User Manual
• The product warranty is printed on the back of this guide.
• This product is manufactured for use only in USA / CA.
• This product is suitable for 120 V only.
AM90Model
Use & Care
Guide
•
Dedicated Call Center:
☎
(877) 699-4649
•
Website: www.winixamerica.com
Contact Winix for
product related inquiries
and customer service
AIR PURIFIER
2610-0257-01 Rev.01
To expedite service, please specify the model name and number, the nature of the problem,
your contact information, and your address.
UNIT SPECIFICATIONS
SAFETY INSTRUCTIONS
Thank you for purchasing a Winix air purifier. This product is for household use only.
•
Do not repair or modify the unit. All repairs should be
completed by a qualified technician.
•
The plug for this unit is polarized with one blade wider
than the other. Do not force the plug into an electrical
outlet. Do not alter the plug in any way. If the plug does
not fit into the outlet, reverse the plug. If it still does
not fit, contact a qualified technician to install a proper
outlet.
•
Do not use if the power cord or plug is damaged or the
connection to the wall outlet is loose.
•
Use AC 120V only.
•
Do not damage, break, forcefully bend, pull, twist, bundle,
coat, pinch, or place heavy objects on the power cord.
•
Periodically remove dust from the power plug.
This will reduce the risk of shock due to humidity build up.
•
Remove the power plug from the outlet before cleaning
the unit. When removing the power plug, grasp by
holding the plug itself, never hold by the cord.
•
If the power plug is damaged, it must be replaced by
the manufacturer or a qualified technician.
•
Remove the power plug from the outlet when not in use.
•
Do not handle the power plug with wet hands.
•
Do not operate the unit when using indoor smoke-
generating insecticides.
•
Do not clean unit with benzene or paint thinner.
Do not spray insecticides on the unit.
•
Do not use the unit where it is humid or where the unit
may become wet, such as the bathroom.
•
Do not insert fingers or foreign objects into air intake or
outlet.
•
Do not use the unit near flammable gases. Do not use
near cigarettes, incense, or other spark-creating items.
•
Unit will not remove carbon monoxide emitted from
heating appliances or other sources.
IMPORTANT CAUTIONS FOR USING YOUR AIR PURIFIER:
WARNING: Follow the instructions in this manual to reduce the risk of electric shock, short circuit, and/or fire.
Model Name
AM90
Power Voltage
AC 120 V / 60 Hz
Power Rate
65W
Verified Room Size
360sq.ft.
Dimensions
14.9 in (W) x 7.8 in (D) x 23.6 in (H)
Weight
15.8 lbs
Replacement Filter
FILTER A / SKU : 115115
The exterior, design, and product specifications may be changed without prior notice to improve product performance.
Warning: Changes or modifications to this unit not expressly approved by the party responsible for compliance could
void the user's authority to operate the equipment.
Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in
a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
•
Reorient or relocate the receiving antenna.
•
Increase the separation between the equipment and receiver.
•
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
•
Consult the dealer or an experienced radio/TV technician for help.
This device contains license-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic
Development Canada's license-exempt RSS(s). Operation is subject to the following two conditions:
•
This device may not cause interference.
•
This device must accept any interference, including interference that may cause undesired operation of the device.
In French:
Cet appareil contient des émetteurs/récepteurs exemptés de licence et conformes aux normes Innovation, Science
et Economic. RSS(s) sans licence de Développement Canada. Le fonctionnement est soumis aux deux conditions
suivantes:
•
cet appareil ne doit pas causer d’interférences nuisibles, et
•
cet appareil doit accepter toute interférence reçue, y compris les interférences pouvant provoquer un fonctionnement
non souhaité.
Before operating this equipment, carefully read and
follow these safety cautions.
Ensure filters are inserted before running unit.
Running the unit without filters can shorten the
lifespan of the unit and cause electric shock or injury.
Be sure foreign objects are NOT inserted into the
vents on the unit.
Objects can include pins, rods, and coins.
Do not touch any part of the interior of the unit with
wet hands.
The high voltage may cause electric shock.
Ensure unit intake and outlet vents do not become
blocked.
Blockage may lead to increased internal temperatures,
causing product failure and deformation.
Do not use the unit as a step stool or place heavy
objects on the unit.
Personal injury may occur or product failure and
deformation.
WARNING
Follow these instructions to reduce the risk of serious
injury or death and to reduce risk of damaging the unit.
•
If the power cord is damaged, it must be replaced
by a special cord. Reassembly is available from the
manufacturer or its service agent.
•
This appliance is not intended for use by a person
(including children) with reduced physical, sensory or
mental capabilities, or lack of experience and knowledge
of the unit, unless they have been given supervision or
instruction concerning use of the appliance by a person
responsible for their safety.
•
Children should be supervised to ensure that they do not
play with the appliance.
•
This unit is not intended to be used to preserve
documents or art conservation.
Do not pull on the power cord when unplugging the
unit.
Do not tie or knot the power cord when unit is in
operation.
If the unit becomes submerged in water, unplug it
and contact customer service.
Do not unplug or move the unit while in operation.
Do not plug additional appliances into the same
outlet or power supply.
Do not touch the plug with wet hands.
Unplug the unit when not in operation for extended
periods of time.
Do not place around heating elements.
Do not use around mist or fumes from industrial oil
or around large quantities of metallic dust.
The cord can become damaged by forcefully
bending, pulling, twisting, bundling, pinching or
placing heavy objects on it.
Do not install in any sort of motor or transport
vehicle (trucks, boats, ships, etc.).
Do not place in an area with excessive amounts of
noxious gases.
Do not place near any flammable materials
(aerosols, fuel, gases etc.).
Do not have the unit facing into wind or drafts.
Do not place below any electrical outlet.
Do not place in excessively humid areas where the
unit may become wet.
To reduce the risk of fire or electric shock,
do not use this fan with any solid-state speed
control device.
SAFETY AND CAUTIONS
PRODUCT WARRANTY
The terms of the warranty are as follows:
1.
This product is manufactured under stringent
quality control and inspections.
2.
The warranty will be voided if product failure is a
result of negligence or misuse by the consumer.
3.
A proof of purchase must be presented upon
claiming a Product Warranty.
4.
Store the proof of purchase in a safe place or
register your product on winixamerica.com to
upload your proof of purchase.
5.
This warranty is valid only in the USA and Canada.
* for more information visit
https://winixamerica.com/terms-and-conditions/
Product Name Air Purifier
Model Name AM90
Purchase Date
Warranty Period
Two (2) Years
Place of Purchase
Place of Purchase
tel.
Customer
Address
Name
Tel.
The unit does not turn on at all
•
Is the plug securely attached to the outlet?
-
Make sure the outlet has power going to it and ensure
the plug is secured.
•
Is there a power outage?
-
Check to see if other lights and electrical equipment
are working and try again.
The unit doesn’t work in Auto Mode
•
Has Auto Mode been selected?
-
Press the Fan Speed button until Auto Mode is
selected.
•
Is the sensor blocked or clogged?
-
Wipe Smart Sensor with wet cloth, then dry.
It vibrates and makes a lot of noise
•
Is it running on a slanted or uneven surface?
-
Move the unit to a hard, flat, even area.
The power plug and outlet feel hot
•
Is the plug securely plugged in?
-
Make sure the plug is properly plugged into the outlet.
There is a strange smell
•
Is it being used in a place with a lot of smoke, dust, or
odors?
-
Clean the air intakes on either side and clean the
Pre-Filter.
-
Replace the Carbon or the True HEPA filter.
The fan strength is weak. The unit is not purifying the air
•
Is the Check Filter Indicator light on?
-
Change the filters as required.
The display panel is dim
•
Is the Light Sensor blocked by debris?
-
When Auto Mode is on, Sleep Mode is automatically activated
when the Light Sensor detects that the room is dark.
FREQUENTLY ASKED QUESTIONS
The energy efficiency of this ENERGY STAR
certified model is measured based on a ratio
between the model’s CADR for Smoke and the
electrical energy it consumes, or CADR/Watt.
IMPORTANT PRECAUTIONS FOR USING YOUR AIR PURIFIER:
•
Do not block the intake or outlet vents.
•
Do not use near hot objects, such as a stove.
•
Do not use where the unit may come into contact with
steam.
•
Do not use the unit on its side.
•
Keep away from products that generate oily residue,
such as a deep fryer.
•
Do not use detergent to clean the unit.
•
Do not operate without a filter.
•
Do not wash and reuse the True HEPA Filter.
•
Hold the handle on the back of the unit to transport.
•
Do not hold by the front panel.
•
Do not stick any small objects into the air outlet vents
or fan.
