PACKAGE CONTENTS
Work Light Front
Work Light Back
1
Sealed
Weather
resistant lens
LED
5ft. Grounded
Plug (Outdoor
Rated)
ON/OFF
Switch
Bracket
Star Knob
Fastener A
QTY:2 PCS
Oval Knob
Fastener
QTY:2 PCs
Oval Knob
Fastener
QTY:2PCS
Clamp
Supporting
Bracket
SKU NO.: 370-5449
MODEL NO.: Z-1200-C
1200 Lumen LED Work Light
With Clamp
Do not return this product to the stores. Please call our customer service at
1-855-508-3883 Monday - Friday 9:00 a.m. - 5:00 p.m. CST
Questions, problems, missing parts?
SKU NO.: 370-5449
MODEL NO.: Z-1200-C
2
Fig 1
Fig 2
SAFETY INFORMATION
WARNING
ASSEMBLY INSTRUCTIONS
1. Add the light to the clamp. Insert one of the oval knob fasteners through the middle hole in the bottom bracket of the work
light into the hole on the supporting bracket of the clamp and tighten down until secure (Fig1).
2. To adjust the light angle, loosen both star knob fasteners on the sides of the light head by turning them in a counterclockwise
manner. Pivot the light body to redirect the light (Fig 2). Once the light has been readjusted, turn the knobs clockwise to tighten.
3. To adjust the light tilt while holding the clamp firmly in position, loosen the oval knob fastener on the supporting bracket of
the clamp by turning it in a counterclockwise manner. Pivot the light body to redirect the light. Once the light has been
readjusted, turn the knobs clockwise to tighten (Fig 3, Fig 4).
CAUTION
1. DO NOT plug in the work light before completing assembly.
2. NEVER operate the light with the lens cover off and the lamp exposed.
3. DO NOT look directly at the LED Lens.
4. The unit can become extremely hot while in operation. Please allow light’s temperature to properly cool before moving or
touching.
5. DO NOT alter or disassemble the fixture.
6. Use in 120V, 60Hz only.
7. NEVER submerge the light and or cord in water.
8. Always keep the work light away from any flammable surfaces or materials.
9. The clamp is not suitable for mounting on a tubular surface
1. While ON, avoid touching the product’s surface(s) during adjustments or in normal operation.
2. Avoid long duration of direct eye contact with light while in operation.
3. Integrated LED’s never need to be replaced.
4. Suitable for use(s) around wet locations and in operating environments ranging between
-4° to 113°F (-20°C to 45°C).
Fig 3
Fig 4
WARNINGS
SKU NO.: 370-5449
MODEL NO.: Z-1200-C
3
LIGHT OPERATION
CARE AND MAINTENANCE
1. WARNING - Always make sure that the work light is unplugged and cooled down before attempting to clean it.
2. Using a soft cloth, clean the fixture using a mild, non-abrasive glass cleaner. DO NOT use solvents. DO NOT use cleaners
containing abrasive agents. NEVER spray liquid cleaner directly onto the light.
3. STORAGE - Always allow the work light to cool down completely before storing. Store in a safe place, out of the reach of
children.
TROUBLESHOOTING
PROBLEM POSSIBLE CAUSE CORRECTIVE ACTION
The work light will not
operate.
The power is off.
The switch is off.
Improper voltage or power supply.
Check to ensure the power supply is on.
Check to ensure the switch is in the ON
position.
The work light will only operate on
standard household 120V AC/ 60 Hz power.
If unable to fix any of the above issues, please consult a certified electricion.
CUSTOMER SERVICE
For question/comments, please contact at 1-855-508-3883 or through an authorized reseller.
Press ON/OFF button located on the backside of the light for ON/OFF operations.
This product is guaranteed against failure due to the factory defects in materials workmanship for five years
from the date of purchase. This warranty does not cover normal wear of parts or damage resulting from any
misuse of the product.
Important: This warranty is only valid if the product has been purchased through an authorized reseller. Proof
of purchase is required for repair or replacement. Misuse of the product includes but is not limited to: washing
the product, using in extreme weather conditions, opening the product, or altering the product.
5 YEAR LIMITED WARRANTY
