Page.:1
Page.:2
Page.:3
Page.:4
Page.:5
Page.:6
Digital operating panel sketch
1. Connect power, press on/off, the two
displays show present rotate speed and
temperature
2. Power on then press "mode" to choose
modes, then the red light flashes on
the chosen mode,machine start to work.
Parameter setting
1、entrance mode：
After connect power,press "setting",
begin to set parameter(user operate)
2、 setting method
（a）Change present mode rotate
speed and temperature by pressing
"setting", while the light flashing in the left
square, the rotate speed can be set by
adjust “+ -”。while the light flashing
in the right rectangle area, the temperature
can be set by adjust “+ -”。
（b）Mode light flashes indicate the
present setting mode
3、Attention
Only rotate speed setting during
washing mode.
（b）dispense time showed in the
rectangle area during dispensing mode
一、 Alarm
—— —— Frozen protect（dischargeable in 5
mins）
NL defrost（
dischargeable in 3 mins
）
Err Temperature fault
Page.:7
Page.:8
Page.:9
Page.:10
Page.:11
Page.:12
Page.:13
Page.:14
Page.:15
Page.:16
Page.:17
Page.:18
Page.:19
Page.:20
Page.:21
