entitled to
have the goods repaired or replaced if the goods fail to be of acceptable quality and the failure does not amount to a major failure.
In New Zealand this warranty is additional to the conditions and guarantees of the Consumers Guarantee Act (1993).
Black & Decker One Year Warranty (IMPORTANT: Please complete and retain this warranty card)
Name
Address
Place Of Purchase Date of Purchase
Name Of Product Model Number
Attach a copy of the purchase receipt to this warranty card
Due to continual design improvements, the product illustrated in this User Manual may differ slightly from the actual product.
New Zealand
CDB
PO Box 100-707
N.S.M.C
Auckland , 0745
Phone +64 (0)9 917 4000
Phone 0800 232 633
Australia
CDB Goldair Australia Pty
PO Box 574
South Morang
Victoria, 3752
Phone +61 (0)3 9365 5100
Phone 1300 465 324
1 Year Warranty
New Zealand
CDB Media Ltd.
PO Box 100-707
North Shore Mail Centre
Auckland, 0745
Tel. +64 (0)9 917 4000
Tel. 0800 232 633
Email info@cdb.co.nz
Monday – Friday 8am-5pm
Australia
CDB Goldair Australia PTY
PO Box 574
South Morang
Victoria, 3752
Tel. +61 (0)3 9365 5100
Tel. 1300 465 324
Email info@cdbgoldair.com.au
Monday – Friday 8am-5pm
TECHNICAL SPECIFICATION
Model: BDPF350
Supply: 220-240VAC 50Hz
Wattage: 50W
