WINIX AIR CLEANE
R
5500-2
User Manual
x
Please read and follow all safety rules and instructions in
this manual before operating.
x
The product warranty is printed on the back of this guide,
so please keep it in a safe place for future use.
x
This product is manufactured for use only in USA/CA
Model
Use & Care
Guide
English
2
5500-2
CONTENTS
Set Up
Where to use 5
Installing the filters 6
Safety Instructions
Safety and Cautions 8
Operation
Initial Operation 9
Modes of Operation 10
Features and Settings 11
Care and Maintenance
Filter Care 13
Cleaning Care 17
Remote
Remote Control Guide 18
Troubleshooting
Frequently Asked Questions 19
Unit Specifications 21
Product Warranty 23
X This product is suitable for 120V only.
3-Stage Air Purification 3
Controls 4
English
3
5500-2
Light sensor
➍
User Manual
PACKAGE
CONTENTS
Front panel
➋ True HEPA filter
Power cord with plug
(This product is suitable for
120V only.)
Odor
sensor
➊ Washable Advanced
Odor Control (AOC
TM
)
Carbon Filter
Pre-filter
➌
PlasmaWave
Control Panel / Display Panel
3-STAGE AIR PURIFICATION
➊ Unit ➋ Pre-filter / Washable
AOC
TM
Carbon Filter /True
HEPA Filter
➌ Remote Control
English
4
5500-2
Air
Outlet
Vent
CONTROLS
Reset Button
After replacing a filter,
press the RESET button
for at least 5 seconds.
Fan Speed
Indicator
Indicates the
current fan speed.
Timer Indicator
If timer has been set, the
LED light indicates the set
time of operation.
PlasmaWave
Indicator
Indicates whether
PlasmaWave
is enabled or
disabled.
Air Quality
Indicator
Color-coded LED
indicates one of
three levels of air
quality.
Mode Button
Press to cycle through
and set the desired
mode of operation
(Auto, Sleep).
Power Button
Turns the unit on
or off.
Fan Speed Button
Enables Manual operation of the
unit. Press to cycle through and
set the desired fan speed (Low,
Medium, High, Turbo).
PlasmaWave
Button
Enables or disables
PlasmaWave
.
Light Sensor
Detects the
amount of
ambient light
within the
environment,
to adjust the
brightness
of the LED
indicators.
Timer Button
Press to cycle
through and set
desired length of
operation (1hr,
4hr, 8hr,[NO
TIMER])
Change Filter Indicator
LED light indicates when it is time to
change the filter.
Odor Sensor
When in Auto
Mode, detects the
amount of odor in
the environment
to adjust fan
speeds.
