CADBND
INSTALLATION INSTRUCTIONS
IMPORTANT!
Before you begin, read these instructions completely and carefully.
CAUTION:
Some parts have sharp edges; care must be taken when handling the various components to avoid
injury. Wear gloves when handling.
Two or more people should work together to mount the Bend Unit. CAD-BND Bend Unit must be
installed between CAD carts or Refrigerator Wrappers.
Getting Started
Remove packaging ■
Contents
Eye Goggles
Work Gloves
7/16” Socket and Ratchet Driver
7/16” Box or Open End Wrench
Screw Driver - Phillips #2
Description Qty
CAD-BND Bend Unit 1
Hex Bolt SS 1/4-20 x 1/2” 4
Washer 5/16” ID x 3/4” OD 8
Hex Nut 1/4-20 4
Tools Needed
Locating the Bend Unit:
For proper use, this product should be installed/positioned on a at ground or patio. Unevenness such as
bumps, cracks and protrusions should be 1/4” or less. If positioning the Bend Unit on uneven ground, it is
recommend to mount the CAD carts on leveling legs (CAD-LVL). If mounting to a refrigerator, the built in
leveling legs can serve the same purpose.
Before Installing:
Before you begin installing the CAD-BND Bend Unit, make note of the four sets of mounting holes located near
the top of the sidewalls. The Bend Unit is
capable of a variety of congurations that
require use of dierent mounting holes.
The top row of holes will be used when
mounting to any CAD cart; the bottom
row of holes will be used for mounting to
any of the wrappers for outdoor refrig-
eration products; the rear set of holes
will be used in the standard orientation;
the front set of holes will be used in the
reverse orientation (Fig. 01). The Bend
Unit can be mounted to all size CAD
carts as well as all outdoor refrigeration
products equipped with a wrapper.
CAD CARTS
REFRIGERAT OR
WRAPPERS
STANDARD
CONFIGURATION
REVERSE
CONFIGURATION
STANDARD
CONFIGURATION
REVERSE
CONFIGURATION
REAR
FRONT
SIDE VIEW
Fig. 01
