SKU NO.: 370-5457
1
MODEL NO.: Z-20000-DT-2
20000 Lumen LED Work Lights
With Dual Head Tripod
PACKAGE CONTENTS
Do not return this product to the stores. Please call our customer service at
1-855-508-3883 Monday - Friday 9:00 a.m. - 5:00 p.m. CST
Questions, problems, missing parts?
Front
Back
X1 - Light Holding Bar
X3 - Star Knob Fastener
ASSEMBLY INSTRUCTIONS
X2 - LED Heads Attached
Together with Electrical cord
Leads
X1 - Telescoping Height
Stand with Fold-up Legs
Attached LED Heads to
Light Holding Bar.
X1 - Screw for Fixing
Y Splice
SKU NO.: 370-5457
MODEL NO.: Z-20000-DT-2
2
Y Splice
Set Legs and Adjust Height
Legs
Legs
Tighten to
Secure Stand
Legs
Loosen to Extend
Tighten to Hold
Height
View From Front
Attach Light Holding Bar and Electrical Cord to Stand Front
SAFETY INFORMATION
WARNING
1. DO NOT plug in the work light before completing assembly.
2. NEVER operate the light with the lens cover off and the lamp exposed.
3. DO NOT look directly at the LED Lens.
4. The unit can become extremely hot while in operation. Please allow light’s temperature to properly cool before moving or
touching.
5. DO NOT alter or disassemble the fixture.
6. Use in 120V, 60Hz only.
7. NEVER submerge the light and or cord in water.
8. Always keep the work light away from any flammable surfaces or materials.
CUSTOMER SERVICE
For question/comments, please contact at 1-855-508-3883.
This product is guaranteed against failure due to the factory defects in materials workmanship for five years
from the date of purchase. This warranty does not cover normal wear of parts or damage resulting from any
misuse of the product.
Important: This warranty is only valid if the product has been purchased through an authorized reseller. Proof
of purchase is required for repair or replacement. Misuse of the product includes but is not limited to: washing
the product, using in extreme weather conditions, opening the product, or altering the product.
5 YEAR LIMITED WARRANTY
SKU NO.: 370-5457
MODEL NO.: Z-20000-DT-2
3
CAUTION
LIGHT OPERATION
CARE AND MAINTENANCE
1. WARNING - Always make sure that the work light is unplugged and cooled down before attempting to clean it.
2. Using a soft cloth, clean the fixture using a mild, non-abrasive glass cleaner. DO NOT use solvents. DO NOT use cleaners
containing abrasive agents. NEVER spray liquid cleaner directly onto the light.
3. STORAGE - Always allow the work light to cool down completely before storing. Store in a safe place, out of the reach of
children.
TROUBLESHOOTING
PROBLEM POSSIBLE CAUSE CORRECTIVE ACTION
The work light will not
operate.
The power is off.
The switch is off.
Improper voltage or power supply.
Check to ensure the power supply is on.
Check to ensure the switch is in the ON
position.
The work light will only operate on
standard household 120V AC/ 60 Hz power.
1. While ON, avoid touching the product’s surface(s) during adjustments or in normal operation.
2. Avoid long duration of direct eye contact with light while in operation.
3. Integrated LED’s never need to be replaced.
4. Suitable for use(s) around wet locations and in operating environments ranging between
-4° to 113°F (-20°C to 45°C).
Press ON/OFF button located on the back of each light.
