QUICK REFERENCE GUIDE > RF15IR2 Date: 13.05.2021 > 1
15" Outdoor Clear Ice Maker
Stainless Steel | Right Hinge
A seemingly limitless supply of ice on tap for any occasion. Our
icemaker makes up to 35lb a day of clear ice.
Produces up to 39 lb. of clear, fresh ice per day
LED lighting for ice illumination effect
Quiet operation with sound-buffering ice deflector
Eco and Delay Start modes help minimise wasteful water and
energy usage
DIMENSIONS
Height
33 3⁄4 - 35 3⁄4 "
Width
14 7⁄8 "
Depth
21 1⁄2 "
SPECIFICATIONS
Accessories
Caster kit UC
Drain pump kit RFIDP
Capacity
Ice produced 39lbs/day
Features
Digital temperature control
•
Door alarm •
LED lighting •
Outdoor listed (CSA or UL) •
Power cord length 6'
Vacation mode •
Finish
Material 304 grade stainless steel
Weather resistant •
Installation Dimensions
Cutout depth 24 "
Cutout height 34 -35 "
Cutout width 15 "
Performance
Gravity fed drain •
Ice scoop •
Power requirements
Amperage 15A
Supply frequency 60Hz
Supply voltage 110-120V
Product dimensions
Depth 21 1⁄2 "
Depth to front of door
23 5⁄8 "
Height 33 3⁄4 - 35 3⁄4 "
Width 14 7⁄8 "
Shipping Information
Packaged weight 125lbs
Warranty
Parts and labor 2 years
Sealed system parts only 3 years
SKU 71509
TEST The product dimensions and specifications in this page apply to the specific
product and model. Under our policy of continuous improvement, these dimensions
and specifications may change at any time. You should therefore check with Fisher
& Paykel's Customer Care Centre to ensure this page correctly describes the model
currently available. ? DCS by Fisher & Paykel Appliances Limited 2020
