AIR FLOW ANEMOMETER
INSTRUCTION MANUAL
Thank you for purchasing our company Air Flow
Anemometer.
This manual provides relative information on how to use the
Air Anemometer and warning in operation Please make
some simple test measurement to ensure proper
performance of the unit.
To make the best use of this Anemometer, read this
Manual thoroughly before use it. Please Keep this Manual
Handy for reference.
1. Before Use Notice
Check up
Carefully unpack your kit and ensure that you
have the following Items. In case that any items is
missing or if you find any mismatch or
damage .promptly contact your local dealer.
Air Flow Anemometer unit-------------- 1pcs
wind velocity sensors ----------------- 1pcs
6F22 or NEDA 1604 9V battery ----------1pcs
English/Chinese Instruction Manual ------1pcs
Warranty Card --------------------- 1pcs
PP Packing box -------------------- 1pcs
Features
Measurement of wind velocity, temperature and wind
flow
Unit conversion of wind velocity, temperature and
flow
Measurement of maximum and minimum wind
velocity
Measurement of 2/3V max and average wind flow
Data holding, storing and deleting function
Low battery indicating function
Auto power off function (Button without any operation
and the fan static after 5 minutes will be turned off)
Memory of 600 records
Backlight function
Pressing key audio alert
Large LCD display
Wind Handle Can Elongate
DIAGRAM OF THE UNIT
1). LCD display
2). Max/Min value switch
3). Power key: press once to power on, again for two seconds
to power off
4). Wind velocity/flow transform key
5). Data holding key
6). Temperature unit switch
7) Unit transform key
8) Measuring key for average value of wind flow.
9) Record the measurement data
10) Wind flow AVG 2/3 MAX and figure input
11) Read out recorded data key
12) Reset key in "READ" mode/clear recorded
13) Backlight on/off key, press down to start the backlight
function, again to cancel.
14) Duct area input and sampling time setting key
15) Connecting wire
16) wind velocity sensors
NOTE:
Aforesaid key function descriptions are simple
introduction.
Pleas read operation instructions parts for details.
LCD Display
1) ： When measuring wind velocity, this symbol will
appears
2) ： When measuring wind flow, this symbol
