Smart Electrician SE311 1000 Lumen Rechargeable LED Work User Manual

FOR BLACK BACKGROUND ONLY

cyan background for visual,

do not print

1000 LUMEN RECHARGEABLE

LED WORK LIGHT

370-5486

OPERATOR’S MANUAL

To Reduce The Risk Of Injury, User Must Read And

Understand Operator’s Manual. Save These Instructions For Future Reference.

CAUTION:

IMPORTANT SAFETY INSTRUCTIONS

READ AND UNDERSTAND ALL WARNINGS, CAUTIONS AND OPERATING INSTRUCTIONS

BEFORE USING THIS EQUIPMENT. Failure to follow all instructions listed below may result in

electric shock, ﬁre and/or serious personal injury.

PRODUCT USE AND CARE

WARNING: TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK OR

PERSONAL INJURY.

•Always unplug the charger/adaptor from light and power source when not in use.

•Do not look directly at the lighted lamps to avoid eye injuries.

•Always keep the work light away from any ﬂammable surface or materials.

•Always check damaged or worn-out parts before using the work light.

Broken parts

will affect the work light operation. Replace or repair damaged or worn parts immediately. If repairs are needed,

consult a professional electrician.

•Do not use a pressure washer to clean this product.

•Do not modify the work light in any way.

Unauthorized modiﬁcation may impair the function and/or

safety and could affect the life of the product. There are speciﬁc applications for which the work light was designed.

•Store work light in a secure place out of the reach of children. Inspect it for good

working condition prior to storage and before re-use.

SPECIFIC SAFETY INSTRUCTIONS FOR LITHIUM-ION BATTERY POWERED

PRODUCTS

This work light is powered by a Lithium-ion battery. Lithium-ion batteries are small, compact and ideal for providing

long-lasting power to this product. However they must be used and charged properly. Improper use can result in

serious injury, ﬁre or death.

CAUTION: This product comes with the battery installed internally. You are

not allowed to install or remove the battery from the product.

•Donotplacethislithium-ionbatterypoweredproductinre

or apply heat to it.

•Donotapplystrongimpactorshocks to this lithium-ion battery powered product.

•Donotallowthelithium-ionbatterytogetwet.

•Donotleavethislithium-ionbatterypoweredproductinthedirectsunlight,

or use

or store it inside cars in hot weather. Doing so may cause the battery to generate heat, rupture, or ignite. Using the

battery in this matter may also result in a loss of performance and a shortened battery life.

•NEVER THROW WATER ON A BURNING LITHIUM-ION BATTERY!

If a lithium-ion

battery does catch on ﬁre, it will burn even more violently when contacted with water. Use a ﬁre extinguisher.

•Storetheproductattemperaturebetween41°Fand77°F(5°Cand25°C).

SAVE THESE INSTRUCTIONS

IMPORTANT BATTERY INFORMATION: DISPOSING OF THE BATTERY

• YourbatteriesareLITHIUM-IONrechargeablebatteries.CertainLocal,Stateand 

Federal laws prohibit disposal of these batteries in ordinary trash.

• Consultyourlocalwasteauthoritiesforyourdisposal/recyclingoptions.

• MoreinformationregardingbatterydisposalinU.S.andCanadaisavailableat;

 http://www.rbrc.org/index.html,orbycalling1-800-822-8837(1-800-8BATTERY).

SPECIFICATIONS

Output Power: ........................... 10 Watts

Brightness: ................................ 1000/500 Lumens

ColorTemperature:.................... 5000KBrightWhite

Run Time: ................................... 2/4 Hours

Battery: ...................................... Lithium-Ion 3.7V, 4.0Ah

Recharge Time: .......................... 5 Hours

NetWeight:.................................0.78lb

OVERVIEW

UNPACKING AND CONTENT

IMPORTANT! Due to modern mass production techniques, it is unlikely the product is

faulty or that a part is missing. If you ﬁnd anything wrong, do not operate the product until the

parts have been replaced or the fault has been rectiﬁed. Failure to do so could result in serious

personal injury.

CONTENTS IN PACKAGE

Description QTY Description QTY

Worklight  1  USBChargingCable  1

Operator's Manual 1

1. Frosted Lens

2. Stand/Handle

3. On/Off Switch

4. Battery Power Indicator

5. ChargingPort

6. 1/4" Thread Hole for Tripod Mount

7. USBChargingCable

OPERATION

CHARGING THE WORK LIGHT (FIG 1)

Thisrechargeableworklightisshippedwiththebatterypartiallycharged.Chargetheworklightafterpurchaseand

before ﬁrst use by connecting the included USB charging cable to a USB power output, a cellular phone power adaptor

or a laptop USB port for example.

1. Make sure the work light is off.

2. Lifttherubbercovertoexposethechargingport(5).

3. ConnectthemicroendoftheUSBchargingcabletothechargingport.

4. ConnecttheUSBendofthechargingcabletoaUSBpoweroutput(notincluded).

5. Thebatterypowerindicator(4)willbeashingblue,indicatingchargingisinprogress.

6. Once all 4 bars of the power indicator turn solid blue, the charging is completed.

STAND/HANDLE (FIG 1)

Thestand/handle(2)rotates180°toturnittobeastand,acarryinghandleorinaatstorageposition.Thereisa1/4"

metal screw hole in the middle for a tripod mounting.

ON/OFF SWITCH (FIG 1)

TheworklightisequippedwithanOn/Offswitch(3).Presstheswitchoncetoturntheworklightonatitsfullbrightness

press the switch a second time to be its half brightness, and press the switch the third time to turn it off

NOTE: The work light is always on its brightest setting when switched on.

MAINTENANCE

WARNING: Do not modify the work light in any way. Unauthorized modiﬁcation

may impair the function and/or safety and could affect the life of the product. There are speciﬁc

applications for which the work light was designed.

Therearenouser-replacableparts.Periodicallyinspecttheconditionofadaptors,connectorsandwires.Contactthe

manufacturer to replace any components that have become worn or broken.

WARRANTY

Thisproductiswarrantedfreefromdefectsinmaterialandworkmanshipfor1(one)yearsafterdateofpurchase.This

limited warranty does not cover normal wear and tear or damage from neglect or accident. The original purchaser is

covered by this warranty and it is not transferable. Prior to returning your product to store location of purchase, please

call the Toll-Free Help Line for possible solutions.

SAVE YOUR RECEIPTS, THIS WARRANTY IS VOID WITHOUT THEM

HELP LINE

For questions / comments, technical assistance or repair parts -

Please call toll free at:

1-800-868-7421(M-F8am-5pmEST)

2020/07 V01

Menard,Inc.,EauClaire,WI54703
